2019 VOLKSWAGEN E-GOLF instrument

Component protection is a protective feature that helps to:
x Prevent any factory-installed parts from functioning fully if they are installed into other vehicles (for example, after theft),
x Prevent full function of components outside of the vehicle,
x Allow legitimate installation or exchange of parts and control units by a professional should they require service.

Where What appears Possible solution
The instrument
cluster display
SAFE CP See an authorized
Volkswagen dealer or an
authorized Volkswagen Ser-
vice Facility for assistance.
Radio or naviga-
tion system dis-
play
Component theft
protection: the
Infotainment sys-
tem is not fully
available at pre-
sent. Please
switch on the ig-
nition.
Switch on the ignition.
If this does not deactivate
component protection, see
an authorized Volkswagen
dealer or an authorized
Volkswagen Service Facility
for assistance.

Volkswagen service information

Protecting yourself and the vehicle

Fig. 159 In the center of the instrument panel: Button for the emergency flashers.

Checklist
Carry out the following steps in the order listed before starting to inflate a tire ⇒ :
1. If you have a flat tire, move it as far away from traffic as possible. Park the vehicle on a flat, level surface at a safe spot.
2. Firmly apply the parking brake to help prevent the vehicle from moving
3. Move the selector lever into Park (P)
4. Switch off the electric motor and remove the key from the ignition switch
5. Have all passengers exit and go to a safe place, such as behind the guard rail.
6. Switch on emergency flashers and use a warning triangle or other device to warn oncoming traffic. Observe all legal requirements.
7. Check whether a repair with the tire mobility set is possible
8. If the luggage compartment is loaded: Remove the luggage.
9. Remove the tire mobility set from the luggage compartment.
10. Affix the label ⇒ fig. 177 (2) from the tire mobility set on the instrument panel in the driver's field of vision.
11. The foreign object (screw or nail, for example) should not be removed from the tire!
WARNING
Disregarding the safety-related checklist may lead to accidents and serious injuries.
x Always review and follow the checklist. Follow accepted safety practices and use common sense.
Sealing and inflating the tire

Fuses in the vehicle

Fig. 178 On the driver side in the instrument panel: Fuse box cover.

Fig. 179 In the electric motor compartment: Fuse box cover 1 with tweezers 2.

Color Current strength in
amps
(ATO® /MINI®)
Current strength in
amps
(JCASE®)
Light
brown
5 —
Brown 7.5 —
Red 10 50
Blue 15 20
Yellow 20 60
White or
clear
25 —
Green 30 40
Orange 40 —
Pink 30 30

Opening the fuse box in the instrument panel
x Pull the lower part of the cover toward the steering wheel (in the direction of the arrow ⇒ fig. 178) and remove the cover from the bottom. This action may require moderate force.
x To install, guide the cover from the bottom into the instrument panel and push in the direction
opposite to the arrow ⇒ fig. 178 until you can hear it latch into place.
Opening the fuse box in the electric motor compartment
x Open the electric motor hood

WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Whenever stalled or stopped for repair, move the vehicle a safe distance off the road, turn on the emergency flashers, stop the electric motor, and use other warning devices to warn approaching traffic.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Tow-starting

WARNING
If the vehicle is towed even though the text message Towing damages electrical sys-tem. See owner's man.! appears in the instrument cluster, vibrations can occur in the electric drive and the front wheels can lock, especially on ice or wet roads. Locking front wheels can impair the steering functions and cause accidents and serious injuries.
x If the message Towing damages electrical system. See owner's man.! appears in the instrument cluster, only tow the vehicle in emergency situations at walking speed and for a maximum of 330 ft. (100 m).
NOTICE
If the vehicle is towed even though the text message Towing damages electrical system. See owner's man.! appears in the instrument cluster and walking speed is exceeded or it is towed further than 330 ft. (100 m), serious damage can be done to the to the electric drive.
A vehicle can be towed only if the electronic parking brake is switched off and the electronic steering column lock is released. In case of a power loss or malfunctions of the electrical system, the electric motor may have to be jump-started in order to release the electronic steering column lock and the electronic parking brake.
Installing the front towing eye

Fig. 184 In the right front bumper: Removing the cover.
