2019 YAMAHA TMAX tire size

Special features
4-5
1
2
3
4
5
6
7
8
9
10
11
12
13
14
When the vehicle is turned on, traction
control is automatically turned on.
To turn the traction control system off,
see page 5-10.
TIP
Turn the traction control system off to
help free the rear wheel if the vehicle
gets stuck in mud, sand, or other soft
surfaces.
NOTICE
ECA16801
Use only the specified tires. (See
page 8-18.) Using different sized
tires will prevent the traction control
system from controlling tire rotation
accurately.
Resetting the traction control sys-
tem
The traction control system will auto-
matically disable under certain condi-
tions; such as when a sensor fault is
detected, or when only one wheel is al-
lowed to rotate for more than a few sec-
onds. Should this happen, the “ ”
indicator light will come on, and possi-
bly the “ ” warning light, too.
TIP
When the vehicle is on the centerstand,
do not rev the engine for an extended
period of time. Otherwise, the traction
control system will automatically dis-
able and need to be reset.
If the traction control system automati-
cally disables, try resetting it as follows.
1. Stop the vehicle and turn it off completely.
2. Wait a few seconds and then turn the vehicle power on.
3. The “ ” indicator light should turn off and the system be enabled.
TIP
If the “ ” indicator light remains on af-
ter resetting, the vehicle may still be rid-
den; however, have a Yamaha dealer
check the vehicle as soon as possible.
4. Have a Yamaha dealer check the vehicle and turn off the “ ” warn-
ing light.
BV1-9-E2.book 5 ページ ２０１８年８月２８日　火曜日　午後５時２８分

Periodic maintenance and adjustment
8-19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
TIP
The tire tread depth limits may differ
from country to country. Always comply
with the local regulations.
WARNING
EWA10472
Have a Yamaha dealer replace
excessively worn tires. Besides
being illegal, operating the vehi-
cle with excessively worn tires
decreases riding stability and
can lead to loss of control.
The replacement of all wheel
and brake-related parts, includ-
ing the tires, should be left to a
Yamaha dealer, who has the
necessary professional knowl-
edge and experience to do so.
Ride at moderate speeds after
changing a tire since the tire
surface must first be “broken
in” for it to develop its optimal
characteristics.
Tire information
This model is equipped with tubeless
tires and tire air valves.
Tires age, even if they have not been
used or have only been used occasion-
ally. Cracking of the tread and sidewall
rubber, sometimes accompanied by
carcass deformation, is an evidence of
ageing. Old and aged tires shall be
checked by tire specialists to ascertain
their suitability for further use.
WARNING
EWA16101
The front and rear tires should
be of the same make and de-
sign, otherwise the handling
characteristics of the vehicle
may be different, which could
lead to an accident.
Always make sure that the valve
caps are securely installed to
prevent air pressure leakage.
Use only the tire valves and
valve cores listed below to
avoid tire deflation during a ride.
After extensive tests, only the tires list-
ed below have been approved for this
model by Yamaha.
Minimum tire tread depth (front and
rear): 1.6 mm (0.06 in)
Front tire:Size:120/70R15M/C(56H)
Manufacturer/model:
BRIDGESTONE/BATTLAXSCF
(XP530-A)
DUNLOP/ROADSMART3
(XP530D-A)
Tire air valve: PVR59A
Valve core: #9100 (original)
Rear tire:
Size:160/60R15M/C(67H)
Manufacturer/model:
BRIDGESTONE/BATTLAXSCR
(XP530-A)
DUNLOP/ROADSMART3
(XP530D-A)
Tire air valve: TR412
Valve core: #9100 (original)
BV1-9-E2.book 19 ページ ２０１８年８月２８日　火曜日　午後５時２８分

10-1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Specifications
EAU84872Dimensions:
Overall length:2200 mm (86.6 in)
Overall width: 765 mm (30.1 in)
Overall height:
1420/1475 mm (55.9/58.1 in) (XP530-A)
1420/1555 mm (55.9/61.2 in) (XP530D-A)
Seat height:
800 mm (31.5 in)
Wheelbase: 1575 mm (62.0 in)
Ground clearance: 125 mm (4.92 in)
Minimum turning radius:
2.8 m (9.19 ft)
Weight:
Curb weight:213 kg (470 lb) (XP530-A)
216 kg (476 lb) (XP530D-A)
Engine:
Combustion cycle:4-stroke
Cooling system: Liquid cooled
Valve train: DOHC
Cylinder arrangement:
Inline
Number of cylinders: 2-cylinder
Displacement: 530 cm
3
Bore  stroke:
68.0  73.0 mm (2.68  2.87 in)
Starting system: Electric starter
Engine oil:
Recommended brand:
SAE viscosity grades:
10W-40
Recommended engine oil grade:
API service SG type or higher, JASO stan-
dard MA Engine oil quantity:
Oil change: 2.60 L (2.75 US qt, 2.29 Imp.qt)
With oil filter removal:
2.90 L (3.07 US qt, 2.55 Imp.qt)
Coolant quantity:
Coolant reservoir (up to the maximum level
mark):0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator (including all routes): 1.67 L (1.77 US qt, 1.47 Imp.qt)
Fuel:
Recommended fuel:Premium unleaded gasoline (Gasohol
[E10] acceptable)
Fuel tank capacity: 15 L (4.0 US gal, 3.3 Imp.gal)
Fuel reserve amount: 3.0 L (0.79 US gal, 0.66 Imp.gal)
Fuel injection:
Throttle body:ID mark:
BC31 00
Front tire:
Type:Tubeless
Size:
120/70R15M/C(56H)
Manufacturer/model: BRIDGESTONE/BATTLAXSCF (XP530-
A)
DUNLOP/ROADSMART3 (XP530D-A)
Rear tire:
Type:Tubeless
Size: 160/60R15M/C(67H)
Manufacturer/model:
BRIDGESTONE/BATTLAXSCR (XP530-
A)
DUNLOP/ROADSMART3 (XP530D-A)
Loading:
Maximum load:199 kg (439 lb) (XP530D-A)
202 kg (445 lb) (XP530-A)
* (Total weight of rider, passenger, cargo and accessories)
Front brake:
Type:
Hydraulic dual disc brake
