2019 MAZDA MODEL CX-5 SKYACTIV-D specification

Vehicle InformationLabels
▼Vehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on a
plate attached to the cowl panel located on
the left corner of the dashboard. This plate
can easily be seen through the windshield.
▼Motor Vehicle Safety Standard
Label (U.S.A. and Canada)
▼ Chassis Number
Open the cover shown in the figure to
check the chassis number.
▼Vehicle Emission Control
Information Label (U.S.A. and
Canada)
▼Tire Pressure Label
Specifications
Identification Numbers
9-2
CX-5_8HH4-EA-19A_Edition1
2018-11-21 10:03:20

▼Engine Number
SKYACTIV-G 2.0, SKYACTIV-G 2.5,
and SKYACTIV-G 2.5T

Forward
SKYACTIV-D 2.2

Forward
Specifications
Identification Numbers
9-3
CX-5_8HH4-EA-19A_Edition1
2018-11-21 10:03:20

Specifications
▼Engine
Gasoline engine
Item Specification
SKYACTIV-G 2.0 SKYACTIV-G 2.5 SKYACTIV-G 2.5T
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 83.5 × 91.2 mm (3.29 × 3.59
in) 89.0 × 100 mm (3.50 × 3.94 in)
Displacement 1,997.6 ml (1,997.6 cc) 2,488.5 ml (2,488.5 cc)
Compression ra-
tio 13.0
10.5
Diesel engine
Item Specification
SKYACTIV-D 2.2
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 86.0 × 94.3 mm (3.39 × 3.71 in)
Displacement 2,191.1 ml (2,191.1 cc)
Compression ratio 14.4
▼Electrical System
Battery
Classification
Specification
SKYACTIV-G 2.0,
SKYACTIV-G 2.5,
SKYACTIV-G 2.5T 12V-60Ah/20HR or 12V-65Ah/20HR
SKYACTIV-D 2.2 12V-65Ah/20HR or 12V-80Ah/20HR
Spark-plug
Classification Specification
SKYACTIV-G 2.0,
SKYACTIV-G 2.5 Mazda Genuine spark plug
*1PE5R-18-110 or PE5S-18-110
SKYACTIV-G 2.5T Mazda Genuine spark plug
*1PY8V-18-110
*1 The spark plugs provide the SKYACTIV-G its optimum performance. Consult an Authorized Mazda Dealer
for details.
Specifications
Specifications
9-4
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-25.
Coolant FL-22 type
Manual transaxle oil Mazda Long Life Gear Oil G7
*1
Automatic transaxle fluid Mazda Genuine ATF-FZ
Transfer case oil Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil Mazda Long Life Hypoid Gear Oil SG1
Brake fluid/Clutch fluid SAE J1703 or FMVSS116 DOT-3
*1 Mazda Long Life Gear Oil G7 is superior oil for low fuel cost and optimum shift-feel. Using Mazda Long Life
Gear Oil G7 is recommended.
If Mazda Long Life Gear Oil G7 cannot be obtained, use standard oil (API Service GL-4 (SAE 75W-80)).
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
▼Capacities
(Approximate Quantities)
Item
Capacity
Engine oil SKYACTIV-G
2.0
With oil filter replacement 4.2 L (4.4 US qt, 3.7 Imp qt)
Without oil filter replace-
ment
4.0 L (4.2 US qt, 3.5 Imp qt)
SKYACTIV-G
2.5 With oil filter replacement 4.5 L (4.8 US qt, 4.0 Imp qt)
Without oil filter replace-
ment
4.3 L (4.5 US qt, 3.8 Imp qt)
SKYACTIV-G
2.5T With oil filter replacement 4.8 L (5.1 US qt, 4.2 Imp qt)
Without oil filter replace-
ment
4.6 L (4.9 US qt, 4.0 Imp qt)
SKYACTIV-D
2.2 With oil filter replacement 5.1 L (5.4 US qt, 4.5 Imp qt)
Without oil filter replace-
ment
4.8 L (5.1 US qt, 4.2 Imp qt)
Specifications
Specifications
9-5
CX-5_8HH4-EA-19A_Edition1
2018-11-21 10:03:20

