702-1. Instrument cluster
■Locations of gauges and meters
The units of measure may differ depending on the intended destination of the vehicle.
Multi-information display
Presents the driver with a variety of vehicle data ( P.73)
Displays warning messages if a malfunction occurs (P.368)
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C)
Low outside temperature indicator comes on wh en the ambient temperature is 37°F (3°C)
or lower
Hybrid System Indicator
Displays hybrid system outp ut or regeneration level (P.71)
This display changes to a tachometer depending on the driving mode, and can be set to
show the tachometer in any driving mode on the settings display. (P.75, 202)
Speedometer
Clock
Time displayed is linked to the analog clock on the center panel. (P.272)
Engine coolant temperature gauge
Displays the engine coolant temperature
Fuel gauge
Displays the quantity of fuel remaining in the tank
Gauges and meters
Meter display
A
B
C
D
E
F
G

762-1. Instrument cluster
log.
Drive information 1/Drive informa-
tion 2
Select to select up to 2 items ( P.74) that
will be displayed on ea ch Drive information
screen (Drive information 1 screen and
Drive information 2 screen) respectively.
 Clock
Select to switch be tween 12-hour display
and 24-hour display.
 Pop-up display
Select to enable/disable pop-up displays
for each relevant system.
Accent color
Select to change the accent color on the
screen, such as the cursor color.
Tachometer setting
Select to set the display of the Hybrid Sys-
tem Indicator or tachometer for each driv-
ing mode.
EV indicator
Select to enable/disab le the EV indicator.
Default setting
Select to reset the meter display settings to
the default setting.
■Vehicle functions and settings that
can be changed
 P.412
■Suspension of the settings display
●Some settings cannot be changed while
driving. When changing settings, park
the vehicle in a safe place.
●If a warning message is displayed, opera-
tion of the settings display will be sus-
pended.
Displays suggestions to the driver in
the following situations. To select a
response to a displayed suggestion,
use the meter control switches.
■Suggestion to turn off the head-
lights
If the headlights are left on for a certain
amount of time with the headlight
switch in after the power switch
has been turned off, a suggestion mes-
sage will be displayed asking if you
wish to turn the headlights off.
To turn the headlight s off, select “Yes”.
If a front door is opened after the power
switch is turned off, this suggestion mes-
sage will not be displayed.
■Customization
Some functions can be customized.
(  P.412)
WARNING
■Cautions during setting up the dis-
play
As the hybrid system needs to be operat-
ing during setting up the display, ensure
that the vehicle is parked in a place with
adequate ventilation. In a closed area
such as a garage, ex haust gases includ-
ing harmful carbon monoxide (CO) may
collect and enter the vehicle. This may
lead to death or a serious health hazard.
NOTICE
■During setting up the display
To prevent 12-volt battery discharge,
ensure that the hybrid system is operat-
ing while setting up the display features.
Suggestion function

3827-2. Steps to take in an emergency
■Unlocking the door
1
Pull the driver’s door handle and
insert the mechanical key.
2
Unlock the door.
3
Remove the key, return the handle,
and then pull the handle again.
■Locking the door
1
With the door open, push down the
inside lock button.
2
Close the door.
■Opening the trunk
Turn the mechanical key clockwise to open.
■Key linked functions
1
Closes the windows and the moon roof
(turn and hold)
2
Opens the windows and the moon roof
(turn and hold)
These settings must be customized at your
Lexus dealer.
WARNING
■When using the mechanical key and
operating the power windows or
moon roof
Operate the power window after check-
ing to make sure that there is no possibil-
ity of any passenger having any of their
body parts caught in the window or
moon roof.
Also, do not allow children to operate the
mechanical key. It is possible for children
and other passengers to get caught in
the power window or moon roof.

