3-20
Pre-driving checksandadjustments
GUID-17F A495C-3D75-4AC6- BDA1-CF035 C5BC711
Y our vehicle haseither orboth ofthe following security
systems:
. Theft warning
. NISSAN Anti-theft System(NATS)*
The security condition willbeshown bythe security
indicator light.
(* immobilizer)
THEFT WARNING SYSTEM (ifequipped)
GUID-76 C0FFDE-576D -4F0F-954F-F551549C6BCD
The theft warning systemprovides visualandaudio
alarm signals ifparts ofthe vehicle aredisturbed.
Security indicator light
GUID-4DC D2AF1-FA12-44F6 -BC69-8E08 33CCECA6
SIC2045
The security indicator light,located onthe meter panel,
operates whenever theignition switchisin the ªLOCKº
or ªOFFº position. Thisisnormal.
For models withultrasonic sensor
GUID-607 4FDDD-A03 E-4D79-AE83- 4F6D45B64020
How toactivate system:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
1. Close allwindows andsunroof (ifequipped) .
2. Place theignition switchinthe ªOFFº position.
3. Carry theremote controller orthe Intelligent Key
with youand getoutofthe vehicle.
4. Make surethehood andtheback doorareclosed.
Close andlock alldoors withtheremote
controller, theIntelligent Key orthe request switch.
If a door orthe hood isopen, thebuzzer will
sound. Thebuzzer willstop when thedoor is
correctly closed.
5. Confirm thatthesecurity indicator lightcomes on.
The security indicator lightblinks rapidly for
approximately 20seconds andthen blinks slowly.
The system isnow activated. If,during this20-
second timeperiod, thedoor isunlocked bythe
remote controller, theIntelligent Key orthe request
switch, orthe ignition switchisplaced inthe ªONº
position, thesystem willnot activate.
Even when thedriver and/or passengers arein
the vehicle, thesystem willactivate withall
doors locked andtheignition switchoff.Place
the ignition switchinthe ªONº position toturn
the system off.
If the system malfunctions, theshort beep
sounds 5times whenthesystem isactivated.
Have thesystem checked byaNISSAN dealer.
Theft warning systemoperation:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The warning systemwillgive thefollowing alarm:
. The hazard indicator blinksandthealarm sounds
intermittently forapproximately 30seconds. (The
alarm willrepeat 8times.) .
The alarm automatically turnsoffafter approxi-
mately 30seconds. However, thealarm reacti-
vates ifthe vehicle istampered withagain.
The alarm isactivated when:
. operating thedoor orthe back doorwithout using
the remote controller, theIntelligent Key orthe
request switch.
. opening thehood (ifequipped) .
. thevolumetric sensingsystem(ultrasonic sensors)
is triggered (whenitis activated) .
. thepower supply isdisconnected.
How tostop alarm:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
. The alarm willstop byunlocking adoor withthe
request switch(ifequipped) orthe ªUNL OCKº
button onthe Intelligent Key .
. The alarm willstop ifthe ignition switchisplaced
in the ªONº position.
Cancel switchforultrasonic sensor:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94A EAE0
JVP0311X
The ultrasonic sensors
*
A
(volumetric sensing),
located onthe ceiling, detectmovement inthe
passenger's compartment. Whenthetheft warning
system isset tothe armed position, itwill automatically
SECURITY SY STEM
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
switch onthe ultrasonic sensor.
It is possible toexclude theultrasonic (forexample,
when leaving petsinside thecar ortransporting the
vehicle onaferry) .
T o exclude theultrasonic:
1. Close allthe windows.
2. Place theignition switchinthe ªOFFº position.
3. Push thecancel switch
*
B
located onthe ceiling.
The security indicator lightwillstart flashing
rapidly .
4. Close thedoors, hoodandback door. Lockthem
using theremote controller, theIntelligent Key or
the request switch.Thesecurity indicator lightwill
start flashing fasterandabuzzer willsound once.
The ultrasonic sensorisnow excluded fromthetheft
warning system.Allother functions ofthe system
remain activated untilthetheft warning systemis
disarmed again.
For models without ultrasonic sensor
GUID-F6 883F2C-1 8CE-4385-9B AC-D9C25E45F1E2
How toactivate system:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
1. Close allwindows andsunroof (ifequipped) .
The system canbearmed evenifthe
windows areopen.
