2019 OPEL VIVARO B stop start

Vehicle care173The brake fluid level must be between
the MINI and MAXI marks.
When topping up, ensure maximum
cleanliness as contamination of the
brake fluid can lead to brake system
malfunctions. Have the cause of the
loss of brake fluid remedied by a
workshop.
Only use high-performance brake
fluid approved for your vehicle.
Brake fluid 3 207.
Vehicle battery
The vehicle battery is located under a cover in the engine compartment.
The vehicle battery is maintenance-
free provided that the driving profile
allows sufficient charging of the
battery. Short-distance driving and
frequent engine starts can discharge
the battery. Avoid the use of
unnecessary electrical consumers.
Control indicator p illuminates if
there is a fault with the charging
system. Stop, switch off engine and
seek the assistance of a workshop.
Charging system 3 99.
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.
Laying up the vehicle for more than
four weeks can lead to battery
discharge.
9 Danger
Ensure the ignition is switched off
completely (the vehicle must not
be in an Autostop) before
connecting or disconnecting the
vehicle battery.
Stop-start system 3 137.
Replacing the vehicle battery
Ensure that the battery is alwaysreplaced by the same type of battery.
Seek the assistance of a workshop to
have the vehicle battery replaced.
Stop-start system 3 137.
Charging the vehicle battery
9 Warning
On vehicles with stop-start
system, ensure that the charging potential does not exceed 14.6 V
when using a battery charger.
Otherwise the vehicle battery may be damaged.

176Vehicle careWith power button
● Insert the electronic key in thecard reader.
● Press START/STOP without
pressing any of the pedals.
● Wait a few minutes before starting engine.
Power button 3 133.
If the engine fails to start, seek the
assistance of a workshop.
Starting the engine 3 135.
Wiper blade replacement
Wiper blades on the windscreen
Before replacing the wiper blades,
move the wiper lever to the
maintenance position (if equipped).
Windscreen wiper and washer 3 86.
Lift the wiper arm, press button to
disengage the wiper blade and
remove.
Attach new wiper blade slightly
angled to the wiper arm and push until
it engages.
Lower wiper arm carefully.
Wiper blade on the rear window
Lift wiper arm, press retaining lugs
together to disengage the wiper blade
and raise to remove.
Lower wiper arm carefully.
When attaching new wiper blade,
ensure it is engaged securely.

206Service and maintenanceRomania, Bulgaria, Moldova, Cyprus:
Maintenance of your vehicle is
required every 30,000 km or after
one year, whichever occurs first,
unless otherwise indicated by the service display.
Turkey:
Maintenance of your vehicle is
required every 20,000 km or after
one year, whichever occurs first,
unless otherwise indicated by the
service display.
Morocco, South Africa, Russia,
Ukraine, Belarus, Kazakhstan:
Maintenance of your vehicle is
required every 15,000 km or after
one year, whichever occurs first, unless otherwise indicated by the
service display.
Algeria, Tunisia, Malta, Singapore:
Maintenance of your vehicle is
required every 10,000 km or after
one year, whichever occurs first,
unless otherwise indicated by the service display.Egypt:
Maintenance of your vehicle is
required every 8,000 km or after
one year, whichever occurs first, unless otherwise indicated by the
service display.
Severe operating conditions exist if
one or more of the following
circumstances occur frequently: Cold
starting, stop and go operation, trailer operation, mountain driving, driving
on poor and sandy road surfaces,
increased air pollution, presence of
airborne sand and high dust content,
driving at high altitude and large
variations of temperature. Under
these severe operating conditions, certain service work may be required
more frequently than the regular service interval.
Service display 3 94.
Confirmations
Confirmation of service is recorded in the Service and warranty booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.Make sure that the Service and
warranty booklet is completed
correctly as continuous proof of
service is essential if any warranty or
goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service display The service interval is based on
several parameters depending on
usage.
The service display, located in the
Driver Information Centre, indicates
when the next service is due. Seek
the assistance of a workshop.
Service display 3 94.

