2019 OPEL KARL traction control

In brief111Central locking system ..........22
Power windows .....................30
2 Exterior mirrors .....................28
3 Cruise control .....................117
Speed limiter ...................... 118
Heated steering wheel ..........60
4 Turn lights, headlight
flash, low beam and high
beam ..................................... 92
Exit lighting ........................... 94
Parking lights ........................ 93
5 Side air vents ...................... 102
6 Instruments .......................... 64
7 Driver Information Centre ...... 75
8 Steering wheel controls .......60
9 Windscreen wiper,
windscreen washer
system, rear window
wiper, rear window washer
system ................................... 61
10 Centre air vents .................. 102
11 Hazard warning flashers ......91
12 Info Display ........................... 8013Anti-theft alarm system
status LED ........................... 27
14 Infotainment system
15 Glovebox .............................. 52
16 Climate control system .......... 96
17 AUX input, USB input
18 Selector lever .....................111
19 Seat heating .......................... 37
20 Parking brake ......................113
21 Ignition switch with
steering wheel lock ............105
22 Horn ..................................... 61
Driver airbag ........................ 43
23 Bonnet release lever ..........128
24 Steering wheel adjustment ..60
25 Fuse box ............................ 143
26 Traction Control system .....114
City mode ............................ 115
Stop-start system ................107
Lane departure warning .....121
Electronic Stability Control . 11527 Light switch .......................... 90
Headlight range
adjustment ........................... 91
Front fog light ........................ 92
Rear fog light ........................ 92
Brightness of instrument
panel illumination ..................93

In brief131Central locking system ..........22
Power windows .....................30
2 Exterior mirrors .....................28
3 Cruise control .....................117
Speed limiter ...................... 118
Heated steering wheel ..........60
4 Turn lights, headlight
flash, low beam and high
beam ..................................... 92
Exit lighting ........................... 94
Parking lights ........................ 93
5 Side air vents ...................... 102
6 Instruments .......................... 64
7 Driver Information Centre ...... 75
8 Steering wheel controls .......60
9 Windscreen wiper,
windscreen washer
system, rear window
wiper, rear window washer
system ................................... 61
10 Centre air vents .................. 102
11 Hazard warning flashers ......91
12 Info Display ........................... 8013Anti-theft alarm system
status LED ........................... 27
14 Infotainment system
15 Glovebox .............................. 52
16 Climate control system .......... 96
17 AUX input, USB input
18 Selector lever .....................111
19 Seat heating .......................... 37
20 Parking brake ......................113
21 Ignition switch with
steering wheel lock ............105
22 Horn ..................................... 61
Driver airbag ........................ 43
23 Bonnet release lever ..........128
24 Steering wheel adjustment ..60
25 Fuse box ............................ 143
26 Traction Control system .....114
City mode ............................ 115
Stop-start system ................107
Lane departure warning .....121
Electronic Stability Control . 11527 Light switch .......................... 90
Headlight range
adjustment ........................... 91
Front fog light ........................ 92
Rear fog light ........................ 92
Brightness of instrument
panel illumination ..................93

