2474-5. Using the driving support systems
LS500_OM_(U)_1810 4
Driving *
:If equipped
The RSA system recognizes specific
road signs using the front camera
and/or navigation system (when data is
available) to provide information to the
driver via the display.
When the front camera recognizes a
sign and/or informat ion of a sign is available from navigation system, the
sign will be displayed on the
multi-information display.
 When the Driving support system
information display is selected, a
maximum of 3 signs can be dis-
played. (  P.80)
 When a tab other than the Driving
support system information display
is selected, only a recognized speed
limit sign or do not enter sign (when
notification is necessary) will be dis-
played. (  P.80)
If signs other than speed limit signs are rec-
ognized, they will be displayed in an over-
lapping stack under th e current speed limit
sign.
The following types of ro ad signs are recognized.
A non-official or recently introduced traffic signs may not be recognized.RSA (Road Sign Assist) *
Summary of function
WARNING■
Before using the RSA
Do not rely solely upon the RSA system.
RSA is a system which supports the
driver by providing information, but it is
not a replacement for a driver’s own
vision and awareness. Drive safely by
always paying careful attention to the
traffic rules.
Indication on the multi-informa-
tion display
Supported types of road signs

304 5-1. Remote Touch/Display
LS500_OM_(U)_1810 5-1.Remote Touch/Display
■
Switches
“MAP” buttonVehicles with navigation function:
Press this button to display the vehicle’s
current position.
Vehicles without navigation function:
Press this button to display the compass
mode screen.
“MENU” buttonPress this button to display the menu
screen.
Back buttonPress this button to display the previous
screen.
TouchpadSlide your finger on the touchpad and
move the pointer to select a function, letter
and screen button.
Press the touchpad to enter the selected function, letter or screen button. Certain
finger movements on the touchpad can
perform functions, su ch as changing map
scalings and scrolling list screens.
Sub function button When is displayed on the screen, a
function screen assigned to the screen can
be displayed. ■
Using the touchpad
1 Select: Touch the touchpad to
select the desired button on the
screen.
2 Enter: Buttons on the screen can be
selected by either depressing or
double tapping the touchpad.
Once a button has been selected,
the screen will change. ■
Touch operation
Operations are performed by touching
the touchpad with your finger.
 Trace Trace the pad surface while maintaining
contact with the touchpad. Moving the
cursor and the pointer.Remote Touch The Remote Touch can be used to
operate the Center Display.
For details on the Remote touch,
refer to “NAVIGATION AND
MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
Remote Touch operation
A
B
C
D E

306 5-1. Remote Touch/Display
LS500_OM_(U)_1810 ■
Menu screen
Press the “MENU” button on the
Remote Touch to display the menu
screen.
The displays shown in the illustrations
are used for example only and may dif-
fer from the actual vehicle. *1
: Refer to the “NAVIGATION AND
MULTIMEDIA SYSTEM OWNER’S
MANUAL”. *2
: This function is not available on some
models.
■
Split-screen display
Different information can be displayed on the left and right sides of the screen. For
example, air conditioning system screen can be displayed and operated while the
fuel consumption information screen is be ing displayed. The large screen on the Center Display
Center Display overview
Switch Function
Select to display the
“Destination”
screen. *1
Select to display the
media control
screen or the audio
control screen. *1
Select to display the
hands-free control
screen. *1 Select to display the
“Apps” screen. *1, 2
When an Apple
CarPlay connection
is established and
button displays
“Apple CarPlay”,
select to display the
home screen of
Apple CarPlay. *1, 2
Select to display the
information screen. *1

(  P.91)
Select to display the
setup screen. *1
Select to display the
air conditioning con-
trol screen.
(  P.316)Switch Function

3075-1. Remote Touch/Display
LS500_OM_(U)_1810 5
Interior features left of the display is called the main display, and the small screen to the right is
called the side display.
■
Main display
For details about the functions and
operation of the main display, refer to
the respective section and “NAVIGA-
TION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”. ■
Side display
The following functions can be dis-
played and operated on the side dis-
play.
Select or to display the desired
screen.
Navigation system *
Audio * Vehicle information (  P.93)
Air conditioning system (  P.319)
Show/hide the side display **
: Refer to the “NAVIGATION AND
MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
■
Screen display during low temperatures
When the ambient temperature is
extremely low, screen response may be
delayed even if the Remote Touch is oper-
ated.
A
B C
D
E

