2019 LEXUS RX350 display

692 8-2. Steps to take in an emergency
RX350/RX350L_U Stop the vehicle in a safe place and tu rn off the air conditioning system, and
then stop the engine.
If you see steam:
Carefully lift the hood after the steam subsides.
If you do not see steam:
Carefully lift the hood.
After the engine has cooled down
sufficiently, insp ect the hoses and
radiator core (radiator) for any
leaks.
Radiator
Cooling fans If a large amount of coolant leaks,
immediately contact your Lexus
dealer.
The coolant level is satisfactory if it is
between the “FULL” and “LOW”
lines on the reservoir.
Reservoir
“FULL” line
“LOW” line
Radiator capIf your vehicle overheats The following may indicate that your vehicle is overheating. ●
The needle of the engine coolant temperature gauge (  P. 86) enters the
red zone, or a loss of engine power is experienced. (For example, the vehi-
cle speed does not increase.) ●
“Engine Coolant Temp High Stop in a Safe Place See Owner’s Manual” is
shown on the multi-information display. ●
Steam comes out from under the hood.
Correction procedures 1
2
3
1
2
4
1
2
3
4

6938-2. Steps to take in an emergency
8
When trouble arises
RX350/RX350L_U Add coolant if necessary. Water can be used in an emergency if
coolant is unavailable.
Start the engine and turn the air conditio ning system on to check that the radi-
ator cooling fans operate and to check for coolant leaks from the radiator or
hoses. The fans operate when the air conditioning system is turned on immediately after a
cold start. Confirm that the fans are operating by checking the fan sound and air flow.
If it is difficult to check these, turn the air conditioning system on and off repeatedly.
(The fans may not operate in freezing temperatures.)
If the fans are not operating:
Stop the engine immediately an d contact your Lexus dealer.
If the fans are operating:
Have the vehicle inspected at the nearest Lexus dealer.
Check if “Engine Coolant Temp High St op in a Safe Place See Owner’s Man-
ual” is shown on the multi-information display.
If the message does not disappear:
Stop the engine and contact your Lexus dealer.
If the message is not displayed:
Have the vehicle inspected at the nearest Lexus dealer. 5
6
7
8

722
RX350/RX350L_U 9-2. Customization
When customizing vehicle features, ensure that the vehicle is parked in a safe
place with the shift lever in P and the parking brake set.■
Changing on the audio system screen 
Vehicles with a navigation system
Press the “MENU” button on the Remote Touch.
Select on the “Menu” screen and select .
Various setting can be changed. Refer to the list of settings that can be
changed for details. 
Vehicles with a Lexus Display Audio system
Press the “MENU” button on the Lexus Display Audio controller.
Select “Setup” on the “Menu” screen and select “Vehicle”.
Various setting can be changed. Refer to the list of settings that can be
changed for details. ■
Changing using the multi-information display
 P. 97Customizable features Your vehicle includes a variety of elec tronic features that can be personalized
to suit your preferences. The settings of these features can be changed using
the multi-information display, on the audio system screen, or at your Lexus
dealer.
Customizing vehicle features 1
2
1
2

7239-2. Customization
9
Vehicle specifications
RX350/RX350L_U Some function settings are changed simultaneously with other functions being
customized. Contact your Lexu s dealer for further details.
Settings that can be changed on the audio system screen
Settings that can be changed by your Lexus dealer
Definition of symbols: O = Available, – =Not available ■
Gauges, meters and multi-information display (  P. 86, 90)
* 1
: The default setting varies according to countries.
* 2
:Except F SPORT modelsCustomizable Features 1
2
Function Default setting Customized setting
Language English French
O—
Spanish
Units
* 1
miles (MPG US) miles
(MPG Imperial)
O —
km (L/100 km)
km (km/ L)
Color
* 2
Color 1 Color 2
O —
Suggestion function On Off — O 1 2

