2TABLE OF CONTENTS
For your information ......................................6
Reading this manual .................................... 10
How to search ................................................. 11
Pictorial index ................................................. 12
1-1. For safe use Before driving .................................... 22
For safe driving.................................. 23
Seat belts ............................................. 24
SRS airbags ....................................... 28
Front passenger occupant classifi- cation system ................................. 37
Exhaust gas precautions ................ 41
1-2. Child safety Riding with children......................... 42
Child restraint systems .................. 42
1-3. Hybrid system Hybrid system features ................. 53
Hybrid system precautions ......... 56
1-4. Theft deterrent system Immobilizer sy stem ........................ 60
Alarm..................................................... 62
2-1. Instrument cluster Warning lights and indicators .... 66
Gauges and meters ....................... 70
Multi-information display............. 73
Head-up display ............................... 77
Energy monitor/consumption screen ................................................ 813-1. Key information
Keys ...................................................... 88
3-2. Opening, closing and locking the doors and trunk
Doors ..................................................... 91
Trunk ..................................................... 95
Smart access system with push-but- ton start .......................................... 102
3-3. Adjusting the seats Front seats........................................ 109
Driving position memory ............ 110
Head restraints ................................ 113
3-4. Adjusting the steering wheel and mirrors
Steering wheel ................................. 115
Inside rear view mirror ................. 116
Outside rear view mirrors........... 117
3-5. Opening and closing the windows and moon roof
Power windows ............................. 120
Moon roof ......................................... 122
4-1. Before driving Driving the vehicle......................... 126
Cargo and luggage........................ 131
Vehicle load limits......................... 133
Trailer towing...................................134
Dinghy towing ................................. 134
4-2. Driving procedures Power (ignition) switch ............... 135
EV drive mode ............................... 139
1For safety and security
2Vehicle status information and
indicators
3Before driving
4Driving

231-1. For safe use
1
For safety and security
Adjust the angle of the seatback so
that you are sitting straight up and
so that you do not have to lean for-
ward to steer. (P.109)
Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the
elbow when gripping the steering
wheel. ( P.109)
Lock the head restraint in place
with the center of the head restraint
closest to the top of your ears.
( P.113)
Wear the seat belt correctly.
( P.25) Make sure that all occupants are wear-
ing their seat belts before driving the
vehicle. (
P.25)
Use a child restraint system appropri-
ate for the child until the child becomes
large enough to properly wear the
vehicle’s seat belt. ( P.42)
Make sure that you can see backward
clearly by adjusting the inside and out-
side rear view mirrors properly.
( P.116, 117)
For safe driving
For safe driving, adjust the seat and
mirror to an appropriate position
before driving.
Correct driving posture
WARNING
Observe the following precautions.
Failure to do so may result in death or
serious injury.
A
B
C
D
●Do not adjust the position of the
driver’s seat while driving.
Doing so could cause the driver to lose
control of the vehicle.
●Do not place a cushion between the
driver or passenger and the seatback.
A cushion may prevent correct pos-
ture from being achieved, and reduce
the effectiveness of the seat belt and
head restraint.
●Do not place anything under the front
seats.
Objects placed under the front seats
may become jammed in the seat
tracks and stop the seat from locking in
place. This may lead to an accident
and the adjustment mechanism may
also be damaged.
●Always observe the legal speed limit
when driving on public roads.
●When driving over long distances, take
regular breaks before you start to feel
tired.
Also, if you feel tired or sleepy while
driving, do not force yourself to con-
tinue driving and take a break immedi-
ately.
Correct use of the seat belts
Adjusting the mirrors

1173-4. Adjusting the steering wheel and mirrors
3
Before driving
When the automatic anti-glare function is
in ON mode, the indicator illuminates.
The function will set to ON mode each
time the power switch is turned to ON
mode.
Pressing the button turns the function to
OFF mode. (The indicator also turns
off.)
■To prevent sensor error
To ensure that the sensors operate properly,
do not touch or cover them.
1To select a mirror to adjust, press
the switch.
Left
Right
A
A
Outside rear view mirrors
The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.
WARNING
■Important points while driving
Observe the following precautions while
driving.
Failure to do so may result in loss of con-
trol of the vehicle and cause an accident,
resulting in death or serious injury.
●Do not adjust the mirrors while driving.
●Do not drive with the mirrors folded.
●Both the driver and passenger side
mirrors must be extended and prop-
erly adjusted before driving.
Adjustment procedure
A
B