2. Place theignition switchinthe ªOFFº position.
3. Remove remotecontroller orthe Intelligent Key
from thevehicle.
4. Close alldoors, hoodandback door. Lockall
doors. Thedoors canbelocked withremote
controller orthe Intelligent Key ,door handle
request switch,powerdoorlockswitch or
mechanical key. 5.
Confirm thatthesecurity indicator lightcomes on.
The security indicator lightstays onfor about 30
seconds. Thevehicle security systemisnow pre-
armed. Afterabout 30seconds thevehicle
security systemautomatically shiftsintothearmed
phase. Thesecurity lightbegins toflash once
every approximately 3seconds. If,during this30
seconds pre-armtimeperiod, thedoor isun-
locked, orthe ignition switchisplaced inªONº ,
the system willnot alarm.
Even when thedriver and/or passengers arein
the vehicle, thesystem willactivate withall
doors, hood,andback doorlocked withthe
ignition switchinthe ªLOCKº position. When
placing theignition switchinthe ªONº position,
the system willbereleased.
Theft warning systemoperation:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The vehicle security systemwillgive thefollowing
alarm:
. The hazard indicator orheadlight blinksandthe
horn sounds intermittently .
. The alarm automatically turnsoffafter approxi-
mately 30or50 seconds. However, thealarm
reactivates ifthe vehicle istampered withagain.
The alarm isactivated by:
. Unlocking thedoor oropening theback door
without usingthebutton onthe remote controller
or the Intelligent Key ,the door handle request
switch orthe mechanical key.(Even ifthe door is
opened byreleasing thedoor inside lockknob, the
alarm willactivate.)
. Opening thehood. How
tostop alarm:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
. The alarm willstop onlybyunlocking adoor by
pushing theªUNL OCKº button onthe remote
controller orthe Intelligent Key .
. The alarm willnotstop ifthe ignition switchis
placed inthe ªONº position.
NISSAN ANTI-THEFT SYSTEM (NATS)
GUID-5E4 37D07-076 E-4181-8CCF -57AFFB80C485
The NISSAN Anti-Theft System (NATS) willnotallow
the engine tostart without theuse ofthe registered
NA TS key.
If the engine doesnotstart using theregistered NATS
key ,it may bedue tointerference causedby:
. Another NATS key.
. Automated tollroad device.
. Automated paymentdevice.
. Other devices thattransmit similarsignals.
Start theengine usingthefollowing procedure:
1. Remove anyitems thatmay becausing the
interference awayfromtheNATS key.
2. Leave theignition switchinthe ªONº position for
approximately 5seconds.
3. Place theignition switchinthe ªOFFº orªLOCKº
position, andwait approximately 10seconds.
4. Repeat steps2and 3again.
5. Start theengine.
6. Repeat thesteps above untilallpossible inter-
ferences areeliminated.
If this procedure allowstheengine tostart, NISSAN
recommends placingtheregistered NATS key sepa-
rate from other devices toavoid interference.
Pre-driving checksandadjustments
3-21
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
OUTSIDE REARVIEW MIRRORS
T32A1308 27-88B732CC-4E0A-4 76C-92A7-0FBBBF5742 F3
WARNING:
. Never touchtheoutside rearview mirrors
while theyareinmotion. Doingsomay pinch
your fingers ordamage themirror.
. Never drivethevehicle withtheoutside
rearview mirrorsfolded.Thisreduces rear
view visibility andmay lead toan accident.
. Objects viewedinthe outside mirrorare
closer thantheyappear (ifequipped) .
. The picture dimensions anddistance inthe
outside mirrorsarenot real.
Adjusting
T32A130 827-51BB26 16-3601-49CE-924F-BB8824381C9 8
JVP0133X
The outside rearview mirrorremote controloperates
when theignition switchisin the ªACCº orªONº
position.
1. Turn theswitch toselect theleftorright mirror
*
1
.
2. Adjust eachmirror bypushing theswitch untilthe
desired position isachieved
*
2
.
Defogging (ifequipped)
T32A130827- 1A2DB6DD-C 4B4-4897-A644-A2C6B1 82286A
The outside rearview mirrorswillbeheated whenthe
rear window defogger switchisoperated.
