GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-1500-11698638) - 2019 - CRC - 5/13/19
Keys, Doors, and Windows 33
Interference from radio-frequency
identification (RFID) tags may
prevent the key from starting the
vehicle. Keep RFID tags away from
the key when starting the vehicle.
The key is used for the ignition, all
door locks, and the glove box.
If equipped with memory seats,
keys 1 and 2 are linked to seating
positions of memory 1 or 2. See
Memory Seats074.
Programming Keys
Follow these procedures to program
up to eight keys to the vehicle. Programming with Two
Recognized Keys
To program a new key:
1. Insert the original, already programmed key in the ignition
and turn the ignition on.
2. Turn the ignition off, and remove the key.
3. Quickly, within five seconds, insert the second original
already programmed key in the
ignition and turn the ignition on.
4. Turn the ignition off, and remove the key.
5. Insert the key to be programmed and turn the
ignition on within five seconds.
6. After a few seconds, the security light will turn off once
the key has been programmed.
7. Repeat Steps 1–5 if additional keys are to be programmed.
If a key is lost or damaged, see your
dealer to have a new key made. Programming without
Recognized Keys
Program a new key to the vehicle
when a recognized key is not
available. Canadian regulations
require that owners see their dealer.
If two currently recognized keys are
not available, follow this procedure
to program the first key.
This procedure will take
approximately 30 minutes to
complete for the first key. The
vehicle must be off and all of the
keys you wish to program must be
with you.
1. Insert the new vehicle key into the ignition.
2. Turn the ignition on. The security light will come on.
3. Wait 10 minutes until the security light turns off.
4. Turn the ignition off.
5. Repeat Steps 2–4 two more times. After the third time, turn
the ignition on; the key is

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-1500-11698638) - 2019 - CRC - 5/13/19
126 Storage
Storage
Storage Compartments
Storage Compartments . . . . . . . 126
Glove Box . . . . . . . . . . . . . . . . . . . . 126
Cupholders . . . . . . . . . . . . . . . . . . . 126
Underseat Storage . . . . . . . . . . . 127
Rear Storage . . . . . . . . . . . . . . . . . 127
Center Console Storage . . . . . . 127
Floor Console Storage . . . . . . . . 128
Additional Storage Features
Cargo Tie-Downs . . . . . . . . . . . . . 129
Storage
Compartments
{Warning
Do not store heavy or sharp
objects in storage compartments.
In a crash, these objects may
cause the cover to open and
could result in injury.
Glove Box
To access the upper glove box, pull
up on the handle.To access the lower glove box,
unlock with the key and pull down
on the handle.
Cupholders
Front
There may be cupholders on the
center front seat console armrest.
Rear
If equipped, pull the rear seat
armrest down to access the
cupholders.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-1500-11698638) - 2019 - CRC - 5/13/19
198 Climate Controls
1. Open the lower glove box doorcompletely.
2. Press the sides of the glovebox door inward and rotate the
door downward to remove.
3. Pull lever on left side of the
filter door and slide left, then
remove the door. Remove the
old filter.
4. Install the new air filter.
5. Reinstall the filter door.
6. Reverse the steps to reinstall the glove box.
See your dealer if additional
assistance is needed.
Service
All vehicles have a label underhood
that identifies the refrigerant used in
the vehicle. The refrigerant system
should only be serviced by trained
and certified technicians. The air
conditioning evaporator should
never be repaired or replaced by
one from a salvage vehicle.
It should only be replaced by a new
evaporator to ensure proper and
safe operation.
During service, all refrigerants
should be reclaimed with proper
equipment. Venting refrigerants
directly to the atmosphere is harmful
to the environment and may also
create unsafe conditions based on
inhalation, combustion, frostbite,
or other health-based concerns.
The air conditioning system requires
periodic maintenance. See
Maintenance Schedule 0420.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-1500-11698638) - 2019 - CRC - 5/14/19
218 Driving and Operating
equipment. See www.gmupfitter.com
for additional pickup box load
bearing structural information.
Truck-Camper Loading
Information
A vehicle-specific Truck-Camper
Loading Information label is
attached to the inside of the
vehicle's glove box. This label
indicates if a slide-in camper
can be carried, how much of a
load the vehicle can carry, and
how to correctly spread out the
load. It will help to match the
right slide-in camper to the
vehicle.
Your dealer can help make a
good vehicle-camper match and
help determine the Cargo
Weight Rating (CWR).