1284-1. Before driving
WARNING
●During normal driving, do not turn off
the hybrid system. Turning the hybrid
system off while driving will not cause
loss of steering or braking control,
however, power assist to the steering
will be lost. This will make it more diffi-
cult to steer smoothly, so you should
pull over and stop the vehicle as soon
as it is safe to do so.
In the event of an emergency, such as if
it becomes impossible to stop the vehi-
cle in the normal way: P.350
●Use engine braking (downshift) to
maintain a safe speed when driving
down a steep hill.
Using the brakes continuously may
cause the brakes to overheat and lose
effectiveness. ( P.141)
●Do not adjust the positions of the
steering wheel, the seat, or the inside
or outside rear view mirrors while driv-
ing.
Doing so may result in a loss of vehicle
control.
●Always check that all passengers’
arms, heads or other parts of their
body are not outside the vehicle.
●Do not drive in excess of the speed
limit. Even if the legal speed limit per-
mits it, do not drive over 85 mph (140
km/h) unless your vehicle has high-
speed capability tires. Driving over 85
mph (140 km/h) may result in tire fail-
ure, loss of control and possible injury.
Be sure to consult a tire dealer to
determine whether the tires on your
vehicle are high-speed capability tires
or not before driving at such speeds.
■When driving on slippery road sur-
faces
●Sudden braking, acceleration and
steering may cause tire slippage and
reduce your ability to control the vehi-
cle.
●Sudden acceleration, engine braking
due to shifting, or changes in engine
speed could cause the vehicle to skid,
resulting in an accident.
●After driving through a puddle, lightly
depress the brake pedal to make sure
that the brakes are functioning prop-
erly. Wet brake pads may prevent the
brakes from functioning properly. If the
brakes on only one side are wet and
not functioning properly, steering con-
trol may be affected.
■When shifting the shift lever
●Do not let the vehicle roll backward
while the shift lever is in a driving posi-
tion, or roll forward while the shift lever
is in R.
Doing so may result in an accident or
damage to the vehicle.
●Do not shift the shif t lever to P while
the vehicle is moving.
Doing so can damage the transmission
and may result in a loss of vehicle con-
trol.
●Do not shift the shift lever to R while
the vehicle is moving forward.
Doing so can damage the transmission
and may result in a loss of vehicle con-
trol.
●Do not shift the shift lever to a driving
position while the vehicle is moving
backward.
Doing so can damage the transmission
and may result in a loss of vehicle con-
trol.
●Shifting the shift lever to N while the
vehicle is moving will disengage the
hybrid system. Engine braking is not
available when N is selected.
●Be careful not to shift the shift lever
with the accelerator pedal depressed.
Shifting the shift lever to a gear other
than P or N may lead to unexpected
rapid acceleration of the vehicle that
may cause an accident and result in
death or serious injury.

