2019 INFINITI QX30 warning

Lumbar support:
The lumbar support feature provides lower
back support to the driver.
Push each side of the adjusting switch to
adjust the seat lumbar area until the desired
position is achieved.
1To raise the seatback contour
2To soften the seatback contour
3To lower the seatback contour
4To harden the seatback contour
REAR SEATS
WARNING
•Never allow anyone to ride in the cargo
area or on the rear seat when it is in the
fold-down position. Use of these areas
by passengers without proper restraints
could result in serious injury or death in
an accident or sudden stop.
•Properly secure all cargo with ropes or
straps to help prevent it from sliding or
shifting. Do not place cargo higher than
the seatbacks. In a sudden stop or colli-
sion, unsecured cargo could cause per-
sonal injury.
•Do not allow people to ride in any area of
your vehicle that is not equipped with
seats and seat belts. Be sure everyone in
your vehicle is in a seat and using a seat
belt properly.
•Do not allow more than one person to
use the same seat belt.
•Do not fold down the rear seats when
occupants are in the rear seat area or
any luggage is on the rear seats.
–Make sure that the seat path is clear
before moving the seat.
–Be careful not to allow hands or feet
to get caught or pinched in the seat.
•Head restraints/headrests should be
adjusted properly as they may provide
significant protection against injury in
an accident. Always replace and adjust
them properly if they have been re-
moved for any reason.
•If the head restraints/headrests are re-
moved for any reason, they should be
securely stored to prevent them from
causing injury to passengers or damage
to the vehicle in case of sudden braking
or an accident.
•When returning the seatbacks to the
upright position, be certain they are
completely secured in the latched posi-
tion. If they are not completely secured,
passengers may be injured in an accident
or sudden stop.
NIC2607
Safety — seats, seat belts and supplemental restraint system1-5

Folding
The luggage compartment loading capacity
can be increased by folding the rear seat-
backs forward.
To fold the seatback:
1. Ensure head restraints are properly
stowed, see "Head restraints/Headrests"
later in this section.
2. Move the front driver or passenger seat
forward if necessary.
3. Release the seatback lock by pulling the
release handle as shown.
4. Fold the seatback forward as shown.5. Insert the seat belt into the seat belt
holder as shown.
6. Move the front driver or passenger seat
back if necessary. Avoid contact between
the rear seat and the front seat.
To return the seatback to an upright posi-
tion:
1. Move the front driver or passenger seat
forward if necessary.
2. Make sure the seat belts are clear of the
seatback latch mechanism.
3. Lift the seatback up and push firmly to
lock.
4. If the red marker is visible then the seat-
back has not latched properly — release
and then re-latch the seat.5. If the head restraint/headrest was re-
moved, reinstall and properly adjust the
head restraint/headrest before an occu-
pant uses the seating position. See "Head
restraints/Headrests" later in this section.
WARNING
Always use the seat belt holder, and ensure
that the seat belt is not trapped in the seat-
back latch mechanism. Failure to do so may
cause damage to the seat belt, and this may
increase the risk of serious injury or death
in a collision.
NPA1293NIC2669
1-6Safety — seats, seat belts and supplemental restraint system

ARMREST (IF EQUIPPED)
Rear
Pull the tab and draw the armrest1forward
as shown until it is horizontal.
Indicates that the seating position is
equipped with a head restraint.
Indicates that the seating position is
equipped with a non-removable head rest.
WARNING
Head restraints/headrests supplement the
other vehicle safety systems. They may
provide additional protection against in-
jury in certain rear end collisions. Adjust-
able head restraints/headrests must be
adjusted properly, as specified in this sec-
tion. Check the adjustment after someone
else uses the seat. Do not attach anything
to the head restraint/headrest stalks or
remove the head restraint/headrest. Do
not use the seat if the head restraint/
headrest has been removed. If the head
restraint/headrest was removed, reinstalland properly adjust the head restraint/
headrest before an occupant uses the seat-
ing position. Failure to follow these in-
structions can reduce the effectiveness of
the head restraints/headrests. This may
increase the risk of serious injury or death
in a collision.
•Your vehicle is equipped with head
restraints/headrests that may be inte-
grated, adjustable or non-adjustable.
•Adjustable head restraints/headrests have
multiple notches along the stalk to lock them
in a desired adjustment position.
•The non-adjustable head restraints/
headrests have a single locking notch to
secure them to the seat frame.
•Proper Adjustment:
– For the adjustable type, align the head
restraint/headrest so the center of your
ear is approximately level with the cen-
ter of the head restraint/headrest.
– If your ear position is still higher than
the recommended alignment, place the
head restraint/headrest at the highest
position.
NIC2611NPA1500
HEAD RESTRAINTS/HEADRESTS
Safety — seats, seat belts and supplemental restraint system1-7