ItemCapacity
Coolant U.S.A. and Can-
adaSKYACTIV-G 2.0
7.1 L (7.5 US qt, 6.2 Imp qt)
SKYACTIV-G 2.5 7.4 L (7.8 US qt, 6.5 Imp qt)/
7.5 L (7.9 US qt, 6.6 Imp qt)
SKYACTIV-G 2.5T 8.5 L (9.0 US qt, 7.5 Imp qt)
SKYACTIV-D 2.2 8.7 L (9.2 US qt, 7.7 Imp qt)
Mexico SKYACTIV-G 2.0
7.5 L (7.9 US qt, 6.6 Imp qt)
SKYACTIV-G 2.5 7.6 L (8.0 US qt, 6.7 Imp qt)
SKYACTIV-G 2.5T 8.5 L (9.0 US qt, 7.5 Imp qt)
Manual transaxle oil 1.65 L (1.74 US qt, 1.45 Imp qt)
Automatic transaxle
fluid SKYACTIV-G 2.0
7.8 L (8.2 US qt, 6.9 Imp qt)
SKYACTIV-G 2.5 7.8 L (8.2 US qt, 6.9 Imp qt)/
8.0 L (8.5 US qt, 7.0 Imp qt)
SKYACTIV-G 2.5T, SKYACTIV-D 2.2 8.0 L (8.5 US qt, 7.0 Imp qt)
Transfer case oil 0.45 L (0.48 US qt, 0.40 Imp qt)
Rear differential oil 0.35 L (0.37 US qt, 0.31 Imp qt)
Fuel tank 2WD
56.0 L (14.8 US gal, 12.3 Imp gal)
AWD 58.0 L (15.3 US gal, 12.8 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
▼Dimensions
Item
Vehicle specification
Overall length 4,550 mm (179.1 in)
Overall width 1,840 mm (72.4 in)
Overall height 1,675 mm (65.9 in)
Front tread 17 inch styled steel wheel
vehicle
1,586 mm (62.4 in)
17 inch aluminum wheel
vehicle 1,596 mm (62.8 in)
19 inch aluminum wheel
vehicle 1,596 mm (62.8 in)
Rear tread 17 inch styled steel wheel
vehicle
1,586 mm (62.4 in)
17 inch aluminum wheel
vehicle 1,596 mm (62.8 in)
19 inch aluminum wheel
vehicle 1,596 mm (62.8 in)
Wheelbase 2,698 mm (106.2 in)
Specifications
Specifications
9-6
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

▼We i g h t s
U.S.A. and Canada
SKYACTIV-G 2.0
Item
Weight
GVWR (Gross Vehicle Weight Rating) 1,960 kg (4,321 lbs)
GAWR (Gross Axle Weight
Rating) Front
980 kg (2,161 lbs)
Rear 980 kg (2,161 lbs)
SKYACTIV-G 2.5
Item We i g h t
2WD AWD
GVWR (Gross Vehicle Weight Rating) 2,060 kg (4,541 lbs)/
2,075 kg (4,575 lbs) 2,100 kg (4,630 lbs)/
2,143 kg (4,724 lbs)
GAWR (Gross Axle Weight
Rating) Front
1,060 kg (2,337 lbs)/
1,075 kg (2,370 lbs) 1,070 kg (2,359 lbs)/
1,100 kg (2,425 lbs)
Rear 1,000 kg (2,205 lbs) 1,030 kg (2,271 lbs)/
1,043 kg (2,299 lbs)
SKYACTIV-G 2.5T
Item We i g h t
2WD AWD
GVWR (Gross Vehicle Weight Rating) 2,140 kg (4,718 lbs) 2,180 kg (4,806 lbs)
GAWR (Gross Axle Weight
Rating) Front
1,120 kg (2,469 lbs) 1,140 kg (2,513 lbs)
Rear 1,020 kg (2,249 lbs) 1,040 kg (2,293 lbs)
SKYACTIV-D 2.2
Item We i g h t
2WD AWD
GVWR (Gross Vehicle Weight Rating) 2,175 kg (4,795 lbs) 2,240 kg (4,938 lbs)
GAWR (Gross Axle Weight
Rating) Front
1,150 kg (2,535 lbs) 1,170 kg (2,579 lbs)
Rear 1,025 kg (2,260 lbs) 1,070 kg (2,359 lbs)
Specifications
Specifications
9-7
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