7319-2. Customization
9
Vehicle specifications
RX350/RX350L_U ■
Intuitive parking assist
* 1
(  P. 326)
* 1
: If equipped
* 2
: When intuitive parking assist is operating. ■
BSM (Blind Spot Monitor)
* (  P. 313)
* : If equipped Function Default setting Customized setting
Detection distance of the front
center sensor Far Near O O
Detection distance of the rear
center sensor Far Near O O
Buzzer volume 3 1 to 5 O O
Display setting
* 2
All sensors dis-
played Display off O O 1 2
Function Default setting Customized setting
Outside rear view mirror indica-
tor brightness Bright Dim O O
Alert timing for presence of
approaching vehicle (BSM func-
tion only) Intermediate Early
O OLate
Only when in blind
spot
RCTA buzzer volume Level 2 Level 1
O —
Level 3 1 2

754 What to do if... (Troubleshooting)
RX350/RX350L_U ●
The seat belt reminder light is flashing
Are the driver and the passengers wearing the seat belts?
(  P. 656, 656)●
The parking brake indicator is on
Is the parking brake released? (  P. 247)
Depending on the situation, other type s of warning buzzer may also sound.
(  P. 654, 661) ●
Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. (  P. 77)
Do one of the following to stop the alarms: • Unlock the doors.
• Turn the engine switch to ACCESSORY or IGNITION ON mode, or start the
engine.
●
Is the message displayed on the multi-information display?
Check the message on the multi-information display. (  P. 661)
●
When a warning light turns on or a wa rning message is displayed, refer to
P. 654, 661. A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed

757Alphabetical index
RX350/RX350L_U Alarm ............................................................. 77
All-wheel drive lock mode ................377
Anchor brackets ...................................... 57
Antenna
Radio ........................................................ 423
Smart access system
with push-button start ................... 146
Anti-lock Brake System (ABS)....... 378
Warning light ...................................... 654
Approach warning...............................308
Armrest .................................................... 555
Assist grips .............................................. 556
Audio system (with Lexus
Display Audio System) ................... 394
Antenna .................................................. 423
Audio input........................................... 403
AUX port.............................................. 403
Bluetooth ®
audio ..............................453
CD player .............................................. 427
iPod ...........................................................434
MP3/WMA disc ............................... 427
Optimal use ........................................... 413
Portable music player ...................... 442
Radio ........................................................420
Setup menu .......................................... 406
Steering wheel audio
switches .............................................. 400
USB memory ...................................... 438 Audio system
(with navigation system)
* Automatic air conditioning
system .......................................... 503, 518
Air conditioning filter ........................ 618
S-FLOW mode..................................... 511
Automatic headlight leveling
system .....................................................254
Automatic High Beam ....................... 256
Automatic light control system .......252
Automatic transmission.......... 236, 240
If the shift lever cannot be
shifted from P ....................... 239, 244
M mode .................................................. 242
Paddle shift switches.............. 241, 242
S mode.....................................................237
AUX port ................................................ 403
Auxiliary boxes ......................... 535, 540
* : Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

761Alphabetical index
RX350/RX350L_U Daytime running light system .......... 254
Defogger
Outside rear view mirrors .............. 513
Rear window ......................................... 513
Windshield ............................................. 513
Differential ............................................... 703
Dimensions ............................................. 698
Dinghy towing........................................ 230
Display
Dynamic radar cruise control
with full-speed range ................... 300
LKA (Lane-Keeping Assist) .........296
Multi-information display ..................90
Warning messages............................ 661
Do-it-yourself maintenance .............590
Doors
Automatic door locking and
unlocking system .............................. 127
Door lock ................................................ 126
Outside rear view mirrors .............. 184
Power back door ................................ 130
Rear door child-p rotectors ............ 127
Side doors ...............................................124
Side windows ........................................ 187 Drive information .....................................94
Drive-start control ........ 203, 238, 243
Driver’s seat belt reminder light .... 656
Driver’s seat position memory.......... 172
Driving
Break-in tips ......................................... 204
Correct posture .................................... 30
Driving mode select switch .......... 373
Procedures ........................................... 202
Winter drive tips ................................384
Driving position memory .................... 172
Memory recall function .................... 175
Power easy access system ............. 172
Dynamic radar cruise control
with full-speed range....................... 300
Dynamic Torque Control AWD
system .....................................................379D
