2019 OPEL COMBO E warning light

In brief111Electric child locks ................. 29
Unlocking tailgate .................33
Child safety system for
rear windows ......................... 41
2 Power windows .....................41
3 Exterior mirrors .....................38
4 Side air vents ...................... 140
5 Cruise control .....................169
Speed limiter ....................... 171
Adaptive cruise control .......169
6 Turn lights ........................... 125
Headlight flash ....................124
High beam ........................... 123
High beam assist ...............123
Exit lighting ......................... 129
Parking lights ...................... 127
Buttons for Driver
Information Centre ..............112
7 Instruments ........................ 100
Driver Information Centre .... 112
8 Infotainment controls9Head-up display ..................116
10 Windscreen wiper and
washer, rear wiper and
washer ................................. 91
11 Centre air vents .................. 140
12 Info Display ........................ 114
13 Hazard warning flashers ....125
Central locking system ..........25
14 Anti-theft alarm system
status LED ........................... 35
15 USB charging port ................ 95
16 Storage ................................. 71
17 Glovebox .............................. 71
18 Climate control system ........ 132
19 Electronic Stability Control
and Traction Control ...........164
Eco mode ............................ 159
Descent control system ....... 165
20 Selective ride control ..........167
21 Inductive charging .................96
22 Manual transmission ..........159
Automatic transmission ......156
23 Power outlet .......................... 9524Electric parking brake .........161
25 Power button ....................... 145
26 Ignition switch .....................144
27 Steering wheel adjustment ..90
28 Horn ..................................... 91
29 Parking assist / Advanced
parking assist .....................185
Electric child locks ................. 29
Eco button for stop-start
system ................................. 148
Lane keep assist .................198
Tyre deflation detection
system ................................. 231
Heated windscreen ...............43
Parking heater ....................139
30 Fuse box ............................ 227
31 Bonnet release lever ..........212
32 Head-up display ..................116
33 Light switch ........................ 122
Front / rear fog lights ..........126
Instrument illumination .......127

22Keys, doors and windowsKey with foldaway key section
Press button to extend. To fold the
key, first press the button.
Radio remote controlDepending on the version, the radio
remote control enables a operation of
the following functions:
● central locking system 3 25
● anti-theft locking system 3 35
● anti-theft alarm system 3 35
● tailgate unlocking 3 25
● power windows 3 41
● mirrors folding 3 39
● vehicle locator lighting 3 130
● peripheral lighting 3 130
The remote control has a range of up
to several metres, but may also be
much less due to external influences. The hazard warning flashers confirm
operation.
Handle with care, protect from
moisture and high temperatures and
avoid unnecessary operation.
Replacing battery in radio remote
control
Replace the battery as soon as the
range reduces.

Keys, doors and windows29Automatic relock after unlockingThis feature automatically locks all
doors, load compartment and fuel
filler flap a short time after unlocking
with the remote control or electronic
key, provided no door has been
opened.
Child locks9 Warning
Use the child locks whenever
children are occupying the rear
seats.
Mechanical child locks
Turn the red child lock in the rear door clockwise as far as it will go by using
a key. The door cannot be opened
from the inside.
To deactivate, turn the child lock to
the horizontal position.
Electric child locks
Depending on version, the R button
may be located in the driver's door or
below the light switch.

32Keys, doors and windows9Warning
The rear lights may be obscured if
the rear doors are open and the
vehicle is parked on the roadside.
Make other road users aware of the vehicle, by using a warning
triangle or other equipment
specified in the road traffic
regulations.
The doors are retained in the 90º
position by locking stays. To open the
doors to 180º, push the latch and
swing open to the desired position.
Before closing the doors fix the
locking stays to the 90º position.
9 Warning
Ensure extended opening doors
are secured when fully opened.
Opened doors may slam closed due to the force of the wind!
Always close the right hand doorbefore the left hand door.
Central locking system 3 25.
Driving with an open load
compartment
In exceptional cases only, it is
possible to drive with the right-hand rear door open, e.g. if long objects
need to be transported. Open the left- hand followed by the right-hand rear
door, then close the left-hand rear door and lock it.9 Danger
Engine exhaust gases contain
poisonous carbon monoxide,
which is colourless and odourless and could be fatal if inhaled.
When driving with an open load
compartment, exhaust gases
could enter the vehicle. Open the
windows.
Note
Do not use the left-hand rear door to
hold objects in place.
If possible, secure objects with
lashing straps attached to lashing
eyes 3 80.

