Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 11/1/18
300 Vehicle Care
occurs, take the vehicle to the
dealer and have it repaired as soon
as possible.
Change the fluid at the intervals
listed inMaintenance Schedule
0 373, and be sure to use the
transmission fluid listed in
Recommended Fluids and
Lubricants 0382.
Caution
Use of the incorrect automatic
transmission fluid may damage
the vehicle, and the damage may
not be covered by the vehicle
warranty. Always use the correct
automatic transmission fluid. See
Recommended Fluids and
Lubricants 0382.
If you need to check the
transmission fluid level, take the
vehicle to your dealer.
Engine Air Cleaner/Filter
The engine air cleaner/filter is in the
engine compartment on the
passenger side of the vehicle. See
Engine Compartment Overview
0 293 for location.
When to Inspect the Engine Air
Cleaner/Filter
For intervals on changing and
inspecting the engine air cleaner/
filter, see Maintenance Schedule
0 373.
How to Inspect the Engine Air
Cleaner/Filter
Do not start the engine or have the
engine running with the engine air
cleaner/filter housing open. Before
removing the engine air cleaner/
filter, make sure that the engine air
cleaner/filter housing and nearby
components are free of dirt and
debris. Remove the engine air
cleaner/filter. Lightly tap and shake
the engine air cleaner/filter (away
from the vehicle), to release loose
dust and dirt. Inspect the engine air
cleaner/filter for damage, and replace if damaged. Do not clean
the engine air cleaner/filter or
components with water or
compressed air.
To inspect or replace the air cleaner/
filter:
2.0L L4 Engine
1. Remove the five screws and lift the cover out of the assembly.
2. Inspect or replace the engine air cleaner/filter.
3. Lower the cover and secure with the five screws.

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 11/1/18
308 Vehicle Care
Replacing Brake System Parts
Always replace brake system parts
with new, approved replacement
parts. If this is not done, the brakes
may not work properly. The braking
performance expected can change
in many other ways if the wrong
replacement brake parts are
installed or if parts are improperly
installed.
Brake Fluid
The brake master cylinder reservoir
is filled with GM approved DOT 3
brake fluid as indicated on the
reservoir cap. SeeEngine
Compartment Overview 0293 for
the location of the reservoir. Checking Brake Fluid
With the vehicle in P (Park) on a
level surface, the brake fluid level
should be between the minimum
and maximum marks on the brake
fluid reservoir.
There are only two reasons why the
brake fluid level in the reservoir may
go down:
.
Normal brake lining wear. When
new linings are installed, the
fluid level goes back up.
. A fluid leak in the brake
hydraulic system. Have the
brake hydraulic system fixed.
With a leak, the brakes will not
work well.
Always clean the brake fluid
reservoir cap and the area around
the cap before removing it.
Do not top off the brake fluid.
Adding fluid does not correct a leak.
If fluid is added when the linings are
worn, there will be too much fluid
when new brake linings are installed. Add or remove fluid, as
necessary, only when work is done
on the brake hydraulic system.
{Warning
If too much brake fluid is added, it
can spill on the engine and burn,
if the engine is hot enough. You
or others could be burned, and
the vehicle could be damaged.
Add brake fluid only when work is
done on the brake hydraulic
system.
When the brake fluid falls to a low
level, the brake warning light comes
on. See Brake System Warning
Light 0144.
Brake fluid absorbs water over time
which degrades the effectiveness of
the brake fluid. Replace brake fluid
at the specified intervals to prevent
increased stopping distance. See
Maintenance Schedule 0373.

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 11/1/18
Vehicle Care 357
3. Good Battery Negative (-)Terminal
4. Good Battery Positive (+) Terminal
The jump start positive (+)
Terminal (1) and the negative
remote negative terminal (2) for the
discharged battery are on the driver
side of the vehicle.
The jump start positive (+)
terminal (4) and negative (-)
terminal (3) are on the battery of the
vehicle providing the jump start.
The positive jump start connection
for the discharged battery is under a
cover. Remove the cover to expose
the terminal.
1. Check the other vehicle. It must have a 12-volt battery
with a negative ground system.
Caution
If the other vehicle does not have
a 12-volt system with a negative
ground, both vehicles can be
(Continued)
Caution (Continued)
damaged. Only use a vehicle that
has a 12-volt system with a
negative ground for jump starting.
2. Position the two vehicles so that they are not touching.
3. Set the parking brake firmly and put the shift lever in
P (Park) with an automatic
transmission, or Neutral with a
manual transmission. See
Shifting Into Park 0230.
Caution
If any accessories are left on or
plugged in during the jump
starting procedure, they could be
damaged. The repairs would not
be covered by the vehicle
warranty. Whenever possible, turn
off or unplug all accessories on
either vehicle when jump starting. 4. Turn the ignition off. Turn off all
lights and accessories in both
vehicles, except the hazard
warning flashers if needed.
{Warning
An electric fan can start up even
when the engine is not running
and can injure you. Keep hands,
clothing, and tools away from any
underhood electric fan.
{Warning
Using a match near a battery can
cause battery gas to explode.
People have been hurt doing this,
and some have been blinded.
Use a flashlight if you need more
light.
Battery fluid contains acid that
can burn you. Do not get it on
you. If you accidentally get it in
your eyes or on your skin, flush
the place with water and get
medical help immediately.