4138-2. Customization
8
Vehicle specifications
Definition of symbols: O = Available,  = Not available
■Gauges, meters and multi-information display (P.70, 73)
*1: For details about each function: P.75
*2: The default setting varies according to country.
Function*1Default settingCustomized set-
ting
LanguageEnglishFrenchOOSpanish
Units*2miles (MPG)
km (km/L)
OOkm (L/100 km)
miles (MPG Impe- rial)
Drive information 1
Current fuel con-sumption
Customizable items:  P.74O
Average fuel econ-
omy (after reset)
Drive information 2
Distance (driving range)
Average vehicle
speed (after reset)
Clock12-hour display24-hour displayO
Pop-up displayOnOffO
Accent colorColor 1Color 2OO
Tachometer settingChange according to driving mode
Always tachome- ter
OAlways Hybrid
System Indicator
EV indicatorOnOffO
Suggestion functionOn
On (when the vehi- cle is stopped)
OO
Off
ABC

4228-2. Customization
unlocking the doors and the timer acti-
vated automatic door lock function acti-
vates, signals will be generated in
accordance with the operation buzzer
volume and operational signal (Emer-
gency flashers) function settings.
●Some settings can be changed using a
switch or the Center Display. If a setting is
changed using a switch, the changed set-
ting will not be reflected on the Center
Display until the power switch is turned
off and then to ON mode.
■Clock settings screen
If the clock adjustment screen is displayed
continuously when attempting to change
the clock settings, the system may be mal-
functioning. Have the vehicle inspected by
your Lexus dealer.

447What to do if... (Troubleshooting)Alphabetical index447
Master warning light .................................. 365
Menu icons.........................................................73
MeterClock .................................................................. 70
Hybrid System Indicator ............................. 71
Indicators .......................................................... 67
Instrument panel light control .................72
Meter control switches ...............................74
Meters ................................................................ 70
Multi-information display ...........................73
Settings .............................................................. 75
Warning lights ............................................ 358
Warning message.....................................368
Mirrors Inside rear view mirror............................... 116
Outside rear view mirror defoggers254
Outside rear view mirrors ........................117
Vanity mirrors...............................................272
Moon roof Door lock linked moon roof operation........................................................................... 123
Jam protection function............................ 123
Operation........................................................ 122
Multi-information display .............................73 Audio system-linked display................... 75
Drive information 1/Drive information 2.............................................................................74
Driving information display.......................74
Driving support system information dis- play ................................................................... 75
Dynamic radar cruise control with full- speed range ................................................187
Energy monitor................................................81
LTA (Lane-Tracing Assist) ...................... 181
Menu icons .......................................................73
Meter control switches ...............................74
Navigation system-linked display ........ 75
Pop-up display................................................73
Settings .............................................................. 75
Suggestion function..................................... 76
Tire pressure ................................................ 328
Warning message.....................................368N
Navigation system-linked display.....75, 77
Noise from under vehicle ...............................6
O
Odometer ..........................................................72
Odometer and trip meter display “ODO TRIP” switch .................................... 72
Display items ................................................... 72
Pop-up display ............................................... 72
“ODO TRIP”switch ........................................72
Oil Engine oil....................................................... 396
Opener Fuel filler door ................................................. 161
Hood ................................................................. 316
Trunk ................................................................... 97
Outer foot lights Replacing light bulbs ................................344
Outside door handle lig hts...................... 265
Outside rear view mirrors .......................... 117 Adjustment ....................................................... 117
BSM (Blind Sport Monitor)....................197
Folding................................................................ 118
Linked mirror functi on when reversing
............................................................................. 118
Mirror position memory ............................ 110
Outside rear view mirror defoggers254
RCTA function ............................................... 211
Outside temperature.................................... 70
Overheating ..................................................388
P
Paddle shift switches ..........................143, 144
Panic mode ....................................................... 89
Parking assist sensors (intuitive parking assist) ............................................................. 205
Parking brake..................................................146 Operation ....................................................... 146
Parking brake engaged warning buzzer............................................................................147
