2019 LEXUS RCF display

3154-5. Using the driving support systems
4
Driving
RC F_U 
RC F
To turn the TRAC system off, quickly
press and release ( ). The “TRAC OFF” indicator light will
come on.
Press ( ) again to turn the
system back on. ■
Turning off both TRAC and VSC systems 
RC350
/RC300To turn the TRAC and VSC systems off, pr ess and hold for more than 3 seconds
while the vehicle is stopped.
The VSC OFF indicator light will come on an d the “Traction Control Turned Off” will be
shown on the multi-information display.
* 1
Press again to turn the systems back on. 
RC F
To turn the TRAC and VSC systems off, press and hold ( ) for more than
3 seconds.
The “TRAC OFF” indicator li ght and the VSC OFF indica tor light will come on.
* 2
Press ( ) again to turn the systems back on.
* 1
: On vehicles with PCS (Pre-Collision System ), pre-collision brake assist, pre-collision
braking, and steering control (performed through cooperative control of PCS and
LDH) (if equipped) will also be disabled. The pre-collision system warning light will
come on and a message will be displaye d on the multi-information display. (  P. 460)
* 2
: On vehicles with PCS (Pre-Collision Syst em), pre-collision brake assist and pre-
collision braking will also be disabled. The pre-collision system warning light will come
on and a message will be displayed on the multi-information display. (  P. 460)

316 4-5. Using the driving support systems
RC F_U ■
Expert mode (RC F)
When expert mode is se lected, it is possible to drive in a more sp orty manner than other
drive modes. Expert mode disables the TRAC and VSC systems but the engine and
brakes may be controlled depending on the vehicle behavior.
■
When the message is displayed on the mu lti-information displa y showing that TRAC
has been disabled even if has not been pressed (RC350/RC300)
TRAC cannot be operated. Contact your Lexus dealer.■
When the “TRAC OFF” indicator light comes on even if
( ) has not been
pressed (RC F)
TRAC cannot be operated. Contact your Lexus dealer.■
VGRS is disabled when
VGRS may stop operating in the following situations.
In this event, the steering wheel may move from its straight forward position, but it will
return when the system restarts. ●
When the steering wheel is operated for an extended period of time while the vehicle is
stopped or is moving very slowly
(on vehicles with LDH, DRS is disabled together with VGRS) ●
When the steering wheel has been held fully to the left or right
The center position of the steering wheel may change when VGRS is disabled. However,
the position will return to normal after VGRS is reactivated. ■
When the battery is disconnected (vehicles with VGRS)
The steering wheel may move from its straight forward position, but this will be corrected
automatically when driving.To select expert mode, press
()when in SPORT S+ mode.
The “EXPERT” indicator will come on together
with the TRAC OFF and VSC OFF indicators.
To cancel expert mode, press
() or
use the driving mode sele ct switch to select a
driving mode other than SPORT S+ mode.

325
Interior features
5
RC F_U 5-1. Using the air conditioning
system
Remote Touch .............................326
10.3-inch display ......................... 331
Automatic air conditioning
system ......................................... 333
Heated steering wheel/
seat heaters/
seat ventilators .........................344
5-2. Using the interior lights
Interior lights list.......................... 347
• Interior lights ......................... 348
• Personal lights .......................349
5-3. Using the storage features
List of storage features............ 350
• Glove box ................................ 351
• Console box ............................ 351
• Cup holders............................352
Trunk features............................. 353 5-4. Using the other interior
features
Other interior features ............ 354
• Sun visors ................................ 354
• Vanity mirrors ....................... 354
• Clock ........................................355
• Power outlet...........................355
• Armrest .................................... 356
•Trunk storage
extension ................................. 357
• Assist grips..............................358
• Coat hooks .............................358
Garage door op ener ...............359
Compass ....................................... 366
LEXUS Enform Safety
Connect ...................................... 370

326
RC F_U 5-1. Using the air conditioning system 
Vehicles with a 10.3-inch display
“MAP” button
*Press this button to display the vehicle’s current position.
“MENU” button Press to display th e “Menu” screen. (  P. 330)
Back button Press to display the previous screen.
Touchpad Slide your finger on the touchpad and move the pointer to select a function, letter and
screen button.
Press the touchpad to enter the selected function, letter or screen button. Certain fin-
ger movements on the touchpad can perform functions, such as changing map scal-
ings and scrolling list screens.
Sub function button When is displayed on the screen, a functi on screen assigned to the screen can be
displayed.
* : Refer to the “NAVIGATION AND MU LTIMEDIA SYSTEM OWNER’S MANUAL”.Remote Touch The Remote Touch can be used to operate the Remote Touch screens.
Owners of models equipped with a navi gation system should refer to the
“NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
1
2
3
4
5

3275-1. Using the air conditioning system
5
Interior features
RC F_U 
Vehicles with a 7-inch display
“HOME” button
*Press this button to display the “Home” screen.
“MENU” button Press to display th e “Menu” screen. (  P. 330)
Back button Press to display the previous screen.
Touchpad Slide your finger on the touchpad and move the pointer to select a function, letter and
screen button.
Press the touchpad to enter the selected function, letter or screen button. Certain fin-
ger movements on the touchpad can perform functions, such as changing map scal-
ings and scrolling list screens.
Sub function button When is displayed on the screen, a functi on screen assigned to the screen can be
displayed.
* : Refer to the “NAVIGATION AND MU LTIMEDIA SYSTEM OWNER’S MANUAL”.1
2
3
4
5

3295-1. Using the air conditioning system
5
Interior features
RC F_U ●
Pinch in/Pinch out Slide fingers toward each other or
apart on the touchpad. Change the
scale of the map.■
Screen display during low temperatures
When the ambient temperature is extremely low, screen response may be delayed even
if the Remote Touch is operated.
NOTICE ■
To prevent damage to the Remote Touch
Observe the following precautions. Failure to do so may cause damage to the Remote
Touch. ●
Do not allow food, liquid, stickers or lit cigarettes to contact the Remote Touch.●
Do not subject the Remote Touch to ex cessive pressure or strong impact.●
Do not push the touchpad with a strong force or use a sharp pointed object to oper-
ate the pad.

330 5-1. Using the air conditioning system
RC F_U Press the “MENU” button on the Remote Touch to display the “Menu” screen.
The display may differ depending on the type of the system.
* 1
: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
* 2
: This function is not made available on some models.“Menu” screen 
Vehicles with a 10.3-inch display 
Vehicles with a 7-inch display
Switch Function
Select to display the “Destination” screen.
* 1
Select to display the audio control screen.
* 1
Select to display the hand s-free operation screen.
* 1
Select to display the “Apps” screen.
* 1, 2
When an Apple CarPlay connection is established and this button
displays “Apple CarPlay” , select to display the home screen of Apple
CarPlay.
* 1, 2
Select to display the “Information” screen.
* 1
Select to display the “Setup” screen.
* 1
Select to display the air conditioning control screen. (  P. 335)
Select to adjust the contrast and brightness of the screens, turn the
screen off, etc.
* 1, 2

3315-1. Using the air conditioning system
5
Interior features
RC F_U ■
Full screen display
The following functions can be displayed full screen:
• Initial screen
•“Menu” screen (  P. 330)
• Map screen
*
* : Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MAN-
UAL”.■
Split-screen display
Different information can be displayed on the left and right of the screen. For
example, audio screen can be displa yed and operated while the fuel con-
sumption information screen is being disp layed. The large screen on the left of
the display is called the main display, and the small screen to the right is called
the side display.10.3-inch display 
 : If equipped10.3-inch display overview