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
Service and Maintenance 379
Additional
Maintenance and Care
Your vehicle is an important
investment and caring for it properly
may help to avoid future costly
repairs. To maintain vehicle
performance, additional
maintenance services may be
required.
It is recommended that your dealer
perform these services—their
trained dealer technicians know
your vehicle best. Your dealer can
also perform a thorough
assessment with a multi-point
inspection to recommend when your
vehicle may need attention.
The following list is intended to
explain the services and conditions
to look for that may indicate
services are required. Battery
The 12-volt battery supplies power
to start the engine and operate any
additional electrical accessories.
.
To avoid break-down or failure to
start the vehicle, maintain a
battery with full cranking power.
. Trained dealer technicians have
the diagnostic equipment to test
the battery and ensure that the
connections and cables are
corrosion-free.
Belts
. Belts may need replacing if they
squeak or show signs of
cracking or splitting.
. Trained dealer technicians have
access to tools and equipment
to inspect the belts and
recommend adjustment or
replacement when necessary. Brakes
Brakes stop the vehicle and are
crucial to safe driving.
.
Signs of brake wear may include
chirping, grinding, or squealing
noises, or difficulty stopping.
. Trained dealer technicians have
access to tools and equipment
to inspect the brakes and
recommend quality parts
engineered for the vehicle.
Fluids
Proper fluid levels and approved
fluids protect the vehicle’s systems
and components. See
Recommended Fluids and
Lubricants 0382 for GM approved
fluids.
. Engine oil and windshield
washer fluid levels should be
checked at every fuel fill.
. Instrument cluster lights may
come on to indicate that fluids
may be low and need to be
filled.

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
Index 415
IndexA
Accessories andModifications . . . . . . . . . . . . . . . . . . 291
Accessory Power . . . . . . . . . . . . . . . 230
Adaptive Cruise Control . . . . . . . . 248
Add-On Electrical Equipment . . . 288
Additional Information OnStar . . . . . . . . . . . . . . . . . . . . . . . 405
Additional Maintenance and Care . . . . . . . . . . . . . . . . . . . . . . 379
Adjustments Lumbar, Front Seats . . . . . . . . . . . . 64
Agreements Trademarks and License . . . . . 200
Air Cleaner/Filter, Engine . . . . . . . 300
Air Conditioning . . . . . . . . . . . 201, 204
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . 207
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 206
Airbag System
Check . . . . . . . . . . . . . . . . . . . . . . . . . . 97
How Does an AirbagRestrain? . . . . . . . . . . . . . . . . . . . . . 90
Passenger Sensing System . . . . 92
What Makes an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 90
What Will You See after an Airbag Inflates? . . . . . . . . . . . . . . . 90 Airbag System (cont'd)
When Should an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 89
Where Are the Airbags? . . . . . . . . 87
Airbags Adding Equipment to theVehicle . . . . . . . . . . . . . . . . . . . . . . . . 96
Passenger Status Indicator . . . 141
Readiness Light . . . . . . . . . . . . . . 141
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . 96
System Check . . . . . . . . . . . . . . . . . . 85
Alarm Vehicle Security . . . . . . . . . . . . . . . . 50
Alert Lane Change . . . . . . . . . . . . . . . . . 267
Side Blind Zone (SBZA) . . . . . . 267
All-Season Tires . . . . . . . . . . . . . . . . 327
All-Wheel Drive . . . . . . . . . . . . 237, 310
AM-FM Radio . . . . . . . . . . . . . . . . . . . 181
Antenna . . . . . . . . . . . . . . . . . . . . . . . . 185
Multi-band . . . . . . . . . . . . . . . . . . . . 185
Antilock Brake System (ABS) . . . 237
Warning Light . . . . . . . . . . . . . . . . . 145
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . 362
Interior . . . . . . . . . . . . . . . . . . . . . . . . 366

