2019 LEXUS LS500 seats

LS500_OM_(U)_1810 1
2
3
4
5
6
7
8
9Pictorial index Search by illustration
For safety
and security Make sure to read through them
(Main topics: Child seat, theft deterrent system)
Vehicle status
information and
indicators Reading driving-related information
(Main topics: Meters, multi-information display)
Before driving Opening and closing the doors and windows,
adjustment before driving
(Main topics: Keys, doors, seats)
Driving Operations and advice which are necessary for driving
(Main topics: Starting engine, refueling)
Interior features Usage of the interior features
(Main topics: Air conditioner, storage features)
Maintenance
and care Caring for your vehicle and maintenance procedures
(Main topics: Interior and exterior, light bulbs)
When trouble
arises What to do in case of malfunction and emergency
(Main topics: Battery discharge, flat tire)
Vehicle
specifications Vehicle specifications, customizable features
(Main topics: Fuel, oil, tire inflation pressure)
For owners Reporting safety defects for U.S. owners, seat belt and
SRS airbag instructions for Canadian owners
Index Search by symptom
Search alphabetically

2
LS500_OM_(U)_1810 TABLE OF CONTENTS
For your information ...................................... 6
Reading this manual .................................... 10
How to search ................................................. 11
Pictorial index ................................................. 12
1-1. For safe use
Before driving .................................... 22
For safe driving.................................. 23
Seat belts ............................................. 24
SRS airbags ........................................ 29
Pop Up Hood ................................... 38
Front passenger occupant classifi-
cation system ................................. 40
Exhaust gas precautions .............. 44
1-2. Child safety
Riding with children........................ 45
Child restraint systems ................. 45
1-3. Lexus Enform
Lexus Enform Safety Connect .. 58
1-4. Theft deterrent system
Engine immobilizer system ......... 63
Alarm.................................................... 65
2-1. Instrument cluster
Warning lights and indicators .... 68
Gauges and meters (except F
SPORT models) ........................... 73
Gauges and meters (F SPORT
models) ............................................. 76
Multi-information display............. 80
Head-up display .............................. 87
Fuel consumption information ..... 91 3-1. Key information
Keys ....................................................... 96
3-2. Opening, closing and locking the
doors and trunk
Doors ................................................. 100
Trunk .................................................. 104
Smart access system with push-but-
ton start ............................................. 111
3-3. Adjusting the seats
Front seats.......................................... 119
Power rear seat .............................. 126
Driving position memory ........... 130
Rear seat position memory........ 134
Head restraints .............................. 135
3-4. Adjusting the steering wheel and
mirrors
Steering wheel ............................... 138
Inside rear view mirror ............... 139
Outside rear view mirrors......... 140
3-5. Opening, closing the windows and
moon roof
Power windows .............................. 142
Moon roof ........................................ 145
Panoramic moon roof .................. 147
4-1. Before driving
Driving the vehicle........................ 154
Cargo and luggage...................... 160
Vehicle load limits.......................... 162
Trailer towing.................................. 163
Dinghy towing ................................ 1631
For safety and security
2
Vehicle status information and
indicators 3
Before driving
4
Driving

19Pictorial index
LS500_OM_(U)_1810 ■ Interior
SRS airbags.................................................................................................................P.2 9
Floor mats ....................................................................................................................P .22
Front seats .................................................................................................................. P. 119
Head restraints ........................................................................................................P.135
Seat belts ..................................................................................................................... P.24
Inside lock buttons ..................................................................................................P.102
Console box............................................................................................................ P.338
Cup holders .............................................................................................................P.337
Assist grips ...............................................................................................................P.34 4
Coat hooks ...............................................................................................................P.344
Rear Multi Operation Panel *1
.......................................................................... P.308
Rear seat entertainment system *1, 2
*1
: If equipped *2
: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”. A
B
C
D
E
F
G
H
I
J
K
L