Keys, doors and windows37
Electronic key system: Unlocking the
vehicle by pressing on one of the front
door handles at the markings
deactivates the anti-theft alarm
system.
The electronic key must be outside
the vehicle, within a range of approx. one metre of the relevant door side.
The system is not deactivated by
unlocking the driver's door with the
key or with the central locking button
in the passenger compartment.
Note
If the vehicle is unlocked and no door is opened, the vehicle is
automatically relocked after 30
seconds. In this case, the anti-theft
alarm will be reactivated, too.
Alarm
When triggered, the alarm horn
sounds and the hazard warning lights flash simultaneously. The number
and duration of alarm signals are
stipulated by legislation.
The anti-theft alarm system can be
deactivated by pressing c, by
pressing on one of the front door
handles at the markings with
electronic key system. The LED of the
U button will extinguish and the turn
lights flash for a short time.
A triggered alarm, which has not been interrupted by the driver, will be
indicated by the rapid flashing of the
LED of the U button. If the ignition is
switched on, the flashing stops
immediately
If the vehicle's battery is to be
disconnected (e.g. for maintenance
work), the alarm siren must bedeactivated as follows: switch the
ignition on then off, then disconnect
the vehicle's battery within 15 s.
Locking the vehicle without
activation of the anti-theft alarm
Lock the vehicle by inserting and
turning the integrated key of the
remote control or the electronic key
system in the lock cylinder of the
driver's door.
Malfunction of the remote control
Unlock the vehicle by inserting and
turning the integrated key of the
remote control or the electronic key
system in the lock cylinder of the
driver's door.
Open the driver's door.
The horn of the anti-theft alarm will
sound.
Switch on ignition.
The horn will stop sounding and the
status LED extinguishes.

Seats, restraints47Head restraints on rear seats
Height adjustment
Pull the head restraint upwards or
push it downwards.
Removal
Press catch, pull the respective head
restraint upwards and remove.
Front seats
Seat position9 Warning
Only drive with the seat correctly
adjusted.
9 Warning
Never adjust seats while driving as
they could move uncontrollably.
9 Danger
Do not sit closer than 25 cm to the
steering wheel, to permit safe
airbag deployment.
9 Warning
Never store any objects under the
seats.
● Sit with buttocks as far back against the backrest as possible.
Adjust the distance between the
seat and the pedals so that legs
are slightly angled when pressing the pedals. Slide the front
passenger seat as far back as
possible.
● Set seat height high enough to have a clear field of vision on allsides and of all display
instruments. There should be at
least one hand of clearance
between head and the roof
frame. Your thighs should rest
lightly on the seat without
pressing into it.

Seats, restraints63The side airbag system consists of an
airbag in each front seat backrest.
This can be identified by the word
AIRBAG .
The side airbag system is triggered in
the event of a side impact of a certain severity. The ignition must be
switched on.
The inflated airbags cushion the
impact, thereby reducing the risk of
injury to the upper body and pelvis in
the event of a side-on collision
considerably.
9 Warning
Keep the area in which the airbag
inflates clear of obstructions.
Note
Only use protective seat covers that have been approved for the vehicle.Be careful not to cover the airbags.
Curtain airbag system
The curtain airbag system consists of an airbag in the roof frame on each
side. This can be identified by the
word AIRBAG on the roof pillars.
The curtain airbag system is triggered
in the event of a side-on impact of a
certain severity. The ignition must be
switched on.
The inflated airbags cushion the
impact, thereby reducing the risk of
injury to the head in the event of a
side-on impact considerably.
9 Warning
Keep the area in which the airbag
inflates clear of obstructions.
The hooks on the handles in the
roof frame are only suitable for
hanging up light articles of
clothing, without coat hangers. Do not keep any items in these
clothes.

Storage73
A storage compartment is located
above the Instrument cluster.
A coin holder is located on the
instrument panel.
Folding the centre seatback
The front centre passenger seat
backrest has a document tray.
Seat folding 3 49.
9 Warning
When the front centre passenger
seat is in the folded position, the front passenger airbag system
must be deactivated.
Airbag deactivation 3 64.
Overhead console
Store only lightweight items such as
paperwork or maps in the overhead
console.