226IndexAAbsorptive Glass Mat battery .....173
Accessories and vehicle modifications .......................... 167
AdBlue ................ 101, 106, 142, 207
AdBlue tank ................................ 215
Adjustable air vents ...................129
AGM battery ............................... 173
Airbag and belt tensioners ...........98
Airbag deactivation ................64, 98
Airbag label............................. 60, 64
Airbag system .............................. 60
Air conditioning regular operation ................................ 130
Air conditioning system .............. 119
Air intake .................................... 130
Air recirculation ...................119, 200
Air vents...................................... 129
Alert ............................................ 105
Antifreeze ................................... 171
Antilock brake system ................ 148
Antilock brake system (ABS) .....100
Anti-theft alarm system ................38
Anti-theft bolts............................. 196
Anti-theft locking system .............. 37
Anti-theft security lock ..................25
Appearance care ........................202
Armrest ........................................ 50
Ashtrays ....................................... 90 Automatic anti-dazzle ..................42Automatic fuel cut-off ..................136
Automatic light control ...............111
Automatic locking ........................31
Autostop ............................. 135, 137
Auxiliary heater ........................... 124
B Battery .................... 22, 23, 124, 173
Battery discharge protection ......117
Battery, jump starting.................. 199
Belts.............................................. 55 Bench seat.................................... 76
Bonnet ....................................... 168
Bottle holders................................ 76
Brake and clutch fluid .................207
Brake assist ............................... 149
Brake fluid .................................. 172
Brakes ............................... 148, 172
Brake system ............................... 99
Breakdown.................................. 200
Bulb replacement ....................... 177
C
Capacities .................................. 215
Car Pass ...................................... 22
Catalytic converter .....................141
Central locking system ................26
Centre high-mounted brake light 179
Changing tyre and wheel size ...192
Charging system .......................... 99
Child locks ................................... 32

230Recommended fluids andlubricants ........................ 207, 211
Refuelling ................................... 162 Registered trademarks ...............221
Remote control ............................. 22
Restraining lattice .........................81
Reversing light ........................... 180
Reversing lights .........................114
Ride control systems ..................150
Roof load ...................................... 82
Roof rack ..................................... 82
S Safety belts ................................... 55
Safety net .................................... 80
Seat adjustment ....................... 7, 48 Seat belt ........................................ 8
Seat belt reminder .......................98
Seat belts ..................................... 55
Seat folding .................................. 50
Seat heating ................................. 50
Seat position ................................ 47
Seats ............................................ 76
Selective catalytic reduction .......142
Service ............................... 130, 205
Service display ............................ 94
Service information ....................205
Service vehicle soon .................... 99
Side airbag system ......................63
Sidelights .................................... 110Side turn lights ........................... 179
Sliding door .................................. 32
Sliding side door ........................... 32
Spare wheel ............................... 197
Spare wheel security tool ...........187
Speed limiter ................91, 103, 155
Speedometer ............................... 91
Starting and operating ................133
Starting off ................................... 18
Starting the engine ...............18, 135
Steering ...................................... 132
Steering column controls ..............85
Steering wheel adjustment ......9, 85
Steering wheel controls ...............85
Stop engine .................................. 99
Stop-start system.......... 18, 102, 137
Storage ......................................... 73
Storage box .................................. 76
Storage compartment ...................75
Storage compartments .................73
Sun visors .................................... 45
Symbols ......................................... 4
T
Tablet holder................................. 73
Tachograph ........................ 103, 108
Tachometer ................................. 92
Tailgate ......................................... 35
Tailgate emergency release .........35
Tail lights ................................... 178Temporary spare wheel ..............197
Three-point seat belt .................... 56
Toll road stickers .......................... 43
Tools .......................................... 187
Top-Tether .................................... 66
Torx key ...................................... 187
Touchscreen ............................... 104
Tow bar....................................... 164
Towing ................................ 164, 200
Towing another vehicle .............201
Towing a trailer ........................... 164
Towing eye ......................... 187, 200
Towing the vehicle .....................200
Traction Control system ............. 150
Trailer coupling ........................... 164
Trailer stability assist .................165
Trailer towing ............................. 164
Transmission ............................... 18
Tread depth ............................... 191
Trip computer ............................ 106
Trip odometer .............................. 92
Turbo engine warm-up ...............135
Turn lights ............................ 97, 113
Tyre chains ................................ 192
Tyre changing ............................. 196
Tyre designations ......................188
Tyre pressure ............................ 188
Tyre pressure monitoring system ............................. 101, 190
Tyre pressures ........................... 216
