2019 LEXUS RC300 sensor

2877-2. Steps to take in an emergency
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810
7
When trouble arises
■Master warning light (warning buzzer)
■Tire pressure warning light
■SRS warning light
This warning light system monitors the air-
bag sensor assembly, fr ont impact sensors,
side impact sensors (door), side impact
sensors (front), side impact sensors (rear),
driver’s seat position sensor, driver’s seat
belt buckle switch, front passenger occu-
pant classification system, “AIR BAG ON”
indicator light, “AIR BAG OFF” indicator
light, front passenger’s seat belt buckle
switch, seat belt pret ensioners, airbags,
interconnecting wiring and power sources.
(  P.29)
■Front passenger detection sensor, seat
belt reminder and warning buzzer
●If luggage is placed on the front passen-
ger seat, the front passenger detection
sensor may cause th e warning light to
flash and the warning buzzer to sound
even if a passenger is not sitting in the
seat.
●If a cushion is placed on the seat, the sen-
sor may not detect a passenger, and the warning light may not operate properly.
■If the malfunction indicator lamp comes
on while driving
First check the following:
●Is the fuel tank empty?
If it is, fill the fuel tank immediately.
●Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after several driving
trips.
If the light does not go off even after several
trips, contact your Lexus dealer as soon as
possible.
■Electric power steering system warning
light (warning buzzer)
When the battery charge becomes insuffi-
cient or the voltage temporarily drops, the
electric power steering system warning
light may come on and the warning buzzer
may sound.
Warning lightDetails/Actions
A buzzer sounds and the warning light comes on and flashes to indicate
that the master warning system has detected a malfunction.
 P.290
Warning lightDetails/Actions
When the light comes on:
Low tire inflation pressure such as
Natural causes ( P.288)
 Flat tire ( P.294)
 Adjust the tire inflation pressure to the specified level. The light will
turn off after a few minutes. In case the light does not turn off even if
the tire inflation pressure is adju sted, have the system checked by
your Lexus dealer.
When the light comes on after blinking for 1 minute:
Malfunction in the tire pressure warning system
 Have the system checked by your Lexus dealer.

3458-2. Customization
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810
8
Vehicle specifications
■Automatic light control system ( P.136)
■Lights ( P.136)
■PCS (Pre-Collision System) ( P.154)
■LDA (Lane Departure Alert with steering control) ( P.161)
FunctionDefault settingCustomized setting
Light sensor sensitivityStandard-2 to 2O—O
Time elapsed before head-
lights automatically turn off
after doors are closed
30 seconds
Off
O—O60 seconds
90 seconds
ABC
FunctionDefault settingCustomized setting
Daytime running light system
(except Canada)OnOffO—O
FunctionDefault settingCustomized setting
PCS (Pre-Collision System)OnOff—O—
Adjust alert timingMiddleFar—O—Near
FunctionDefault settingCustomized setting
Steering assist functionOnOff—O—
Alert typeSteering wheel
vibrationBuzzer—O—
Alert sensitivityStandardHigh—O—
Vehicle sway warning func-
tionOnOff—O—
Vehicle sway warning sensi-
tivityStandardHigh—O—Low
ABC
ABC
ABC

3468-2. Customization
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810
■Intuitive parking assist* ( P.176)
*:If equipped
■Driving mode select switch ( P.190)
*:If equipped
■Automatic air conditioning system ( P.205)
■Seat heaters* ( P.212)
*:If equipped
FunctionDefault settingCustomized setting
Detection distance of the
front center sensorFarNearO—O
Detection distance of the rear
center sensorFarNearO—O
Buzzer volume21 to 3O—O
ABC
FunctionDefault settingCustomized setting
Powertrain control in custom
mode
*NormalPowerO——Eco
Chassis control in custom
mode
*NormalSportO——
Air conditioning operation in
custom mode
*NormalEcoO——
ABC
FunctionDefault settingCustomized setting
A/C auto switch operationOnOffO—O
Exhaust gas sensor sensitivityStandard-3 to 3O—O
ABC
FunctionDefault settingCustomized setting
Seat heater timer controlOffOnO—O
ABC

3528-4. Certifications
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810
Millimeter wave radar sensor

3538-4. Certifications
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810
8
Vehicle specifications
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions; (1) This
device may not cause harmful interfer-
ence, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.
This ISM device complies with Cana-
dian ICES-001. Cet appareil ISM est conforme a la
norme NMB-001 du Canada.
Intuitive parking assist sensor

3711-1. What to do if... (Troubleshooting)
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810371What to do if... (Troubleshooting)
 Is the engine switch in IGNITION
ON mode?
If you cannot release the shift lever by
depressing the brake pedal with the engine
switch in IGNITION ON mode. ( 
P.129)
It is locked automatically to prevent
theft of the vehicle. ( P.125)
 Is the window lock switch pressed?
The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. ( 
P.111)
The auto power off function will be
operated if the vehicle is left in
ACCESSORY or IGNITION ON
mode (the engine is not running) for
a period of time. ( P.127)
 The seat belt reminder light is flash-
ing
Are the driver and the front passenger
wearing the seat belts? ( 
P.286)
The parking brake indicator is on
Is the parking brake released? ( P.134)
Depending on the situation, other
types of warning buzzer may also
sound. (P.282, 290)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm sounds.
(
P.58)
Do one of the following to deactivate
or stop the alarm:
 Unlock the doors.
 Open the trunk using the entry
function or wireless remote control.
 Turn the engine switch to ACCES-
SORY or IGNITION ON mode, or
start the engine.
 Is the message displayed on the
multi-information display?
Check the message on the multi-informa-
tion display. ( 
P.290)
When a warning light turns on or a
warning message is displayed, refer
to P.282, 290.
The steering wheel cannot be
turned after the engine is
stopped
The windows do not open or
close by operating the power
window switches
The engine switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed

