GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146149) - 2019 - crc - 7/30/18
Vehicle Care 367
Caution (Continued)
dust and ice. Always wash the
chrome with soap and water after
exposure.
Caution
To avoid surface damage on
wheels and wheel trim, do not
use strong soaps, chemicals,
abrasive polishes, cleaners,
or brushes. Use only GM
approved cleaners. Do not drive
the vehicle through an automatic
car wash that uses silicone
carbide tire/wheel cleaning
brushes. Damage could occur
and the repairs would not be
covered by the vehicle warranty.
Brake System
Visually inspect brake lines and
hoses for proper hook-up, binding,
leaks, cracks, chafing, etc. Inspectdisc brake pads for wear and rotors
for surface condition. Inspect all
other brake parts.
Steering, Suspension, and
Chassis Components
Visually inspect steering,
suspension, and chassis
components for damaged, loose,
or missing parts or signs of wear at
least once a year.
Inspect power steering for proper
electrical connections, binding,
cracks, chafing, etc.
Visually check constant velocity joint
boots and axle seals for leaks.
Body Component Lubrication
Lubricate all key lock cylinders,
hood hinges, liftgate hinges, and the
steel fuel door hinges, unless the
components are plastic. Applying
silicone grease on weatherstrips
with a clean cloth will make them
last longer, seal better, and not stick
or squeak.
Underbody Maintenance
At least twice a year, spring and fall,
use plain water to flush any
corrosive materials from the
underbody. Take care to thoroughly
clean any areas where mud and
other debris can collect.
Do not directly power wash the
transfer case and/or front/rear axle
output seals. High pressure water
can overcome the seals and
contaminate the fluid. Contaminated
fluid will decrease the life of the
transfer case and/or axles and
should be replaced.
Sheet Metal Damage
If the vehicle is damaged and
requires sheet metal repair or
replacement, make sure the body
repair shop applies anti-corrosion
material to parts repaired or
replaced to restore corrosion
protection.
Original manufacturer replacement
parts will provide the corrosion
protection while maintaining the
vehicle warranty.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146149) - 2019 - crc - 7/30/18
Service and Maintenance 373
Service and
Maintenance
General Information
General Information . . . . . . . . . . 373
Maintenance Schedule
Maintenance Schedule . . . . . . . 375
Special Application Services
Special ApplicationServices . . . . . . . . . . . . . . . . . . . . 380
Additional Maintenance
and Care
Additional Maintenanceand Care . . . . . . . . . . . . . . . . . . . . 380
Recommended Fluids,
Lubricants, and Parts
Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . 383
Maintenance Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . 384
Maintenance Records
Maintenance Records . . . . . . . . 385
General Information
Your vehicle is an important
investment. This section describes
the required maintenance for the
vehicle. Follow this schedule to help
protect against major repair
expenses resulting from neglect or
inadequate maintenance. It may
also help to maintain the value of
the vehicle if it is sold. It is the
responsibility of the owner to have
all required maintenance performed.
Your dealer has trained technicians
who can perform required
maintenance using genuine
replacement parts. They have
up-to-date tools and equipment for
fast and accurate diagnostics. Many
dealers have extended evening and
Saturday hours, courtesy
transportation, and online
scheduling to assist with service
needs.
Your dealer recognizes the
importance of providing
competitively priced maintenance
and repair services. With trained
technicians, the dealer is the place for routine maintenance such as oil
changes and tire rotations and
additional maintenance items like
tires, brakes, batteries, and wiper
blades.
Caution
Damage caused by improper
maintenance can lead to costly
repairs and may not be covered
by the vehicle warranty.
Maintenance intervals, checks,
inspections, recommended fluids,
and lubricants are important to
keep the vehicle in good working
condition.
Do not have chemical flushes that
are not approved by GM
performed on the vehicle. The
use of flushes, solvents, cleaners,
or lubricants that are not
approved by GM could damage
the vehicle, requiring expensive
repairs that are not covered by
the vehicle warranty.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146149) - 2019 - crc - 7/30/18
Service and Maintenance 379
Maintenance Schedule
Additional Required
Services - Severe12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi 180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
Rotate tires and perform Required Services.
Check engine oil level and oil life percentage.
