GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-1500-11698638) - 2019 - CRC - 5/14/19
Vehicle Care 383
driving. When storing a vehicle for
at least a month, remove the tires or
raise the vehicle to reduce the
weight from the tires.
Buying New Tires
GM has developed and matched
specific tires for the vehicle. The
original equipment tires installed
were designed to meet General
Motors Tire Performance Criteria
Specification (TPC Spec)
system rating. When
replacement tires are needed,
GM strongly recommends
buying tires with the same TPC
Spec rating.
GM's exclusive TPC Spec
system considers over a dozen
critical specifications that impact
the overall performance of the
vehicle, including brake system
performance, ride and handling,
traction control, and tire
pressure monitoring
performance. GM's TPC Spec
number is molded onto the tire'ssidewall near the tire size. If the
tires have an all-season tread
design, the TPC Spec number
will be followed by MS for mud
and snow. See
Tire Sidewall
Labeling 0365 for additional
information.
GM recommends replacing worn
tires in complete sets of four (six
for dual rear wheels). Uniform
tread depth on all tires will help
to maintain the performance of
the vehicle. Braking and
handling performance may be
adversely affected if all the tires
are not replaced at the same
time. If proper rotation and
maintenance have been done,
all four tires (six for dual rear
wheels) should wear out at
about the same time. See Tire
Rotation 0381 for information
on proper tire rotation. However,
if it is necessary to replace only
one axle set of worn tires, place the new tires on the rear axle
(two for single rear wheels, four
for dual rear wheels).
{Warning
Tires could explode during
improper service. Attempting
to mount or dismount a tire
could cause injury or death.
Only your dealer or authorized
tire service center should
mount or dismount the tires.
{Warning
Mixing tires of different sizes,
brands, or types may cause
loss of control of the vehicle,
resulting in a crash or other
vehicle damage. Use the
correct size, brand, and type
of tires on all wheels.
(Continued)

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-1500-11698638) - 2019 - CRC - 5/14/19
384 Vehicle Care
Warning (Continued)
This vehicle may have a
different size spare than the
road tires originally installed
on the vehicle. When new, the
vehicle included a spare tire
and wheel assembly with a
similar overall diameter as the
road tires and wheels, so it is
all right to drive on it. The
spare tire was developed for
use on this vehicle and will not
affect vehicle handling.
{Warning
Using bias-ply tires on the
vehicle may cause the wheel
rim flanges to develop cracks
after many miles of driving.
A tire and/or wheel could fail
suddenly and cause a crash.
Use only radial-ply tires with
the wheels on the vehicle. Winter tires with the same speed
rating as the original equipment
tires may not be available for H,
V, W, Y and ZR speed rated
tires. Never exceed the winter
tires’
maximum speed capability
when using winter tires with a
lower speed rating.
If the vehicle tires must be
replaced with a tire that does not
have a TPC Spec number, make
sure they are the same size,
load range, speed rating, and
construction (radial) as the
original tires.
Vehicles that have a tire
pressure monitoring system
could give an inaccurate
low-pressure warning if non-TPC
Spec rated tires are installed.
See Tire Pressure Monitor
System 0374.
The Tire and Loading
Information label indicates the
original equipment tires on the vehicle. See
Vehicle Load Limits
0 212 for the label location and
more information about the Tire
and Loading Information label.
Different Size Tires and
Wheels
If wheels or tires are installed that
are a different size than the original
equipment wheels and tires, vehicle
performance, including its braking,
ride and handling characteristics,
stability, and resistance to rollover
may be affected. If the vehicle has
electronic systems such as antilock
brakes, rollover airbags, traction
control, electronic stability control,
or All-Wheel Drive, the performance
of these systems can also be
affected.
{Warning
If different sized wheels are used,
there may not be an acceptable
level of performance and safety if
tires not recommended for those
(Continued)

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-1500-11698638) - 2019 - CRC - 5/14/19
Vehicle Care 387
Some aluminum wheels can be
repaired. See your dealer if any of
these conditions exist.
Your dealer will know the kind of
wheel that is needed.
Each new wheel should have the
same load-carrying capacity,
diameter, width, offset and be
mounted the same way as the one it
replaces.
Replace wheels, wheel bolts, wheel
nuts, or Tire Pressure Monitor
System (TPMS) sensors with new
GM original equipment parts.
{Warning
Using the wrong replacement
wheels, wheel bolts, or wheel
nuts can be dangerous. It could
affect the braking and handling of
the vehicle. Tires can lose air,
and cause loss of control, causing
a crash. Always use the correct
wheel, wheel bolts, and wheel
nuts for replacement.
Caution
The wrong wheel can also cause
problems with bearing life, brake
cooling, speedometer or
odometer calibration, headlamp
aim, bumper height, vehicle
ground clearance, and tire or tire
chain clearance to the body and
chassis.
