2019 TOYOTA AVALON navigation system

2
OVERVIEWInstrument panel
Steering wheel controls
Audio control switches2
Audio control switches2
Meter control switches Paddle shift switches
1
Telephone switches2
Voice command switch2
Full-Speed　Range Dynamic Radar
Cruise Control (DRCC)
Vehicle-to-vehicle distance switch
Tilt and telescopic
steering lock
release lever
1
Tilt and telescopic
steering control
switch
1
Bird’s Eye View Camera ON/OFF switch1,2“ODO/TRIP” switchInstrument panel light control switch
Automatic High Beam (AHB) switch
Heated steering
wheel switch
1
VSC OFF switch
Fuel tank door release switch
Trunk opener
Hood lock
release lever
Meters/Multi-Information Display (MID)
Windshield wiper and washer switch
“ENGINE START STOP” switch
1
If equipped.2 For details, refer to the “Navigation System Owner’s Manual” or visit www.toyota.com/entune
for additional audio/multimedia resources.
Lane Departure Alert with Steering
Assist (LDA w/SA) switch Full-Speed Range
Dynamic Radar Cruise
Control (DRCC) switch
Headlights/turn signals
controls
2019_Avalon_QRG_V3_3_ML_0406.indd 24/12/18 3:13 PM

3
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Audio control switches2
Full-Speed　Range Dynamic Radar
Cruise Control (DRCC)
Vehicle-to-vehicle distance switch
Windshield wiper and washer switch
Emergency flasher switch
Audio system
1,2/
Navigation system1,2
“ENGINE START STOP” switch
Air Conditioning controls
ECO mode switch
ECO mode switch
Without AVS
With AVS
NORMAL mode switch
NORMAL/CUSTOM mode switch SPORT mode switch
SPORT S/S+ mode switchBrake HOLD switch
Brake HOLD switch
1
If equipped.2 For details, refer to the “Navigation System Owner’s Manual” or visit www.toyota.com/entune
for additional audio/multimedia resources.
Full-Speed Range
Dynamic Radar Cruise
Control (DRCC) switch
2019_Avalon_QRG_V3_3_ML_0406.indd 34/12/18 3:13 PM

14
FEATURES & OPERATIONS
Refer to the Owner’s Manual for more settings and customizable featur\
es.
IndicatorsMenu icons
Push MID control switches to view or change information in the following\
:
Right turn
Lane change
1
Lane change2
Left turn
1 The right hand signals will flash three times.
2 The left hand signals will flash three times.
High beam
or
Auto High Beam*
Daytime Running Light system (DRL) Automatically turns on the headlights at a
reduced intensity. Automatic light cut off system Automatically turns lights off after 30-second
delay, or lock switch on remote may be pushed after locking. Automatic High Beam (AHB) system Automatically switches between high
and low beams as appropriate to provide the most light possible and enha\
nce
forward visibility. Refer to Toyota Safety Sense™ P (TSS-P) in this guide or the
Owner’s Manual for more details on the Automatic High Beam feature.
* Operating conditions must be met. Refer to Owner’s Manual for detai\
ls.
Headlights
Parking lights High beam
flasher
Auto OFF Low beam
Lights & turn signals
HEADLIGHTS
TURN SIGNALS
Engine switch must be in the “IGNITION ON” mode.
Steering wheel-heater (if equipped)
The head-up display is linked to the meters and navigation system and pr\
ojects a
variety of information in front of the driver, such as the current vehic\
le speed.
Refer to the Owner’s Manual for more details.
Driving assist
system status/
navigation system-
linked display area
Information display area
2019_Avalon_QRG_V3_3_ML_0406.indd 144/12/18 3:14 PM

