2019 VOLKSWAGEN E-GOLF headlight

Function Action
Switching the
DRL off:
– Switch the ignition on.
– Turn the light switch to the / posi-
tion.
– Set the parking brake.
Switching the
DRL back on:
– Release the parking brake.

Static cornering lights
Your vehicle may have fog lights under the front bumper, which on some models are also static cor-nering lights. On some models the static cornering lights may be integrated in the headlights. At speeds below about 25 mph (40 km/h), the light on one side of the vehicle will come on automatically when you turn a corner. If you turn to the right, the right fog light comes on; turn left and the left fog light comes on. The light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. If you are using automatic headlights
(headlight switch in the !54/ position ⇒ fig. 75), they work only when the headlights have been auto-matically switched on. The static cornering lights do not come on when the headlight switch is in the /
position or when the fog lights themselves have been switched on ⇒  Switching lights on and off.
Automatic headlights (!54/)
Your vehicle may be equipped with automatic headlights (!54/), which are a convenience feature only and cannot always recognize all lighting and driving situations.
If the light switch is in the !54/ position, both vehicle lighting and instrument and switch lighting are
automatically switched on and off in the following situations ⇒ :

Automatic activation: Automatic deactivation:
If the low-light sensor registers
darkness, for example when driving
through a tunnel.
If sufficient brightness is registered.
If the rain sensor recognizes rain
and switches the windshield wipers
on.
If the windshield wipers have not
moved for several minutes.

You can adjust the level of darkness the vehicle must register before automatically switching on the headlights in the Infotainment system by pressing the #!2 button followed by the function keys

Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System (AFS) works only with the low beams switched on and only at speeds above about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumina-tion during cornering.
In some models, the headlights will turn independently, even when driving straight ahead. They can adjust according to the weather conditions and the speed of the vehicle to better light up the road ahead. The bulbs return to their original position after a short period of time, depending on the vehicle speed.
On vehicles equipped with AFS, the feature can be switched on and off in the Infotainment system by
pressing the #!2 button followed by the

Button Function
s Door contact button.
Press the button in, and the interior lights come on automatically
when the vehicle is unlocked, a door is opened, or the vehicle
key is removed from the ignition.
The lights go out about 20 seconds after you close the doors.
They also go out when you lock the vehicle or switch on the
ignition.
Press the button back out again to switch the door contact fea-
ture off.
* Reading light on or off.


Glove and luggage compartment lights
The glove and luggage compartments may have lights that come on automatically when they are opened and go off when they are closed.
Ambient (background) lighting
When the ignition and the headlights are switched on, ambient lights in the doors light up.
On appropriately equipped vehicles, you can adjust the brightness of the ambient lighting in the Info-
tainment system by pressing the #!2 button followed by the

WARNING
The electric motor compartment of any motor vehicle is a potentially dangerous area and can cause serious personal injury.
x Always use extreme caution when doing any work in the electric motor compartment. Always follow commonly accepted safety practices and use common sense. Never risk per-sonal injury.
x Never perform any work in the electric motor compartment unless you know exactly how to carry out the job and have the correct technical information and the correct tools.
x If you are uncertain about what to do, have the work performed by an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified work-shop. Serious personal injury may result from improperly performed work.
x We strongly recommend that you always have HID – High Intensity Discharge (Xenon) headlights and H7 bulbs replaced by a qualified technician. Serious personal injury may re-sult from improperly performed work.
x Never open or close the electric motor hood if steam or coolant is escaping. Hot steam or coolant can cause serious burns. Always wait until you no longer see or hear steam or cool-ant escaping from the electric motor.
x Always let the electric motor cool down completely before carefully opening the hood.
x Hot parts of the electric motor and the exhaust system will burn skin on contact.
x When the electric motor has cooled down and you are ready to open the hood:
– Firmly apply the parking brake and shift the transmission into Park (P) (automatic) or Neutral (manual only).
– Take the vehicle key out of the ignition.
– On vehicles with Keyless Access, make sure that the remote control vehicle key is out of range of the vehicle and that the vehicle cannot be started by depressing the starter
button ⇒  Unlocking or locking the vehicle with Keyless Access.
– Always keep children and others away from the electric motor compartment and never leave them unsupervised.
x The electric motor coolant system is under pressure when the electric motor is hot. Never unscrew the coolant expansion tank cap when the electric motor is hot. Hot coolant can spray out and cause severe burns and other serious injuries.
– Turn the cap slowly and very carefully in a counterclockwise direction while applying light downward pressure on the top of the cap.
– Always protect your face, hands, and arms from hot escaping coolant or steam by covering the cap with a large, thick rag.
x Never spill fluids on the electric motor or exhaust system when refilling. Spilling fluids onto hot parts of the electric motor or exhaust system can cause a fire.

