2019 MAZDA MODEL CX-5 SKYACTIV-D display

▼Warning/Indicator Lights
Instrument Cluster varies depending on model and specifications.
Instrument Cluster
Center of Dashboard
Warning lights will appear in any of the highlighted areas
▼Warning Indication/Warning Lights
These lights turn on or flash to notify the user of the system operation status or a system
malfunction.
Signal
Warning Page
Brake System Warning Indication/Warning Light*1*27-25
ABS Warning Light*1
Electronic Brake
Force Distribu- tion SystemWa r n i n g 7-25
ABS warning 7-27
Charging System Warning Indication/Warning Light*17-25
Engine Oil Warning Light*17-25
(Red) High Engine Coolant Temperature Warning Light
*17-25
Power Steering Malfun
ction Indication 7-25
When Driving
Instrument Cluster and Display
4-40
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

SignalWarning Page
Master Warning Indication/Warning Light 7-27
Electric Parking Brake (EPB) Warning Indication/Warning Light*17-27
Check Engine Light*17-27
*Selective Catalytic Reduction (SCR) system Warning Indication/Warning
Light*17-27
Automatic Transaxle Warning Indication 7-27
*AWD Warning Indication7-27
Air Bag/Front Seat Belt Preten
sioner System Warning Light*17-27
*Tire Pressure Monitoring System Warning Light*1
Flashing
7-27
Turns on 7-34
(Amber/White) KEY Warning Indication Amber
7-27
White 7-34
(Amber)
*High Beam Control System (HBC) Warning Indication/Warning Light*17-27
*Blind Spot Monitoring (BSM) Warning Indication 7-27
(Amber)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
& Go function) Warning Indication 7-27
*Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) Warning Indication 7-27
LED Headlight Warning Light*17-27
*Smart Brake Support/Smart City Brake Support (SBS/SCBS) Warning In-
dication 7-34
Low Fuel Warnin
g Indication 7-34
Check Fuel Cap Warning Indication/Warning Light*17-34
When Driving
Instrument Cluster and Display
*Some models.4-41
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

SignalWarning Page
Engine Oil Level Warning Light*17-34
Seat Belt Warning Light (Front seat) 7-34
(Red)Seat Belt Warning Light (Rear seat) 7-34
*Low Washer Fluid Level Warning Indication
7-34
Door-Ajar Warning Indication
7-34
Liftgate-Ajar Warning Indication 7-34
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
▼ Indication/Indicator Lights
These lights turn on or flash to notify the user of the system operation status or a system
malfunction.
Signal
Indicator Page
(Green)Seat Belt Indicator Light (Rear seat) 2-72
*Front Passenger Air Bag Deactivation Indicator Light*12-72
Security Indicator Light*13-47
Wrench Indication
4-45
(Blue)Low Engine Coolant Temperature Indicator Light 4-45
*Glow Indicator Light*14-45
When Driving
Instrument Cluster and Display
4-42*Some models.
CX-5_8HH4-EA-19A_Edition1
2018-11-21 10:03:20

SignalIndicator Page
*Diesel Particulate Filter Indication 4-225
Shift Position Indication
4-66
Lights-On Indication/Indicator Light 4-73
Headlight High-Beam Indicator LightHeadlight
High-Low Beam 4-76
Flashing the Headlights 4-76
Turn Signal/Hazard Warning Indicator Lights Turn and
Lane-Change Signals4-79
Hazard Warning Flasher4-86
AUTOHOLD Active Indicator Light*14-102
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
& Go function) indicator Light 4-154
TCS/DSC Indicator Light*1
Traction Control
System (TCS) 4-107
Dynamic Stabil- ity Control(DSC)4-109
Turns on 7-27
TCS OFF Indicator Light*14-108
Select Mode Indication 4-114
(Green)
*High Beam Control System (HBC) Indicator Light4-123
*Blind Spot Monitoring (BSM) OFF Indicator Light*1
Malfunction
7-27
Except malfunc- tion
4-129
When Driving
Instrument Cluster and Display
*Some models.4-43
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

