GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-12460267) - 2019 - crc - 9/11/18
186 Lighting
change. This causes the turn
signals to automatically flash three
times. It will flash six times if Tow/
Haul Mode is active. Holding the
turn signal lever for more than
one second will cause the turn
signals to flash until the lever is
released.
The lever returns to its starting
position whenever it is released.
If after signaling a turn or a lane
change the arrows flash rapidly or
do not come on, a signal bulb could
be burned out.
Replace any burned out bulbs. If a
bulb is not burned out, check the
fuse. SeeFuses and Circuit
Breakers 0329.
Turn Signal On Chime
If the turn signal is left on for more
than 1.2 km (0.75 mi), a chime
sounds at each flash of the turn
signal. The message TURN
SIGNAL ON will also appear in the
Driver Information Center (DIC). To
turn the chime and message off,
move the turn signal lever to the off
position.Fog Lamps
If equipped with fog lamps, the
button is on the exterior lamp
control, to the left of the steering
column.
The ignition must be on for the fog
lamps to come on.
#: Press to turn the fog lamps on
or off. A light will come on in the
instrument cluster.
When the fog lamps are turned on,
the parking lamps automatically
turn on. When the headlamps are changed
to high beam, the fog lamps also go
off. When the high-beam headlamps
are turned off, the fog lamps will
come on again.
Some localities have laws that
require the headlamps to be on with
the fog lamps.

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-12460267) - 2019 - crc - 9/11/18
Vehicle Care 295
Vehicle Care
General Information
General Information . . . . . . . . . . 296
California Proposition65 Warning . . . . . . . . . . . . . . . . . 296
California Perchlorate Materials Requirements . . . . . 297
Accessories and Modifications . . . . . . . . . . . . . . . . 297
Vehicle Checks
Doing Your OwnService Work . . . . . . . . . . . . . . . 297
Hood . . . . . . . . . . . . . . . . . . . . . . . . . 298
Engine Compartment Overview . . . . . . . . . . . . . . . . . . . . 299
Engine Oil . . . . . . . . . . . . . . . . . . . . 302
Engine Oil Life System . . . . . . . 304
Automatic Transmission Fluid (6-Speed Transmission) . . . . . 305
Automatic Transmission Fluid (10 Speed Transmission) . . . 308
Engine Air Cleaner/Filter . . . . . . 309
Cooling System . . . . . . . . . . . . . . 310
Engine Overheating . . . . . . . . . . 313
Engine Fan . . . . . . . . . . . . . . . . . . . 315
Washer Fluid . . . . . . . . . . . . . . . . . 315
Brakes . . . . . . . . . . . . . . . . . . . . . . . 316 Brake Fluid . . . . . . . . . . . . . . . . . . . 317
Battery - North America . . . . . . 318
Four-Wheel Drive . . . . . . . . . . . . . 318
Front Axle . . . . . . . . . . . . . . . . . . . . 319
Rear Axle . . . . . . . . . . . . . . . . . . . . 320
Noise Control System . . . . . . . . 320
Starter Switch Check . . . . . . . . . 321
Automatic Transmission Shift
Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 322
Ignition Transmission Lock Check . . . . . . . . . . . . . . . . . . . . . . . 322
Park Brake and P (Park) Mechanism Check . . . . . . . . . . 322
Wiper Blade Replacement . . . . 323
Glass Replacement . . . . . . . . . . 324
Windshield Replacement . . . . . 324
Gas Strut(s) . . . . . . . . . . . . . . . . . . 324
Headlamp Aiming
Headlamp Aiming . . . . . . . . . . . . 325
Bulb Replacement
Bulb Replacement . . . . . . . . . . . . 326
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . . . . . . . 326
LED Lighting . . . . . . . . . . . . . . . . . 326
Fog Lamps . . . . . . . . . . . . . . . . . . . 326
Back-Up Lamps . . . . . . . . . . . . . . 327
License Plate Lamp . . . . . . . . . . 328
Electrical System
Electrical System Overload . . . 329
Fuses and Circuit Breakers . . . 329
Engine Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 330
Instrument Panel Fuse Block
(Right) . . . . . . . . . . . . . . . . . . . . . . 334
Instrument Panel Fuse Block (Left) . . . . . . . . . . . . . . . . . 337
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 339
