2019 VOLVO XC60 TWIN ENGINE display

||
KEY, LOCKS AND ALARM
* Option/accessory.242
1.Press the button on the remote key.
>The lock and alarm indicator on the dash-board will go out to indicate that the vehi-cle is no longer fully armed.
The tailgate will be unlocked but remainclosed. However, the side doors willremain locked and armed.
Press lightly on the rubberized pressureplate under the tailgate handle to openthe tailgate.
If the tailgate is not opened within2 minutes, it will be relocked and thealarm armed.
2.With the optional power tailgate* -
Hold and press (about 1.5 seconds) the button on the remote key
>The tailgate will unlock and open. How-ever, the side doors will remain locked andarmed.

Related information
Locking and unlocking using the remote key(p. 240)
Opening and closing the power tailgate*(p. 260)
Remote key range
In order to function correctly, the remote keymust be within a certain distance from the vehi-cle.
Manual use
The remote key's functions for e.g. locking and
unlocking, which are activated by pressing or
, have a range of approx. 20 meters (65 feet)from the vehicle.
If the vehicle's locks do not react, move closerand try again.

Keyless use 8
The shaded areas around the vehicle illustrate the rangeof the system's antennas.
For keyless use, a remote key or the Key Tagmust be within the shaded areas shown in theillustration, i.e. a semicircle with a radius ofapprox. 1.5 meter (5 feet) along the sides of thevehicle or approx. 1 meter (3 feet) from the tail-gate.
NOTE
The functions of the remote control key canbe disrupted by ambient radio waves, build-ings, topographical conditions, etc. The vehi-cle can always be locked/unlocked using thekey blade.

If the remote key is removed from the
vehicle
If the remote key is removed from thevehicle while the engine is running, thewarning message Vehicle key notfound Removed from vehicle will bedisplayed in the instrument panel and an audiblesignal will sound when the last door is closed.
The message will disappear when the key isreturned to the vehicle and the O button on theright-side steering wheel keypad is pressed orwhen the last door is closed again.

8
Models equipped with keyless locking/unlocking (Passive Entry * ) only.

KEY, LOCKS AND ALARM
}}
* Option/accessory.243

Related information
Remote key (p. 237)
Antenna locations for the start and lock sys-tem (p. 256)
Keyless and touch-sensitive surfaces*(p. 252)
Replacing the remote key's battery
The battery in the remote key must be replacedwhen it is discharged.

NOTE
All batteries have a limited service life andmust eventually be replaced (does not applyfor Key Tag). The battery's service life variesdepending on how often the vehicle/key isused.
The remote key battery should be replaced if:
the information symbol illuminates andthe message Vehicle key bat. lowSee Owner's manual is displayed inthe instrument panel
and/or
the locks do not react after several attemptsto lock or unlock the vehicle using theremote key within approx. 20 meter (65 feet)from the vehicle.

NOTE
Move closer to the vehicle and try to unlock itagain.
The battery in the smaller key without buttons9
(the Key Tag) cannot be replaced. A new key canbe ordered from an authorized Volvo workshop.
CAUTION
An end-of-life Key Tag must be turned in toan authorized Volvo workshop. The key mustbe deleted from the vehicle because it canstill be used to start the vehicle via backupstart.
9This key is provided with vehicles equipped with keyless locking/unlocking (Passive Entry*).

||
KEY, LOCKS AND ALARM
* Option/accessory.246

CAUTION
Be sure to dispose of end-of-life batteries ina way that protects the environment.

WARNING
California Proposition 65
Operating, servicing and maintaining a pas-senger vehicle can expose you to chemicalsincluding engine exhaust, carbon monoxide,phthalates, and lead, which are known to theState of California to cause cancer and birthdefects or other reproductive harm. To mini-mize exposure, avoid breathing exhaust, donot idle the engine except as necessary, serv-ice your vehicle in a well ventilated area andwear gloves or wash your hands frequentlywhen servicing your vehicle. For more infor-mation go to www.P65Warnings.ca.gov/passenger-vehicle.