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
416 Index
Apple CarPlay andAndroid Auto . . . . . . . . . . . . . . . . . . 197
Assistance Program, Roadside . . . . . . . . . . . . . . . . . . . . . . 393
Assistance Systems for Driving . . . . . . . . . . . . . . . . . . . . . . . . 261
Assistance Systems for
Parking and Backing . . . . . . . . . . 258
Audio Theft-Deterrent Feature . . . . . . . 177
Auto Stop
Stop/Start System . . . . . . . . . . . . 227
Automatic Dimming Mirrors . . . . . . . . . . . . . . . . 53
Door Locks . . . . . . . . . . . . . . . . . . . . . 41
Forward Braking . . . . . . . . . . . . . . 263
Headlamp System . . . . . . . . . . . . 170
Transmission . . . . . . . . . . . . . . . . . 233
Transmission Fluid . . . . . . . . . . . 299
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 235
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 310
Auxiliary Devices . . . . . . . . . . . . . . . . . . . . . . . 191
Avoiding Untrusted Media Devices . . . . . . . . . . . . . . . . . . . . . . . 185B
BatteryExterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 175
Load Management . . . . . . . . . . . . 174
Power Protection . . . . . . . . . . . . . 175
Battery - North America . . . . 309, 356
Blade Replacement, Wiper . . . . . 311
Bluetooth Overview . . . . . . . . . . . . . . . . 192, 193
Brake Parking, Electric . . . . . . . . . . . . . . 238
System Warning Light . . . . . . . . 144
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 307
Antilock . . . . . . . . . . . . . . . . . . . . . . . 237
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 240
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 308
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 210 Automatic Forward . . . . . . . . . . . 263
Braking System Front Pedestrian (FPB) . . . . . . . 265
Break-In, New Vehicle . . . . . . . . . . 224
Bulb Replacement Headlamp Aiming . . . . . . . . . . . . . 314
Headlamps . . . . . . . . . . . . . . . . . . . 314
Headlamps, Front Turn
Signal, and Sidemarker . . . . . 315 Bulb Replacement (cont'd)
High Intensity Discharge
(HID) Lighting . . . . . . . . . . . . . . . 314
License Plate Lamps . . . . . . . . . 315
Buying New Tires . . . . . . . . . . . . . . . 342
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 128
California Perchlorate Materials
Requirements . . . . . . . . . . . . . . . 291
California Proposition
65 Warning . . . . . . . . . .290, 309, 356, Back Cover
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 386
Carbon Monoxide
Engine Exhaust . . . . . . . . . . . . . . . 232
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 43
Winter Driving . . . . . . . . . . . . . . . . 218
Cargo Management System . . . . . . . . . 120
Caution, Danger, and Warning . . . . 3
Center Console Storage . . . . . . . . 120
Chains, Tire . . . . . . . . . . . . . . . . . . . . 346

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
Index 417
ChargingWireless . . . . . . . . . . . . . . . . . . . . . . 132
Charging System Light . . . . . . . . . 142
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 142
Child Restraints
Infants and Young Children . . . . . 99
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . 105
Older Children . . . . . . . . . . . . . . . . . . 98
Securing . . . . . . . . . . . . . . . . . .113, 115
Systems . . . . . . . . . . . . . . . . . . . . . . 102
Circuit Breakers . . . . . . . . . . . . . . . . 317
Cleaning Exterior Care . . . . . . . . . . . . . . . . . 362
Interior Care . . . . . . . . . . . . . . . . . . 366
Climate Control Systems Dual Automatic . . . . . . . . . . . . . . . 201
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . 204
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Cluster, Instrument . . . . . . . . . . . . . 135
Collision Damage Repair . . . . . . . 396
Compact Spare Tire . . . . . . . . . . . . 354
Compartments
Storage . . . . . . . . . . . . . . . . . . . . . . . .119
Compass . . . . . . . . . . . . . . . . . . . . . . . 128 Connected Services
Connections . . . . . . . . . . . . . . . . . . 412
Diagnostics . . . . . . . . . . . . . . . . . . . 414
Navigation . . . . . . . . . . . . . . . . . . . . .411
Connections Connected Services . . . . . . . . . . 412
Control
Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . 241
Control of a Vehicle . . . . . . . . . . . . . 210
Convex Mirrors . . . . . . . . . . . . . . . . . . 52
Coolant Engine Temperature Gauge . . 139
Cooling . . . . . . . . . . . . . . . . . . . . 201, 204
Cooling System . . . . . . . . . . . . . . . . . 301
Courtesy Lamps . . . . . . . . . . . . . . . . 172
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . . . . 395
Cruise Control . . . . . . . . . . . . . . . . . . 246 Light . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Cruise Control, Adaptive . . . . . . . . 248
Customer Assistance . . . . . . . . . . . 392
Offices . . . . . . . . . . . . . . . . . . . . . . . . 391
Text Telephone (TTY)Users . . . . . . . . . . . . . . . . . . . . . . . 392
Customer Information Publications OrderingInformation . . . . . . . . . . . . . . . . . . 398 Customer Satisfaction
Procedure . . . . . . . . . . . . . . . . . . . . . 389
D
Damage Repair, Collision . . . . . . . 396
Danger, Warning, and Caution . . . . 3
Data Collection
Infotainment System . . . . . . . . . . 402
OnStar . . . . . . . . . . . . . . . . . . . . . . . 402
Data Recorders, Event . . . . . . . . . 401
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . . . 169
Defensive Driving . . . . . . . . . . . . . . . 210
Delayed Locking . . . . . . . . . . . . . . . . . 41
Devices Auxiliary . . . . . . . . . . . . . . . . . . . . . . 191
Diagnostics
Connected Services . . . . . . . . . . 414
Distracted Driving . . . . . . . . . . . . . . . 209
Dome Lamps . . . . . . . . . . . . . . . . . . . 172
Door Ajar Light . . . . . . . . . . . . . . . . . . . . . 151
Delayed Locking . . . . . . . . . . . . . . . . 41
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Power Locks . . . . . . . . . . . . . . . . . . . . 41
Drive Belt Routing, Engine . . . . . . 388
Drive Systems
All-Wheel Drive . . . . . . . . . . 237, 310

