Distance & Speed Alert
Operation Canceled Drive
Safely This message is indicated when the Dis‐
tance & Speed Alert (DSA) have been
canceled other than by the driver.
Have your vehicle inspected by an Au‐
thorized Mazda Dealer.
Cruise Control Operation
Canceled. Drive Safely This message is indicated when the
Cruise Control have been canceled other
than by the driver. Have your vehicle inspected by an Au‐
thorized Mazda Dealer.
Emergency Braking Acti‐
vated. Depress Brake Ped‐
al to Hold Stop This message is indicated after the Smart
Brake Support (SBS) brakes operate and
when the Smart Brake Support (SBS) is
canceled.
Depress the brake pedal.
Touch Key Fob to Push
Button Start Switch This message is indicated when the key
battery is weak (battery dead or damaged
key). Touch the key against push button start
to start the engine.
Refer to Engine Start Function When
Key Battery is Dead on page 4-8.
Depress Brake Pedal to
Start Engine This message is indicated when the push
button start is presse
d without depressing
the brake pedal. Depress the brake pedal and press the
push button start.
Depress Clutch Pedal to
Start Engine This message is indicated when the push
button start is presse
d without depressing
the clutch pedal. Depress the clutch pedal and press the
push button start.
Check Gear Selector Lever
Position This message is indicated when the se‐
lector lever is shifted to the P or R posi‐
tion while driving.
Check the selector lever position.
Close Door and Fasten
Seat Belt This message is indicated when AUTO‐
HOLD is about to operate and a door is
opened or a seat belt is unfastened. When the AUTOHOLD is turned on,
close the doors and fasten seat belts.
Wiper Blades Must Be on
Windshield Before Operat‐
ing This message is indicated when the
windshield wipers are operated with the
wipers raised off the windshield.
Lower the windshield wipers.
Windshield Wiper Range
of Motion Reduced. Re‐
move Obstruction(s) This message is indicated when there is
snow or dirt accumulation on the wind‐
shield and the wiper operation range is
narrowed.
Remove foreign matter from the wind‐
shield.
Ignition Not Switched Off This message is indicated when the driv‐
er’s door is opened without switching the
ignition OFF. Switch the ignition OFF before leaving
the vehicle.
Gear Selector Lever Not in
Park This message is indicated when a door is
opened with the selector lever in a posi‐
tion other than the P position. Shift the selector lever to the P position
before leaving the vehicle.
Excessive Transmission
Temperature. Drive Slowly This message is indicated when the inter‐
nal temperature of the automatic trans‐
mission is high. Drive slowly to redu
ce load on the auto‐
matic transmission.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-39
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

If the Active Driving
Display Does Not Operate
*
▼ If the Active Driving Display Does
Not Operate
If the active driving display does not
operate, switch the ignition off and then
restart the engine. If the active driving
display does not operate even with the
engine restarted, have the vehicle
inspected at an Authorized Mazda Dealer.
If Trouble Arises
Active Driving Displ ay Does Not Operate
7-48*Some models.
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

You may have the following problems if
you do take your vehicle outside of the
United States/Canada:
Recommended fuel may be unavailable.
Any kind of leaded fuel or low-octane
fuel will affect vehicle performance and
damage the emission controls and
engine.
Proper repair facilities, tools, testing
equipment, and replacement parts may
not be available.
Please refer to your Manufacturer's
Warranty Booklet for more information.
Registering Your Vehicle
in A Foreign Country
(Except United States and Canada)
▼Registering Your Vehicle in A
Foreign Country
Registering your vehicle in a foreign
country may be problematic depending on
whether it meets the specific emission and
safety standards of
the country in which
the vehicle will be driven. Consequently,
your vehicle may require modifications at
personal expense in order to meet the
regulations.
In addition, you should be aware of the
following issues:
Satisfactory vehicle servicing may be
difficult or impossible in another country.

The fuel specified for your vehicle may be
unavailable.

Parts, servicing techniques, and tools
necessary to mainta in and repair your
vehicle may be unavailable.

There might not be an Authorized Mazda
Dealer in the country you plan to take your
vehicle.

