2019 MERCEDES-BENZ E CLASS sensor

NOTEImpairment ofthe operating effi‐ciency oftherestraint systems frominstalling accessory parts or fromrepairsorwelding
Airbags and EmergencyTensioning Devices,aswell as control units and sensorsfortherestraint systems, may be installed inthefol‐lowing areas ofyourvehicle:
RDoors
RDoor pillars
RDoor sills
RSeats
RCockpit
RInstrument cluster
RCenter console
RLateralroof frame
Do not install accessory parts such asaudio systems inthese areas.
Do not carryoutrepairs orwelding.
Haveaftermarket installation of acces‐sories carried out at aqualified special‐istworkshop.
You could jeopardizethe operating safety ofyourvehicle ifyou use parts, tires and wheels aswellas accessoriesrelevanttosafety which havenotbeen approvedbyMercedes-Benz. Safety-rele‐vant systems, e.g.the brake system, may mal‐function. Only use Mercedes-Benz GenuinePartsor parts of equalquality.Only use tires, wheelsand accessoriesthat havebeen specificallyapprovedforyourvehicle model.
Mercedes-Benz GenuineParts are subjecttostrictquality control. Each part has been spe‐cially developed, manufactured or selectedforMercedes-Benzvehicles andfine-tunedforthem.Therefore, only Mercedes-Benz GenuinePartsshould be used.
Morethan 300,000 different Mercedes-BenzGenuineParts areavailablefor Mercedes-Benzmodels.
All authorized Mercedes-Benz Centers maintaina supply of Mercedes-Benz GenuinePartsfor
necessaryservice andrepairwork. In addition,strategically located parts delivery centers pro‐videforquick andreliable parts service.
Always specifythevehicle identification number(VIN) (→page417) when ordering Mercedes-Benz GenuineParts.
Operator's Manual
This Operator's Manual describes all models andallstandard and optional equipmentavailableforyourvehicle atthe time ofthis Operator's Man‐ual goingtopress. Country-specific differencesare possible. Notethatyourvehicle may not beequipped with allfeatures described. This is alsothe casefor systems and functionsrelevanttosafety.Therefore,the equipment onyourvehiclemay differ fromthat inthe descriptions and illus‐trations.
The original purchase agreementforyourvehiclecontains a list of all ofthe systems inyourvehi‐cle.
Shouldyou haveanyquestions concerningequipment and operation, please consult anauthorized Mercedes-Benz Center.
20General notes

technical information aboutthevehicle's operat‐ingstate, component loads, maintenancerequirements andtechnicalevents or malfunc‐tions.
Ingeneral,this information documentsthestateof a component part, a module, a system orthesurroundings such as:
Roperatingstatus of system components (e.g.fill levels, batterystatus, tire pressure)
Rstatus messages concerningthevehicle orits individual components (e.g. number ofwheelrevolutions/speed, longitudinal accel‐eration, lateral acceleration, display offas‐tened seat belts)
Rmalfunctions orfaults in important systemcomponents (e.g. lights, brakes)
Rinformation onevents leadingtovehicledamage
Rsystemreactions in special driving situations(e.g. airbag deployment, intervention ofsta‐bility control systems)
Rambient conditions (e.g.temperature,rainsensor)
In additiontoprovidingthe actual control unitfunction,this data assiststhe manufacturer indetecting andrectifying malfunctions and opti‐mizingvehicle functions. The majority ofthisdata istemporary and is only processed inthevehicle itself. Only a small portion ofthe data isstored intheevent or malfunction memory.
Whenyourvehicle is serviced,technical datafromthevehicle can beread outbyservice net‐workemployees (e.g.workshops, manufactur‐ers) orthird parties (e.g. breakdown services).Services includerepair services, maintenanceprocesses,warranty claims andquality assur‐ance measures,forexample. Theread out is per‐formed viathe legally prescribed portforthediagnostics connection inthevehicle. Therespective service network locations orthirdparties collect, process and usethe data. Theydocumenttechnicalstatuses ofthevehicle,assist infinding malfunctions and improvingquality and are transmittedtothe manufacturer,if necessary.Furthermore,the manufacturer issubjecttoproduct liability.Forthis,the manu‐facturerrequirestechnical datafromvehicles.
Fault memories inthevehicle can beresetby aservice outlet as part ofrepair or maintenancework.
Depending onthe selected equipment,you canimport data intothevehicle's comfort and info‐tainment functionsyourself.
This includes,forexample:
Rmultimedia data such as music,films or pho‐tosfor playbackin an integrated multimediasystem
Raddress book datafor use in connection withan integrated hands-free system or an inte‐grated navigation system
Rentered navigation destinations
Rdata aboutthe use of Internet services
This data can be saved locally inthevehicle or itis located on a device whichyou haveconnectedtothevehicle (e.g. smartphone, USBflash driveor MP3 player). Ifthis data isstored inthevehi‐cle,you can deleteit at any time. This data issenttothird parties only atyourrequest, partic‐ularlywhenyou use online services in accord‐ance withthe settingsthatyou haveselected.
General notes27