Related information
Remote key (p. 237)
Ordering additional remote keys
Two remote keys are provided with the vehicle.One Key Tag is also included if the vehicle isequipped with keyless locking/unlocking*. Addi-tional keys can be ordered.
A total of 12 keys can be programmed and usedfor the same vehicle. An additional driver profilewill be added for each new remote key. This alsoapplies to the key tag.
Loss of a remote key
If you lose your remote key, you can order areplacement from a workshop - an authorizedVolvo workshop is recommended. Bring the otherremaining remote keys to the workshop. As ananti-theft measure, the code of the lost remotekey must be erased from the system.
The current number of keys registered for thevehicle can be checked via driver profiles in the
center display's Top view. Select Settings
SystemDriver Profiles.
NOTE
Volvo recommends that you order a new orduplicate remote control key from an author-ized Volvo workshop.
You can also obtain additional or duplicateremote control keys from certain independentrepair facilities and locksmiths that are quali-fied to make remote control keys. Each keymust be programmed to work with your vehi-cle.
A list of independent repair facilities and/orlocksmiths known to Volvo that can cut andcode replacement keys can be found:
on Volvo's website www.volvocars.com/us
by calling Volvo Customer Care1-800-458-1552.

Related information
Remote key (p. 237)

KEY, LOCKS AND ALARM
}}
* Option/accessory.247
Red Key - restricted remote key*
A Red Key makes it possible for the vehicleowner to set limitations for certain vehicle prop-erties. The limitations are intended to promotesafe use of the vehicle, e.g. when it is loanedout.
For a Red Key, it is possible to define the vehi-cle's maximum speed, set speed reminders andlimit the audio system's volume. Several of thedriver support systems will also always be active.Otherwise, the Red Key functions in the sameway as a standard remote key.
One or more Red Key can be ordered from aVolvo retailer. A total of twelve keys can be pro-grammed and used for the same vehicle. Up toten may be restricted keys, but at least two mustbe standard remote keys.
These restrictions are intended to help reducethe risk of accidents and help the driver feel more
secure when handing over the vehicle to e.g. ayoung driver, parking attendant or workshop. Thesettings for a Red Key cannot be changed by itsuser; a regular remote key is needed to changesettings.

Related information
Red Key* settings (p. 247)
Remote key (p. 237)
Red Key* settings
The holder of a regular remote key can adjustsettings for a Red Key. Certain driver supportfunctions are always active.
1.Tap Settings in the center display's Topview.
2.Tap SystemDriver ProfilesRed Key.
> The following settings can be made:
Set Time Gap For Adaptive CruiseControl
Reduced Maximum Volume
Max Speed Limit
Speed Limit Warning

Adaptive Cruise Control * :
Default setting: Longest interval

Reduced maximum volume (On/Off):
Default setting: On

Speed Limiter (On/Off):
Setting interval: 50-250 km/h (30-160 mph)
The default setting is 120 km/h (75 mph)
Increments: 1 km/h (1 mph)
The following symbol and message willbe shown in the instrument panel
Red key Speed limitation cannotbe exceeded.

KEY, LOCKS AND ALARM
* Option/accessory.255
Keyless unlock settings*
Several different sequences are available forkeyless unlocking.
1.Tap Settings in the center display's Topview.
2.Tap My CarLockingKeyless Unlock
3. Select alternative:
All Doors
- unlocks all doors at the same time.
Single Door
- unlocks the selected door.

Related information
Keyless locking and unlocking* (p. 253)
Keyless and touch-sensitive surfaces*(p. 252)
Keyless tailgate unlock*
The tailgate can be opened using the remotekey. The key only needs to be within range, e.g.in a pocket or bag.
The tailgate is held closed by an electronic lock-ing mechanism.
To open the tailgate:
1.Lightly press the rubberized pressure plateon the underside of the tailgate handle.
> The lock will disengage.

NOTE
One of the vehicle's remote keys must bewithin range behind the vehicle for unlockingto be possible.
2. Lift the outer handle to fully open the tail-gate.
CAUTION
Only light pressure on the rubberized pres-sure plate is necessary to release the tail-gate's locking mechanism.
Use the handle to lift the tailgate and donot apply force to the rubberized pressureplate. Too much force can damage thepressure plate's electrical connections.
Hands-free unlocking of the tailgate is also pos-sible using a foot movement under the rearbumper; see the separate section.