When installing and loading a
slide-in camper, check the
manufacturer's instructions.When carrying a slide-in
camper, the total cargo load of
the vehicle is the weight of the
camper plus:
.Everything added to the
camper after it left the
factory.
.Everything in the camper.
.All the people inside.
The CWR is the maximum
weight of the load the vehicle
can carry. It does not include the
weight of the people inside. But,
use about 68 kg (150 lb) for
each seat.
The total cargo load must not be
more than the vehicle's CWR.
Refer to the Truck-Camper
Loading Information label in the
glove box for dimensions A and
B as shown in the following
illustration.Use the rear edge of the load
floor for measurement purposes.
The recommended location for
the cargo center of gravity is in
zone C for the CWR. It is the
point where the mass of a body
is concentrated and,
if suspended at that point, would
balance the front and rear.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-1500-11698638) - 2019 - CRC - 5/13/19
434 Technical Data
Technical Data
Vehicle Identification
Vehicle IdentificationNumber (VIN) . . . . . . . . . . . . . . . 434
Service Parts Identification Label . . . . . . . . . . . . . . . . . . . . . . . . 434
Vehicle Data
Capacities andSpecifications . . . . . . . . . . . . . . . 435
Engine Drive Belt Routing . . . . 437
Vehicle Identification
Vehicle Identification
Number (VIN)
This legal identifier is in the front
corner of the instrument panel, on
the driver side of the vehicle. It can
be seen through the windshield from
outside. The Vehicle Identification
Number (VIN) also appears on the
Vehicle Certification and Service
Parts labels and certificates of title
and registration.
Engine Identification
The eighth character in the VIN is
the engine code. This code
identifies the vehicle's engine,
specifications, and replacement parts. See
“Engine Specifications”
under Capacities and Specifications
0 435 for the vehicle's engine code.
Service Parts
Identification Label
There may be a label on the inside
of the glove box that contains the
following information:
.
Vehicle Identification
Number (VIN)
. Model designation
. Paint information
. Production options and special
equipment
If there is no label, there is a
barcode on the certification label on
the center (B) pillar to scan for this
same information.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-1500-11698638) - 2019 - CRC - 5/13/19
468 Index
F
FanEngine . . . . . . . . . . . . . . . . . . . . . . . . 338
Features Memory . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filter, Engine Air Cleaner . . . . . . . . . . . 331
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 182
Flashers, Hazard Warning . . . . . . 183
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 388 Changing . . . . . . . . . . . . . . . . . . . . . 390
FlexFuel E85 . . . . . . . . . . . . . . . . . . . . . . . . . . . 278
Floor Console Storage . . . . . . . . . . 128
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 416
Fluid
Automatic Transmission . . . . . . 330
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 341
Four-Wheel DriveTransfer Case . . . . . . . . . . . . . . . 239
Washer . . . . . . . . . . . . . . . . . . . . . . . 339
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 184
Folding Mirrors . . . . . . . . . . . . . . . . . . 58
Forward Automatic Braking . . . . . 268
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 265
Four-Wheel Drive . . . . . . . . . . 239, 345
Four-Wheel-Drive Light . . . . . . . . . 155 Frequency Statement
Radio . . . . . . . . . . . . . . . . . . . . . . . . . 448
Front Axle . . . . . . . . . . . . . . . . . . . . . . 345
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Front Pedestrian Braking (FPB) System . . . . . . . . . . . . . . . . . 269
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . . 70
Heated and Ventilated . . . . . . . . . . 76
Fuel
Additives . . . . . . . . . . . . . . . . . . . . . 277
Economy Driving . . . . . . . . . . . . . . . 30
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 280
Filling the Tank . . . . . . . . . . . . . . . 278
Foreign Countries . . . . . . . . . . . . 277
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 145
Low Fuel Warning Light . . . . . . . 160
Management, Active . . . . . . . . . . 231
Prohibited Fuels . . . . . . . . . . . . . . 277
Recommended . . . . . . . . . . 276, 277
Top Tier . . . . . . . . . . . . . . . . . . . . . . 276
Full-Size Spare Tire . . . . . . . . . . . . 399
Fuses Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 355
Fuses and Circuit Breakers . . . 355 Fuses (cont'd)
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . 359, 361
