2019 VAUXHALL INSIGNIA display

280Vehicle careilluminates. For the further three
wheels the system remains
operational.
The use of commercially available
liquid tyre repair kits can impair the
function of the system. Factory-
approved repair kits can be used.
Operating electronic devices or being close to facilities using similar wave
frequencies could disrupt the tyre
pressure monitoring system.
Each time the tyres are replaced tyre
pressure monitoring system sensors
must be dismounted and serviced.
For the screwed sensor replace valve
core and sealing ring, for clipped
sensor replace complete valve stem.
Use only original plastic valve caps to protect valve on any damage.Caution
Do not use metal valve caps as
they lead to valve oxidation and
damage.
Vehicle loading status
Adjust tyre pressure to load condition
according tyre information label or
tyre pressure chart 3 317, and select
the appropriate setting in the Tyre
loading page under the Settings
menu in the Driver Information Centre 3 111. This setting determines the
reference pressures for the tyre
pressure warnings.
Depending on the display, the menu
Tyre loading only appears if the
vehicle is at a standstill and the
parking brake is applied. On vehicles
with automatic transmission the
selector lever must be in P.Select:
● Light for comfort pressure up to
3 people.
● Eco for Eco pressure up to
3 people.
● Max for full loading.
Auto learn function After changing wheels or wheel
positions the vehicle must be
stationary for approx. 20 minutes,
before the system recalculates. The
following relearn process takes up to
10 minutes of driving in a speed range
of 25 to 60 mph. Avoid to drive outside
of this range for a longer time. If
possible, use a country road or similar which allows continuous driving.
During relearn process $ can be
displayed or pressure values can
swap in the Driver Information Centre.
If problems occur during the relearn
process, a failure message is
displayed in the Driver Information
Centre. w will flash for 60 seconds
and then illuminate continuously.

Vehicle care297UnderbodySome areas of the vehicle underbody
have a PVC undercoating while other
critical areas have a durable
protective wax coating.
After the underbody is washed, check the underbody and have it waxed if
necessary.
Bitumen/rubber materials could
damage the PVC coating. Have
underbody work carried out by a
workshop.
Before and after winter, wash the
underbody and have the protective
wax coating checked.
Liquid gas system9 Danger
Liquid gas is heavier than air and
can collect in sink points.
Take care when performing work
at the underbody in a pit.
For painting work and when using a
drying booth at a temperature above
60 °C, the liquid gas tank must be
removed.
Do not make any modifications to the
liquid gas system.
Towing equipment
Do not clean the coupling ball bar with a steam-jet or high-pressure jet
cleaner.
Interior care
Interior and upholstery
Only clean the vehicle interior,
including the instrument panel fascia
and panelling, with a dry cloth or
interior cleaner.
Clean the leather upholstery with
clear water and a soft cloth. In case of heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light-
coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could
damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.

Service and maintenance299Service and
maintenanceGeneral information ...................299
Service information ..................299
Recommended fluids, lubricants and parts .................................... 300
Recommended fluids and lubricants ................................ 300General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 103.
European service intervals Maintenance of your vehicle is
required every 20,000 miles or after
one year, whichever occurs first. Additional engine oil and filter change
is indicated by the engine oil life
system, when required earlier than
maintenance.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania,
Luxembourg, Macedonia, Malta,
Monaco, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
San Marino, Serbia, Slovakia,
Slovenia, Spain, Sweden,
Switzerland, United Kingdom.
Service display 3 103.
International service intervals
Maintenance of your vehicle is
required every 10,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
Severe operating conditions exist if
one or more of the following
circumstances occur frequently: Cold starting, stop and go operation, trailer
operation, mountain driving, driving
on poor and sandy road surfaces,
increased air pollution, presence of
airborne sand and high dust content,

300Service and maintenancedriving at high altitude and large
variations of temperature. Under
these severe operating conditions,
certain service work may be required more frequently than the regular
service interval.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 103.
Confirmations Confirmation of service is recorded inthe Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or
goodwill claims are to be met, and is
also a benefit when selling the
vehicle.Recommended fluids,
lubricants and parts
Recommended fluids and lubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for
petrol and diesel engines. If it is
unavailable, engine oils of other listed qualities must be used.
Recommendations for petrol engines
are also valid for Compressed Natural
Gas (CNG), Liquified Petroleum Gas
(LPG) and Ethanol (E85) fuelled
engines.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 304.
Topping up engine oilCaution
In case of any spilled oil, wipe it up and dispose it properly.
Engine oils of different manufacturersand brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.