WARNING
Do not drive with the tailgate open. Toxicexhaust fumes can be sucked into the vehiclethrough the cargo compartment.

Related information
Keyless locking and unlocking* (p. 253)
Keyless and touch-sensitive surfaces*(p. 252)
Remote key range (p. 242)
Foot movement tailgate operation* (p. 264)

KEY, LOCKS AND ALARM
* Option/accessory.257

Alternative unlocking method
Alternative unlocking method using side door openinghandle15.
–Pull either of the side door inside openinghandles and release.
>Depending on the remote key settings,either all doors will be unlocked or just theselected door will be unlocked andopened.
To change this setting, tap Settings
My CarLockingRemote andInterior Unlock in the Top view of thecenter display.

Locking using the front door buttons
–Press the button (both front doors mustbe closed).
>All doors and the tailgate will lock.

Locking using the rear door button *
Button with indicator light for locking/unlocking in reardoor.
The lock buttons in the rear doors only lock/unlock that particular door.

Unlocking the rear door
1. Pull the opening handle to unlock the reardoor.
2. Pull the opening handle again to open the
rear door16.
Related information
Settings for remote and inside door unlock(p. 241)
Unlocking the tailgate from inside the vehicle(p. 258)
Activating and deactivating child safety locks(p. 258)
15The illustration is generic - details may vary according to vehicle model.16Provided the child safety lock is not activated.

KEY, LOCKS AND ALARM
* Option/accessory.265
To activate opening and closing using a footmovement on a vehicle with skid plate, make akicking motion from the side of the vehicle. Oneof the vehicle's remote keys must be within range(approx. 1 meter (3 feet)) for opening and closingto be possible.
Kicking motion within the sensor's activation area.

Related information
Keyless and touch-sensitive surfaces*(p. 252)
Opening and closing the power tailgate*(p. 260)
Remote key range (p. 242)
Private Locking
The tailgate can be locked using the privatelocking function to prevent it from being opened,e.g. when the vehicle is left at a workshop orwith a valet.
The function button for privatelocking is located in the centerdisplay's Function view.Depending on the current sta-tus of the lock, PrivateLocking Unlocked or PrivateLocking Locked will be dis-played.

Related information
Activating and deactivating private locking(p. 266)

KEY, LOCKS AND ALARM
* Option/accessory.266
Activating and deactivating privatelocking
Private locking is activated using the functionbutton in the center display and a PIN code.

NOTE
For the valet lock function to be activated thecar must be in at least ignition mode I.

Entering security code before initial use
The first time the function is used, a securitycode must be selected. This code can then beused to deactivate private locking if the selectedPIN code has been lost or forgotten. The securitycode functions as a PUK (security) code for allPIN codes used for private locking.
Save the security code in a safe place.
To create a security code:
1. Tap the button for private locking in Functionview.
> A pop-up window will appear.
2.Enter your security code.
> The security code is saved. The privatelocking function is now ready for activa-tion.
If the system has been reset, the above proce-dure will need to be repeated.
Activating private locking
1. Tap the button for private locking in Functionview.
> A pop-up window will appear.
2.Enter the code you would like to use tounlock the tailgate and tap Confirm.
>The tailgate will lock. A green indicatorlight will illuminate next to the button inFunction view to confirm locked status.
Deactivating private locking
1. Tap the button for private locking in Functionview.
> A pop-up window will appear.
2.Enter the code used for locking and tapConfirm.
>The tailgate will unlock. The green indica-tor light next to the button in Functionview will go out to confirm unlocked sta-tus.

NOTE
If you have forgotten or lost your PIN code orif the PIN code has been entered incorrectlymore than three times, the security code canbe used to deactivate private locking.

NOTE
If private locking is activated and the vehicleis unlocked using Volvo On Call* or the VolvoOn Call* app, private locking will be deacti-vated automatically.
