2019 Ram ProMaster Connect settings

NOTE:The key fob may not be able to be detected by the
vehicle if it is located next to a mobile phone, laptop or
other electronic device; these devices may block the key
fob’s wireless signal.
To Unlock The Doors
Push and release the unlock button on key fob once to
unlock only the front doors. Push and release the cargo
unlock button on key fob once to unlock the cargo area
(rear lateral sliding doors and rear door). The turn signal
lights will flash twice to acknowledge the unlock signal.
To Lock The Doors
Push and release the lock button on the key fob to lock all
doors. The turn signal lights will flash once to acknowl-
edge the signal. If a door is open, the turn signal lights will
flash at an increased rate.
Locking Doors With A Key
1. Insert the key with either side up.
2. Turn the key to the right to lock the door.
3. Turn the key to the left to unlock the door.
Refer to “Dealer Service” in “Servicing And Maintenance”
for maintenance procedures.
Sound Horn With Lock
This feature will cause the horn to chirp when the doors are
locked with the key fob. This feature can be turned on or
turned off. To change the current setting, refer to
“Uconnect Settings” in “Multimedia” for further informa-
tion.
Key Fob Battery Replacement
NOTE: Perchlorate Material – special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Key Fob
3
GETTING TO KNOW YOUR VEHICLE 17

Headlights
To turn on the headlights, turn the end of the multifunction
lever to the headlight position. When the headlight switch
is on, the parking lights, taillights, license plate light, the
clearance lights and instrument panel lights are also turned
on. To turn off the headlights, turn the end of the multi-
function lever back to the O (Off) position.
Daytime Running Lights — If Equipped
NOTE:When the headlights are turned on, the Daytime
Running Lights will be deactivated. To activate the Daytime Running Lights (DRL), rotate the
end of the multifunction lever to the O (Off) position.
NOTE:
•
The low beams and side/taillights will not be on with
DRL.
• In certain markets, the DRL function may be optional
and can be programmed to be on or off through the
Uconnect system screen. Refer to “Uconnect Settings” in
“Multimedia” for further information.
The Daytime Running Lights will come on whenever the
ignition is ON, the headlight switch is off, the parking
brake is off, and the turn signal is off.
High Beam/Low Beam Select Switch
Pull the multifunction lever toward you to switch the
headlights to high beam. Pull the lever a second time to
switch the headlights back to low beam.
NOTE: If the vehicle’s ignition is turned OFF, both high
and low beam headlights will also turn off.
Multifunction Lever
3
GETTING TO KNOW YOUR VEHICLE 39

This system allows the driver to select a variety of useful
information by pushing the switches mounted on the
instrument panel. Examples of menu items are:
•Speed Beep
• Buzzer Volume
• Seat Belt Buzzer (Just Available After SBR Disable Made
By CHR Service)
• Exit Menu
If equipped with a Uconnect system, some customer pro-
grammable features will display in the radio. Refer to the
“Uconnect Settings” in “Multimedia” for further informa-
tion.
The system allows the driver to select information by
pushing the following buttons mounted on the instrument
panel to the left of the steering column: NOTE:
TheMODE button must be pushed prior to
pressing the uparrow and downarrow buttons.
• MODE Button
Push and hold the MODEbutton for a time longer than
one second to access/select the information screens or
submenu screens of a main menu item. Push and hold the
MODE button for two seconds to reset displayed/selected
features that can be reset.
Display Control Buttons
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 69

NOTE:The range depends on several factors: driving
style, type of route (freeway, residential, mountain roads,
etc.), conditions of use of the vehicle (load, tire pressure,
etc.). Trip planning must take into account the above notes.
Travel Distance
This value shows the distance covered since the last reset.
Average Fuel Consumption
This value shows the approximate average consumption
since the last reset.
Current Fuel Consumption
This indicates the fuel consumption. The value is con-
stantly updated. The message “----” will appear on the
display if the vehicle is parked with the engine running.
Average Speed
This value shows the vehicle’s average speed as a function
of the overall time elapsed since the last reset.
Travel Time
This value shows the time elapsed since the last reset.
Personal Settings (Customer-Programmable
Features)
• Speed Beep
• Buzzer Volume
• Seat Belt Buzzer (Just Available After SBR Disable Made
By CHR Service)
• Exit Menu
NOTE: If equipped, some customer programmable fea-
tures will display in the Uconnect system. Refer to
“Uconnect Settings” in “Multimedia” for further informa-
tion.
TRIP COMPUTER
The Trip Computer is located in the instrument cluster. It
features a driver-interactive display (displays information
such as trip information, range, fuel consumption, average
speed, and travel time).
NOTE: The Uconnect System also has a Trip Computer
display and menus to customize the information displayed
in the cluster. For further information, refer to “Uconnect
Settings” in “Multimedia”.
72 GETTING TO KNOW YOUR INSTRUMENT PANEL