Instruments and controls59Instruments and
controlsControls ....................................... 60
Steering wheel adjustment ........60
Steering wheel controls .............60
Heated steering wheel ...............60
Horn ........................................... 61
Windscreen wiper and washer ..61
Rear window wiper and washer ...................................... 62
Outside temperature ..................62
Clock ......................................... 62
Power outlets ............................. 64
Cigarette lighter ......................... 64
Ashtrays .................................... 64
Warning lights, gauges and indi‐ cators ........................................... 64
Instrument cluster ......................64
Speedometer ............................. 64
Odometer .................................. 65
Trip odometer ............................ 65
Tachometer ............................... 65
Fuel gauge ................................ 65
Engine coolant temperature gauge ....................................... 66
Service display .......................... 66Control indicators ......................67
Turn lights .................................. 69
Seat belt reminder .....................70
Airbag and belt tensioners .........70
Airbag deactivation ....................70
Charging system .......................71
Malfunction indicator light ..........71
Service vehicle soon .................71
Brake and clutch system ...........71
Operate pedal ............................ 71
Antilock brake system (ABS) .....72
Gear shifting .............................. 72
Power steering .......................... 72
Lane departure warning ............72
Parking assist ............................ 72
Electronic Stability Control off ...72
Electronic Stability Control and Traction Control system ...........72
Traction Control system off .......73
Engine coolant temperature ......73
Tyre pressure monitoring system ...................................... 73
Engine oil pressure ....................73
Low fuel ..................................... 74
Immobiliser ................................ 74
Reduced engine power .............74
Exterior light .............................. 74
High beam ................................. 74
Front fog lights ........................... 74
Rear fog light ............................. 74Cruise control............................ 74
Speed limiter ............................. 74
Bonnet open .............................. 74
Door open .................................. 75
Displays ....................................... 75
Driver Information Centre ..........75
Info Display ................................ 80
Vehicle messages ........................81
Warning chimes .........................83
Battery voltage .......................... 83
Vehicle personalisation ................83
Telematics service .......................86
OnStar ....................................... 86

Instruments and controls69Control indicators in the overheadconsole
Overview
OTurn lights 3 69XSeat belt reminder 3 70vAirbag and belt tensioners
3 70VAirbag deactivation 3 70pCharging system 3 71ZMalfunction indicator light
3 71gService vehicle soon 3 71RBrake and clutch system
3 71-Operate pedal 3 71uAntilock brake system (ABS)
3 72[Gear shifting 3 72cPower steering 3 72)Lane departure warning 3 72rParking assist 3 72aElectronic Stability Control off
3 72bElectronic Stability Control and
Traction Control system 3 72kTraction Control system off
3 73WEngine coolant temperature
3 73wTyre pressure monitoring
system 3 73IEngine oil pressure 3 73YLow fuel 3 74dImmobiliser 3 74#Reduced engine power 3 748Exterior light 3 74CHigh beam 3 74>Fog light 3 74rRear fog light 3 74mCruise control 3 74LSpeed limiter 3 74/Bonnet open 3 74NDoor open 3 75
Turn lights
O illuminates or flashes green.
Illuminates briefly The parking lights are switched on.
Flashes
A turn light or the hazard warning flashers are activated.
Rapid flashing: failure of a turn light or associated fuse.

72Instruments and controlsFlashes
Pedal must be depressed to start the engine with the key 3 107.
Antilock brake system
(ABS)
u illuminates yellow.
Illuminates for a few seconds after the ignition is switched on. The system is
ready for operation when the control
indicator extinguishes.
If the control indicator does not go out after a few seconds, or if it illuminates while driving, there is a fault in the
ABS. The brake system remains
operational but without ABS
regulation.
Antilock brake system 3 112.
Gear shifting [ with the number of a higher gear is
indicated, when upshifting is
recommended for fuel saving
reasons.Power steering
c illuminates yellow.
Illuminates with power steering disabled
Failure in the power steering system.
Consult a workshop.
Illumination of c and b
simultaneously
Seek the assistance of a workshop.
Lane departure warning
) illuminates green or flashes yellow.
Illuminates green
System is switched on and ready to
operate.
Flashes yellow
System recognises an unintended
lane change.
Lane departure warning 3 121.
Parking assist
r illuminates yellow.Fault in system
or
Fault due to sensors that are dirty or
covered by ice or snow
or
Interference due to external sources
of ultrasound. Once the source of
interference is removed, the system
will operate normally.
Have the cause of the fault in the
system remedied by a workshop.
Parking assist 3 119.
Electronic Stability Control
off
t illuminates yellow.
The system is deactivated.
Electronic Stability Control 3 115.
Electronic Stability Control
and Traction Control system
b flashes or illuminates yellow.