SignalIndicator Page
(White)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
& Go function) Main Indication 4-149
(Green)
*Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop
& Go function) Set Indication 4-149
*Lane-keep Assist System (LAS)
& Lane Departure Warning System
(LDWS) Indication 4-161
*Lane-keep Assist System (LAS)
& Lane Departure Warning System
(LDWS) OFF Indicator Light*14-165
*Smart City Brake Supp ort (SCBS) Indication Advanced Smart
City Brake Sup- port (Advanced SCBS)4-171
Smart City
Brake Support (SCBS)4-174
*Smart Brake Support/Smart City Brake Support (SBS/SCBS) OFF Indica-
tor Light*1
Advanced Smart City Brake Sup- port (Advanced
SCBS)4-171
Smart City
Brake Support (SCBS)4-174
Smart Brake
Support (SBS) System4-177
(White)
*Cruise Main Indication 4-217
(Green)
*Cruise Set Indication4-217
*1 The light turns on when the i
gnition is switched on for an operation check, and turns off
a few seconds later or when the engine is sta rted. If the light does not turn on or remains
turned on, have the vehicle inspected at an Authorized Mazda Dealer.
When Driving
Instrument Cluster and Display
4-44*Some models.
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

▼Wrench Indication
The wrench indication is displayed under
the following conditions.
When the preset maintenance period has
arrived.
Refer to Maintenance Monitor on page
6-16.
When the engine oil replacement period
has arrived.
(SKYACTIV-D 2.2)
When the engine oil has deteriorated.
When fuel filter (sedimentor) draining
is required. Consult an Authorized
Mazda Dealer.
NOTE
The wrench indication may display
earlier than the preset period depending
on vehicle usage conditions.
Whenever the engine oil is replaced, a
reset of the vehicle engine control unit is
necessary.
Refer to Maintenance Monitor on page
6-16.

▼ Low Engine Coolant Temperature
Indicator Light (Blue)
The light illuminates continuously when
the engine coolant temperature is low and
turns off after the engine is warm.
▼Glow Indicator Light
(SKYACTIV-D 2.2)
When the ignition is
switched ON, the
glow indicator light turns on. The glow
indicator light turns off when preheating is
finished.

The maintenance period for the glow plug
or a problem in the system may be
indicated under the following conditions.
Have your vehicle inspected by an
Authorized Mazda Dealer.
The glow indicator light does not turn
on when the ignition is switched ON or
it remains on.
The glow indicator light is flashing.
NOTE
If the vehicle is left with the ignition
switched ON without starting the engine
and a long period of time has elapsed
since preheating finished, the preheating
may be performed again and the glow
indicator light may turn on.
When Driving
Instrument Cluster and Display
4-45
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

Instrument Cluster (Type C)

ƒSpeedometer.......................................................................................................... page 4-46
„ Tachometer............................................................................................................ page 4-46
… Multi-information Display (Type C)..................... ................................................ page 4-47
† Dashboard Illumination.........................................................................................page 4-50
▼Speedometer
The speedometer indicates the speed of the
vehicle.
▼Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the tachometer
needle in the RED ZONE.
This may cause severe engine damage.

STRIPED
ZONE
RED ZONE
*
1The range varies depending on the type
of gauge. *
1
*1
NOTE
When the tachometer needle enters the
STRIPED ZONE, this indicates to the
driver that the gears should be shifted
before entering the RED ZONE.
When Driving
Instrument Cluster and Display
4-46
CX-5_8HH4-EA-19A_Edition1
2018-11-21 10:03:20

▼Multi-information Display (Type C)
INFO switch
Multi-information Display (Type C)
The multi-information display indi
cates the following information.
Odometer
Trip meter
Engine coolant temperature gauge
Fuel gauge
Outside temperature
Trip Computer
Cruise Control Display
Compass Display
When Driving
Instrument Cluster and Display
4-47