Folding
GUID-96BDC 7B9-7343-4A 0F-A3F9-0CF6EA2A1 DAF
Remote controltype:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94A EAE0
JVP0134X
The outside rearview mirrorremote controloperates
when theignition switchisin the ªACCº orªONº
position.
The outside rearview mirrorsautomatically foldwhen
the outside rearview mirrorfolding switchispushed in.
T o unfold, pushtothe switch again.
CAUTION:
Continuously performingthefold/unfold opera-
tion ofthe outside rearview mirrormaycause
the switch tostop theoperation. Manual
controltype:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94A EAE0
JVP0194X
Fold theoutside rearview mirrorbypushing ittoward
the rear ofthe vehicle.
V ANITY MIRROR
T32A130827-2 31ADF9C-8000-48A4-98 23-818818 E5CEE5
SP A1733
T o use thefront vanity mirror, pulldown thesun visor
and pullupthe cover.
Pre-driving checksandadjustments
3-29
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
T32A130827- 864D3105-3368-482B-83 DC-0BF9829189CD
When theshift lever isshifted intotheªRº (Reverse)
position, themonitor displayshowstheview tothe rear
of the vehicle.
The system isdesigned asan aid tothe driver in
detecting largestationary objectstohelp avoid
damaging thevehicle. Thesystem willnotdetect small
objects belowthebumper andmay notdetect objects
close tothe bumper oron the ground.
WARNING:
Failure tofollow thewarnings andinstructions
for proper useofthe RearView Monitorcould
result inserious injuryordeath.
. The RearView Monitorisaconvenience but
it is not asubstitute forproper backing.
Always turnandlook outthewindows, and
check mirrors tobe sure thatitis safe to
move before operating thevehicle. Always
back upslowly.
. The system isdesigned asan aid tothe
driver inshowing largestationary objects
directly behindthevehicle, tohelp avoid
damaging thevehicle.
. The system cannotcompletely eliminate
blind spots andmay notshow every object.
. Underneath thebumper andthecorner
areas ofthe bumper cannotbeviewed on
the RearView Monitorbecause ofits mon-
itoring rangelimitation. Thesystem willnot
show small objects belowthebumper, and
may notshow objects closetothe bumper or
on the ground.
. Objects viewedinthe RearView Monitor
differ fromactual distance becauseawide-
angle lensisused. .
Objects inthe RearView Monitorwillappear
visually opposite thanwhen viewed inthe
rear view andoutside mirrors.
. Make surethattheback doorissecurely
closed whenbacking up.
. Donot putanything onthe rearview camera.
. When washing thevehicle withhigh pres-
sure water, besure nottospray itaround the
camera. Otherwise, watermayenter the
camera unitcausing watercondensation on
the lens, amalfunction, fireoran electric
shock.
. Donot strike thecamera. Itis aprecision
instrument. Otherwise,itmay malfunction or
cause damage resulting inafire oran
electric shock.
CAUTION:
Do not scratch thecamera lenswhen cleaning
dirt orsnow fromthelens.
HOW TO READ DISPLA YEDLINES
GUID-F7 84552C-A F4F-44B5-A7 9F-3127745 C344B
SAA2776
Guiding lineswhich indicate thevehicle widthand distances
toobjects withreference tothe bumper line
*
A
are displayed onthe monitor.
Distance guidelines:
Indicate distances fromthebumper.
. Red line
*
1
: approx. 0.5m(1.5 ft)
. Yellow line
*
2
: approx. 1m (3 ft)
. Green line
*
3
: approx. 2m (7 ft)
. Green line
*
4
: approx. 3m (10 ft)
V ehicle widthguide lines
*
5
:
Indicate thevehicle widthwhenbacking up.
Display screen,heaterandairconditione r,and audio system
4-7
REARVIEW
MONITOR(ifequippe d)
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
4-10
Display screen,heaterandaircondition er,and audio system
OPERA TINGTIPS
T32A1308 27-4F7D57D D-7549-4CCF -8296-1AB785FE95AF
. When theshift lever isshifted tothe ªRº (Reverse)
position, themonitor screenautomatically
changes tothe RearView Monitormode.
. When theview isswitched, thedisplay images on
the screen maybedisplayed withsome delay.
. When thetemperature isextremely highorlow ,
the screen maynotclearly display objects. Thisis
not amalfunction.