G
Garage Door Opener . . . . . . . . . . . 175Programming . . . . . . . . . . . . . . . . . 175
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 350
Gauges Engine Coolant
Temperature . . . . . . . . . . . . . . . . 147
Engine Oil Pressure . . . . . . . . . . 146
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Odometer . . . . . . . . . . . . . . . . . . . . . 145
Speedometer . . . . . . . . . . . . . . . . . 144
Tachometer . . . . . . . . . . . . . . . . . . . 145
Trip Odometer . . . . . . . . . . . . . . . . 145
Voltmeter . . . . . . . . . . . . . . . . . . . . . 148
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . 139
General Information Service and Maintenance . . . . . 418
Towing . . . . . . . . . . . . . . . . . . . . . . . . 281
Vehicle Care . . . . . . . . . . . . . . . . . . 317
Glove Box . . . . . . . . . . . . . . . . . . . . . . 126
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 442

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-1500-11698638) - 2019 - CRC - 5/13/19
Index 473
Safety Defects Reporting (cont'd)U.S. Government . . . . . . . . . . . . . 448
Safety Locks . . . . . . . . . . . . . . . . . . . . . 47
Safety System Check . . . . . . . . . . . . 85
Scheduling Appointments . . . . . . . 444
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . 80 Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Extender . . . . . . . . . . . . . . . . . . . . . . . . 85
How to Wear Seat BeltsProperly . . . . . . . . . . . . . . . . . . . . . . . 81
Lap-Shoulder Belt . . . . . . . . . . . . . . 83
Reminders . . . . . . . . . . . . . . . . . . . . 149
Replacing after a Crash . . . . . . . . 86
Use During Pregnancy . . . . . . . . . . 85
Seats Adjustment, Front . . . . . . . . . . . . . . . 70
Center Seat . . . . . . . . . . . . . . . . . . . . 71
Head Restraints . . . . . . . . . . . . . . . . 69
Heated and Ventilated Front . . . . 76
Heated, Rear . . . . . . . . . . . . . . . . . . . 79
Lumbar Adjustment, Front . . . . . . 72
Memory . . . . . . . . . . . . . . . . . . . . . . . . . 74
Power Adjustment, Front . . . . . . . 71
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Reclining Seatbacks . . . . . . . . . . . . 72
Underseat Storage . . . . . . . . . . . 127
Securing Child Restraints . . . . . . . . . . . . . . . . 118, 122 Security
Light . . . . . . . . . . . . . . . . . . . . . . . . . . 160
OnStar . . . . . . . . . . . . . . . . . . . . . . . 454
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 55
Vehicle Alarm . . . . . . . . . . . . . . . . . . . 55
Service . . . . . . . . . . . . . . . . . . . . . . . . . 198 Accessories and
Modifications . . . . . . . . . . . . . . . . 318
Climate Control System . . . . . . . 191
Doing Your Own Work . . . . . . . . 319
Maintenance Records . . . . . . . . 433
Maintenance, General Information . . . . . . . . . . . . . . . . . . 418
Parts Identification Label . . . . . 434
Scheduling Appointments . . . . . 444
Service Electric Parking
Brake Light . . . . . . . . . . . . . . . . . . . . 154
Services Special Application . . . . . . . . . . . 426
Servicing the Airbag . . . . . . . . . . . . . 97
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . 229
Out of Park . . . . . . . . . . . . . . . . . . . 230
Side Blind Zone Alert (SBZA) . . . 271
Signals, Turn and Lane-Change . . . . . . . . . . . . . . . . . 184
Snow Plow . . . . . . . . . . . . . . . . . . . . . 312
Special Application Services . . . . 426 Specifications and
Capacities . . . . . . . . . . . . . . . . . . . . . 435
Speedometer . . . . . . . . . . . . . . . . . . . 144
Start Vehicle, Remote . . . . . . . . . . . 44
Starter Switch Check . . . . . . . . . . . 348
Starting the Engine . . . . . . . . . . . . . 224
Steering . . . . . . . . . . . . . . . . . . . . . . . . 202 Heated Wheel . . . . . . . . . . . . . . . . 133
Wheel Adjustment . . . . . . . . . . . . 132
Wheel Controls . . . . . . . . . . . . . . . 133
Steps
Power Assist . . . . . . . . . . . . . . . . . . . 54
Stop/Start System . . . . . . . . . . . . . . 225
Stoplamps and Back-up Lamps Bulb Replacement . . . . . . . . . . . . 352
Storage
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Storage Areas Center Console . . . . . . . . . . . . . . . 127
Floor Console . . . . . . . . . . . . . . . . 128
Glove Box . . . . . . . . . . . . . . . . . . . . 126
Underseat . . . . . . . . . . . . . . . . . . . . 127
Storage Compartments . . . . . . . . . 126
Struts Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . 350
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 211
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 66
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 66