WARNING
•Every person who drives or rides in this
vehicle should use a seat belt at all times.
Children should be in the rear seats and
in an appropriate restraint.
SSS0134AZ
Sit upright and well back
SSS0136AZ
Sit upright and well back
SSS0016Z
SSS0014Z
Safety — seats, seat belts and supplemental restraint system1-11

•The seat belt should be properly ad-
justed to a snug fit. Failure to do so may
reduce the effectiveness of the entire
restraint system and increase the
chance or severity of injury in an acci-
dent. Serious injury or death can occur if
the seat belt is not worn properly.
•Always route the shoulder belt over
your shoulder and across your chest.
Never put the belt behind your back, un-
der your arm or across your neck. The
belt should be away from your face and
neck, but not falling off your shoulder.
•Position the lap belt as low and snug as
possible AROUND THE HIPS, NOT THE
WAIST. A lap belt worn too high could
increase the risk of internal injuries in an
accident.
•Be sure the seat belt tongue is securely
fastened to the proper buckle.
•Do not wear the seat belt inside out or
twisted. Doing so may reduce its effec-
tiveness.
•Do not allow more than one person to
use the same seat belt.
•Never carry more people in the vehicle
than there are seat belts.
•If the seat belt warning light glows con-
tinuously while the ignition is turned ON
with all doors closed and all seat belts
fastened, it may indicate a malfunction
in the system. Have the system checked.
It is recommended that you visit an
INFINITI retailer for this service.
•No changes should be made to the seat
belt system. For example, do not modify
the seat belt, add material or install de-
vices that may change the seat belt
routing or tension. Doing so may affect
the operation of the seat belt system.
Modifying or tampering with the seat
belt system may result in serious per-
sonal injury.
•Once a seat belt pretensioner has acti-
vated, they cannot be reused and must
be replaced together with the retractor.
It is recommended that you visit an
INFINITI retailer for this service.
•All seat belt assemblies, including re-
tractors and attaching hardware,
should be inspected after any collision.
It is recommended that you visit an
INFINITI retailer for this service.
INFINITI recommends that all seat belt
assemblies in use during a collision be
replaced unless the collision was minor
and the belts show no damage and con-tinue to operate properly. Seat belt as-
semblies not in use during a collision
should also be inspected and replaced if
either damage or improper operation is
noted.
•All child restraints and attaching hard-
ware should be inspected after any col-
lision. Always follow the restraint
manufacturer’s inspection instructions
and replacement recommendations. The
child restraints should be replaced if
they are damaged.
PREGNANT WOMEN
INFINITI recommends that pregnant women
use seat belts. The seat belt should be worn
snug, and always position the lap belt as low
as possible around the hips, not the waist.
Place the shoulder belt over your shoulder
and across your chest. Never put the lap/
shoulder belt over your abdominal area. Con-
tact your doctor for specific recommenda-
tions.
INJURED PERSONS
INFINITI recommends that injured persons
use seat belts. Check with your doctor for
specific recommendations.
1-12Safety — seats, seat belts and supplemental restraint system

SEAT BELT WARNING LIGHT
The seat belt warning light reminds you to
fasten your seat belts. The light illuminates if
the engine is started, all doors are closed and
the driver’s and/or front passenger’s seat
belt is unfastened. It will remain illuminated
until the driver and/or front passenger fas-
tens their seat belt. A chime will sound once
the vehicle is in motion.
If the seat belt warning light flashes, together
with an intermittent warning tone, this means
that the driver or passenger has not fastened
their seat belt, and the speed of the vehicle is
exceeding 15 MPH (25 km/h).
For additional information, refer to "Warning
lights, indicator lights and audible reminders".
THREE-POINT TYPE SEAT BELT
WITH RETRACTOR
WARNING
•Every person who drives or rides in this
vehicle should use a seat belt at all times.
Children should be in the rear seats and
in an appropriate restraint.
•Do not ride in a moving vehicle when the
seatback is reclined. This can be danger-
ous. The shoulder belt will not be against
your body. In an accident, you could be
thrown into it and receive neck or other
serious injuries. You could also slide un-
der the lap belt and receive serious inter-
nal injuries.
•For the most effective protection when
the vehicle is in motion, the seat should
be upright. Always sit well back and up-
right in the seat with both feet on the
floor and adjust the seat belt properly.
•Do not allow children to play with the
seat belts. Most seating positions are
equipped with Automatic Locking Re-
tractor (ALR) mode seat belts. If the
seat belt becomes wrapped around a
child’s neck with the ALR mode acti-
vated, the child can be seriously injured
or killed if the seat belt retracts and be-
comes tight. This can occur even if the
vehicle is parked. Unbuckle the seat belt
to release the child. If the seat belt can-
not be unbuckled or is already unbuck-
led, release the child by cutting the seat
belt with a suitable tool (such as a knife
or scissors) to release the seat belt.
Fastening the seat belts
1. Adjust the seat. (See "Seats" earlier in this
section.)
2. Slowly pull the seat belt out of the retrac-
tor and insert the tongue into the buckle
until you hear and feel the latch engage.
NIC2743
Safety — seats, seat belts and supplemental restraint system1-13

