2019 YAMAHA NIKEN GT Control

Instrument and control functions
3-12
3
The multi-function meter unit is
equipped with the following:
 speedometer
 tachometer
 clock
 fuel meter
 eco indicator
 transmission gear display
 drive mode display
 TCS display
 QS indicator
 grip warmer display
 multi-function display
 brightness and shift light control
mode
TIPThe multi-function meter unit can be
set to kilometers or miles. To switch
between kilometers and miles, set the
multi-function display to the odometer,
and then push the “RESET” button for
one second.
Speed ometer
The speedometer shows your traveling
speed.
Tachometer The tachometer shows the engine
speed.
NOTICE
ECA10032
Do not operate the en
gine in the ta-
chometer red zone.
Re d zone: 11200 r/min an d a boveClock
The clock uses a 12-hour time system.
To set the clock1. Turn the vehicle on.
2. Push the “MENU” switch for one
second, and the hour digits will
start flashing.
3. Push the “SELECT” switch up or down to set the hours.
1. Speedometer
1. Tachometer
2. Tachometer red zone
1
1
2
1. Clock
1
UB5BE0E0.book Page 12 Friday, September 7, 2018 10:34 AM

Instrument and control functions
3-13
3 4. Push the “MENU” switch, and the
minute digits will start flashing.
5. Push the “SELECT” switch up or down to set the minutes.
6. Push the “MENU” switch to start the clock.
Fuel meter
The fuel meter indicates the amount of
fuel in the fuel tank. The display seg-
ments of the fuel meter disappear from
“F” (full) towards “E” (empty) as the fuel
level decreases. When the last seg-
ment starts flashing, approximately 4.0
L (1.06 US gal, 0.88 Imp.gal) of fuel re-
mains. Refuel as soon as possible.
TIPIf a problem is detected in the electrical
circuit, the fuel level segments will flash
repeatedly. If this occurs, have a
Yamaha dealer check the vehicle.Eco in dicator
This indicator comes on when the vehi-
cle is being operated in an environ-
mentally friendly, fuel-efficient manner.
The indicator goes off when the vehicle
is stopped.TIPConsider the following tips to reduce
fuel consumption:  Avoid high engine speeds during
acceleration. 
Travel at a constant speed.
 Select the transmission gear that
is appropriate for the vehicle
speed.
Transmission gear display
This display shows the selected gear.
The neutral position is indicated by “N”
and by the neutral indicator light.
1. Fuel meter
1
1. Eco indicator “ECO”
1
1. Neutral indicator light “ ”
2. Transmission gear display
1
2
UB5BE0E0.book Page 13 Friday, September 7, 2018 10:34 AM

Instrument and control functions
3-14
3
Drive mo
de display
This display indicates which drive
mode has been selected: “1”, “2” or
“3”. For more details on the modes and
on how to select them, see page 3-19.
TCS display This display indicates which traction
control system setting has been se-
lected: “1”, “2”, or “OFF”. For more de-
tails on the TCS settings and how to
select them, see page 3-22.
QS in
dicator
This indicator comes on when the
quick shift system (page 3-20) is turned
on. Grip warmer
display
The grip warmers can be used when
the engine is running. There are 4 grip
warmer settings and 10 temperature
levels.
To change the grip warmer setting
1. Turn the vehicle on.
1. Drive mode display
1. TCS display
1
1
1. QS indicator1
1. Grip warmer display Display Settin g
Off
Low
Middle High
1
UB5BE0E0.book Page 14 Friday, September 7, 2018 10:34 AM