308 5-1. Remote Touch/Display
LS500_OM_(U)_1810 *
:If equipped
■
Home screen
Touch to display the audio control
screen.
Refer to “NAVIGATION AND
MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
Touch to display the rear air condi-
tioning control screen. (  P.324)
Touch to display the rear seat
adjustment screen. (  P.126)
Touch to display the relaxation seat
(if equipped) control screen.
(  P.129) Touch to display the rear sunshade
(if equipped)/rear interior light con-
trol screen. (  P.347)
Touch to display the Rear Multi
Operation Panel settings screen.
(  P.308)
Rear Multi Operation Panel unlock
button
Touch and hold until the unlock sta-
tus indicators are completely illumi-
nated to unlock the Rear Multi
Operation Panel.
Touch “Screen Lock” to lock the
Rear Multi Operation Panel sys-
tem. (  P.308)
Shortcut button
Shortcut screen is displayed. Touch
to display/hide commonly used
buttons for a selected mode on the
bottom portion of the screen.
button
Press to display the home screen.
When the screen is on, press and
hold to turn the screen off. ■
Rear Multi Operation Panel set-
tings screen
Screen operation settings and the
brightness of the screen can be
changed.Rear Multi Operation Panel *
The Rear Multi Operation Panel
built-into the rear armrest can be
used to operate the rear audio sys-
tem, air conditioning system, seat,
relaxsation, shade or lamp.
Rear Multi Operation Panel
overview
A
B
C
D E
F
G
H
I

3155-3. Using the air conditio ning system and defogger
LS500_OM_(U)_1810 5
Interior features ●
When the engine switch is turned off, the
current air conditioning settings will auto-
matically be registered to the electronic
key that was used to unlock the vehicle.●
The system may not operate correctly if
more than one electr onic key is in the
vicinity or if the smart access system with
push-button start is used to unlock a pas-
senger door.●
The doors that can recall the air condi-
tioning setting *
when unlocked using the
smart access system with push-button
start can be changed. For details, contact
your Lexus dealer. *
: The doors that can recall the driving
position memory are changed at the
same time.■
Operation of the air conditioning sys-
tem in Eco drive mode
In Eco drive mode, the air conditioning sys-
tem is controlled as follows to prioritize fuel
efficiency: ●
Engine speed and compressor operation
controlled to restri ct heating/cooling
capacity●
Fan speed restricted when automatic
mode is selected
To improve air condit ioning performance,
perform the following operations: ●
Turn off eco air conditioning mode
(  P.316) ●
Adjust the fan speed●
Turn off Eco drive mode (  P.289)
■
When the outside temperature falls to
nearly 32°F (0°C)
The dehumidification function may not
operate even when “A/C” is selected.
■
Ventilation and air conditioning odors
●
To let fresh air in, set the air conditioning
system to the outside air mode.
●
During use, various odors from inside and
outside the vehicle may enter into and
accumulate in the air conditioning sys-
tem. This may then cause odor to be
emitted from the vents.
●
To reduce potential odors from occur- ring:
• It is recommended that the air condition-
ing system be set to outside air mode
prior to turning the vehicle off.
• The start timing of the blower may be
delayed for a short pe riod of time imme-
diately after the air conditioning system is
started in automatic mode or with the
micro dust and pollen filter on. ●
When parking, the system automatically
switches to outside air mode to encour-
age better air circulation throughout the
vehicle, helping to reduce odors that
occur when starting the vehicle. ■
Using the voice command system
Air conditioning system can be operated
using voice commands. For details, refer to
the “NAVIGATION AND MULTIMEDIA
SYSTEM OWNER’S MANUAL”. ■
Air conditioning filter
 P.398 ■
Customization
Some functions can be customized.
(  P.466)
WARNING■
To prevent the windshield from fog-
ging up
Do not use the windshield defogger
switch during cool air operation in
extremely humid weather. The difference
between the temperature of the outside
air and that of the windshield can cause
the outer surface of the windshield to fog
up, blocking your vision.
■
When the outside rear view mirror
defoggers are operating
Do not touch the outside rear view mir-
ror surfaces, as they can become very
hot and burn you.