. When strong lightisdirectly coming onthe
camera, objectsmaynotbedisplayed clearly.
This isnot amalfunction.
. Vertical linesmaybeseen inobjects onthe
screen. Thisisdue tostrong reflected lightfrom
the bumper. Thisisnot amalfunction.
. Thescreen mayflicker underfluorescent light.This
is not amalfunction.
. The colors ofobjects onthe RearView Monitor
may differ somewhat fromtheactual colorof
objects. Thisisnot amalfunction.
. Objects onthe monitor maynotbeclear inadark
environment. Thisisnot amalfunction.
. Ifdirt, rainorsnow accumulates onthe camera,
the RearView Monitormaynotdisplay object
clearly .Clean thecamera.
. Donot use alcohol, benzine, orthinner toclean the
camera. Thiswillcause discoloration. To clean the
camera, wipewithacloth dampened withdiluted
mild cleaning agentandthen wipe withadry cloth.
. Donot damage thecamera asthe monitor screen
may beadversely affected.
. Donot use wax onthe camera window.Wipe off
any wax with aclean clothdampened withmild
detergent dilutedwithwater.
T32A1308 27-ECEC19 D2-1058-4FF 9-9BB2-B72671D2617 C
JVH0658X
Models withnavigation system
JVH0648X
Models without navigation system
With theignition switchinthe ON position, pushthe
CAMERA button(models withnavigation system)/
DISP button (models withoutnavigation system)or
move theshift lever tothe ªRº (Reverse) positionto
operate theAround ViewMonitor. Themonitor displays
various viewsofthe position ofthe vehicle.
Available views:
. Bird's-eye View
The surrounding viewofthe vehicle.
. Front-side View
The view around andahead ofthe front passen-
ger's sidewheel. .
Front View
The view tothe front ofthe vehicle.
. Rear View
The view tothe rear ofthe vehicle.
The system isdesigned asan aid tothe driver in
situations suchasslot parking orparallel parking.
JVH0730X
There aresome areaswhere thesystem willnot display
objects. Wheninthe front orthe rear view display ,an
object belowthebumper oron the ground maynotbe
displayed
*
1
. When inthe bird's-eye view,a tall
object neartheseam ofthe camera detecting areas
will notappear inthe monitor
*
2
.
AROUND VIEWMONIT OR(if
equipped)
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
WARNING:
. The Around ViewMonitor isaconvenient
feature butitis not asubstitute forproper
vehicle operation becauseithas areas
where objects cannotbeviewed. Always
look outthewindows andcheck mirrors to
be sure thatitis safe tomove.
. The driver isalways responsible forsafety
during parking andother maneuvers.
. Donot use theAround ViewMonitor with
the outside mirrorinthe stored position, and
make surethattheback doorissecurely
closed whenoperating thevehicle usingthe
Around ViewMonitor.
. The distance between objectsviewedonthe
Around ViewMonitor differsfromtheactual
distance.
. The cameras areinstalled abovethefront
grille, theoutside mirrorsandabove therear
license plate.Donot putanything onthe
cameras.
. When washing thevehicle withhigh-pres-
sure water, besure nottospray itaround the
cameras. Otherwise, watermayenter the
camera unitcausing watercondensation on
the lens, amalfunction, fireoran electric
shock.
. Donot strike thecameras. Theyarepreci-
sion instruments. Doingsocould cause a
malfunction orcause damage resulting ina
fire oran electric shock.
CAUTION:
Clean thecamera lenswith softcloth tokeep it
free from dirt,snow, etc.Do not scratch thelens
when cleaning.
A VAILABLE VIEWS
T32A1308 27-19D269 B1-F21D-499 3-921A-1CA8E91509E 0
WARNING:
. The distance guidelineand thevehicle width
line should beused asareference only
when thevehicle ison apaved, levelsurface.
The distance viewedonthe monitor isfor
reference onlyandmay bedifferent thanthe
actual distance between thevehicle and
displayed objects.
. Use thedisplayed linesandthebird's-eye
view asareference. Thelines andthebird's-
eye view aregreatly affected bythe number
of occupants, fuellevel, vehicle position,
road condition androad grade.
. Ifthe tires arereplaced withdifferent sized
tires, thepredictive courselineand the
bird's-eye viewmaybedisplayed incorrectly.