Instrument and control functions
3-15
3 2. Push the “MENU” switch to select
the grip warmer display, and
will disappear.
3. Push the “SELECT” switch up or down to change the setting level.
4. Push the “MENU” switch.
TIPThe current grip warmer setting is
saved when the vehicle is turned off.NOTICE
ECA17932
 Be sure to wear gloves when
usin g the grip warmers.
 Do not use the grip warmers in
warm weather.
 If the han dle bar grip or throttle
g rip becomes worn or dam-
a g ed , stop usin g the grip warm-
ers an d replace the g rips.To set the grip warmer temperaturelevels1. Turn the vehicle on.
2. Push the “MENU” switch to select
the grip warmer display, and
will disappear. 3. Push the “MENU” switch for one
second, and the grip warmer dis-
play and multi-function display will
start flashing.
4. Push the “MENU” switch to change the setting level.
5. Push the “SELECT” switch up or down to set the temperature level.
6. Push the “MENU” switch for one second.
Multi-function display
The multi-function display can show
the following:  odometer (ODO)
 two tripmeters (TRIP 1 and TRIP 2)
 fuel reserve tripmeter (TRIP F)
 instantaneous fuel consumption 
average fuel consumption
 coolant temperature
 air temperature
TIPThe odometer will lock at 999999.
 The tripmeters reset and continue
counting after 9999.9 is reached.Push the “SELECT” switch to change
the display between the odometer
“ODO”, the tripmeters “TRIP 1” and
“TRIP 2”, instantaneous fuel consump-
tion “km/L”, “L/100 km”, or “MPG”, av-
erage fuel consumption “AVE – –.–
km/L”, “AVE – –.– L/100 km”, or “AVE
– –.– MPG”, coolant temperature “°C”,
1. Multi-function display
1
1. “SELECT” switch
1
UB5BE0E0.book Page 15 Friday, September 7, 2018 10:34 AM

Instrument and control functions
3-16
3
and air temperature “°C Air”. When
pushing “ ”, the display will change
in the following order.
ODO
→ TRIP 1 → TRIP 2 → km/L,
L/100 km, or MPG → AVE – –.– km/L,
AVE – –.– L/100 km, or AVE – –.– MPG
→ °C (coolant) → °C Air → ODO
When the last segment of the fuel me-
ter starts flashing, the display changes
to the fuel reserve tripmeter “TRIP F”
and starts counting the distance trav-
eled from that point. In this case,
push “ ” to change the display in the
following order.
TRIP F → km/L, L/100 km, or MPG →
AVE – –.– km/L, AVE – –.– L/100 km, or
AVE – –.– MPG → °C (coolant) → °C Air
→ ODO → TRIP 1 → TRIP 2 → TRIP F
TIP Push “ ” to change the display
in the opposite order.
 To reset a tripmeter, push the
“RESET” button for one second. 
The fuel reserve tripmeter can be
reset manually, or you can allow it
to reset automatically after refuel-
ing and traveling about 5 km (3
mi).
Instantaneous fuel consumption
Instantaneous fuel consumption can
be set to “km/L”, “L/100 km”, or
“MPG”.
 “km/L”: the distance that can be
traveled on 1.0 L of fuel
 “L/100 km”: the amount of fuel
necessary to travel 100 km
 “MPG”: the distance that can be
traveled on 1.0 Imp.gal of fuel
TIPTo switch between “km/L”, “L/100
km”, and “MPG”, push the “RE-
SET” button for one second.
 When traveling under 10 km/h (6
mi/h), “– –.–” is displayed.Avera ge fuel consumption
Average fuel consumption can be set
to either “AVE – –.– km/L”, “AVE – –.–
L/100 km”, or “AVE – –.– MPG”.  “AVE – –.– km/L”: the average dis-
tance that can be traveled on 1.0 L
of fuel
 “AVE – –.– L/100 km”: the average
amount of fuel necessary to travel
100 km
1. Instantaneous fuel consumption display
1
1. Average fuel consumption display
1
UB5BE0E0.book Page 16 Friday, September 7, 2018 10:34 AM

Instrument and control functions
3-17
3 
“AVE – –.– MPG”: the average dis-
tance that can be traveled on
1.0 Imp.gal of fuel
TIPTo reset the average fuel con-
sumption, push the “RESET” but-
ton for one second.
 After resetting, “– –.–” will be
shown until the vehicle has trav-
eled a sufficient distance.
 The display units cannot be
switched between “km/L”, “L/100
km”, and “MPG” in this mode;
change to the instantaneous fuel
consumption mode first.Coolant temperature The temperature of the engine coolant
from 40 °C to 124 °C is shown in 1 °C
increments.
If the message “Hi” flashes, stop the
vehicle, then stop the engine and let it
cool. (See page 6-36.)
TIP
When the coolant temperature is
below 40 °C, “Lo” will be dis-
played.
 The coolant temperature varies
with changes in the weather and
engine load.Air temperature The temperature of the air drawn into
the intake system from –9 °C to 50 °C
is shown in 1 °C increments.
TIP
–9 °C will be displayed even if the
air temperature falls below –9 °C.
 The temperature displayed may
vary from the actual ambient tem-
perature.Bri ghtness and shift light control
mo de
This mode cycles through five control
functions in the order listed below.  Display brightness
 Shift light on / flash / off
 Shift light on r/min
1. Coolant temperature display
1
1. Air temperature display
1
1. Brightness level display
1
UB5BE0E0.book Page 17 Friday, September 7, 2018 10:34 AM