Restraint system functionality
Whenthe ignition is switched on, a self-test isperformed, during whichtheurestraint sys‐temwarning lamp lights up. It goes out no laterthan afew seconds afterthevehicle isstarted.The components oftherestraint system arethenfunctional.
Malfunctioningrestraint system
A malfunction has occurred intherestraint sys‐tem if:
Rtheurestraint systemwarning lamp doesnot light up whenthe ignition is switched on
Rtheurestraint systemwarning lamplights up continuously orrepeatedly during ajourney
\nWARNINGRisk of injuryorfatal injuryduetoa malfunction intherestraint sys‐tem
Iftherestraint system is malfunctioning,restraint system components may be trig‐
gered unintentionally or might not be trig‐gered at all intheevent of an accident. Thismay affectthe EmergencyTensioning Deviceor airbag,forexample.
Havetherestraint systemchecked andrepaired immediately at aqualified spe‐cialistworkshop.
Function oftherestraint system in an acci‐dent
Howtherestraint systemworks is determinedbythe severity ofthe impact detected andthe typeof accident anticipated:
RFrontal impact
RRear impact
RSide impact
RRollover
The activationthresholdsforthe components oftherestraint system are determined based ontheevaluation ofthe sensorvalues measured atvarious points inthevehicle. This process is pre-emptive in nature. The triggering/deployment of
the components oftherestraint system musttakeplace in good time atthestart ofthe colli‐sion.
Factors whichcan only be seen and measuredafter a collision has occurred do not play a deci‐siverole inthe deployment of an airbag.Nordotheyprovide an indication of airbag deployment.
Thevehicle may be deformed significantly with‐out an airbag being deployed. This isthe case ifonly parts which arerelatively easily deformedare affected andtherateofvehicle decelerationis not high. Conversely, an airbag may bedeployedeventhoughthevehicle suffersonlyminor deformation. Ifveryrigidvehicle partssuch as longitudinal members are hit,forexam‐ple,this mayresult in sufficiently high levels ofvehicle deceleration.
32Occupant safety

particularthe information on suitable placesfor installation.
RThere are no heavy, sharp-edged or fragileobjects inthe pockets ofyour clothing.Storesuch objects in a suitable place.
Limited protection from airbags
\nWARNINGRisk of injuryduetomodifi‐cationstothe airbag cover
Ifyou modifythe cover of an airbag or affixobjects such asstickerstoit,the airbag mayno longer function correctly.
Never modifythe cover of an airbag anddo not affix objectstoit.
The installation location of an airbag is identifiedbythe AIRBAGsymbol (→page 39).
\nWARNINGRisk of injuryor death duetothe use of unsuitable seat covers
Unsuitable seat coverscan obstruct or pre‐ventthe deployment of air bags integratedintothe seats.
Consequently,the air bags cannotprotectvehicle occupants astheyare designedtodo. In addition, operation ofthe automaticfront passenger air bag shutoff may berestricted.
You should onlyuse seat coversthathavebeen approvedforthe correspond‐ing seatsbyMercedes-Benz.
\nWARNINGRisk of injuryduetomalfunc‐tions ofthe sensors inthe door paneling
Sensorstocontrolthe airbags are located inthe doors. Modifications orworknot per‐formed correctlytothe doors or door panel‐ing, aswell as damaged doors, can leadtothe function ofthe sensors being impaired.The airbags mighttherefore not functionproperlyany more.
Consequently,the airbags cannotprotectvehicle occupants astheyare designedtodo.
Never modifythe doors or parts ofthedoors.
Always haveworkonthe doors or doorpaneling carried out at aqualified spe‐cialistworkshop.
\nWARNINGRisk of injuryduetodeployedairbag
A deployed airbag no longer has a protectivefunction and cannotprotect as intended intheevent of an accident.
Havethevehicletowedtoaqualifiedspecialistworkshop in ordertohavethedeployed airbagreplaced.
Havedeployed airbagsreplaced immediately.
Occupant safety41

Tounlockthevehicle:touchthe inner sur‐face ofthe door handle.
Tolockthevehicle:touch sensor surface1or2.
Convenience closing:touchrecessed sen‐sor surface2untilthe closing procedure iscomplete.
Further information on convenience closing(→page79).
Ifyou openthe trunk lid from outside it is auto‐matically unlocked.
Problems with KEYLESS-GO
ProblemPossible causes/consequences andPPSolutions
You can no longer lock or unlockthevehicle using KEYLESS-GO.Possible causes are:
RThe SmartKeyfunctions havebeen deactivated (→page 63).
RThe SmartKeybattery is discharged or nearly discharged.
RThere is interference from a powerfulradio signal source.
68Opening and closing