466 8-2. Customization
LS500_OM_(U)_1810 8-2.Customization
■
Changing by using the meter con-
trol switches
1 Press or to select .
2 Operate the meter control
switches to select the desired item
to be customized.
3 According to the display, select the
desired setting and then press .To go back to the previous screen or exit
the customize mode, press .
■
Changing by using the Remote
Touch
1 Press the “MENU” button on the
Remote Touch.
2 Select “Setup” on the menu screen
and select “Vehicle”.
3 Select “Vehicle Customization” or
“Drive Mode Customization”.Various setting can be changed. Refer to
the list of settings that can be changed for
details.
For details on the Remote Touch, refer
to the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S MAN- UAL”. ■
Changing by using the Rear Multi
Operation Panel (if equipped)
1 Display the home screen on the
Rear Multi Operation Panel and
then touch “Settings”.
2 Touch “Seat”.
3 Select the desired setting. ■
When customizing using the Remote
Touch
Stop the vehicle in a safe place, apply the
parking brake, and shift the shift position to
P. Also, to prevent battery discharge, leave
the engine running while customizing the
features.Customizable features Your vehicle includes a variety of
electronic features that can be per-
sonalized to your preferences. The
settings of these features can be
changed by using the meter control
switches, the Remote Touch, Rear
Multi Operation Panel or at your
Lexus dealer.
Customizing vehicle features WARNING■
During customization
As the engine needs to be running
during customization, ensure that the
vehicle is parked in a place with ade-
quate ventilation. In a closed area such as
a garage, exhaust gases including harm-
ful carbon monoxide (CO) may collect
and enter the vehicle. This may lead to
death or a serious health hazard.
NOTICE
■
During customization
To prevent battery discharge, ensure that
the engine is running while customizing
features.

5011-1. What to do if... (Troubleshooting)
LS500_OM_(U)_1810 501Alphabetical Index
Front side marker light
Light switch ..................................................... 179
Replacing light bulbs................................404
Front turn signal lights
Replacing light bulbs................................404
Turn signal lever ........................................... 173
Fuel
Capacity ......................................................... 447
Fuel gauge ............................................... 73, 76
Fuel pump shut off system ...................... 414
Information ....................................................455
Refueling ......................................................... 189
Type.................................................................. 447
Warning light ................................................ 418
Fuel consumption
Average fuel economy .............................. 82
Current fuel consumption........................ 82
Fuel filler door
If the fuel filler door cannot be opened
......................................................................... 432
Refueling ......................................................... 189
Fuel gauge ..................................................73, 76
Fuel pump shut off system..........................414
Fuses .................................................................. 401
G
Garage door opener ................................. 350
Gauges ........................................................73, 76
Gear Position................................................... 84
G-force............................................................... 84
Glove box ....................................................... 336
Glove box light ............................................. 337
H
Hands Free Power Trunk Lid ...................107
Head restraints ...............................................135
Headlights
Adaptive Front-lighting System (AFS)
............................................................................ 181
Automatic High Beam system..............182
Light switch ..................................................... 179 Replacing light bulbs ............................... 404
Head-up display.............................................. 87
Driving information display area ........... 87
Driving support system display area ..90
Eco Driving Indicator....................................91
HUD (Head-up display) switch ............89
Navigation system-linked display ........ 87
Pop-up display ...............................................90
Settings...............................................................89
Heated steering wheel .............................. 326
Heaters
Front automatic air conditioning system
........................................................................... 313
Heated steering wheel ............................326
Outside rear view mirrors.......................314
Rear automatic air conditioning system
.......................................................................... 323
Seat heaters ..................................................326
Height control
Electronically modulated air suspension
.......................................................................... 292
Hill-start assist control ............................... 295
Hood
Open..................................................................371
Pop Up Hood.................................................38
Hooks
Coat hooks ................................................... 344
Retaining hooks (floor mat) ..................... 22
Horn ................................................................... 138
HUD (Head-up display) switch ................ 89
I
I/M test ............................................................ 368
Identification
Engine.............................................................. 447
Vehicle ............................................................446
Ignition switch (engine switch).................164
Auto power off function........................... 166
Changing the engine switch modes . 166
If your vehicle has to be stopped in an
emergency ................................................ 406
Indicators ........................................................... 70