Instrument and control functions
3-18
3

Shift light off r/min
 Shift light brightness
TIPThe brightness level display shows the
selected brightness level.To adjust the display brightness1. Turn the key to “OFF”.
2. Push and hold the “MENU”
switch.
3. Turn the key to “ON”, and then re- lease the “MENU” switch after five
seconds.
4. Push the “SELECT” switch up or down to select the desired bright-
ness level.
5. Push the “MENU” switch to con- firm the selected brightness level.
The control mode changes to the
shift light on / flash / off setting
function.
To set the shift light on / flash / off1. Push the “SELECT” switch up or down to select one of the follow-
ing style settings: 
On setting: the shift light will
come on when the set engine
speed is reached. This setting
is selected when the indicator
light is lit continuously.
 Flash setting: the shift light
will flash when the set engine
speed is reached. This setting
is selected when the indicator
light flashes four times per
second.
 Off setting: the shift light is
deactivated. This setting is
selected when the indicator
light flashes once every two
seconds.
2. Push the “MENU” switch to con- firm the selection. The control
mode changes to the shift light on
r/min setting function.
To set the shift light on r/min
The shift light can be set between 6000
r/min and 12000 r/min in increments of
200 r/min. 1. Push the “SELECT” switch up or down to select the desired engine
speed for activating the indicator
light. 2. Push the “MENU” switch to con-
firm the selected engine speed.
The control mode changes to the
shift light off r/min setting function.
To set the shift light off r/min
The shift light can be set between 6000
r/min and 12000 r/min in increments of
200 r/min. Be sure to set the off r/min
to a higher engine speed than the on
r/min setting, otherwise the shift light
will not come on. 1. Push the “SELECT” switch up or down to select the desired engine
speed for deactivating the indica-
tor light.
2. Push the “MENU” switch to con- firm the selected engine speed.
The control mode changes to the
shift light brightness setting func-
tion.
To adjust the shift light brightness1. Push the “SELECT” switch up or down to select the desired shift
light brightness level.
2. Push the “MENU” switch to con- firm the selected brightness level
and exit the control mode.
UB5BE0E0.book Page 18 Friday, September 7, 2018 10:34 AM

Instrument and control functions
3-19
3
EAU84550
D-mo de ( drive mo de)D-mode is an electronically controlled
engine performance system.
WARNING
EWA18440
Do not chan ge the d rive mo de while
the vehicle is movin g.With the throttle grip closed, push the
drive mode switch “MODE” to change
the drive mode. MODE 3
This mode offers response that is
somewhat less sharp compared to
MODE 2 for riding situations that re-
quire especially sensitive throttle oper-
ation.
MODE 2
This mode is suitable for various riding
conditions.
This mode allows the rider to enjoy
smooth and sporty drivability from the
low-speed range to the high-speed
range.
MODE 1
This mode offers a sportier engine re-
sponse in the low- to mid-speed range
compared to MODE 2.
TIPThe current drive mode is saved when
the vehicle is turned off.
EAU12822
Clutch leverThe clutch lever is located on the left
side of the handlebar. To disengage
the clutch, pull the lever toward the
handlebar grip. To engage the clutch,
release the lever. The lever should be
pulled rapidly and released slowly for
smooth clutch operation.
The clutch lever is equipped with a
clutch switch, which is part of the igni-
tion circuit cut-off system. (See page
3-35.)
1. Drive mode display
2. Drive mode switch “MODE”
2
1
1. Clutch lever
1
UB5BE0E0.book Page 19 Friday, September 7, 2018 10:34 AM