374Alphabetical Index
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810
Seat belts........................................................ 235
Cargo capacity...............................................123
Cargo hooks ...................................................219
Center Display ............................................. 202
Chains ................................................................ 197
Child restraint system Child seats definition................................... 40
Child seats installation....................... 44, 48
Front passenger occupant classification system ............................................................. 36
Installing a CRS to the front passenger seat ....................................................................42
Installing a CRS to the rear seat............ 44
Installing CRS with LATCH anchors . 48
Installing CRS with seat belts.................. 44
Installing CRS with top tether strap.....50
Child safety Airbag precautions.......................................32
Battery precautions ..................... 254, 308
Child restraint system................................. 40
Heated steering wheel or seat heater precautions.................................................. 212
How your child should wear the seat belt 25
Installing child restraints ............................ 40
Moon roof precautions ..............................114
Power window lock switch........................ 111
Removed electronic key battery precau- tions ............................................................... 266
Seat belt extender precautions ............. 25
Seat belt precautions .................................. 40
Trunk precautions ........................................ 89
Cleaning Aluminum wheels ...................................... 232
Exterior ........................................................... 232
Interior ............................................................. 235
Radar sensor..................................................152
Seat belts........................................................ 235
Clock ........................................................ 66, 220
Clock settings ............................................... 220
Coat hooks..................................................... 220
Compass ..........................................................227 Condenser ..................................................... 252
Console box ....................................................218
Consumption screen .................................... 78
Cooling system............................................. 250
Engine overheating.................................. 309
Cornering lights ............................................. 137 Replacing light bulbs ................................270
Cruise control Dynamic radar cruise control............... 168
Cup holders .....................................................218
Current fuel consumption ...........................72
Curtain shield airbags .................................. 28
Customizable features .............................. 339
D
Daytime running light system ...................136
Daytime running lights Replacing light bulbs ................................270
Defogger Outside rear view mirrors.................... 209
Rear window ............................................... 209
Windshield ................................................... 209
Differential Front differential oil. .......................... ...........321
Rear differential oil. ......................................321
Dimension ........................................................316
Dinghy towing................................................. 124
Display Center Display ............................................202
Drive information .......................................... 72
LDA (Lane Departure Alert with steering control) ......................................................... 163
Multi-information display ............................ 71
Warning messages.....................................291
Distance until next engine oil change .... 70
Do-it-yourself maintenance .................... 239
Door courtesy lights .....................................215
Door lock Doors ..................................................................86
Smart access system with push-button start ................................................................... 93
Wireless remote control ...........................84

380Alphabetical Index
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810
Jam protection function............................. 110
Operation......................................................... 110
Window lock switch ..................................... 111
Pre-Collision System (PCS) Function ............................................................154
PCS OFF switch ......................................... 156
Warning light ...............................................285
Warning message.......................... 160, 290
R
Radar cruise control (dynamic radar cruise control) .......................................................... 168
Radiator ........................................................... 252
Rear seats .......................................................... 99 Head restraints ............................................ 103
Seat heaters .................................................... 212
Seat ventilators.............................................. 212
Rear side marker lights Light switch .....................................................136
Rear turn signal lights Turn signal lever ...........................................133
Wattage.......................................................... 326
Rear view mirror Inside rear view mirror..............................107
Outside rear view mirrors ..................... 108
Rear window defogger ............................. 209
Refueling Capacity .......................................................... 318
Fuel types........................................................ 318
If the fuel filler door cannot be opened ....
303
Opening the fuel tank cap ..................... 148
Remote Touch ..............................................200
Replacing Electronic key battery.............................. 265
Fuses ................................................................ 267
Light bulbs..................................................... 270
Tires .................................................................. 294
Resetting the message indicating mainte- nance is required ...................................... 238
Rev indicator .................................................... 69
Rev peak............................................................. 69
S
Seat belt reminder light............................. 286
Seat belts............................................................ 24 Automatic Locking Retractor................. 26
Child restraint system installation .........40
Cleaning and maintaining the seat belt ....235
Emergency Locking Retractor .............. 26
How to wear your seat belt ..................... 25
How your child should wear the seat belt 25
Pregnant women, proper seat belt use .... 24
Reminder light and buzzer .................. 286
Seat belt extender......................................... 25
Seat belt pretensioners .............................. 27
SRS warning light.......................................283
Seat heaters ..................................................... 212
Seat position memory................................. 100
Seat ventilators ............................................... 212
Seating capacity.............................................123
Seats Adjustment ....................................................... 97
Cleaning .........................................................235
Driving position memory ........................ 100
Head restraints............................................. 103
Power easy access system .................... 100
Properly sitting in the seat ........................ 23
Seat heaters .................................................... 212
Seat position memory ..............................100
Seat ventilators .............................................. 212
Seats, Front Child seats/child restraint system installa-tion ....................................................................40
Sensor Automatic headlight system .................. 136
Automatic High Beam system ............. 138
Inside rear view mirror .............................108
LDA (Lane Departure Alert with steering control) ........................................................... 161
Radar sensor ................................................. 152
