302Technical dataTechnical dataVehicle identification..................302
Vehicle Identification Number ..302
Identification plate ...................302
Engine identification ................303
Vehicle data ............................... 304
Recommended fluids and lubricants ................................ 304
Engine data ............................. 307
Performance ............................ 309
Vehicle weight ......................... 312
Vehicle dimensions .................315
Capacities ................................ 316
Tyre pressures ........................ 317
Towing hitch installation dimensions ............................. 322Vehicle identification
Vehicle IdentificationNumber
The Vehicle Identification Number is
visible through the windscreen.
The Vehicle Identification Number
may be stamped on the identification
plate and on the floor pan, under the floor covering, visible under a cover,
or in the engine compartment on the
right body panel.
Identification plate
The identification label is located on
the front left or right door frame.

Technical data315Vehicle dimensionsGrand SportSports Tourer, Country TourerLength min.-max. [mm]4897-49104986-500411)Width with folded exterior mirrors [mm]19411941Width with unfolded exterior mirrors [mm]20932093Height (without antenna) [mm]1425-1485 12)1450-1550 12)Vehicle height - Rear compartment open [mm]21282065-2088 11)Length of load compartment floor [mm]11331178Length of load compartment with folded rear seats [mm]19372005Load compartment width [mm]10301030Load compartment height [mm]497384Wheelbase [mm]28292829Turning circle diameter [m]11.7511.7511)
Minimum length for standard version, maximum length for Country Tourer version.
12) Depending on body- and equipment variants.

322Technical dataTowing hitch installation dimensions
Grandsport

340Speech recognition.....................157
Speed limiter....................... 110, 202
Speedometer ............................. 100
Starting and operating ................176
Starting off ................................... 17
Starting the engine ....................178
Steering ...................................... 176
Steering wheel adjustment ......9, 87
Steering wheel controls .......87, 144
Stop-start system........................ 180
Storage ......................................... 72
Storage compartments .................72
Sunglasses storage .....................73
Sunroof ........................................ 42
Sunvisor lights ........................... 141
Sun visors .................................... 42
Symbols ......................................... 4
System settings .......................... 148
T
Tachometer ............................... 102
Tail lights ................................... 264
Three-point seat belt .................... 56
Tools .......................................... 275
Tow bar....................................... 248
Towing ................................ 248, 293
Towing another vehicle .............294
Towing equipment .....................250
Towing hitch installation dimensions ............................. 322Towing the vehicle .....................293
Traction Control system ............. 196
Traction Control system off......... 108
Traffic programme ......................152
Traffic sign assistant ...........110, 238
Trailer coupling ........................... 248
Trailer stability assist .................251
Trailer towing ............................. 249
Transmission ............................... 16
Tread depth ............................... 281
Trip odometer ............................ 101
Turn lights .......................... 104, 138
Tyre chains ................................ 282
Tyre designations ......................277
Tyre pressure ............................ 277
Tyre pressure monitoring system ............................. 108, 278
Tyre pressures ........................... 317
Tyre repair kit ............................. 282
U
Upholstery .................................. 297
Uplevel display ........................... 111
Usage ......................................... 159
USB port ............................... 92, 152
User profiles ............................... 151
Using smartphone applications ..162
Using this manual ..........................3V
Valet mode ................................. 117
Vehicle battery ........................... 258
Vehicle checks............................ 254
Vehicle data ................................ 304
Vehicle data recording and privacy ..................................... 331
Vehicle detected ahead ..............110
Vehicle dimensions .................... 315
Vehicle Identification Number ....302
Vehicle jack ................................ 275
Vehicle messages .....................122
Vehicle personalisation .............123
Vehicle security ............................ 33
Vehicle specific data ......................3
Vehicle storage ........................... 253
Vehicle tools ............................... 275
Vehicle unlocking ........................... 6 Vehicle weight ........................... 312
Ventilating ..................................... 53
Voice pass-thru application 157, 159
Voice prompts............................. 159
Voice recognition ........................157
W
Warning chimes .........................122
Warning lights ............................. 100
Warning triangle .......................... 82
Washer and wiper systems .........13
Washer fluid ............................... 257
