Table of contentsSafety information........................... 1-1
Description ....................................... 2-1
Left view ......................................... 2-1
Right view ....................................... 2-2
Controls and instruments................ 2-3
Special features ............................... 3-1
D-mode (drive mode)...................... 3-1
Traction control system .................. 3-1
Quick shift system ...... .................... 3-3
Instrument and co ntrol functions... 4-1
Immobilizer system ..... .................... 4-1
Main switch/steering lock................ 4-2
Handlebar switches ........................ 4-3
Indicator lights and warning lights ............................................ 4-5
Multi-function meter unit ................. 4-7
Clutch lever................................... 4-14
Shift pedal..... ............................ .... 4-14
Brake lever ................................... 4-14
Brake pedal .................................. 4-15
ABS .............................................. 4-15
Fuel tank cap ................................ 4-16
Fuel............................................... 4-17
Fuel tank overflow hose................ 4-19
Catalytic converter ........................ 4-19
Seat .............................................. 4-20
Storage compartment ................... 4-20
Adjusting the front fork.................. 4-21 Adjusting the shock absorber
assembly................................... 4-23
Luggage strap holders . ................ 4-24
Auxiliary DC connectors ............... 4-25
Sidestand ..................................... 4-25
Ignition circuit cut- off system ........ 4-26
For your safety – pre-operation
checks .............................................. 5-1
Operation and important riding
points ................................................ 6-1
Starting the engine ......................... 6-1
Shifting ........................................... 6-2
Tips for reducing fuel consumption ............................... 6-3
Engine break-in .............................. 6-3
Parking ........................................... 6-4
Periodic maintenance and
adjustment ....................................... 7-1
Tool kit............................................ 7-2
Periodic maintenance charts .......... 7-3
Periodic maintenance chart for the emission control system ............. 7-3
General maintenance and lubrication chart .......................... 7-5
Removing and installing the
panel ........................................... 7-9
Checking the spark plugs ............. 7-10
Canister ........................................ 7-11 Engine oil ..................................... 7-11
Why Yamalube ............................ 7-14
Coolant ........................................ 7-14
Air filter element ........................... 7-16
Checking the engine idling
speed............ ............................ 7-16
Checking the throttle grip free play ........................................... 7-16
Valve clearance ........................... 7-17
Tires ............................................. 7-17
Cast wheels ................................. 7-19
Adjusting the clutch lever free play ........................................... 7-20
Checking the brake lever free
play ........................................... 7-20
Brake light switches ..................... 7-21
Checking the front and rear
brake pads................................ 7-21
Checking the brake fluid level ...... 7-22
Changing the brake fluid .............. 7-23
Drive chain slack.......................... 7-24
Cleaning and lubricating the drive chain ................................ 7-25
Checking and lubricating the cables ....................................... 7-26
Checking and lubricating the throttle grip and cable ............... 7-26
Checking and lubricating the
brake and shift pedals .............. 7-27
Checking and lubricating the brake and clutch levers ............ 7-27BS2-9-E2.book 1 ページ ２０１８年８月１０日　金曜日　午前９時３６分

Instrument and control functions
4-25
1
2
345
6
7
8
9
10
11
12
EAU77390
Auxiliary DC connectorsThis vehicle is equipped with an auxilia-
ry DC connector and a grip warmer DC
connector. Consult your Yamaha deal-
er before installing any accessories.
EAU15306
SidestandThe sidestand is located on the left side
of the frame. Raise the sidestand or
lower it with your foot while holding the
vehicle upright.TIPThe built-in sidestand switch is part of
the ignition circuit cut-off system, which
cuts the ignition in certain situations.
(See the following section for an expla-
nation of the ignition circuit cut-off sys-tem.)
WARNING
EWA10242
The vehicle must not be ridden with
the sidestand down, or if the sides-
tand cannot be properly moved up
(or does not stay up), otherwise the
sidestand could contact the ground
and distract the operator, resulting
in a possible loss of control.
Yamaha’s ignition circuit cut-off
system has been designed to assist
the operator in fulfilling the respon-
sibility of raising the sidestand be-
fore starting off. Therefore, check
this system regularly and have a Yamaha dealer repair it if it does not
function properly.
BS2-9-E2.book 25 ページ ２０１８年８月１０日　金曜日　午前９時３６分