15
Multi-Information Display (MID)
Head-up display (if equipped)
Refer to the Owner’s Manual for more settings and customizable features.
Previous screen
Indicators
Enter/Select
Scroll/search
screens
“ODO/TRIP” switch
Speed limit display
(with navigation system)
Full-Speed DRCC and
Lane Departure Alert display
Menu icons
Shift positionDisplay area
Speedometer
Outside temperature
Odometer/trip
meter display
Push MID control switches to view or change information in the following:
Driving assist system information Driving information
Vehicle information
Audio system-linked display
Settings display
Warning display
1 The right hand signals will flash three times.
2 The left hand signals will flash three times.
Daytime Running Light system
(DRL) Automatically turns on the headlights at
a
reduced intensity.
Automatic light cut off system Automatically turns lights off after 30-second
delay, or lock switch on remote may be pushed after locking. Automatic High Beam (AHB) system Automatically switches between high
and low beams as appropriate to provide the most light possible and enhance\

forward visibility. Refer to Toyota Safety Sense™ P (TSS-P) in this guide or the
Owner’s Manual for more details on the Automatic High Beam feature.
* Operating conditions must be met. Refer to Owner’s Manual for detail\
s.
High beam
flasher
Engine switch must be in the “IGNITION ON” mode.
Steering wheel-heater (if equipped)
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
The head-up display is linked to the meters and navigation system and proje\
cts a
variety of information in front of the driver, such as the current vehicle spee\
d.
Refer to the Owner’s Manual for more details.
Driving assist
system status/
navigation system-
linked display area Shift position/speed
limit display area
Eco Driving Indicator/
Tachometer
Information display area Vehicle speed display
2019_Avalon_QRG_V3_3_ML_0406.indd 154/12/18 3:14 PM

18
FEATURES & OPERATIONS
Seat heatersSeat heaters and ventilators
Driver’s seatPassenger’s
seatPassenger’s
seatDriver’s seat
The engine switch must be in the “IGNITION ON” mode.
USB charge-ports
FrontRear
Access
AUDIO screen Access
HOME screen
Access
MENU screen
ENTUNE™ 3.0 AUDIO PLUS
ENTUNE™ 3.0 PREMIUM (JBL®) AUDIO, WITH APP SUITE AND DYNAMIC
NAVIGATION
Access
MAP screen
USB media port
By connecting a USB-compatible portable audio device or USB memory stick\
into
the USB media port, you can listen to music through the vehicle’s spe\
aker system.
AUX port
By inserting an AUX cable into the AUX port, you can listen to music fro\
m a
portable audio device through the vehicle’s speaker system while in A\
UX mode.
REAR SEAT HEATERS (IF EQUIPPED)
NOTE: Concentrating on the road should always be your first priority while
driving. Do not use the Entune system if it will distract you.
Visually match your vehicle’s Entune
TM 3.0 audio system to one featured in
this guide for the most accurate information.
Refer to the “Navigation System Owner’s Manual” or visit www.to\
yota.com/entune
for additional audio/multimedia resources.
(Charge-only)
(Charge-only)
Seat heaters/ventilators (if equipped)
FRONT SEAT HEATERS/VENTILATORS (IF EQUIPPED)
2019_Avalon_QRG_V3_3_ML_0406.indd 184/12/18 3:14 PM

19
Seat heaters and ventilators
The engine switch must be in the “IGNITION ON” mode.
USB charge-ports
Rear
Audio
Touch screen display
Access
AUDIO screen
Push to turn ON/OFF or
turn to adjust volume Turn to tune radio stations
manually or select tracks or filesAccess
Bluetooth
hands-free system
Seek
station/CD
track select
Access
HOME screen
Access
MENU screen
Access
APPS screen
ENTUNE™ 3.0 AUDIO PLUS
ENTUNE™ 3.0 PREMIUM (JBL®) AUDIO, WITH APP SUITE AND DYNAMIC
NAVIGATION
Access
MAP screen
USB media port
By connecting a USB-compatible portable audio device or USB memory stick i\
nto
the USB media port, you can listen to music through the vehicle’s speake\
r system.
AUX port
By inserting an AUX cable into the AUX port, you can listen to music from \
a
portable audio device through the vehicle’s speaker system while in AUX mode.\
Open
USB media/AUX port
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
NOTE: Concentrating on the road should always be your first priority while
driving. Do not use the Entune system if it will distract you.
Visually match your vehicle’s Entune
TM 3.0 audio system to one featured in
this guide for the most accurate information.
Refer to the “Navigation System Owner’s Manual” or visit www.toyota.\
com/entune
for additional audio/multimedia resources.
Seat heaters/ventilators (if equipped)
2019_Avalon_QRG_V3_3_ML_0406.indd 194/12/18 3:14 PM