Change engine oil and filter, if needed.@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @
Replace passenger compartment air filter. (1)@ @@@@@
Inspect evaporative control system. (2)@ @@
Replace engine air cleaner filter. (3)@@@
Change automatic transmission fluid.@@@
Replace spark plugs. Inspect spark plug wires.@
Drain and fill engine cooling system. (4)@
Visually inspect accessory drive belts. (5)@
Replace brake fluid. (6)
Replace windshield wiper blades. (7)
@ @ @ @ @ @ @ @ @ @
Replace hood and/or body lift support gas struts.@ @
Footnotes—Maintenance
Schedule Additional Required
Services - Severe
(1) Or every two years, whichever
comes first. More frequent
passenger compartment air filter
replacement may be needed if driving in areas with heavy traffic,
poor air quality, high dust levels,
or environmental allergens.
Passenger compartment air filter
replacement may also be needed if
there is reduced airflow, window
fogging, or odors. Your GM dealer
can help determine when to replace
the filter.
(2)
Visually check all fuel and vapor
lines and hoses for proper
attachment, connection, routing, and
condition.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146149) - 2019 - crc - 7/30/18
Service and Maintenance 381
.To avoid break-down or failure to
start the vehicle, maintain a
battery with full cranking power.
. Trained dealer technicians have
the diagnostic equipment to test
the battery and ensure that the
connections and cables are
corrosion-free.
Belts
. Belts may need replacing if they
squeak or show signs of
cracking or splitting.
. Trained dealer technicians have
access to tools and equipment
to inspect the belts and
recommend adjustment or
replacement when necessary.
Brakes
Brakes stop the vehicle and are
crucial to safe driving.
. Signs of brake wear may include
chirping, grinding, or squealing
noises, or difficulty stopping. .
Trained dealer technicians have
access to tools and equipment
to inspect the brakes and
recommend quality parts
engineered for the vehicle.
Fluids
Proper fluid levels and approved
fluids protect the vehicle’s systems
and components. See
Recommended Fluids and
Lubricants 0383 for GM approved
fluids.
. Engine oil and windshield
washer fluid levels should be
checked at every fuel fill.
. Instrument cluster lights may
come on to indicate that fluids
may be low and need to be
filled.
Hoses
Hoses transport fluids and should
be regularly inspected to ensure
that there are no cracks or leaks.
With a multi-point inspection, your
dealer can inspect the hoses and
advise if replacement is needed. Lamps
Properly working headlamps,
taillamps, and brake lamps are
important to see and be seen on
the road.
.
Signs that the headlamps need
attention include dimming, failure
to light, cracking, or damage.
The brake lamps need to be
checked periodically to ensure
that they light when braking.
. With a multi-point inspection,
your dealer can check the lamps
and note any concerns.
Shocks and Struts
Shocks and struts help aid in control
for a smoother ride.
. Signs of wear may include
steering wheel vibration, bounce/
sway while braking, longer
stopping distance, or uneven
tire wear.
. As part of the multi-point
inspection, trained dealer
technicians can visually inspect
the shocks and struts for signs

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146149) - 2019 - crc - 7/30/18
388 Technical Data
ApplicationCapacities
Metric English
Fuel Tank
FWD 73.4 L 19.4 gal
AWD 82.1 L 21.7 gal
Transfer Case Fluid 1.0 L 1.0 qt
Wheel Nut Torque 190 Y140 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this
manual. Recheck fluid level after filling.