Customer information331Verband der Automobilindustrie e.V.
AdBlue ®
is a registered trademark of
the VDA.Vehicle data recording
and privacy
Event data recorders
Electronic control units are installed in
your vehicle. Control units process
data which is received by vehicle
sensors, for example, or which they
generate themselves or exchange
amongst themselves. Some control
units are necessary for the safe
functioning of your vehicle, others
assist you while you drive (driver
assistance systems), while others
provide comfort or infotainment
functions.
The following contains general
information about data processing in
the vehicle. You will find additional
information as to which specific data
is uploaded, stored and passed on to third parties and for what purpose in
your vehicle under the key word Data Protection closely linked to the
references for the affected functional
characteristics in the relevant owner's manual or in the general terms of
sale. These are also available online.Operating data in the vehicle
Control units process data for
operation of the vehicle.
This data includes, e.g.: ● vehicle status information (e.g. speed, movement delay, lateral
acceleration, wheel rotation rate,
"seat belts fastened" display)
● ambient conditions (e.g. temperature, rain sensor,
distance sensor)
As a rule such data is transient, not
stored for longer than an operational
cycle, and only processed on board
the vehicle itself. Control units often
include data storage (including the
vehicle key). This is used to allow
information to be documented
temporarily or permanently on vehicle
condition, component stress,
maintenance requirements and
technical events and errors.

336IndexAAccessories and vehicle modifications .......................... 252
Activating phone projection ........162
Active bonnet ................................ 70
Active emergency braking ..........218
Adaptive cruise control .......110, 204
AdBlue ................................ 108, 185
Adjustable air vents ...................172
Airbag and belt tensioners .........105
Airbag deactivation ..............62, 105
Airbag label................................... 57 Airbag system .............................. 57
Air conditioning regular operation ................................ 174
Air conditioning system .............. 163
Air intake .................................... 173
Air vents...................................... 172
All-wheel drive ........................... 192
Android Auto ............................... 162
Antilock brake system ................ 193
Antilock brake system (ABS) .....107
Anti-theft alarm system ................33
Anti-theft locking system .............. 33
Appearance care ........................295
Apple CarPlay............................. 162
Armrest ................................... 52, 54
Armrest storage ........................... 73
Ashtrays ....................................... 94
Audio .......................................... 152Audio files................................... 152
Automatic anti-dazzle ..................39
Automatic dimming ......................38
Automatic light control ...............132
Automatic locking ........................26
Automatic transmission .............187
Autostop ..................................... 180
Auxiliary heater ........................... 172
B Baselevel display ........................111
Basic operation ........................... 148
Battery discharge protection ......142
Battery voltage ........................... 123
Belts.............................................. 55
BlueInjection ............................... 185
Bluetooth connection ..................161
Bonnet ....................................... 254
Bottom bar .................................. 144
Brake and clutch fluid .................300
Brake and clutch system ...........106
Brake assist ............................... 195
Brake fluid .................................. 257
Brakes ............................... 193, 257
Breakdown.................................. 293
Bulb replacement ....................... 260
C
Capacities .................................. 316
Cargo management system ........79
Catalytic converter .....................184