When makingthe kicking movement, make surethatyourfeetarefirmly onthe ground,other‐wiseyou could loseyour balance, e.g. on ice.
Requirements
RThe SmartKeyis behindthevehicle.
RStand at least12in (30 cm)awayfromthevehicle while performingthe kicking move‐ment.
RDo not come into contact withthe bumperwhile makingthe kicking movement.
RDo not carryoutthe kicking movementtooslowly.
RThe kicking movement must betowardsthevehicle and back again.
1Detectionrange ofthe sensors
If several consecutive kicking movements arenot successful,waitten seconds.
System limitations
The system may be impaired or may not functionif:
RSnow or dirt, e.g. fromroad salt, coversthesensor area.
RThe kicking movement is made using a pros‐thetic leg.
The trunk lid could be opened or closed uninten‐tionally, inthefollowing situations:
RA person's arms or legs are moving inthesensor detectionrange, e.g. when polishingthevehicle or picking up objects.
RObjects are moved or placed behindthevehi‐cle, e.g.tensioningstraps or luggage.
RClampingstraps,tarps orother coverings arepulledoverthe bumper.
RA protective mat with a lengthreachingoverthe trunk sill down intothe detectionrangeofthe sensors is used.
RThe protective mat is not secured correctly.
RWorkis being undertaken onthe trailer hitch,on trailers orrear bicycleracks.
Deactivate KEYLESS-GO (→page 63) or do notcarrythe SmartKeyaboutyour person in suchsituations.
Switching separate trunk locking on or off
Ifyou centrally unlockthevehicle while separatelocking is activated,the trunk willremain locked.
Opening and closing75

Cornering light
Cornering light function
The cornering light improvesthe illumination oftheroadwayover a wide angle inthe turningdirection, enabling better visibility on tightbends,forexample. It can be activated onlywhenthe low beam is switched on.
The function is active:
RAtspeeds below 25mph (40 km/h) whenthe turn signal light is switched on orthesteering wheel is turned
RAtspeeds between 25mph (40 km/h) and45mph (70 km/h) whenthesteering wheelis turned
Traffic circle and intersection function:thecornering light is activated on bothsidesthroughanevaluation ofthe current GPS position ofthevehicle. Itremains active until afterthevehiclehas leftthe traffic circle orthe intersection.
Adaptive Highbeam Assist
Adaptive Highbeam Assist function
\nWARNINGRisk of accident despiteAdaptive Highbeam Assist
Adaptive Highbeam Assist does notrecog‐nizethefollowingroad users:
RRoad users without lights, e.g. pedes‐trians
RRoad users with poor lighting, e.g.cyclists
RRoad users whose lighting is obstructed,e.g.bya barrier
Onveryrareoccasions,Adaptive HighbeamAssist mayfailtorecognizeotherroad userswiththeirown lighting, or mayrecognizethemtoo late.
Inthese or similar situations,the automatichigh beam is not deactivated or is activateddespitethe presence ofotherroad users.
Always observethe traffic carefully andswitch offthe high beam in good time.
Adaptive Highbeam Assist cannottakeintoaccountroad,weather or traffic conditions.
Detection may berestricted inthefollowingcases:
Rin poor visibility,e.g.fog, heavyrain or snow
Rifthere is dirt onthe sensors orthe sensorsare obscured
Adaptive Highbeam Assist is onlyan aid.You areresponsiblefor adjustingthevehicle's lightingtothe prevailing light, visibility and traffic condi‐tions.
12 0Light and visibility

TheAdaptive Highbeam Assist automaticallyswitches betweenthefollowing types of light:
RLow-beam headlamps
RHigh beam
Atspeeds above19mph (30 km/h):
RIf nootherroad users are detected,the highbeam will be switched on automatically.
The high beam switches off automatically inthefollowing cases:
RAtspeeds below16mph (25 km/h).
RIfotherroad users are detected.
RIfstreetlighting is sufficient.
Atspeeds aboveapproximately31mph(50 km/h):
RThe headlamprange ofthe low beam isregu‐lated automatically based onthe distancetootherroad users.
The system's optical sensor is located behindthe windshield neartheoverhead control panel.
SwitchingAdaptive Highbeam Assist on/offToswitch on:turnthe light switchtotheXposition.
Switch onthe high beam usingthe combina‐tion switch.Whenthe high beam is switched on automat‐ically inthe dark,the