WARNING
High voltage systems in the electric motor compartment can cause electrical shocks or even electrocution, severe burns, other serious injuries, and even death!
x Never short-circuit the electrical system. Be especially careful when using jumper cables. The vehicle's battery could explode!
x To reduce the risk of electrical shock and personal injury while the electric motor is acti-vated:
– Never touch ignition cables. Never touch other components of the high voltage elec-tronic ignition system.
– Never touch the wiring of the HID – High Intensity Discharge (Xenon) headlights.
x Read and heed the important information and warnings on cleaning the electric motor
compartment ⇒  Cleaning the electric motor compartment.
WARNING
Moving parts in the electric motor compartment can cause serious personal injury on con-tact.
x Never reach into the area around or touch the radiator fan. Contact with the blades can cause serious personal injury. Always remember that the radiator fan is temperature-controlled and can come on suddenly even when the electric motor has been switched off for a while and the key has been removed from the ignition.
x If you have to perform a check or repair when the electric motor is activated, there are more risks from the rotating parts, such as the drive belts, alternator, radiator fan, etc., and from the high-voltage ignition system. Always use extreme care.
– Always make sure that jewelry, loose clothing and long hair do not get caught in rotat-ing electric motor parts. Before starting any work remove your jewelry, take off your neck-tie, tie back and cover your hair, and do not wear clothing that can hang down and get caught in moving electric motor parts.
– Always use extreme caution if the accelerator pedal has to be depressed to perform a check. The vehicle will start to move even if the parking brake is on.
x Never leave any objects in the electric motor compartment, for example cleaning rags and tools. Objects left behind can cause malfunctions, electric motor damage, and even fires.
WARNING
Additional materials in the electric motor compartment such as blankets can interfere with the operation of the electric motor and can cause fires, which can lead to serious injuries.
x Never cover the electric motor with blankets or other materials.
WARNING
Operating fluids and some materials in the electric motor compartment can catch fire easily, causing burns and other serious personal injuries!
x Never smoke near the electric motor compartment.
x Never work next to open flames or sparks.
x Never pour or spill operating fluids or other flammable liquids on the electric motor. These fluids can ignite on hot electric motor parts and cause injuries.
x Always have a functional, approved fire extinguisher nearby.

WARNING
After the vehicle has been washed, the wet brakes or, in winter, brake discs or pads coated with ice, react slower and need longer stopping distances.
x Always dry the brakes and clean off any ice coatings with a few careful applications of the brake. Make sure not to endanger other motorists or cyclists or disobey legal requirements.
CAUTION
Sharp edges under the vehicle can cut exposed skin.
x Always protect your hands and arms from cuts on sharp metal edges when cleaning the underbody, the inside of the wheel housings, etc.
NOTICE
x The water temperature must not be more than +140 °F (+60 °C).
x To help prevent damage to the paint, do not wash the vehicle in direct sunlight.
x Do not use insect sponges, abrasive kitchen sponges or similar things to clean the vehicle. These can damage the paint finish.
x Never clean headlights with a dry cloth or sponge. Always use a wet cloth or sponge. For best results use soapy water.
x When washing or rinsing the vehicle in cold weather, do not let water get into the lock cylinders or point the hose at gaps around the doors, hood, or rear hatch. The water could freeze on the locks and seals and make it difficult to open the vehicle!
x When outside temperatures are low, wipe the rubber seals and their contact surfaces dry to help prevent freezing.
NOTICE
To help prevent vehicle damage in a car wash:
x Compare the vehicle track width with the dimensions of the guide rails in the car wash to help prevent damage to wheel rims and tires!
x Switch off the rain sensor before driving the vehicle through a car wash ⇒ page 127, Rain sensor.
x Make sure there is enough clearance for the height and width of the vehicle.
x To help prevent paint damage to the electric motor hood, place wiper blades against the windshield after they have dried. Do not let them snap back into place.
x Fold the outside mirrors toward the vehicle body.
x Lock the rear hatch to help prevent unintentional opening in the car wash.
Washing with a power washer

NOTICE
x To help prevent damage, do not use hard wax or polish on matte-finished parts, plastic parts, headlights or rear lights.
x Do not wax or polish your vehicle if it is dirty, or in a sandy or dusty place.
Caring for and cleaning chrome and aluminum parts

The procedure for attaching and for removing the jumper cables is described below. Perform each of the following steps only in the order described, which follow the letters shown in the illustration
⇒ fig. 183 A – B – C – D.
Attaching jumper cables
1. Switch off the ignition in both vehicles ⇒ page 205, Starting and stopping the electric drive.
2. Open the battery cover in the electric motor compartment if the battery has a cover ⇒  12 Volt vehicle battery.
3. Attach one end of the red jumper cable to the positive terminal (+) of the dead battery: (1) ⇒ .
4. Attach the other end of the red jumper cable to the positive terminal (+) of the good battery (booster battery): (2).
5. Attach one end of the black jumper cable to the negative jump-start terminal ⇒  Jump-start termi-nal, or if that is not available, to the negative terminal (-) of the battery in the vehicle providing
assistance (2) ⇒ fig. 183.
6. Attach the other end of the black jumper cable (3) to the negative jump-start terminal ⇒  Jump-start terminal, or if that is not available, a bare metal part of the vehicle with the dead battery. This part should be connected directly to the electric motor block. You may also attach the cable to the
electric motor block itself or to the towing eye installed on the front of the vehicle ⇒ page 408, Tow-
ing. Attach the clamp to a point that is as far away as possible from the dead battery (1) ⇒ .
7. Route the jumper cables so that they cannot get caught in any moving parts in the electric motor compartment of either vehicle.
Starting the electric motor
x Start the engine of the vehicle with the good battery that is providing help and let it run at idle speed.
x Turn on the ignition of your vehicle with the dead battery. If the electric motor can be activated, wait
2 to 3 minutes before removing the jumper cables as described below ⇒ . If the electric motor cannot be activated within about 10 seconds, turn off the ignition and wait at least 1 minute; then try again.
Before removing the jumper cables
x Switch off the headlights (if they are on).
x In the vehicle with the dead battery, switch on the heater fan and the rear window defroster. This helps to minimize voltage spikes when the cables are disconnected.
Removing jumper cables
With the electric motor activated, remove the jumper cables in reverse order to the way they were connected.
1. Disconnect the black (-) cable from the vehicle with the dead battery.
2. Disconnect the black (-) cable from the other vehicle (vehicle with the good battery).
3. Disconnect the red (+) cable from the other vehicle (vehicle with the good battery).
4. Disconnect the red (+) cable from the vehicle with the dead battery.
5. Close the battery cover.
6. If necessary, unscrew the towing eye on the front of the vehicle ⇒  Installing the front towing eye.