Engine Specifications
Engine VIN CodeTransmission Spark Plug Gap
2.5L L4 Engine AAutomatic 0.95–1.10 mm (0.037–
0.043 in)
3.6L V6 Engine SAutomatic 0.80–0.90 mm (0.031–
0.035 in)

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-12146149) - 2019 - crc - 7/30/18
Index 417
Appearance Care (cont'd)Interior . . . . . . . . . . . . . . . . . . . . . . . . 368
Apple CarPlay and Android Auto . . . . . . . . . . . . . . . . . . 193
Armrest Storage . . . . . . . . . . . . . . . . 112
Assistance Program, Roadside . . . . . . . . . . . . . . . . . . . . . . 394
Assistance Systems for Driving . . . . . . . . . . . . . . . . . . . . . . . . 257
Assistance Systems for Parking and Backing . . . . . . . . . . 253
Audio Theft-Deterrent Feature . . . . . . . 174
Auto Stop
Stop/Start System . . . . . . . . . . . . 224
Automatic Dimming Mirrors . . . . . . . . . . . . . . . . 50
Door Locks . . . . . . . . . . . . . . . . . . . . . 39
Forward Braking . . . . . . . . . . . . . . 259
Headlamp System . . . . . . . . . . . . 167
Transmission . . . . . . . . . . . . . . . . . 230
Transmission Fluid . . . . . . . . . . . 294
Automatic Transmission
Manual Mode . . . . . . . . . . . . . . . . . 232
Shift Lock Control FunctionCheck . . . . . . . . . . . . . . . . . . . . . . . 305
Auxiliary Devices . . . . . . . . . . . . . . . . . . . . . . . 187B
Battery
Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 172
Load Management . . . . . . . . . . . . 171
Power Protection . . . . . . . . . . . . . 171
Battery - North America . . . . 304, 356
Blade Replacement, Wiper . . . . . 306
Bluetooth Overview . . . . . . . . . . . . . . . . 188, 189
Brake Parking, Electric . . . . . . . . . . . . . . 234
System Warning Light . . . . . . . . 138
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 302
Antilock . . . . . . . . . . . . . . . . . . . . . . . 233
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 235
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 303
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 207 Automatic Forward . . . . . . . . . . . 259
Braking System Front Pedestrian (FPB) . . . . . . . 261
Break-In, New Vehicle . . . . . . . . . . 221
Bulb Replacement Halogen Bulbs . . . . . . . . . . . . . . . . 309
Headlamp Aiming . . . . . . . . . . . . . 308
Headlamps . . . . . . . . . . . . . . . . . . . 309
License Plate Lamps . . . . . . . . . 309
Buying New Tires . . . . . . . . . . . . . . . 335
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 122
California
Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . 286
California Proposition
65 Warning . . . . . . . . . .285, 304, 356, Back Cover
Canadian Vehicle Owners . . . . . . . . 2
Capacities and
Specifications . . . . . . . . . . . . . . . . . 387
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 229
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 41
Winter Driving . . . . . . . . . . . . . . . . 215
Cargo Cover . . . . . . . . . . . . . . . . . . . . . . . . . .113
Management System . . . . . . . . . .114
Tie-Downs . . . . . . . . . . . . . . . . . . . . .113
Caution, Danger, and Warning . . . . 2
Center Console Storage . . . . . . . . 112
Chains, Tire . . . . . . . . . . . . . . . . . . . . 340
Charging System Light . . . . . . . . . 136
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 136

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-12146149) - 2019 - crc - 7/30/18
Index 419
Drive Belt Routing, Engine . . . . . . 389
Drive SystemsAll-Wheel Drive . . . . . . . . . . 233, 305
Driver Assistance Systems . . . . . 251
Driver Information Center (DIC) . . . . . . . . . . . . . 145, 148
Driver Mode Control . . . . . . . . . . . . 239
Driving
Assistance Systems . . . . . . . . . . 257
Characteristics andTowing Tips . . . . . . . . . . . . . . . . . 271
Defensive . . . . . . . . . . . . . . . . . . . . . 207
Drunk . . . . . . . . . . . . . . . . . . . . . . . . . 207
For Better Fuel Economy . . . . . . . 26
Hill and Mountain Roads . . . . . . 215
If the Vehicle is Stuck . . . . . . . . . 217
Loss of Control . . . . . . . . . . . . . . . 209
Off-Road . . . . . . . . . . . . . . . . . . . . . 209
Off-Road Recovery . . . . . . . . . . . 208
Vehicle Load Limits . . . . . . . . . . . 217
Wet Roads . . . . . . . . . . . . . . . . . . . 214
Winter . . . . . . . . . . . . . . . . . . . . . . . . 215
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . 198
E
Electric Parking Brake . . . . . . . . . . 234
Electric Parking Brake Light . . . . 139 Electrical Equipment,
Add-On . . . . . . . . . . . . . . . . . . . . . . . 283
Electrical System Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . .311
Fuses and Circuit Breakers . . . 310
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 314
Overload . . . . . . . . . . . . . . . . . . . . . 310
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 316