. When driving thevehicle upahill, objects
viewed inthe monitor arefurther thanthey
appear. Whendriving thevehicle downahill,
objects viewedinthe monitor arecloser
than theyappear.
. Use themirrors oractually looktoproperly
judge distances toother objects.
. The vehicle widthandpredictive courselines
are wider thantheactual widthandcourse.
Front andrear view
T32A130 827-6CBBA5 72-C313-4A5 3-8D27-D42ADCCA771 1
SAA1840
Front view
SAA1896
Rear view
Guiding lines,which indicate thevehicle widthand
distances toobjects withreference tothe vehicle body
line
*
A
, are displayed onthe monitor.
Distance guidelines:
Indicate distances fromthevehicle body.
. Red line
*
1
: approx. 0.5m(1.5 ft)
. Yellow line
*
2
: approx.1 m(3 ft)
. Green line
*
3
: approx. 2m (7 ft)
. Green line
*
4
: approx. 3m (10 ft)
Display screen,heaterandairconditioner ,and audio system
4-11
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
screen fromtheAround ViewMonitor screenwhen:
. The shift lever isin the ªDº (Drive) position (CVT
model) orthe shift lever isout ofthe ªRº (Reverse)
position (MTmodel) ,and thevehicle speed
increases aboveapproximately 10km/h (6MPH) .
. Adifferent screenisselected.
CAMERA AIDINGCORNER SENSOR
FUNCTION (ifequipped)
GUID-0AEEE3 77-4208-4A32-97B6-7 30A3A05647 0
When thecorner ofthe vehicle movesclosertothe
object whiletheAround ViewMonitor isdisplayed, an
indicator isdisplayed andatone issounded bythe
corner sensor function towarn thedriver.
The color ofthe corner sensor indicator andthe
pattern ofthe tone varyaccording tothe distance to
the object.
K eep thecorner sensors (located onthe front andrear
bumper fascia)freefrom snow,ice and large
accumulations ofdirt. Donot clean thesensors with
sharp objects. Ifthe sensors arecovered, theaccuracy
of the corner sensor function willbediminished.
The tone sound andthesensor indicator displaycan
be turn on/off, andthevolume ofthe tone sound and
the sensor detection rangecanbeadjusted. (See
ªDriver Assistanceº (P.2-21) .)
WARNING:
. The corner sensor function isnot designed
to prevent theobject.
. The colors ofthe corner sensor indicator and
the distance guidelinesinthe front/rear
view indicate different distances tothe
object.
. Inclement weathermayaffect thefunction of
the corner sensor system; thismay include reduced
performance orafalse activation.
. This function isdesigned asan aid tothe
driver indetecting largestationary objectsto
help avoid damaging thevehicle. Thesystem
will notdetect smallobjects belowthe
bumper, andmay notdetect objects that
are too close tothe bumper oron the
ground.
. Ifyour vehicle sustains damagetothe
bumper fascia,leaving itmisaligned orbent,
the sensing zonemaybealtered causing
inaccurate measurement ofobstacles or
false alarms.
CAUTION:
Keep theinterior ofthe vehicle asquiet as
possible tohear thetone clearly.
MOVING OBJECTDETECTION (MOD)
FUNCTION (ifequipped)
GUID-6CAFFD 96-0FA6-42CB-8 531-35613FD16A94
The Moving ObjectDetection (MOD)system can
inform thedriver ofmoving objects whendriving outof
garages, maneuvering intoparking lotsand inother
such instances.
The MOD system detects movingobjects byusing
image processing technologyonthe image shown on
the display .The rear view camera isequipped withthe
automatic washerfunction usingwindow washerfluid.
The MOD system operates inthe following conditions
when thecamera viewisdisplayed:
. When theshift lever isin the ªPº (Park) orªNº
(Neutral) position(CVTmodel) orthe shift lever is
out ofthe ªRº (Reverse) position(MTmodel) and
the vehicle isstopped, theMOD system detects
the moving objects inthe bird's-eye view.The MOD
system willnotoperate ifthe outside mirror
is moving inor out orifeither doorisopened.
