2019 DODGE CHARGER height adjustment

NOTE:
•The head restraint should only be removed by qualified
technicians, for service purposes only. If the center rear
head restraint requires removal, see an authorized
dealer.
• The outboard head restraints are not adjustable.
WARNING!
ALL the head restraints MUST be reinstalled in the
vehicle to properly protect the occupants. Follow the
re-installation instructions above prior to operating the
vehicle or occupying a seat.
Front Head Restraint Removal
To remove the head restraint, raise it up as far as it can go.
Then, push the adjustment button and the release button at
the base of each post while pulling the head restraint up. To
reinstall the head restraint, put the head restraint posts into
the holes. Then, adjust it to the appropriate height.
NOTE: Do not reposition the head restraint 180 degrees to
the incorrect position in an attempt to gain additional
clearance to the back of the head.
Adjustment Button
58 GETTING TO KNOW YOUR VEHICLE

Adjustable Upper Shoulder Belt Anchorage
In the driver and outboard front passenger seats, the top of
the shoulder belt can be adjusted upward or downward to
position the seat belt away from your neck. Push or
squeeze the anchorage button to release the anchorage, and
move it up or down to the position that serves you best.
As a guide, if you are shorter than average, you will prefer
the shoulder belt anchorage in a lower position, and if you
are taller than average, you will prefer the shoulder belt
anchorage in a higher position. After you release the
anchorage button, try to move it up or down to make sure
that it is locked in position.NOTE:
The adjustable upper shoulder belt anchorage is
equipped with an Easy Up feature. This feature allows the
shoulder belt anchorage to be adjusted in the upward
position without pushing or squeezing the release button.
To verify the shoulder belt anchorage is latched, pull
downward on the shoulder belt anchorage until it is locked
into position.
WARNING!
• Wearing your seat belt incorrectly could make your
injuries in a collision much worse. You might suffer
internal injuries, or you could even slide out of the
seat belt. Follow these instructions to wear your seat
belt safely and to keep your passengers safe, too.
• Position the shoulder belt across the shoulder and
chest with minimal, if any slack so that it is comfort-
able and not resting on your neck. The retractor will
withdraw any slack in the shoulder belt.
• Misadjustment of the seat belt could reduce the
effectiveness of the safety belt in a crash.
• Always make all seat belt height adjustments when
the vehicle is stationary.
Adjustable Anchorage
5
SAFETY 185

Safety Checks Inside Vehicle...................220
Safety Checks Outside Vehicle .................222
Safety Defects, Reporting .....................537
Safety, Exhaust Gas ........................ .219
Safety Information, Tire ..................... .397
Safety Tips .............................. .219
Schedule, Maintenance ................361, 362, 365
Seat Belt Reminder ........................ .139
Seat Belts ............................ .179, 220
Adjustable Shoulder Belt ...................185
Adjustable Upper Shoulder Anchorage .........185
Adjustable Upper Shoulder Belt Anchorage ......185
Automatic Locking Retractor (ALR) ...........187
Child Restraints ........................ .202
Energy Management Feature ................187
Extender .............................. .186
Front Seat ...................... .179, 181, 183
Inspection ............................. .220
Lap/Shoulder Belt Operation ................183
Lap/Shoulder Belts ...................... .181
Lap/Shoulder Belt Untwisting ...............184
Operating Instructions .....................183
Pregnant Women ........................ .186
Pretensioners .......................... .187
Rear Seat ............................. .181Reminder
............................. .179
Seat Belt Extender ....................... .186
Seat Belt Pretensioner .....................187
Untwisting Procedure .....................184
Seat Belts Maintenance ...................... .422
Seats .............................. .43, 48, 53
Adjustment ....................... .43, 44, 48
Easy Entry ..............................52
Head Restraints ....................... .56, 57
Heated .................................
53
Height Adjustment ........................48
Memory ................................50
Power .................................48
Rear Folding ......................... .43, 46
Seatback Release ...................... .44, 46
Tilting ........................... .43, 44, 48
Vented .................................55
Ventilated ...............................55
Security Alarm ......................... .34, 140
Arm The System ..........................35
Selection Of Coolant (Antifreeze) ...............438
Sentry Key Key Programming .........................34
Sentry Key (Immobilizer) ......................33
Sentry Key Replacement ....................26, 34
12
INDEX 551
