2019 VAUXHALL CROSSLAND X Clock time

76Instruments and controls9Warning
The road surface may already be
icy even though the display
indicates a few degrees above 0
°C.
Clock
Date and time are shown in the
Info Display 3 96.
Setting date and time, see
Infotainment manual.
Power outlets
A 12 V power outlet is located in the
centre console.
Another power outlet is located in the console between the front seats.
Do not exceed the maximum power
consumption of 120 W.
With ignition off, the power outlet is deactivated. Additionally, the poweroutlet is deactivated in the event of
low vehicle battery voltage.
Electrical accessories that are
connected must comply with the
electromagnetic compatibility
requirements laid down in
DIN VDE 40 839.
Do not connect any current-delivering
accessories, e.g. electrical charging
devices or batteries.
Do not damage the outlets by using
unsuitable plugs.
Stop-start system 3 136.
USB charging port
One or two USB ports are located in
the centre console. Both USB ports
are prepared for charging devices.
When two USB ports are available,
the upper USB port can be used to
connect a phone for phone projection.

Driving and operating179Caution
In case of misfuelling, do not
switch on ignition.
Fuel filler flap is located at left rear
side of vehicle.
The fuel filler flap can only be opened
if the vehicle is unlocked. Release the
fuel filler flap by pushing the flap.
Petrol and Diesel refuelling To open, turn the cap slowly
anticlockwise.
The fuel filler cap can be attached to the hook on the fuel filler flap.
Place the nozzle in straight position to the filler neck and press with slight
force to insert.
To refuel, switch on pump nozzle.
After the automatic cut-off, the tank can be topped up by operating the
pump nozzle a maximum of two more
times.
Caution
Wipe off any overflowing fuel
immediately.
To close, turn the fuel filler cap
clockwise.
Close the flap and allow it to engage.
Liquid gas refuellingFollow the operating and safety
instructions of the filling station when
refuelling.
Filling adapter
As filling systems are not
standardised, different adapters are
required which are available from
Vauxhall Distributors and from
Vauxhall Authorised Repairers.

196Vehicle care2.Lift the retainer, then pull the plug
connector backwards.
3. Fold down the retainer and remove the bulb from the reflectorhousing.
4. Replace the bulb and push it into the reflector housing by setting
the lug into position.
5. Fold up the retainer and hold in position.
6. Attach the plug connector to the bulb and fix it with the retainer.
7. Fit the cap and rotate clockwise.
Sidelight / Daytime running light
In case of defective LEDs, have them
replaced by a workshop.
LED headlights
Headlights for low and high beam,
sidelights, daytime running lights and turn lights are designed as LEDs and
cannot be changed.
Have lights repaired by a workshop in
case of failure.
Front fog lights
The bulbs are accessible from the
underside of the vehicle.1. Turn the bulb holder anti- clockwise and remove it from the
reflector housing.
2. Disengage the bulb socket from the plug connector by pressing
the retaining lug.
3. Remove and replace the bulb socket with bulb and attach the
plug connector.
4. Insert the bulb socket into the reflector housing by turning
clockwise and engage.

255Clock............................................. 76
Control indicators.......................... 87
Control of the vehicle .................131
Controls ........................................ 72
Convex shape .............................. 33
Coolant and antifreeze ...............230
Cruise control ...................... 93, 150
Cupholders .................................. 62
Curtain airbag system .................. 54
D Danger, Warnings and Cautions ...4
Daytime running lights ...............111
Declaration of conformity ............244
DEF ............................................ 140
Deflation detection system ...........92
Diesel exhaust fluid ....................140
Diesel fuel system bleeding .......192
Door open .................................... 93
Doors ............................................ 29
Driver alert .................................. 175
Driver assistance systems ..........150
Driver Information Centre .............94
Driving characteristics and towing tips .............................. 182
Driving hints ................................ 131
E Electric adjustment ......................33
Electrical system......................... 201
Electronic climate control system 122Electronic driving programmes ..144
Electronic key system ...................22
Electronic Stability Control and Traction Control system ....91, 148
Electronic Stability Control and Traction Control system off .......91
End-of-life vehicle recovery .......187
Engine compartment fuse box ...202
Engine coolant ........................... 190
Engine coolant temperature ........91
Engine coolant temperature gauge ....................................... 85
Engine data ............................... 237
Engine exhaust .......................... 139
Engine identification ...................233
Engine oil ................... 189, 230, 234
Engine oil level monitor ................86
Engine oil pressure ......................92
Entry lighting .............................. 116
Event data recorders ..................250
Exhaust filter ......................... 91, 139
Exit lighting ................................ 116
Exterior care .............................. 222
Exterior light ................................. 92
Exterior lighting ....................12, 109
Exterior mirrors ............................. 33
F Fault ........................................... 145
First aid ......................................... 68First aid kit ................................... 68
Fixed air vents ........................... 128
Folding mirrors ............................. 34
Forward collision alert................. 155
Front airbag system .....................53
Front fog lights .............93, 113, 196
Front pedestrian protection ........159
Front seats.................................... 42
Fuel............................................. 176
Fuel for diesel engines ..............176
Fuel for liquid gas operation .......178
Fuel for petrol engines ...............176
Fuel gauge ................................... 84 Fuel selector ................................ 84
Fuses ......................................... 201
G
Gauges ......................................... 83
Gear shifting ................................. 90
General information ...................181
Glass panel .................................. 39
Glovebox ..................................... 62
H Halogen headlights ....................194
Hand brake ................................. 147
Hazard warning flashers ............112
Headlight flash ........................... 110
Headlight range adjustment ......111
Headlights................................... 109
Headlights when driving abroad 111