Wheels and Tires
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 341
All-Season Tires . . . . . . . . . . . . . . 342
Winter Tires . . . . . . . . . . . . . . . . . . 342
Low-Profile Tires . . . . . . . . . . . . . 342
All-Terrain Tires . . . . . . . . . . . . . . . 343
Tire Sidewall Labeling . . . . . . . . 343
Tire Designations . . . . . . . . . . . . . 344
Tire Terminology andDefinitions . . . . . . . . . . . . . . . . . . 345
Tire Pressure . . . . . . . . . . . . . . . . . 348
Tire Pressure for High-Speed Operation . . . . . . . . . . . . . . . . . . . 349
Tire Pressure Monitor System . . . . . . . . . . . . . . . . . . . . . . 349
Tire Pressure Monitor Operation . . . . . . . . . . . . . . . . . . . 350
Tire Inspection . . . . . . . . . . . . . . . . 354

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-12460267) - 2019 - crc - 9/11/18
326 Vehicle Care
Bulb Replacement
For the proper type of replacement
bulbs, or any bulb changing
procedure not listed in this section,
contact your dealer.
Caution
Do not replace incandescent
bulbs with aftermarket LED
replacement bulbs. This can
cause damage to the vehicle
electrical system.
High Intensity Discharge
(HID) Lighting
{Warning
The High Intensity Discharge
(HID) lighting system operates at
a very high voltage. If you try to
service any of the system
components, you could be
seriously injured. Have your
dealer or a qualified technician
service them.
After an HID headlamp bulb has
been replaced, the beam might be a
slightly different shade than it was
originally. This is normal.
LED Lighting
This vehicle has several LED lamps.
For replacement of any LED lighting
assembly, contact your dealer.
Fog Lamps
To replace the front fog lamp bulb: 1. Locate the fog lamp under the front bumper.
2. Disconnect the electrical connector from the fog lamp
bulb assembly by pressing the
connector release.
3. Turn the bulb counterclockwise to remove it from the housing.

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./Cana-
da/Mexico-12460267) - 2019 - crc - 9/11/18
438 Index
Assistance Program,Roadside . . . . . . . . . . . . . . . . . . . . . . 415
Assistance Systems for Driving . . . . . . . . . . . . . . . . . . . . . . . . 260
Assistance Systems for Parking and Backing . . . . . . . . . . 256
Automatic
Dimming Mirrors . . . . . . . . . . . . . . . . 58
Door Locks . . . . . . . . . . . . . . . . . . . . . 45
Forward Braking . . . . . . . . . . . . . . 262
Headlamp System . . . . . . . . . . . . 184
Level Control . . . . . . . . . . . . . . . . . 245
Transmission . . . . . . . . . . . . . . . . . 228
Transmission Fluid . . . . . . 305, 308
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 231
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 322
Axle, Front . . . . . . . . . . . . . . . . . . . . . . 319
Axle, Rear . . . . . . . . . . . . . . . . . . . . . . 320
B
Battery Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 189
Load Management . . . . . . . . . . . . 188 Battery (cont'd)
Power Protection . . . . . . . . . . . . . 189
Battery - North America . . . . 318, 374
Blade Replacement, Wiper . . . . . 323
Blind Spot Mirrors . . . . . . . . . . . . . . . 58
Brake Pedal and AdjustableThrottle . . . . . . . . . . . . . . . . . . . . . . 216
System Warning Light . . . . . . . . 155
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 316 Antilock . . . . . . . . . . . . . . . . . . . . . . . 239
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 241
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 317
Parking . . . . . . . . . . . . . . . . . . . . . . . 240
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 201 Automatic Forward . . . . . . . . . . . 262
Break-In, New Vehicle . . . . . . . . . . 216
Bulb Replacement Back-up Lamps . . . . . . . . . . . . . . . 327
Fog Lamps . . . . . . . . . . . . . . . . . . . 326
Headlamp Aiming . . . . . . . . . . . . . 325
Headlamps . . . . . . . . . . . . . . . . . . . 326
High Intensity Discharge(HID) Lighting . . . . . . . . . . . . . . . 326
License Plate Lamps . . . . . . . . . 328
Buying New Tires . . . . . . . . . . . . . . . 357