To Set A Desired Speed
Turn the Speed Control on. When the vehicle has reached
the desired speed, move the Speed Control lever upward
SET (+) and release. Release the accelerator and the vehicle
will operate at the selected speed.
NOTE:The vehicle should be traveling at a steady speed
and on level ground before moving the Speed Control lever
upward SET (+).
To Vary The Speed Setting
To Increase Speed
When the Speed Control is set, you can increase speed by
tapping the Speed Control lever up SET (+).
The driver’s preferred units can be selected through the
radio settings if equipped. Refer to ”Uconnect Settings” in
“Multimedia” for more information. The speed increment
shown is dependant on the chosen speed unit of U.S. (mph)
or Metric (km/h):
U.S. Speed (mph)
• Tapping the Speed Control lever up SET (+) once will
result in a 1 mph increase in set speed. Each subsequent
tap of the lever results in an increase of 1 mph. •
If the lever is continually held up, the set speed will
continue to increase until the lever is released, then the
new set speed will be established.
Metric Speed (km/h)
• Tapping the Speed Control lever up SET (+) once will
result in a 1 km/h increase in set speed. Each subsequent
tap of the lever results in an increase of 1 km/h.
• If the lever is continually held up, the set speed will
continue to increase until the lever is released, then the
new set speed will be established.
To Decrease Speed
When the Speed Control is set, you can decrease speed by
tapping the Speed Control lever down (-).
The driver’s preferred units can be selected through the
radio settings if equipped. Refer to ”Uconnect Settings” in
“Multimedia” for more information. The speed increment
shown is dependant on the chosen speed unit of U.S. (mph)
or Metric (km/h):
U.S. Speed (mph)
• Tapping the Speed Control lever down (-) once will
result in a 1 mph decrease in set speed. Each subsequent
tap of the lever results in a decrease of 1 mph.
152 STARTING AND OPERATING

MULTIMEDIA
CONTENTS
UCONNECT SYSTEMS ...................286
 CYBERSECURITY ...................... .286
 UCONNECT SETTINGS ...................287
▫ Uconnect 3/3 NAV Settings ...............288
 STEERING WHEEL AUDIO CONTROLS .......298
▫ Radio Operation ....................... .298
▫ Player Operation ...................... .298
 IPOD/USB/MP3 CONTROL — IF EQUIPPED . . .298
▫ USB Charging Port ..................... .299
 RADIO OPERATION AND MOBILE PHONES . . .300
▫ Regulatory And Safety Information ..........300
UCONNECT VOICE RECOGNITION .........302
▫ Introducing Uconnect ....................302
▫ Get Started .......................... .302
▫ Basic Voice Commands ...................303
▫ Radio .............................. .304
▫ Media .............................. .304
▫ Phone .............................. .305
▫ Voice Text Reply ...................... .306
▫ General Information .....................307
▫ Additional Information ...................308
10

NOTE:
•FCA US LLC or your dealer may contact you directly
regarding software updates.
• To help further improve vehicle security and minimize
the potential risk of a security breach, vehicle owners
should:
• Routinely check www.driveuconnect.com/support/
software-update.html (U.S. Residents) or www.driveu-
connect.ca (Canadian Residents) to learn about avail-
able Uconnect software updates.
• Only connect and use trusted media devices (e.g.
personal mobile phones, USBs, CDs).
Privacy of any wireless and wired communications cannot
be assured. Third parties may unlawfully intercept infor-
mation and private communications without your consent.
For further information, refer to “Onboard Diagnostic
System (OBD II) Cybersecurity” in “Getting To Know Your
Instrument Panel”.
UCONNECT SETTINGS
The Uconnect system uses a combination of buttons on the
touchscreen and buttons on the faceplate located on the
center of the instrument panel that allows you to access and change the customer programmable features. Many
features can vary by vehicle.
CAUTION!
Do NOT attach any object to the touchscreen, doing so
can result in damage to the touchscreen.
Uconnect 3/3 NAV With 5-inch Display Buttons On The
Touchscreen And Buttons On The Faceplate
1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate
10
MULTIMEDIA 287

NOTE:The NAV button in the middle of your Uconnect
system may also contain the word COMPASS.
Uconnect 3/3 NAV Settings
Push the Settings button on the faceplate to display the
menu setting screen. In this mode the Uconnect system
allows you to access programmable features that may be
equipped such as Display, Units (if equipped), Voice,
Clock, Safety & Driving Assistance (if equipped), Lights,
Doors & Locks, Engine off Options, Audio, Phone (if
equipped), SiriusXM Setup (if equipped), Restore Settings
and Clear Personal Data.
NOTE:
• Only one category may be selected at a time.
• The Back arrow will change into a Done button if any
changes are made. When making a selection, press the button on the touch-
screen to enter the desired mode. Once in the desired
mode, press and release the preferred setting. Once the
setting is complete, either press the Back Arrow button on
the touchscreen or the Back button on the faceplate to
return to the previous menu or press the X button on the
touchscreen to return to the Main Settings screen. Pressing
the Up or Down Arrow buttons on the touchscreen on the
right side of the screen will allow you to toggle up or down
through the available settings.
Display
After pressing the Display button on the touchscreen, the
following settings will be available:
Setting Name
Selectable Options
Display Mode Manual Auto
Display Brightness With Headlights ON Up Arrow Button
Down Arrow Button
NOTE: This feature is only available in Manual Display Mode.
288 MULTIMEDIA