Periodic maintenance and adjustment
7-32
1
2
3
4
5
67
8
9
10
11
12 The main fuse, the fuel injection system
fuse, and fuse box 2 are located under
the seat. (See page 4-20.)
TIPTo access the fuel injection system
fuse, remove the starter relay cover bypulling it upward.
1. Ignition fuse
2. ABS control unit fuse
3. Auxiliary fuse 1
4. Parking lighting fuse
5. Signaling system fuse
6. Headlight fuse
7. Grip warmer fuse
8. Spare fuse
123
8
456
87
1. Fuse box 2
2. Main fuse
3. Fuel injection system fuse
4. Fuel injection system spare fuse
2
3
4
1
1. Radiator fan motor fuse
2. Backup fuse
3. Electronic throttle valve fuse
4. Terminal fuse 1
5. ABS solenoid fuse
6. ABS motor fuse
7. Spare fuse
1234
7
56
BS2-9-E2.book 32 ページ ２０１８年８月１０日　金曜日　午前９時３６分

Periodic maintenance and adjustment7-33
1
2
3
4
5
678
9
10
11
12
If a fuse is blown, replace it as follows.
1. Turn the key to “OFF” and turn off the electrical circuit in question.
2. Remove the blown fuse, and then install a new fuse of the specified
amperage. WARNING! Do not
use a fuse of a higher amperage
rating than recommended to
avoid causing extensive dam-
age to the electrical system and
possibly a fire.
[EWA15132]
3. Turn the key to “ON” and turn on the electrical circuit in question to check if the device operates.
4. If the fuse immediately blows again, have a Yamaha dealer
check the electrical system.
1. Starter relay cover
2. Fuel injection system fuse
3. Fuel injection system spare fuse
1
2
3
Specified fuses:Main fuse:50.0 A
Auxiliary fuse 1:
2.0 A
Terminal fuse 1: 2.0 A
Grip warmer fuse: 5.0 A
Headlight fuse:
10.0 A
Signaling system fuse: 7.5 A
Ignition fuse: 15.0 A
Parking lighting fuse:
7.5 A
Radiator fan motor fuse: 15.0 A
ABS motor fuse: 30.0 A
ABS solenoid fuse:
15.0 A
Fuel injection system fuse: 10.0 A
ABS control unit fuse: 7.5 A
Backup fuse: 7.5 A
Electronic throttle valve fuse: 7.5 A
BS2-9-E2.book 33 ページ ２０１８年８月１０日　金曜日　午前９時３６分

Periodic maintenance and adjustment
7-34
1
2
3
4
5
67
8
9
10
11
12
EAU76271
Vehicle lightsExcept for the turn signal lights, this
model is equipped with full-LED light-
ing. If a light does not come on, check
the fuses and then have a Yamaha
dealer check the vehicle.
If a turn signal light does not come,
check and replace the bulb. (See
page 7-34.)TIPWhen the dimmer switch is set to high
beam or the passing switch is pushed,all four headlights come on.
NOTICE
ECA16581
Do not affix any type of tinted film orstickers to the headlight lens.
EAU24205
Replacing a turn signal light
bulb1. Remove the turn signal light lens by removing the screw.
2. Remove the burnt-out bulb by pushing it in and turning it counter-
clockwise.
1. Headlight (low beam)
2. Headlight (high beam)
3. Auxiliary light
12
3
1. Turn signal light lens
2. Screw
1
2
BS2-9-E2.book 34 ページ ２０１８年８月１０日　金曜日　午前９時３６分

Specifications
9-2
1
2
3
4
5
6
7
89
10
11
12
Manufacturer/model: DUNLOP/D214Loading:Maximum load:174 kg (384 lb)
* (Total weight of rider, passenger, cargo and accessories)Front brake:Type:Hydraulic dual disc brakeRear brake:Type:
Hydraulic single disc brakeFront suspension:Type:Telescopic forkRear suspension:Type:Swingarm (link suspension)Electrical system:System voltage:
12 VBattery:Model:YTZ10S
Voltage, capacity:
12 V, 8.6 Ah (10 HR)Bulb wattage:Headlight:LED
Brake/tail light:
LED
Front turn signal light: 10.0 W Rear turn signal light:
10.0 W
Auxiliary light:
LED
License plate light: LED
BS2-9-E2.book 2 ページ ２０１８年８月１０日　金曜日　午前９時３６分