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
418 Index
Driver Assistance Systems . . . . . 256
Driver InformationCenter (DIC) . . . . . . . . . . . . . . . . . . 151
Driver Mode Control . . . . . . . . . . . . 242
Driving Assistance Systems . . . . . . . . . . 261
Characteristics andTowing Tips . . . . . . . . . . . . . . . . . 275
Defensive . . . . . . . . . . . . . . . . . . . . . 210
Drunk . . . . . . . . . . . . . . . . . . . . . . . . . 210
For Better Fuel Economy . . . . . . . 27
Hill and Mountain Roads . . . . . . 218
If the Vehicle is Stuck . . . . . . . . . 220
Loss of Control . . . . . . . . . . . . . . . 212
Off-Road . . . . . . . . . . . . . . . . . . . . . 212
Off-Road Recovery . . . . . . . . . . . .211
Vehicle Load Limits . . . . . . . . . . . 220
Wet Roads . . . . . . . . . . . . . . . . . . . 217
Winter . . . . . . . . . . . . . . . . . . . . . . . . 218
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . 201
E
Electric Parking Brake . . . . . . . . . . 238
Electric Parking Brake Light . . . . 145
Electrical Equipment,
Add-On . . . . . . . . . . . . . . . . . . . . . . . 288 Electrical System
Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 318
Fuses and Circuit Breakers . . . 317
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 321
Overload . . . . . . . . . . . . . . . . . . . . . 317
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 323
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . 404
Engine Air Cleaner/Filter . . . . . . . . . . . . . 300
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 142
Compartment Overview . . . . . . . 293
Coolant Temperature
Gauge . . . . . . . . . . . . . . . . . . . . . . 139
Cooling System . . . . . . . . . . . . . . . 301
Drive Belt Routing . . . . . . . . . . . . 388
Exhaust . . . . . . . . . . . . . . . . . . . . . . 232
Heater . . . . . . . . . . . . . . . . . . . . . . . . 228
Oil Life System . . . . . . . . . . . . . . . 298
Oil Pressure Light . . . . . . . . . . . . 148
Overheating . . . . . . . . . . . . . . . . . . 305
Power Messages . . . . . . . . . . . . . 154
Running While Parked . . . . . . . . 233
Starting . . . . . . . . . . . . . . . . . . . . . . . 226 Entry Lighting . . . . . . . . . . . . . . . . . . . 174
Equipment, Towing . . . . . . . . . . . . . 283
Event Data Recorders . . . . . . . . . . 401
Exit Lighting . . . . . . . . . . . . . . . . . . . . 174
Extended Parking . . . . . . . . . . . . . . . 231
Extender, Seat Belt . . . . . . . . . . . . . . 83
Exterior Lamp Controls . . . . . . . . . 167
Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . . . 175
F
FeaturesMemory . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter, Engine Air Cleaner . . . . . . . . . . . 300
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 169
Flashers, Hazard Warning . . . . . . 171
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 347 Changing . . . . . . . . . . . . . . . . . . . . . 348
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 370
Fluid Automatic Transmission . . . . . . 299
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 308
Washer . . . . . . . . . . . . . . . . . . . . . . . 306
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 172
Folding Mirrors . . . . . . . . . . . . . . . . . . 52
Forward Automatic Braking . . . . . 263