Whenever a wheel, wheel bolt,
or wheel nut is replaced on a dual
wheel setup, check the wheel nut
torque after 160,1 600, and
10 000 km (100,1,000, and
6,000 mi) of driving. For proper
torque, see “Wheel Nut Torque”
under Capacities and Specifications
0 435.
See If a Tire Goes Flat 0388 for
more information. Used Replacement Wheels{Warning
Replacing a wheel with a used
one is dangerous. How it has
been used or how far it has been
driven may be unknown. It could
fail suddenly and cause a crash.
When replacing wheels, use a
new GM original equipment
wheel.
Tire Chains
{Warning
If the vehicle has LT265/70R17,
LT275/65R18, 275/60R20,
or 275/50R22 size tires, do not
use tire chains. They can damage
the vehicle because there is not
enough clearance. Tire chains
used on a vehicle without the
proper amount of clearance can
cause damage to the brakes,
(Continued)

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-1500-11698638) - 2019 - CRC - 5/14/19
388 Vehicle Care
Warning (Continued)
suspension, or other vehicle
parts. The area damaged by the
tire chains could cause you to
lose control of the vehicle and
you or others may be injured in a
crash.
Use another type of traction
device only if its manufacturer
recommends it for use on the
vehicle and tire size combination
and road conditions. Follow that
manufacturer's instructions. To
help avoid damage to the vehicle,
drive slowly, readjust, or remove
the device if it is contacting the
vehicle, and do not spin the
vehicle's wheels.
If you do find traction devices that
will fit, install them on the rear
tires.
Caution
Use tire chains only where legal
and only when necessary. Use
chains that are the proper size for
the tires. If the vehicle has
265/70R17 or 265/65R18 size
tires, they may be installed on the
tires of the rear axle only. If the
vehicle has 255/70R17 size tires,
they may be installed on the tires
of the front and rear axle. Tighten
them as tightly as possible with
the ends securely fastened. Drive
slowly and follow the chain
manufacturer's instructions. If you
can hear the chains contacting
the vehicle, stop and retighten
them. If the contact continues,
slow down until it stops. Driving
too fast or spinning the wheels
with chains on will damage the
vehicle.
If a Tire Goes Flat
It is unusual for a tire to blowout
while driving, especially if the tires
are maintained properly. If air goes
out of a tire, it is much more likely to
leak out slowly. But if there ever is a
blowout, here are a few tips about
what to expect and what to do:
If a front tire fails, the flat tire
creates a drag that pulls the vehicle
toward that side. Take your foot off
the accelerator pedal and grip the
steering wheel firmly. Steer to
maintain lane position, and then
gently brake to a stop, well off the
road, if possible.
A rear blowout, particularly on a
curve, acts much like a skid and
may require the same correction as
used in a skid. Stop pressing the
accelerator pedal and steer to
straighten the vehicle. It may be
very bumpy and noisy. Gently brake
to a stop, well off the road,
if possible.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-1500-11698638) - 2019 - CRC - 5/14/19
Vehicle Care 399
Return the jack and tools to their
original location in the vehicle. See
“Removing the Spare Tire and
Tools.”
Full-Size Spare Tire
If this vehicle came with a full-size
spare tire, it was fully inflated when
new, however, it can lose air over
time. Check the inflation pressure
regularly. SeeTire Pressure0372
and
Vehicle Load Limits 0212. For
instructions on how to remove,
install, or store a spare tire, see Tire
Changing 0390.
If equipped with a temporary use
full-size spare tire, it is indicated on
the tire sidewall. See Tire Sidewall
Labeling 0365. This spare tire should not be driven on over
112 km/h (70 mph), or 88 km/h
(55 mph) when pulling a trailer, at
the proper inflation pressure. Repair
and replace the road tire as soon as
it is convenient, and stow the spare
tire for future use.
Caution
If the vehicle has four-wheel drive
and a different size spare tire is
installed, do not drive in
four-wheel drive until the flat tire
is repaired and/or replaced. The
vehicle could be damaged and
the repairs would not be covered
by the warranty. Never use
four-wheel drive when a different
size spare tire is installed on the
vehicle.
The vehicle may have a different
size spare tire than the road tires
originally installed on the vehicle.
This spare tire was developed for
use on this vehicle, so it is all right
to drive on it. If the vehicle has four-wheel drive and a different size
spare tire is installed, drive only in
two-wheel drive.
After installing the spare tire on the
vehicle, stop as soon as possible
and check that the spare tire is
correctly inflated.
Have the damaged or flat road tire
repaired or replaced and installed
back onto the vehicle as soon as
possible so the spare tire will be
available in case it is needed again.