. When theshift lever isin the ªDº (Drive) position
(CVT model) orthe shift lever isout ofthe ªRº
(Reverse) position(MTmodel) ,and thevehicle
speed isbelow approximately 8km/h (5MPH) ,
the MOD system detects movingobjects inthe
front view.
. When theshift lever isin the ªRº (Reverse)
position andthevehicle speedisbelow approxi-
mately 8km/h (5MPH) ,the MOD system detects
moving objects inthe rear view.The MOD system
will notoperate ifthe back doorisopen.
The MOD system doesnotdetect moving objects in
the front-side view.The MOD iconisnot displayed on
the screen wheninthis view .
WARNING:
. The MOD system isnot asubstitute for
proper vehicle operation anddoes notpre-
vent contact withtheobjects surrounding
the vehicle. Whenmaneuvering, alwaysuse
the outside mirrorandinside rearview mirror
and turn andlook tocheck thesurroundings
to make sureitis safe tomaneuver.
. The system isdeactivated atspeeds above
10 km/h (6MPH) .It is reactivated atlower
speeds.
. The system isnot designed toprevent
contact withallobjects.
. The MOD system isnot designed todetect
surrounding stationaryobjects.
When theMOD system detects amoving object
surrounding thevehicle, theyellow framewillbe
displayed onthe view where theobjects aredetected
Display screen,heaterandairconditioner ,and audio system
4-15
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
4-16
Display screen,heaterandaircondition er,and audio system
and achime willsound once.While theMOD system
continues todetect moving objects, theyellow frame
continues tobe
displayed.
JVH0872X
bird's-eye view
JVH0873X
front view/rear view
In the bird's-eye view,the yellow frame
*
1
is
displayed oneach camera image(front,rear,right,
left) depending onwhere moving objects aredetected.
The yellow frame
*
2
is displayed onview inthe front
view orrear view modes.
While thesensor isbeeping, theMOD system does
not chime.
The MOD icon
*
3
is displayed inblue inthe view
where theMOD system isoperative. TheMOD icon
*
3
is displayed ingray inthe view where theMOD
system isnot operative.
If the MOD system isturned off,the MOD icon
*
3
is
not displayed.
The MOD system willactivate automatically underthe
following conditions:
. When theshift lever isin the ªRº (Reverse)
position.
. When theCAMERA/DISP buttonispushed to
switch fromadifferent screentothe camera view
on the display .
. When vehicle speeddecreases belowapproxi-
mately 8km/h (5MPH) .
. When theignition switchisplaced inthe ªOFFº
position andthen back tothe ªONº position.
The MOD system canbeset toremain inactive inthe
vehicle information display.(See ªDriver Assistanceº
(P .2-21) .)
WARNING:
. Excessive noise(forexample, audiosystem
volume oropen vehicle window) willinter-
fere with thechime sound, anditmay notbe
heard.
. The MOD system performance willbelim-
ited according toenvironmental conditions
and surrounding objectssuchas:
Ð When thereislow contrast between
background andthemoving objects.
Ð When thereisblinking sourceoflight.
Ð When strong lightsuch asanother
vehicle's headlight orsunlight ispre-
sent. Ð
When thereisdirt, water drops orsnow
on the camera lens.
Ð When theposition ofthe moving objects
in the display isnot changed.
. The MOD system mightdetect flowing water
droplets onthe camera lens,white smoke
from themuffler, movingshadows, etc.
. The MOD system maynotfunction properly
depending onthe speed, direction, distance
or shape ofthe moving objects.
. Ifyour vehicle sustains damagetothe parts
where thecamera isinstalled, leavingit
misaligned orbent, thesensing zonemaybe
altered andtheMOD system maynotdetect
objects properly.
. When thetemperature isextremely highor
low, thescreen maynotdisplay objects
clearly. Thisisnot amalfunction.
T urning theMOD system onoroff
GUID-A A5B2549-6C 8A-49E4-B44 8-E087C02404EF
The MOD system isturned onoroff using thevehicle
information display.See ªDriver Assistanceº (P.2-21) .
MOD malfunction
GUID-1ECC1 104-D4DE-4EF2-996D-E9161CFD D1F3
When theorange MODiconisdisplayed inthe view ,
the system isnot functioning properly.This willnot
hinder normal drivingoperation butthesystem should
be inspected byaNISSAN dealer.
&RQGLWLRQ
([FHSWIRU&KLQD