Instruments and controls73Flashes
The system is actively engaged.
Engine output may be reduced and
the vehicle may be braked
automatically to a small degree.
Illuminates
A fault in the system is present. A
warning code appears in the Driver
Information Centre. Continued driving is possible. The system is not
operational. Driving stability,
however, may deteriorate depending on road surface conditions.
Have the cause of the fault remedied
by a workshop.
Electronic Stability Control 3 115.
Traction Control system 3 114.
Traction Control system off
k illuminates yellow.
The system is deactivated.
Traction Control system 3 114.
Engine coolant temperature
W illuminates red.Illuminates when the engine is
running
Stop, switch off engine.Caution
Coolant temperature too high.
Check coolant level 3 130.
If there is sufficient coolant, consult a workshop.
Tyre pressure monitoring system
w illuminates or flashes yellow.
Illuminates
Tyre pressure loss. Stop immediately
and check tyre pressure.
Flashes
Fault in system or tyre without
pressure sensor mounted ( e.g. spare
wheel). After 60-90 seconds the
control indicator illuminates
continuously. Consult a workshop.
Tyre pressure monitoring system
3 147.
Engine oil pressure
I illuminates red.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
runningCaution
Engine lubrication may be
interrupted. This may result in
damage to the engine and/or
locking of the drive wheels.
1. Depress the clutch.
2. Set selector lever to neutral.
3. Move out of the flow of traffic as quickly as possible without
impeding other vehicles.
4. Switch off the ignition.

104Driving and operatingDriving and
operatingDriving hints ............................... 104
Control of the vehicle ...............104
Steering ................................... 105
Starting and operating ...............105
New vehicle running-in ............105
Ignition switch positions ...........105
Retained power off ..................106
Starting the engine ..................107
Overrun cut-off ........................ 107
Stop-start system ....................107
Parking .................................... 109
Engine exhaust .......................... 110
Catalytic converter ...................110
Manual transmission ..................111
Brakes ........................................ 112
Antilock brake system .............112
Parking brake .......................... 113
Brake assist ............................. 113
Hill start assist ......................... 113
Ride control systems .................114
Traction Control system ..........114
Electronic Stability Control ......115
City mode ................................ 115Driver assistance systems .........117
Cruise control .......................... 117
Speed limiter ........................... 118
Parking assist .......................... 119
Lane departure warning ..........121
Fuel ............................................ 122
Fuel for petrol engines .............122
Refuelling ................................ 123Driving hints
Control of the vehicle Never coast with engine not
running
Many systems will not function in this
situation (e.g. brake servo unit, power steering). Driving in this manner is a
danger to yourself and others.
All systems function during an
Autostop.
Stop-start system 3 107.
Idle boost
If charging of the vehicle battery is
required due to battery condition, the
power output of the generator must
be increased. This will be achieved by an idle boost which may be audible.
A message appears in the Driver
Information Centre.
Pedals
To ensure the pedal travel is
uninhibited, there must be no mats in
the area of the pedals.

114Driving and operatingRide control systems
Traction Control system
The Traction Control system (TC) is a component of the Electronic Stability
Control (ESC).
TC improves driving stability when
necessary, regardless of the type of
road surface or tyre grip, by
preventing the drive wheels from
spinning.
As soon as the drive wheels start to
spin, engine output is reduced and
the wheel spinning the most is braked
individually. This considerably
improves the driving stability of the
vehicle on slippery road surfaces.
TC is operational after each engine
start as soon as the control indicator
b extinguishes.
When TC operates b flashes.
9 Warning
Do not let this special safety
feature tempt you into taking risks
when driving.
Adapt speed to the road
conditions.
Deactivation
TC can be switched off when spinning of drive wheels is required: press t
briefly.
Control indicator k illuminates.
When TC is deactivated, ESC
remains active.
TC is reactivated by pressing t again.
TC is also reactivated the next time
the ignition is switched on.
Fault
If there is a fault in the system the
control indicator b illuminates
continuously and a warning code
appears in the Driver Information
Centre. The system is not
operational.
Have the cause of the fault remedied by a workshop.