Mexico
SKYACTIV-G 2.0
ItemWeight
GVW (Gross Vehicle Weight) Total
2,060 kg (4,542 lbs)
Front 1,035 kg (2,282 lbs)
Rear 1,025 kg (2,260 lbs)
GAW (Permissible axle load) Front
1,055 kg (2,326 lbs)
Rear 1,105 kg (2,436 lbs)
SKYACTIV-G 2.5
Item Weight
Without moonroof With moonroof
GVW (Gross Vehicle Weight) Total
2,060 kg (4,542 lbs) 2,110 kg (4,652 lbs)
Front 1,035 kg (2,282 lbs) 1,045 kg (2,304 lbs)
Rear 1,025 kg (2,260 lbs) 1,065 kg (2,348 lbs)
GAW (Permissible axle load) Front
1,055 kg (2,326 lbs) 1,065 kg (2,348 lbs)
Rear 1,105 kg (2,436 lbs) 1,145 kg (2,524 lbs)
SKYACTIV-G 2.5T
Item Weight
GVW (Gross Vehicle Weight) Total
2,115 kg (4,663 lbs)
Front 1,100 kg (2,425 lbs)
Rear 1,015 kg (2,238 lbs)
GAW (Permissible axle load) Front
1,125 kg (2,480 lbs)
Rear 1,090 kg (2,403 lbs)
▼Air Conditioner
The type of refrigerant used is indicated on a label attached to the inside of the engine com-
partment. Check the label before recharging
the refrigerant. Refer to Climate Control Sys-
tem on page 5-4.
Item Specification
Refrigerant Type HFC134a (R-134a)
Specifications
Specifications
9-8
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

▼Light Bulbs
Exterior light
Light bulb Category
Wa t t ag e UN-R*1(SAE)
Headlights/Daytime running lights LED
*2― (― )
Parking lights LED type
LED
*2― (― )
Front turn signal lights/Parking lights
*28/8 ― (#7444NA)
Front side-marker lights LED type
LED
*2― (― )
Bulb type 5 W5W ( ―)
Fog lights
*LED*2― (― )
Side turn signal lights LED
*2― (― )
High-mount brake light LED
*2― (― )
Rear turn signal lights 21WY21W (7443NA)
Brake lights/Taillights/Rear
side-marker lights LED type
LED
*2― (― )
Bulb type 21/5 W21/5W (7443)
Reverse lights LED
*2― (― )
License plate lights LED
*2― (― )
*1 UN-R stands for United Nations Regulation.*2 LED is the abbreviation for Light Emitting Diode.
Interior light
Light bulb Category
Wa t t ag e UN-R*1
Luggage compartment light LED type
LED*2―
Bulb type 8 ―
Overhead light (Front)/Map lights LED type
LED
*2―
Bulb type 8―
Rear map lights LED type
LED
*2―
Bulb type 8 ―
Vanity mirror lights
*LED type LED*2―
Bulb type 2 ―
Ambient lights
*LED*2―
*1 UN-R stands for United Nations Regulation.*2 LED is the abbreviation for Light Emitting Diode.
Specifications
Specifications
*Some models.9-9
