2019 VAUXHALL GRANDLAND X Windscreen

In brief111Power windows .....................39
2 Exterior mirrors .....................36
3 Side air vents ...................... 130
4 Turn lights, headlight
flash, low/high beam, high
beam assist ......................... 117
Exit lighting ......................... 121
Parking lights ...................... 118
Buttons for Driver
Information Centre ................99
5 Cruise control .....................156
Speed limiter ....................... 159
Heated steering wheel ..........78
6 Instruments .......................... 89
Driver Information Centre ...... 99
7 Infotainment controls
8 Windscreen wiper and
washer, rear wiper and
washer ................................. 79
9 Power button ....................... 135
10 Centre air vents .................. 130
11 Hazard warning flashers ....117
12 Info-Display ........................ 10113Anti-theft alarm system
status LED ........................... 34
14 Central locking system ..........23
15 Glovebox .............................. 67
16 Controls for Info-Display
operation ............................. 101
17 Climate control system ........ 123
18 USB charging port ................ 83
19 Power outlet .......................... 83
20 Parking assist/Advanced
parking assist .....................174
Lane departure warning .....187
Eco button for stop-start
system ................................. 138
Electronic Stability Control and Traction Control ...........153
Sport mode ......................... 156
21 Manual transmission ..........149
Automatic transmission ......146
22 Electric parking brake .........150
23 Selective ride control ..........154
24 Ignition switch .....................134
25 Steering wheel adjustment ..7826 Horn ..................................... 79
27 Storage ................................. 67
28 Bonnet release lever ..........202
29 Light switch ........................ 112
Headlight range
adjustment ......................... 114
Front/rear fog lights ............118
Instrument illumination .......119

In brief13Hazard warning flashers
Operated by pressing ¨.
Hazard warning flashers 3 117.
Horn
Press j.
Washer and wiper systems
Windscreen wiperHI:fastLO:slowINT:interval wiping
orAUTO:automatic wiping with rain
sensorOFF:off
For single wipe when the wiper is off,
press stalk down to position 1x.
Windscreen wiper 3 79.

14In briefWindscreen washer
Pull stalk.
Windscreen washer system 3 79.
Washer fluid 3 205.
Wiper blade replacement 3 207.
Rear window wiper
Turn outer cap to activate the rear
window wiper:
OFF:offINT:intermittent operationON:continuous operationRear window washer
Push stalk.
Washer fluid is sprayed on the rear
window and the wiper wipes a few
times.
Rear window wiper / washer 3 81.

In brief15Climate control
Heated rear windowHeating and ventilation system, air
conditioning system
The heating is operated by pressing
b .
Electronic climate control system
The heating is operated by pressing
b .
Heated rear window 3 40.
Heated exterior mirrors
Pressing b also activates the heated
exterior mirrors.
Heated exterior mirrors 3 37.
Demisting and defrosting the
windows
Heating and ventilation system, air conditioning system
● press à, the air distribution is
directed towards the windscreen
● set temperature controller £ to
warmest level
● switch on air conditioning A/C, if
required
● set fan speed Z to highest level
● switch on heated rear window b

16In brief●switch on heated windscreen ,
● open side air vents as required and direct them towards the doorwindows
Heating and ventilation system
3 122.
Air conditioning system 3 123.
Heated windscreen 3 41.Electronic climate control system
● press à, the LED in the button
illuminates to indicate activation
● temperature and air distribution are set automatically and the fan
runs at high speed
● switch on air conditioning by pressing A/C, if required
● switch on heated rear window b
● switch on heated windscreen ,
● to return to previous mode, press
à again
● to return to automatic mode, press AUTO
Electronic climate control system
3 126.

20Keys, doors and windowsKeys, doors and
windowsKeys, locks ................................... 20
Keys .......................................... 20
Radio remote control .................21
Electronic key system ................22
Central locking system ..............23
Automatic locking ......................27
Child locks ................................. 28
Doors ........................................... 29
Load compartment ....................29
Vehicle security ............................ 34
Anti-theft locking system ...........34
Anti-theft alarm system ..............34
Immobiliser ................................ 36
Exterior mirrors ............................ 36
Convex shape ........................... 36
Electric adjustment ....................36
Folding mirrors .......................... 37
Heated mirrors ........................... 37
Interior mirrors ............................. 38
Manual anti-dazzle ....................38
Automatic anti-dazzle ................38
Windows ...................................... 38
Windscreen ............................... 38Power windows......................... 39
Heated rear window ..................40
Heated windscreen ....................41
Sun visors .................................. 41
Roller blinds ............................... 41
Roof ............................................. 42
Glass panel ............................... 42Keys, locks
KeysCaution
Do not attach heavy or bulky items to the ignition key.
Replacement keys
The key number is specified on a
detachable tag.
The key number must be quoted
when ordering replacement keys as it
is a component of the immobiliser
system.
Locks 3 235.
Central locking 3 23.
Starting the engine 3 137.
Radio remote control 3 21.
Electronic key 3 22.
The code number of the adapter for
the locking wheel nuts is specified on
a card. It must be quoted when
ordering a replacement adapter.
Wheel changing 3 226.

38Keys, doors and windowsInterior mirrors
Manual anti-dazzle
To reduce dazzle, adjust the lever on the underside of the mirror housing.
Automatic anti-dazzle
Dazzle from following vehicles is
automatically reduced, when driving
in the dark.
Windows
Windscreen
Windscreen stickers
Do not attach stickers such as toll
road stickers or similar on the
windscreen in the area of the interior
mirror. Otherwise the detection zone
of the sensor and the view area of the camera in the mirror housing could be
restricted.
Windscreen replacementCaution
If the vehicle has a front-looking
camera sensor for the driver
assistance systems, it is very
important that any windscreen
replacement is performed
accurately according to Vauxhall
specifications. Otherwise, these systems may not work properly
and there is a risk of unexpected
behaviour and / or messages from these systems.

Keys, doors and windows41Vehicles with electronic climate
control system
Heated windscreen
Operated by pressing ,. LED in
button illuminates.
Heating works with the engine
running and is switched off
automatically after a short time.
Depending on climate control
system, , is located at a different
position.
Vehicles with electronic climate
control system
Vehicles with air conditioning
system
Sun visors
The sun visors can be folded down or swivelled to the side to prevent
dazzling.
If the sun visors have integral mirrors, the mirror covers should be closed
when driving.
A ticket holder is located on the
backside of the sun visor.
Roller blinds
To reduce sunlight at the second row seats, pull the blind upwards using
the grip and engage it at the top of the
door frame.