2555-3. Using the air conditioning system
5
Interior features
ditioning setting depending on the
temperature setting or inside tempera-
ture.
■Registering air conditioning settings to
electronic keys
●Unlocking the vehicle using an electronic
key and turning the power switch to ON
mode will recall that key’s registered air
conditioning settings.
●When the power switch is turned off, the
current air conditioning settings will auto-
matically be registered to the electronic
key that was used to unlock the vehicle.
●The system may not operate correctly if
more than one electronic key is in the
vicinity or if the smart access system with
push-button start is used to unlock the
passenger door.
●Vehicles with the driving position mem-
ory: The doors that can recall the air con-
ditioning setting
* when unlocked using
the smart access system with push-but-
ton start can be changed. For details,
contact your Lexus dealer.
*: The doors that can recall the driving posi-
tion memory are changed at the same
time.
■Operation of the air conditioning sys-
tem in Eco drive mode
In Eco drive mode, the air conditioning sys-
tem is controlled as follows to prioritize fuel
efficiency:
●Engine speed and compressor operation
controlled to restri ct heating/cooling
capacity
●Fan speed restricted when automatic
mode is selected
To improve air conditioning performance,
perform the following operations:
●Turn off eco air conditioning mode
(  P.255)
●Adjust the fan speed
●Turn off Eco drive mode ( P.202)
■When the outside temperature falls to
nearly 32°F (0°C)
The dehumidification function may not operate even when “A/C” is selected.
■Ventilation and air conditioning odors
●To let fresh air in, set the air conditioning
system to the outside air mode.
●During use, various odors from inside and
outside the vehicle may enter into and
accumulate in the air conditioning sys-
tem. This may then cause odor to be
emitted from the vents.
●When parking, the system automatically
switches to fresh air intake mode to
encourage better air circulation through-
out the vehicle, helping to reduce odors
that occur when starting the vehicle.
■Using the voice command system
Air conditioning system can be operated
using voice commands. For details, refer to
the “NAVIGATION AND MULTIMEDIA
SYSTEM OWNER’S MANUAL”.
■Air conditioning filter
 P.338
■Customization
Settings (e.g. A/C Auto switch operation)
can be changed.
(Customizable features P.412)
WARNING
■To prevent the windshield from fog-
ging up
Do not use the windshield defogger
switch during cool air operation in
extremely humid weather. The difference
between the temperature of the outside
air and that of the windshield can cause
the outer surface of the windshield to fog
up, blocking your vision.
■When the outside rear view mirror
defoggers are operating
Do not touch the outside rear view mir-
ror surfaces, as they can become very
hot and burn you.

442Alphabetical index
Exterior .......................................................... 300
Interior .............................................................303
Seat belts........................................................303
Cargo capacity...............................................133
Cargo hooks ................................................... 271
Center Display ............................................. 246
Chains .............................................................. 243
Child-protectors............................................. 94
Child restraint system................................... 42 Fixed with a LATCH system .................. 49
Fixed with a seat belt................................... 46
Front passenger occupant classification system ..............................................................37
Points to remember .....................................42
Riding with children ......................................42
Types of child restraint system installation method ........................................................... 43
Using an anchor bracket ............................ 51
Child safety ....................................................... 42 12-volt battery precautions ....... 324, 387
Airbag precautions...................................... 33
Child restraint system................................. 43
Heated steering wheel and seat heater
precautions.................................................. 261
How your child should wear the seat belt ............................................................................ 25
Moon roof precautions ............................ 123
Power window lock switch.......................121
Power window precautions .....................121
Rear door child-protectors ..................... 94
Removed electronic key battery precau- tions ...............................................................340
Seat belt extender precautions ............. 25
Seat belt precautions ...................................42
Trunk precautions ........................................ 95
Cleaning.............................................. 300, 303 Aluminum wheels ..................................... 300
Exterior .......................................................... 300
Interior .............................................................303
Radar sensor.......................................163, 198
Seat belts........................................................303
Clock ........................................................ 70, 272 Coat hooks..................................................... 283
Compass ......................................................... 289
Condenser .......................................................321
Console box .................................................. 269
Console box light ........................................ 269
Cooling system............................................. 320
Engine overheating.................................. 389
Hybrid system overheating ................. 390
Cornering lights .............................................152 Replacing light bulbs ................................344
Cruise control Dynamic radar cruise control with full-
speed range ............................................... 187
Cup holder ..................................................... 269
Current fuel consumption ...........................74
Curtain shield airbags .................................. 28
Customizable features ................................ 412
D
Daytime running light system .................. 150
Defogger Outside rear view mirrors.....................254
Rear window ................................................254
Windshield ....................................................254
Dimension ...................................................... 394
Dinghy towing.................................................134
Display BSM (Blind Spot Monitor)......................197
Dynamic radar cruise control with full-
speed range ............................................... 187
Energy monitor ............................................... 81
Head-up display.............................................77
Intuitive parking assist ............................. 205
LTA (Lane-Tracing Assist) ...................... 181
Multi-information display .......................... 73
Parking Support Brake function (rear
pedestrians)............................................... 233
RCD (Rear Camera Detection) ......... 215
RCTA.................................................................. 211
Warning message .................................... 368
Distance until next engine oil change .....72
Do-it-yourself maintenance ..................... 310