Do not mix tires and wheels of
different sizes, because they will not
fit. Keep your spare tire and its
wheel together. If the vehicle has a
spare tire that does not match the
original road tires and wheels in size
and type, do not include the spare in
the tire rotation.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-1500-11698638) - 2019 - CRC - 5/13/19
468 Index
F
FanEngine . . . . . . . . . . . . . . . . . . . . . . . . 338
Features Memory . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filter, Engine Air Cleaner . . . . . . . . . . . 331
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 182
Flashers, Hazard Warning . . . . . . 183
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 388 Changing . . . . . . . . . . . . . . . . . . . . . 390
FlexFuel E85 . . . . . . . . . . . . . . . . . . . . . . . . . . . 278
Floor Console Storage . . . . . . . . . . 128
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 416
Fluid
Automatic Transmission . . . . . . 330
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 341
Four-Wheel DriveTransfer Case . . . . . . . . . . . . . . . 239
Washer . . . . . . . . . . . . . . . . . . . . . . . 339
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 184
Folding Mirrors . . . . . . . . . . . . . . . . . . 58
Forward Automatic Braking . . . . . 268
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 265
Four-Wheel Drive . . . . . . . . . . 239, 345
Four-Wheel-Drive Light . . . . . . . . . 155 Frequency Statement
Radio . . . . . . . . . . . . . . . . . . . . . . . . . 448
Front Axle . . . . . . . . . . . . . . . . . . . . . . 345
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Front Pedestrian Braking (FPB) System . . . . . . . . . . . . . . . . . 269
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . . 70
Heated and Ventilated . . . . . . . . . . 76
Fuel
Additives . . . . . . . . . . . . . . . . . . . . . 277
Economy Driving . . . . . . . . . . . . . . . 30
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 280
Filling the Tank . . . . . . . . . . . . . . . 278
Foreign Countries . . . . . . . . . . . . 277
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 145
Low Fuel Warning Light . . . . . . . 160
Management, Active . . . . . . . . . . 231
Prohibited Fuels . . . . . . . . . . . . . . 277
Recommended . . . . . . . . . . 276, 277
Top Tier . . . . . . . . . . . . . . . . . . . . . . 276
Full-Size Spare Tire . . . . . . . . . . . . 399
Fuses Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 355
Fuses and Circuit Breakers . . . 355 Fuses (cont'd)
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . 359, 361
G
Garage Door Opener . . . . . . . . . . . 175Programming . . . . . . . . . . . . . . . . . 175
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 350
Gauges Engine Coolant
Temperature . . . . . . . . . . . . . . . . 147
Engine Oil Pressure . . . . . . . . . . 146
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Odometer . . . . . . . . . . . . . . . . . . . . . 145
Speedometer . . . . . . . . . . . . . . . . . 144
Tachometer . . . . . . . . . . . . . . . . . . . 145
Trip Odometer . . . . . . . . . . . . . . . . 145
Voltmeter . . . . . . . . . . . . . . . . . . . . . 148
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . 139
General Information Service and Maintenance . . . . . 418
Towing . . . . . . . . . . . . . . . . . . . . . . . . 281
Vehicle Care . . . . . . . . . . . . . . . . . . 317
Glove Box . . . . . . . . . . . . . . . . . . . . . . 126
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 442

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-1500-11698638) - 2019 - CRC - 5/13/19
474 Index
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SystemBrake Pad Life . . . . . . . . . . . . . . . . 340
Engine Air Filter Life . . . . . . . . . . 330
Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 265
Infotainment . . . . . . . . . . . . . 190, 451
Noise Control . . . . . . . . . . . . . . . . . 347
Systems Driver Assistance . . . . . . . . . . . . . 258
T
Tachometer . . . . . . . . . . . . . . . . . . . . . 145
Tailgate . . . . . . . . . . . . . . . . . . . . . . . . . . 48
TaillampsBulb Replacement . . . . . . . . . . . . 352
Task Lighting . . . . . . . . . . . . . . . . . . . 185
Text Telephone (TTY) Users . . . . 441
Theft-Deterrent Systems . . . . . . . . . 56
Immobilizer . . . . . . . . . . . . . . . . . . . . . 56
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 363
All-Season . . . . . . . . . . . . . . . . . . . . 364
All-Terrain . . . . . . . . . . . . . . . . . . . . 365
Buying New Tires . . . . . . . . . . . . . 383
Chains . . . . . . . . . . . . . . . . . . . . . . . . 387
Changing . . . . . . . . . . . . . . . . . . . . . 390