337Central locking system ................24
Centre console lighting ..............141
Centre console storage ...............73
Changing tyre and wheel size ...281
Charging system ........................ 106
Child locks ................................... 27
Child restraint installation locations ................................... 66
Child restraints.............................. 63
Child restraint systems ................63
Climate control ............................. 15
Clock............................................. 91
Collision damage repair ..............328
Connected navigation .................156
Connecting a phone ...................161
Control elements ........................144
Control indicators........................ 104
Control of the vehicle .................176
Controls ........................................ 87
Convex shape .............................. 36
Coolant and antifreeze ...............300
Cruise control ....................110, 201
Cupholders .................................. 72
Curtain airbag system .................. 61
Curve lighting.............................. 134
D
DAB announcements .................152
DAB-DAB linking ........................152
DAB-FM linking........................... 152Danger, Warnings and Cautions ...4
Daytime running lights ...............134
Declaration of conformity ............324
DEF ............................................ 185
Diesel exhaust fluid ....................185
Diesel fuel system bleeding .......259
Display operation ........................148
Door open .................................. 110
Doors ............................................ 28
Driver assistance systems ..........201
Driver Information Centre ...........111
Driving characteristics and towing tips .............................. 249
Driving hints ................................ 176
E
Electric adjustment ......................36
Electrical system......................... 270
Electric parking brake .........106, 194
Electric parking brake fault .........106
Electronic climate control system 166
Electronic key system ...................21
Electronic Stability Control.......... 197
Electronic Stability Control and Traction Control system ..........107
Electronic Stability Control off..... 107
End-of-life vehicle recovery .......253
Engine compartment fuse box ...271
Engine coolant ........................... 256
Engine coolant temperature ......108Engine coolant temperature
gauge ..................................... 103
Engine data ............................... 307
Engine exhaust .......................... 183
Engine identification ...................303
Engine oil ................... 255, 300, 304
Engine oil pressure ....................108
Entry lighting .............................. 141
Event data recorders ..................331
Exhaust filter ............................... 183
Exit lighting ................................ 141
Extended status view .................144
Exterior care .............................. 295
Exterior light ............................... 109
Exterior lighting ....................12, 131
Exterior mirrors ............................. 36
F
First aid kit ................................... 83
Fixed air vents ........................... 173
Folding mirrors ............................. 37
Following distance ......................107
Following distance indication ......217
Forward collision alert................. 214
Front airbag system .....................60
Front fog lights ...........109, 138, 262
Front pedestrian protection ........221
Front seats.................................... 46
Front storage ................................ 73
Fuel............................................. 244

338Fuel for diesel engines ..............246
Fuel for petrol engines ...............244
Fuel gauge ................................. 102
Fuel price information .................156
Funnel......................................... 246
Fuses ......................................... 270
G Gauges ....................................... 100
Gear shifting ............................... 107
General information ....157, 160, 248
Glovebox ..................................... 72
H
Halogen headlights ....................260
Hand brake ................................. 193
Hazard warning flashers ............137
Headlight flash ........................... 133
Headlight range adjustment ......133
Headlights................................... 131 Headlights when driving abroad 134
Head restraint adjustment .............8
Head restraints ............................ 44
Head-up display.......................... 119
Heated mirrors ............................. 38
Heated rear window ..................... 41
Heated steering wheel .................87
Heated windscreen .......................42
Heating .................................. 53, 54
High beam ......................... 109, 132
High beam assist ................109, 132Hill start assist ........................... 195
Homescreen ............................... 144
Horn ....................................... 13, 88
I Identification plate .....................302
Immobiliser .......................... 36, 109
Indicators .................................... 100
Inductive charging ........................93
Info Display ................................. 117
Information displays.................... 111
Instrument cluster ........................95
Instrument panel fuse box .........274
Instrument panel illumination .....270
Instrument panel illumination control .................................... 139
Instrument panel overview ........... 10
Interactive driving system ...........199
Interior care ............................... 297
Interior lighting ............................ 139
Interior lights ...................... 140, 270
Interior mirrors .............................. 38
Introduction ............................ 3, 144
J Jump starting ............................. 291
K Key, memorised settings ..............24
Keys ............................................. 19
Keys, locks ................................... 19L
Lane change alert .......................231
Lane keep assist ................107, 242
Lashing eyes ............................... 79
LED headlights ...........109, 134, 262
Lighting features .........................141
Light switch ................................ 131
Live traffic ................................... 156
Load compartment ................28, 74
Load compartment cover .............77
Loading information .....................84
Low fuel ..................................... 109
M Mainscreen ................................. 144
Malfunction indicator light ..........106
Manual anti-dazzle ......................38
Manual seat adjustment ...............47
Manual transmission .................. 192
Map updates ............................... 156
Massage ....................................... 54
Memorised settings ......................24
Midlevel display .......................... 111
Mirror adjustment ........................... 8
Misted light covers .....................139
N
Navigation map card port .............93
Navigation system .....................154
New vehicle running-in ..............176
Number plate light .....................270