The Mazda warranty is valid only in
certain countries.
Customer Information and Reporting Safety Defects
Wa r r a n ty
8-16
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

Add-On Non-GenuineParts and Accessories
▼ Add-On Non-Genuine Parts and
Accessories
Non-genuine parts and accessories for
Mazda vehicles can be found in stores.
These may fit your vehicle, but they are
not approved by Mazda for use with
Mazda vehicles. When you install
non-genuine parts or accessories, they
could affect your vehicle's performance or
safety systems; the Mazda warranty
doesn't cover this. Before you install any
non-genuine parts or accessories, consult
an Authorized Mazda Dealer.
WA R N I N G
Always consult an Authorized Mazda
Dealer before you install non-genuine parts
or accessories:
Improperly designed parts or accessories
could seriously affect your vehicle's
performance or safety systems. This could
cause you to have an accident or increase
your chances of injuries in an accident.
Be very careful in choosing and installing
add-on electrical equipment, such as
mobile telephones, two-way radios, stereo
systems, and car alarm systems:
Incorrectly choosing or installing improper
add-on equipment or choosing an
improper installer is dangerous. Essential
systems could be damaged, causing engine
stalling, air-bag (SRS) activation,
ABS/TCS/DSC inactivation, or a fire in the
vehicle.
Mazda assumes no responsibility for
death, injury, or expenses that may result
from the installation of add-on
non-genuine parts or accessories.
Customer Information and Reporting Safety Defects
Wa r r a n t y
8-17
Mazda3_8HE9-EA-18K_Edition3
2018-11-21 14:31:58

Recording of Vehicle Data
▼Recording of Vehicle Data
This vehicle is equipped with a computer
which records the fo
llowing main vehicle
data related to vehicle controls, operation,
and other driving conditions.

Recorded data
Vehicle conditions such as engine speed
and vehicle speed
Driving operation conditions such as
accelerator and brake pedals, and
information related to the environmental
circumstances while the vehicle is
driven
Malfunction diagnosis information from
each on-vehicle computer
Information related to controls of other
on-vehicle computers
NOTE
The recorded data may vary depending on
the vehicle grade and optional equipment.
Voice and images are not recorded.

Data handling
Mazda and its subcontracting parties may
obtain and use the recorded data for
vehicle malfunction diagnosis, research
and development, and quality
improvement.
Mazda will not disclose or provide any of
the obtained d ata to a third party unless:
An agreement from the vehicle owner
(agreements from lessor and lessee for
leased vehicle) is obtained
Officially requested by the police or
other law enforcem ent authorities
For statistical processing by a research
institution after processing the data so
that identification of the owner or the
vehicle is impossible
Customer Information and Reporting Safety Defects
Recording of Vehicle Data
8-20
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

GVW (Gross Vehicle Weight) is the
Vehicle Curb Weight + cargo +
passengers.

GVWR (Gross Vehicle Weight Rating)
is the maximum allowable weight of the
fully loaded vehicle (including all options,
equipment, passengers and cargo). The
GVWR is shown on the Safety
Compliance Certification Label located
on the driver's door frame or door
pillar. The GVW must never exceed the
GVWR.

SAMPLE
WA R N I N G
Never Exceed Axle Weight Rating Limits:
Exceeding the Safety Certification Label
axle weight rating limits is dangerous and
could result in death or serious injury as a
result of substandar d vehicle handling,
performance, engine, transmission and/or
structural damage, serious damage to the
vehicle, or loss of control.
Always keep the vehicle within the axle
weight rating limits.

GCW
GCW (Gross Combination Weight) is
the weight of the loaded vehicle (GVW).

GCWR (Gross Combination Weight
Rating) is the maximum allowable weight
of the vehicle - including all cargo and
passengers - that the vehicle can handle
without risking damage. The GCW must
never exceed the GCWR.

WA R N I N G
Never Exceed GVWR or GAWR
Specifications:
Exceeding the GVWR or the GAWR specified
on the certification label is dangerous.
Exceeding any vehicle rating limitation
could result in a serious accident, injury, or
damage to the vehicle.
Do not use replacement tires with lower
load carrying capacities than the originals
because they may lower the vehicle's
GVWR and GAWR limitations. Replacement
tires with a higher limit than the originals
do not increase the GVWR and GAWR
limitations.
Never exceed the GVWR or the GAWR
specified on the certification label.
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-33
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

▼Engine Number
1. Forward
Specifications
Identification Numbers
9-3
Mazda3_8HE9-EA-18K_Edition3
2018-11-21 14:31:58

Specifications
▼Engine
Item Specification
SKYACTIV-G 2.0 SKYACTIV-G 2.5
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 83.5 × 91.2 mm (3.29 × 3.59 in) 89.0 × 100 mm (3.50 × 3.94 in)
Displacement 1,997.6 ml (1,997.6 cc) 2,488.5 ml (2,488.5 cc)
Compression ratio 13.0
▼Electrical System
Item
Classification
Battery 12V-60Ah/20HR or 12V-65Ah/20HR
Spark-plug number Mazda Genuine spark plug
*1PE5R-18-110 or PE5S-18-110
*1 This spark plug provides the SK YACTIV-G engine with optimum performance. Contact an Authorized Mazda
Dealer for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-15.
Coolant FL-22 type
Manual transmission oil Mazda Long Life Gear Oil G7
Automatic transmission f luid Mazda Genuine ATF FZ
Transfer case oil Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil Mazda Long Life Hypoid Gear Oil SG1
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