Designations . . . . . . . . . . . . . . . . . 368 Tires (cont'd)
Different Size . . . . . . . . . . . . . . . . . 384
Full-Size Spare . . . . . . . . . . . . . . . 399
If a Tire Goes Flat . . . . . . . . . . . . 388
Inspection . . . . . . . . . . . . . . . . . . . . 380
Low Profile . . . . . . . . . . . . . . . . . . . 365
Pressure . . . . . . . . . . . . . . . . . 372, 373
Pressure Light . . . . . . . . . . . . . . . . 159
Pressure Monitor Operation . . 375
Pressure Monitor System . . . . . 374
Rotation . . . . . . . . . . . . . . . . . . . . . . 381
Sidewall Labeling . . . . . . . . . . . . . 365
Terminology and Definitions . . 369
Uniform Tire Quality
Grading . . . . . . . . . . . . . . . . . . . . . 385
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . . . 386
Wheel Replacement . . . . . . . . . . 386
When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . 382
Winter . . . . . . . . . . . . . . . . . . . . . . . . 364
Top Tier Fuel . . . . . . . . . . . . . . . . . . . 276
Tow/Haul Mode . . . . . . . . . . . . . . . . . 238
Tow/Haul Mode Light . . . . . . . . . . . 155
Towing Driving Characteristics . . . . . . . . 281
Equipment . . . . . . . . . . . . . . . . . . . . 290
General Information . . . . . . . . . . 281 Towing (cont'd)
Recreational Vehicle . . . . . . . . . . 404
Trailer . . . . . . . . . . . . . . . . . . . . . . . . 286
Trailer Sway Control (TSC) . . . 299
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 403
Traction Limited-Slip Differential . . . . . . . 255
Off Light . . . . . . . . . . . . . . . . . . . . . . 157
Traction Control/Electronic
Stability Control . . . . . . . . . . . . . . . 247
Trailer Sway Control (TSC) . . . . . . . . . . 299
Towing . . . . . . . . . . . . . . . . . . . . . . . . 286
Trailer Towing
App . . . . . . . . . . . . . . . . . . . . . . . . . . . 301
Trailering App . . . . . . . . . . . . . . . . . . 301
Transfer Case . . . . . . . . . . . . . . . . . . 239
Transmission Automatic . . . . . . . . . . . . . . . . . . . . . 233
Fluid, Automatic . . . . . . . . . . . . . . 330
Transportation Program, Courtesy . . . . . . . . . . . . . . . . . . . . . . 444
Trip Odometer . . . . . . . . . . . . . . . . . . 145
Truck-Camper Loading
Information . . . . . . . . . . . . . . . . . . . . 218
Turn and Lane-Change Signals . . . . . . . . . . . . . . . . . . . . . . . . 184

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-1500-11698638) - 2019 - CRC - 5/13/19
Index 475
Turn SignalBulb Replacement . . . . . . . . . . . . 352
U
Underseat Storage . . . . . . . . . . . . . 127
Uniform Tire Quality Grading . . . 385
Universal Remote System . . . . . . 175
Operation . . . . . . . . . . . . . . . . . . . . . 177
Programming . . . . . . . . . . . . . . . . . 175
Using This Manual . . . . . . . . . . . . . . . . 2
V
Vehicle Alarm System . . . . . . . . . . . . . . . . . . 55
Canadian Owners . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . 201
Identification Number (VIN) . . . 434
Load Limits . . . . . . . . . . . . . . . . . . . 212
Messages . . . . . . . . . . . . . . . . . . . . 169
Personalization . . . . . . . . . . . . . . . 170
Remote Start . . . . . . . . . . . . . . . . . . . 44
Security . . . . . . . . . . . . . . . . . . . . . . . . 55
Speed Messages . . . . . . . . . . . . . 170
Towing . . . . . . . . . . . . . . . . . . . . . . . . 403
Vehicle Ahead Indicator . . . . . . . . 156
Vehicle Care Tire Pressure . . . . . . . . . . . . . . . . . 372
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . 450 Ventilation, Air . . . . . . . . . . . . . . . . . . 197
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Voltmeter Gauge . . . . . . . . . . . . . . . 148
W
Warning
Brake System Light . . . . . . . . . . . 153
Caution and Danger . . . . . . . . . . . . . 3
Lane Departure (LDW) . . . . . . . 274
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . 139
Warnings
Hazard Flashers . . . . . . . . . . . . . . 183
Washer Fluid . . . . . . . . . . . . . . . . . . . 339
Wheels Alignment and Tire Balance . . 386
Different Size . . . . . . . . . . . . . . . . . 384
Replacement . . . . . . . . . . . . . . . . . 386
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 382
Where to Put the Restraint . . . . . 105
Windows . . . . . . . . . . . . . . . . . . . . . . . . 63
Manual . . . . . . . . . . . . . . . . . . . . . . . . . 64
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Windshield
Replacement . . . . . . . . . . . . . . . . . 350
Wiper/Washer . . . . . . . . . . . . . . . . 133 Winter
Driving . . . . . . . . . . . . . . . . . . . . . . . . 210
Winter Tires . . . . . . . . . . . . . . . . . . . . 364
Wiper Blade Replacement . . . . . . 349
Wireless Charging . . . . . . . . . . . . . . 137