•The retractor is designed to lock dur-
ing a sudden stop or on impact. A slow
pulling motion permits the belt to
move and allows you some freedom of
movement in the seat.
•If the seat belt cannot be pulled from
its fully retracted position, firmly pull
the belt and release it. Then smoothly
pull the belt out of the retractor.
3. Position the lap belt portionlow and snug
on the hipsas shown4. Pull the shoulder belt portion toward the
retractor to take up extra slack. Be sure
the shoulder belt is routed over your
shoulder and across your chest.
The front passenger seat and the rear seating
positions three-point seat belts have two
modes of operation:
•Emergency Locking Retractor (ELR)
•Automatic Locking Retractor (ALR)
The ELR mode allows the seat belt to extend
and retract to allow the driver and passen-
gers some freedom of movement in the seat.
The ELR locks the seat belt when the vehicle
slows down rapidly or during certain impacts.The ALR mode (child restraint mode) locks
the seat belt for child restraint installation.
When the ALR mode is activated, the seat
belt cannot be extended again until the seat
belt tongue is detached from the buckle and
fully retracted. The seat belt returns to the
ELR mode after the seat belt fully retracts.
For additional information, refer to "Child
restraints" later in this section. The ALR mode
should be used only for child restraint instal-
lation. During normal seat belt use by an oc-
cupant, the ALR mode should not be acti-
vated. If it is activated, it may cause
uncomfortable seat belt tension. It can also
change the operation of the front passenger
air bag. For additional information, refer to
"Front passenger air bag and status light".
WARNING
When fastening the seat belts, be certain
that the seatbacks are completely secured
in the latched position. If they are not com-
pletely secured, passengers may be injured
in an accident or sudden stop.
SSS0292ZSSS0290Z
1-14Safety — seats, seat belts and supplemental restraint system

WARNING
•After adjustment, release the adjust-
ment button and then try to move the
shoulder belt down to make sure that it
is securely fixed in position.
•The shoulder belt anchor height should
be adjusted to the position that is best
for you. Failure to do so may reduce the
effectiveness of the entire restraint sys-
tem and increase the chance or severity
of injury in an accident.
SEAT BELT EXTENDERS
If, because of body size or driving position, it
is not possible to properly fit the lap/shoulder
belt and fasten it, an extender that is compat-
ible with the installed seat belts is available
that can be purchased. The extender adds
approximately 8 in (200 mm) of length and
may be used for either the driver or front
passenger seating position. It is recom-
mended you visit an INFINITI retailer for as-
sistance with purchasing an extender if an
extender is required.
WARNING
•Only INFINITI seat belt extenders, made
by the same company which made the
original equipment seat belts, should be
used with the INFINITI seat belts.
•Adults and children who can use the
standard seat belt should not use an ex-
tender. Such unnecessary use could re-
sult in serious personal injury in the
event of an accident.
•Never use seat belt extenders to install
child restraints. If the child restraint is
not secured properly, the child could be
seriously injured in a collision or a sud-
den stop.
SEAT BELT MAINTENANCE
•To clean the seat belt webbing,apply a
mild soap solution or any solution recom-
mended for cleaning upholstery or carpets.
Then wipe with a cloth and allow the seat
belts to dry in the shade. Do not allow the
seat belts to retract until they are com-
pletely dry.
•If dirt builds up in the shoulder belt guide
of the seat belt anchors, the seat belts may
retract slowly. Wipe the shoulder belt
guide with a clean, dry cloth.
•Periodically check to see that the seat belt
and the metal components, such as buck-
les, tongues, retractors, flexible wires and
anchors, work properly. If loose parts, de-
terioration, cuts or other damage on the
webbing is found, the entire seat belt as-
sembly should be replaced.
1-16Safety — seats, seat belts and supplemental restraint system