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 136
California Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . 297
California Proposition
65 Warning . . . . . . . . . .296, 318, 374, Back Cover
Canadian Vehicle Owners . . . . . . . . 2
Capacities and
Specifications . . . . . . . . . . . . . . . . . 409
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 227
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 47
Winter Driving . . . . . . . . . . . . . . . . 209
Cargo Tie-Downs . . . . . . . . . . . . . . . . . . . . 129
Caution, Danger, and Warning . . . . 2
Center Console Storage . . . . . . . . 128
Center Seat . . . . . . . . . . . . . . . . . . . . . 67
Chains, Tire . . . . . . . . . . . . . . . . . . . . 361
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . 139
Charging System Light . . . . . . . . . 152
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 153

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./Cana-
da/Mexico-12460267) - 2019 - crc - 9/11/18
Index 441
FluidAutomatic
Transmission . . . . . . . . . . . 305, 308
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 317
Four-Wheel Drive Transfer Case . . . . . . . . . . . . . . . 234
Washer . . . . . . . . . . . . . . . . . . . . . . . 315
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 186 Bulb Replacement . . . . . . . . . . . . 326
Folding Mirrors . . . . . . . . . . . . . . . . . . 57
Forward Automatic Braking . . . . . 262
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 260
Four-Wheel Drive . . . . . . . . . . 234, 318
Four-Wheel-Drive Light . . . . . . . . . 156
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 421
Front Axle . . . . . . . . . . . . . . . . . . . . . . 319
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Front Seats
Heated and Ventilated . . . . . . . . . . 72
Fuel Additives . . . . . . . . . . . . . . . . . . . . . 270
Economy Driving . . . . . . . . . . . . . . . 27
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 272
Filling the Tank . . . . . . . . . . . . . . . 271 Fuel (cont'd)
Foreign Countries . . . . . . . . . . . . 270
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 147
Low Fuel Warning Light . . . . . . . 159
Management, Active . . . . . . . . . . 226
Prohibited Fuels . . . . . . . . . . . . . . 269
Recommended . . . . . . . . . . . . . . . 269
Top Tier . . . . . . . . . . . . . . . . . . . . . . 268
Full-Size Spare Tire . . . . . . . . . . . . 373
Fuses
Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 330
Fuses and Circuit Breakers . . . 329
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . 334, 337
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 339
G
Garage Door Opener . . . . . . . . . . . 177Programming . . . . . . . . . . . . . . . . . 177
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 324
Gauges Engine Coolant
Temperature . . . . . . . . . . . . . . . . 148
Engine Oil Pressure . . . . . . . . . . 147
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Odometer . . . . . . . . . . . . . . . . . . . . . 146 Gauges (cont'd)
Speedometer . . . . . . . . . . . . . . . . . 146
Tachometer . . . . . . . . . . . . . . . . . . . 146
Transmission Temperature . . . . 149
Trip Odometer . . . . . . . . . . . . . . . . 146
Voltmeter . . . . . . . . . . . . . . . . . . . . . 150
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . 142
General Information
Service and Maintenance . . . . . 393
Towing . . . . . . . . . . . . . . . . . . . . . . . . 273
Vehicle Care . . . . . . . . . . . . . . . . . . 296
Glass Replacement . . . . . . . . . . . . . 324
Glove Box . . . . . . . . . . . . . . . . . . . . . . 126
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 415
H
Hazard Warning Flashers . . . . . . . 185
Head Restraints . . . . . . . . . . . . . . . . . 66
Head-up Display . . . . . . . . . . . . . . . . 164
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 325
Automatic . . . . . . . . . . . . . . . . . . . . . 184
Bulb Replacement . . . . . . . . . . . . 326
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 184
Flash-to-Pass . . . . . . . . . . . . . . . . . 184