11-1
1
2
3
4
5
6
7
8
9
1011
12
IndexAABS ....................................................... 4-15
ABS warning light.................................... 4-6
Air filter element .................................... 7-16
Auxiliary DC connectors........................ 4-25BBattery................................................... 7-30
Brake and clutch levers, checking and lubricating ........................................... 7-27
Brake and shift pedals, checking and
lubricating ........................................... 7-27
Brake fluid, changing ............................ 7-23
Brake fluid level, checking .................... 7-22
Brake lever ............................................ 4-14
Brake lever free play, checking ............. 7-20
Brake light switches .............................. 7-21
Brake pedal ........................................... 4-15CCables, checking and lubricating .......... 7-26
Canister................................................. 7-11
Care ........................................................ 8-1
Catalytic converter ................................ 4-19
Clutch lever ........................................... 4-14
Clutch lever free play, adjusting ............ 7-20
Coolant.................................................. 7-14
Coolant temperature warning light .......... 4-5DData recording, vehicle ......................... 10-2
Diagnostic connector ............................ 10-2
Dimmer switch ........................................ 4-4
D-mode (drive mode) .............................. 3-1
Drive chain, cleaning and lubricating .... 7-25
Drive chain slack ................................... 7-24
Drive mode switch................................... 4-4
EEngine break-in ...................................... 6-3
Engine idling speed, checking .............. 7-16
Engine oil .............................................. 7-11
Engine serial number............................ 10-1
Engine trouble warning light ................... 4-6FFront and rear brake pads, checking .... 7-21
Front fork, adjusting .............................. 4-21
Front fork, checking .............................. 7-29
Fuel....................................................... 4-17
Fuel consumption, tips for reducing........ 6-3
Fuel tank cap ........................................ 4-16
Fuel tank overflow hose........................ 4-19
Fuses, replacing ................................... 7-31HHandlebar switches ................................ 4-3
Hazard switch ......................................... 4-4
High beam indicator light ........................ 4-5
Horn switch ............................................. 4-4IIdentification numbers .......................... 10-1
Ignition circuit cut-off system ................ 4-26
Immobilizer system ................................. 4-1
Immobilizer system indicator light........... 4-6
Indicator lights and warning lights .......... 4-5LLuggage strap holders .......................... 4-24MMain switch/steering lock........................ 4-2
Maintenance and lubrication, periodic .... 7-5
Maintenance, emission control system... 7-3
Matte color, caution ................................ 8-1
Model label ........................................... 10-2 Multi-function meter unit .......................... 4-7
NNeutral indicator light .............................. 4-5OOil level warning light .............................. 4-5PPanel, removing and installing ................ 7-9
Parking .................................................... 6-4
Part locations .......................................... 2-1
Pass switch ............................................. 4-4QQuick shift indicator light ......................... 4-6
Quick shift system ................................... 3-3SSafety information ................................... 1-1
Seat ....................................................... 4-20
Shifting .................................................... 6-2
Shift pedal ............................................. 4-14
Shock absorber assembly, adjusting .... 4-23
Sidestand .............................................. 4-25
Sidestand, checking an
d lubricating...... 7-28
Spark plugs, checking ........................... 7-10
Special features ...................................... 3-1
Specifications .......................................... 9-1
Starting the engine .................................. 6-1
Steering, checking................................. 7-29
Stop/Run/Start switch.............................. 4-4
Storage.................................................... 8-3
Storage compartment............................ 4-20
Supporting the motorcycle .................... 7-35
Swingarm pivots, lubricating ................. 7-28TThrottle grip and cable, checking and
lubricating ........................................... 7-26
BS2-9-E2.book 1 ページ ２０１８年８月１０日　金曜日　午前９時３６分