20
FEATURES & OPERATIONS
Steering wheel telephone switches
Microphone
Bluetooth® technology allows dialing or receipt of calls without removing your han\
ds
from the steering wheel or using a cable to connect the compatible telep\
hone and
the system.
* Push and hold to access Mobile Assistant. Once you connect a compatible,\

registered mobile phone, you can access Siri® Eyes Free using Mobile Assistant
access switch.

Refer to the “Bluetooth
® Device Pairing Section” in this guide for more information
about phone connections and compatibility.
Refer to the “Navigation System Owner’s Manual” for more detail\
s.
Back switch
NOTE: Concentrating on the road should always be your first priority while
driving. Do not use the Entune system if it will distract you.
Volume control
Voice command
switch
Start and end call/
Mobile Assistant
access*“MODE”
Push to change an audio
mode. Push and hold to turn
the audio mutes or pauses.
“ ”
Use to search within the
selected audio medium
(radio, CD, etc.).
The “ENGINE START STOP” switch must be in the ACCESSORY or IGNITIO\
N ON
mode for use.
A mobile device can be charged wirelessly on the tray. (1) Press the wireless
charger power switch and the green operation indicator light turns on. (2) Place a
mobile device on the tray as shown in the illustration. An amber indicat\
or illuminates
while charging is in progress. When charging is complete, the indicator \
illuminates
green. Some phones, cases or cover type wireless chargers may not cause \
the
green indicator to illuminate even though it is fully charged.
Refer to the Owner‘s Manual for more details on this system before at\
tempting to
use it.
Steering wheel switches
& telephone controls (Bluetooth®)
2019_Avalon_QRG_V3_3_ML_0406.indd 204/12/18 3:14 PM

21
Bluetooth® technology allows dialing or receipt of calls without removing your han\
ds
from the steering wheel or using a cable to connect the compatible telep\
hone and
the system.
* Push and hold to access Mobile Assistant. Once you connect a compatible,\

registered mobile phone, you can access Siri® Eyes Free using Mobile Assistant
access switch.

Refer to the “Bluetooth
® Device Pairing Section” in this guide for more information
about phone connections and compatibility.
Refer to the “Navigation System Owner’s Manual” for more detail\
s.
NOTE: Concentrating on the road should always be your first priority while
driving. Do not use the Entune system if it will distract you.
“ ”
Use to search within the selected audio medium
(radio, CD, etc.).
The “ENGINE START STOP” switch must be in the ACCESSORY or IGNITIO\
N ON
mode for use.
Power outlets - 12V DC
Wireless charger (if equipped)
A mobile device can be charged wirelessly on the tray. (1) Press the wireless
charger power switch and the green operation indicator light turns on. (2) Place a
mobile device on the tray as shown in the illustration. An amber indicat\
or illuminates
while charging is in progress. When charging is complete, the indicator \
illuminates
green. Some phones, cases or cover type wireless chargers may not cause \
the
green indicator to illuminate even though it is fully charged.
Refer to the Owner‘s Manual for more details on this system before at\
tempting to
use it.
Power switchCharge area
Operation indicator lightPress
When the engine is turned off, the last state (ON/
OFF) of the charger is memorized.
Place device nearest the center of charging area for
best results. Moving device may result in stopping
or restarting the charging process.
Place
(1)
(2)
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Steering wheel switches
& telephone controls (Bluetooth®)
2019_Avalon_QRG_V3_3_ML_0406.indd 214/12/18 3:14 PM