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . 405
Engine Air Cleaner/Filter . . . . . . . . . . . . . 295
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 136
Compartment Overview . . . . . . . 288
Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . 133
Cooling System . . . . . . . . . . . . . . . 296
Drive Belt Routing . . . . . . . . . . . . 389
Exhaust . . . . . . . . . . . . . . . . . . . . . . 229
Heater . . . . . . . . . . . . . . . . . . . . . . . . 225
Oil Life System . . . . . . . . . . . . . . . 293
Oil Pressure Light . . . . . . . . . . . . 142
Overheating . . . . . . . . . . . . . . . . . . 300
Power Messages . . . . . . . . . . . . . 151 Engine (cont'd)
Running While Parked . . . . . . . . 229
Starting . . . . . . . . . . . . . . . . . . . . . . . 223
Entry Lighting . . . . . . . . . . . . . . . . . . . 170
Equipment, Towing . . . . . . . . . . . . . 278
Event Data Recorders . . . . . . . . . . 402
Exit Lighting . . . . . . . . . . . . . . . . . . . . 171
Extended Parking . . . . . . . . . . . . . . . 228
Extender, Seat Belt . . . . . . . . . . . . . . 77
Exterior Lamp Controls . . . . . . . . . 164
Exterior Lamps Off Reminder . . . 166
Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . . . 172
F
FeaturesMemory . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter, Engine Air Cleaner . . . . . . . . . . . 295
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 166
Flashers, Hazard Warning . . . . . . 168
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 340 Changing . . . . . . . . . . . . . . . . . . . . . 349
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 371
Fluid
Automatic Transmission . . . . . . 294
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 303
Washer . . . . . . . . . . . . . . . . . . . . . . . 301

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-12146149) - 2019 - crc - 7/30/18
Index 423
OnStar Emergency . . . . . . . . . . . . . 405
OnStar Overview . . . . . . . . . . . . . . . 404
OnStar Security . . . . . . . . . . . . . . . . 406
OperationFog Lamps . . . . . . . . . . . . . . . . . . . 168
Infotainment System . . . . . . . . . . 176
Outlets
Power . . . . . . . . . . . . . . . . . . . . . . . . 124
Overheating, Engine . . . . . . . . . . . . 300
Overview . . . . . . . . . . . . . . . . . . . . . . . 175
P
Park Shifting Into . . . . . . . . . . . . . . . . . . . 226
Shifting Out of . . . . . . . . . . . . . . . . 227
Park Assist . . . . . . . . . . . . . . . . . . . . . 253
Parking Brake and P (Park)Mechanism Check . . . . . . . . . . 305
Extended . . . . . . . . . . . . . . . . . . . . . 228
Over Things That Burn . . . . . . . 228
Parking or Backing Assistance Systems . . . . . . . . . . 253
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 135
Passenger Compartment Air
Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 204
Passenger Sensing System . . . . . 85 Pedestrian Ahead Indicator . . . . . 141
Perchlorate Materials
Requirements, California . . . . . . 286
Personalization Vehicle . . . . . . . . . . . . . . . . . . . . . . . 152
Phone Apple CarPlay and
Android Auto . . . . . . . . . . . . . . . . 193
Bluetooth . . . . . . . . . . . . . . . . 188, 189
Hands-Free . . . . . . . . . . . . . . . . . . . 194
Port
USB . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Power Door Locks . . . . . . . . . . . . . . . . . . . . . 39
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Outlets . . . . . . . . . . . . . . . . . . . . . . . 124
Protection, Battery . . . . . . . . . . . . 171
Retained Accessory (RAP) . . . 226
Seat Adjustment . . . . . . . . . . . . . . . . 59
Windows . . . . . . . . . . . . . . . . . . . . . . . 51
Pregnancy, Using Seat Belts . . . . 76
Privacy
Vehicle Data Recording . . . . . . . 402
Program Courtesy Transportation . . . . . . 396
Prohibited Fuels . . . . . . . . . . . . . . . . 268 Proposition
65 Warning,
California . . . . . . . . . . . .285, 304, 356,
Back Cover
Publication Ordering Information . . . . . . . . . . . . . . . . . . . . 399
R
Radio Frequency Statement . . . . 400
Radio Reception . . . . . . . . . . . . . . . . 180
RadiosAM-FM Radio . . . . . . . . . . . . . . . . . 178
Satellite . . . . . . . . . . . . . . . . . . . . . . . 179
Reading Lamps . . . . . . . . . . . . . . . . . 170
Rear Climate Control System . . . 201
Rear Seats . . . . . . . . . . . . . . . . . . . . . . 66 Heated . . . . . . . . . . . . . . . . . . . . . . . . . 69
Rear Storage . . . . . . . . . . . . . . . . . . . 112
Rear Vision Camera (RVC) . . . . . 253
Rear Window Washer/Wiper . . . . 121
Rearview Mirrors . . . . . . . . . . . . . . . . 50 Automatic Dimming . . . . . . . . . . . . . 50
Reclining Seatbacks . . . . . . . . . . . . . 59
Recommended Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Recommended Fluids and
Lubricants . . . . . . . . . . . . . . . . . . . . . 383
