2019 LEXUS RX450H dimensions

710
RX450h_RX450hL_U9-1. Specifications
*1:Unladen vehicle
*2: Vehicles with towing package
*3:RX450h
*4:RX450hL
Maintenance data (fuel, oil level, etc.)
Dimensions and weight
Overall length192.5 in. (4890 mm)*3
196.9 in. (5000 mm)*4
Overall width74.6 in. (1895 mm)
Overall height*167.7 in. (1720 mm)
Wheelbase109.8 in. (2790 mm)
Tread
Front64.4 in. (1635 mm)*3
64.5 in. (1640 mm)*4
Rear64.0 in. (1625 mm)*3
64.1 in. (1630 mm)*4
Vehicle capacity weight
(Occupants + luggage)920 lb. (420 kg)*3
1070 lb. (490 kg)*4
Trailer Weight Rating*2
(Trailer weight
+ ca

rgo weight)3500 lb. (1585 kg)*3

7269-1. Specifications
RX450h_RX450hL_U
■Typical tire size information
The illustration indicates typical tire size. Tire use
(P = Passenger car,
T = Temporary use)
Section width (millimeters)
Aspect ratio
(tire height to section width)
Tire construction code
(R = Radial, D = Diagonal)
Wheel diameter (inches)
Load index (2 digits or 3 digits)
Speed symbol (alphabet with one letter)
■Tire dimensionsSection width
Tire height
Wheel diameter
Tire size
1
2
3
4
5
6
7
1
2
3

774Alphabetical index
RX450h_RX450hL_U
Child-protectors.....................................139
Cleaning.......................................580, 584 Aluminum wheels ............................... 581
Exterior................................................... 580
Interior .................................................... 584
Seat belts ............................................... 585
Clock ................................................ 96, 548
Coat hooks.............................................. 559
Compass .................................................. 567
Condenser .............................................. 602
Console box ........................................... 534
Consumption screen ................. 105, 124
Coolant Capacity .................................................. 715
Checking................................................. 601
Preparing and checking before winter ................................... 390
Cooling system ...................................... 601 Hybrid system overheating ..........702
Cornering lights .................................... 259
Cruise control Dynamic radar cruise control with full-speed range ................... 306
Cup holders ............................................ 535
Curtain shield airbags ........................... 37
Customizable features ....................... 736
Customized mode ............................... 379 Daytime running light system.......... 260
Defogger
Outside rear view mirrors ..............516
Rear window..........................................516
Windshield..............................................516
Differential ................................................ 716
Dimensions ............................................... 710
Dinghy towing ....................................... 238
Display Dynamic radar cruise control with full-speed range ...................306
Energy monitor..................................... 124
LKA (Lane-Keeping Assist)......... 302
Multi-information display.................. 101
Warning messages .......................... 667
Do-it-yourself maintenance............. 593
Doors Automatic door locking and unlocking system..............................139
Door lock................................................ 138
Outside rear view mirrors ..............193
Power back door ................................ 142
Rear door child-p rotectors ............139
Side doors ...............................................136
Side windows ........................................196D
