NOTE:When filling warm tires, the tire pressure may need
to be increased up to an additional 4 psi (28 kPa) above the
recommended cold placard pressure in order to turn the
Tire Pressure Monitoring System Warning Light off.
The vehicle may need to be driven for up to 20 minutes
above 15 mph (24 km/h) in order for the TPMS to receive
this information.
Service TPMS Warning
When a system fault is detected, the Tire Pressure Moni-
toring System Warning Light will flash on and off for 75
seconds and then remain on solid. The system fault will
also sound a chime. In addition, the instrument cluster will
display a SERVICE TPM SYSTEM message for a mini-
mum of five seconds and then display dashes (- -) in place
of the pressure value to indicate which sensor is not being
received.
If the ignition switch is cycled, this sequence will repeat,
providing the system fault still exists. If the system fault no
longer exists, the Tire Pressure Monitoring System Warning
Light will no longer flash, and the SERVICE TPM SYS-
TEM message will no longer display, and a pressure value
will display in place of the dashes. A system fault can occur
due to any of the following: •
Jamming due to electronic devices or driving next to
facilities emitting the same radio frequencies as the
TPMS sensors.
• Installing some form of aftermarket window tinting that
affects radio wave signals.
• Lots of snow or ice around the wheels or wheel hous-
ings.
• Using tire chains on the vehicle.
• Using wheels/tires not equipped with TPMS sensors.
NOTE:
• The compact spare tire does not have a tire pressure
monitoring sensor. Therefore, the TPMS will not monitor
the pressure in the compact spare tire.
• If you install the compact spare tire in place of a road tire
that has a pressure below the low-pressure warning
limit, upon the next ignition switch cycle, the Tire
Pressure Monitoring System Warning Light will remain
on and a chime will sound. In addition, the graphic in
the instrument cluster will still display a pressure value
in a different color and an Inflate to XXmessage.
172 SAFETY

Sentry KeyKey Programming .........................28
Sentry Key (Immobilizer) ......................27
Sentry Key Replacement ......................28
Service Assistance ......................... .496
Service Contract .......................... .498
Service Manuals .......................... .500
Settings Personal .............................. .388
Shift Lever Override ....................... .304
Shoulder Belts ............................ .177
Signals, Turn .....................66, 154, 226, 282
Snow Chains (Tire Chains) ....................362
Snow Tires .............................. .358
Spare Tires .....................290, 358, 359, 360
Spark Plugs ............................. .382
Specifications Fuel (Gasoline) ......................... .382
Oil.................................. .382
Speed Control Cancel ............................... .249
Resume .............................. .249
Speed Control (Cruise Control) .................246
Starting ............................. .229, 230
Automatic Transmission ....................229 Button
.................................22
Cold Weather .......................... .231
Engine Fails To Start ..................... .232
Starting And Operating ...................229, 230
Starting Procedures ..................... .229, 230
Steering ..................................56
Column Controls .........................63
Power ............................ .244, 245
Tilt Column .............................56
Wheel, Heated ...........................57
Wheel, Tilt ..............................56
Steering Wheel Audio Controls .................414
Steering Wheel Mounted Sound System Controls . . . .414
Storage ................................. .120
Storage, Vehicle ........................... .100
Stuck, Freeing ............................ .305
Sunglasses
Storage......................... .131
Sun Roof ............................ .105, 107
Sun Visor Extension .........................63
Supplemental Restraint System – Air Bag ..........190
Sway Control, Trailer ....................... .262
Synthetic Engine Oil ....................... .324
Taillights ................................ .282
Telescoping Steering Column ...................56
514 INDEX

Tie Down Hooks, Cargo......................112
Tilt Steering Column .........................56
Time Delay Headlight ...............................65
Tire And Loading Information Placard ............347
Tire Markings ............................ .341
Tires ..................... .226, 351, 358, 359, 365
Aging (Life Of Tires) ..................... .355
Air Pressure ........................... .351
Chains ............................... .362
Changing .......................... .290, 341
Compact Spare ......................... .359
General Information ................351, 358, 359
High Speed ............................ .353
Inflation Pressure ....................... .352
Jacking ............................... .341
Life Of Tires ........................... .355
Load Capacity ...................... .347, 348
Pressure Monitoring System (TPMS) ........151, 168
Quality Grading ........................ .365
Radial ............................... .353
Replacement ........................... .356
Rotation .............................. .363
Safety ............................ .341, 351
Sizes ................................ .343Snow Tires
............................ .358
Spare Tires ...................290, 358, 359, 360
Spinning .............................. .354
Trailer Towing .......................... .267
Tread Wear Indicators .....................355
Wheel Nut Torque ....................... .373
Tire Safety Information ...................... .341
Tongue Weight/Trailer Weight .................265
To Open Hood ........................... .107
Towing ................................. .260
Disabled Vehicle ........................ .306
Guide ................................ .264
Recr

eational ........................... .272
Weight ............................... .264
Towing Behind A Motorhome ..................272
Traction ................................ .273
Traction Control .......................... .167
Trailer Towing ............................ .260
Cooling System Tips ..................... .271
Hitches ............................... .263
Minimum Requirements ....................266
Tips ................................. .270
Trailer And Tongue Weight ..................265
Wiring ............................... .268
Trailer Towing Guide ....................... .264
12
INDEX 515