231-1. For safe use
LS500_OM_(U)_1810 1
For safety and security
Adjust the angle of the seatback so
that you are sitting straight up and
so that you do not have to lean for-
ward to steer. (  P.119)
Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the
elbow when gripping the steering
wheel. (  P.119)
Lock the head restraint in place
with the center of the head restraint
closest to the top of your ears.
(  P.135)
Wear the seat belt correctly.
(  P.24) Make sure that all occupants are wear-
ing their seat belts before driving the
vehicle. (  P.24)
Use a child restraint system appropri-
ate for the child until the child becomes
large enough to properly wear the
vehicle’s seat belt. (  P.45)
Make sure that you can see backward
clearly by adjusting the inside and out-
side rear view mirrors properly.
(  P.139, 140)For safe driving For safe driving, adjust the seat and
mirror to an appropriate position
before driving.
Correct driving posture
WARNING
■
For safe driving
Observe the following precautions.
Failure to do so may result in death or
serious injury. A
B
C
D ●
Do not adjust the position of the
driver’s seat while driving.
Doing so could cause the driver to lose
control of the vehicle. ●
Do not place a cushion between the
driver or passenger and the seatback.
A cushion may prevent correct pos-
ture from being achieved, and reduce
the effectiveness of the seat belt and
head restraint. ●
Do not place anything under the front
seats.
Objects placed under the front seats
may become jammed in the seat
tracks and stop the seat from locking in
place. This may lead to an accident
and the adjustment mechanism may
also be damaged. ●
Always observe the legal speed limit
when driving on public roads. ●
When driving over long distances, take
regular breaks before you start to feel
tired.
Also, if you feel tired or sleepy while
driving, do not force yourself to con-
tinue driving and take a break immedi-
ately.
Correct use of the seat belts
Adjusting the mirrors

24 1-1. For safe use
LS500_OM_(U)_1810 Seat belts Make sure that all occupants are
wearing their seat belts before driv-
ing the vehicle. WARNING
Observe the following precautions to
reduce the risk of injury in the event of
sudden braking, sudd en swerving or an
accident.
Failure to do so may cause death or seri-
ous injury. ■
Wearing a seat belt●
Ensure that all passengers wear a seat
belt.●
Always wear a seat belt properly.●
Each seat belt should be used by one
person only. Do not use a seat belt for
more than one person at once, includ-
ing children.●
Lexus recommends that children be
seated in the rear seat and always use
a seat belt and/or an appropriate child
restraint system.
●
To achieve a proper seating position,
do not recline the seat more than nec-
essary. The seat belt is most effective
when the occupants are sitting up
straight and well back in the seats.
●
Do not wear the shoulder belt under
your arm.
●
Always wear your seat belt low and
snug across your hips. ■
Pregnant women
Obtain medical advice and wear the seat
belt in the proper way. (  P.25)
Women who are pregnant should posi-
tion the lap belt as low as possible over
the hips in the same manner as other
occupants, extending the shoulder belt
completely over the shoulder and avoid-
ing belt contact with the rounding of the
abdominal area.
If the seat belt is not worn properly, not
only the pregnant woman, but also the
fetus could suffer death or serious injury
as a result of sudden braking or a colli-
sion.
■
People suffering illness
Obtain medical advice and wear the seat
belt in the proper way. (  P.25)
■
When children are in the vehicle
 P.53
■
Seat belt damage and wear
●
Do not damage the seat belts by allow-
ing the belt, plate, or buckle to be
jammed in the door.
●
Inspect the seat belt system periodi-
cally. Check for cuts, fraying, and loose
parts. Do not use a damaged seat belt
until it is replaced. Damaged seat belts
cannot protect an occupant from
death or serious injury.

26 1-1. For safe use
LS500_OM_(U)_1810 1 To fasten the seat belt, push the
plate into the buckle until a click
sound is heard.
2 To release the seat belt, press the
release button .If the seat belt cannot be pulled out of the
retractor, firmly pull the belt and release it.
■
Emergency locking retractor (ELR)
The retractor will lock the belt during a sud-
den stop or on impact. It may also lock if you
lean forward too quickly. A slow, easy
motion will allow the belt to extend so that
you can move around fully.
■
Automatic locking retractor (ALR)
When a passenger’s sh oulder belt is com-
pletely extended and then retracted even
slightly, the belt is locked in that position and
cannot be extended. This feature is used to
hold the child restraint system (CRS) firmly.
To free the belt again, fully retract the belt
and then pull the belt out once more.
(  P.45) The front seat belt buckles move out-
ward automatically for easier access. 
When entering the vehicle
When a front door is opened, the seat
belt buckle for the corresponding seat
will move outward automatically. The
buckle will retract automatically after
the plate is inserted and locked to the
buckle. 
When exiting the vehicle (driver’s
seat only)
If the engine switch is turned off when
the driver’s seat belt is fastened, the
driver’s seat belt buckle will move out-
ward. The buckle will retract automati-
cally when the driver’s seat belt is
released. *
: If equipped
■
Easy Access Buckle ●
When the seat belt buckle is in the out-
ward position and not latched, if the front
passenger’s seat is not occupied and the
vehicle is driven, the seat belt buckle will
return to its original position. ●
If an occupant exits the vehicle and leaves
the front door open and then enters the
vehicle again, the seat belt buckle will not
operate until the door is closed and then
opened again.
■
Customization
Some functions can be customized.
(  P.466)NOTICE■
When using a seat belt extender
When releasing the se at belt, press on
the buckle release button on the
extender, not on the seat belt.
This helps prevent damage to the vehicle
interior and the extender itself.
Fastening and releasing the seat
belt
AEasy Access Buckle (front
seats) *

271-1. For safe use
LS500_OM_(U)_1810 1
For safety and security 1 Push the seat belt shoulder anchor
down while pressing the release
button .
2 Push the seat belt shoulder anchor
up.Move the height adjuster up and down as
needed until yo u hear a click. The pretensioners help the seat belts to
quickly restrain the occupants by
retracting the seat belts when the vehi-
cle is subjected to certain types of
severe frontal or side collision or a
vehicle rollover. The pretensioners do not activate in the
event of a minor frontal impact, a minor
side impact or a rear impact.
■
Replacing the belt after the preten-
sioner has been activated
If the vehicle is involved in multiple colli-
sions, the pretensioner will activate for the
first collision, but will not activate for the
second or subsequent collisions.Adjusting the seat belt shoulder
anchor height (front seats)
WARNING■
Adjustable shoulder anchor
Always make sure th e shoulder belt is
positioned across the center of your
shoulder. The belt should be kept away
from your neck, but not falling off your
shoulder. Failure to do so could reduce
the amount of protection in an accident
and cause death or serious injuries in the
event of a sudden stop, sudden swerve or
accident. A Seat belt pretensioners (front
and outboard rear seats)
WARNING
■
Seat belt pretensioners
Observe the following precautions to
reduce the risk of in jury in the event of
sudden braking, sudden swerving or an
accident.
Failure to do so may cause death or seri-
ous injury.

28 1-1. For safe use
LS500_OM_(U)_1810 When the vehicle speed reaches
approximately 12 mph (20 km/h) or
higher, the seat belts will retract slightly
to remove any slack.
If the system determines that a collision
is unavoidable, the front seat belts will
retract before the collision. (  P.205)■
Pre-collision seat belts with comfort
function
A motor sound may be heard when a front
seat belt is released or a front door is
opened. This does not indicate a malfunc-
tion.
■
Customization
Some functions can be customized.
(  P.466) WARNING●
Do not place anything, such as a cush-
ion, on the front passenger’s seat.
Doing so will disperse the passenger’s
weight, which prevents the sensor
from detecting the passenger’s weight
properly. As a result , the seat belt pre-
tensioner for the front passenger’s seat
may not activate in the event of a colli-
sion.●
If the pretensioner has activated, the
SRS warning light will come on. In that
case, the seat belt cannot be used
again and must be replaced at your
Lexus dealer.
Pre-collision seat belts with com-
fort function (front seats of vehi-
cles with Lexus Safety System +
A)
