2019 CHEVROLET SILVERADO 2500 glove box

Chevrolet Silverado LD 1500 and Silverado 2500/3500 Owner Manual (GMNA-
Localizing-U.S./Canada-12162993) - 2019 - crc - 4/4/18
Keys, Doors, and Windows 35
Interference from radio-frequency
identification (RFID) tags may
prevent the key from starting the
vehicle. Keep RFID tags away from
the key when starting the vehicle.
The key is used for the ignition, all
door locks, and the glove box.
If equipped with memory seats,
keys 1 and 2 are linked to seating
positions of memory 1 or 2. See
Memory Seats060.
Programming Keys
Follow these procedures to program
up to eight keys to the vehicle. Programming with Two
Recognized Keys
To program a new key:
1. Insert the original, already programmed key in the ignition
and turn the ignition on.
2. Turn the ignition off, and remove the key.
3. Quickly, within five seconds, insert the second original
already programmed key in the
ignition and turn the ignition on.
4. Turn the ignition off, and remove the key.
5. Insert the key to be programmed and turn the
ignition on within five seconds.
6. After a few seconds, the security light will turn off once
the key has been programmed.
7. Repeat Steps 1–5 if additional keys are to be programmed.
If a key is lost or damaged, see your
dealer to have a new key made. Programming without
Recognized Keys
Program a new key to the vehicle
when a recognized key is not
available. Canadian regulations
require that owners see their dealer.
If two currently recognized keys are
not available, follow this procedure
to program the first key.
This procedure will take
approximately 30 minutes to
complete for the first key. The
vehicle must be off and all of the
keys you wish to program must be
with you.
1. Insert the new vehicle key into the ignition.
2. Turn the ignition on. The security light will come on.
3. Wait 10 minutes until the security light turns off.
4. Turn the ignition off.
5. Repeat Steps 2–4 two more times. After the third time, turn
the ignition on; the key is

Chevrolet Silverado LD 1500 and Silverado 2500/3500 Owner Manual (GMNA-
Localizing-U.S./Canada-12162993) - 2019 - crc - 4/6/18
122 Storage
Storage
Storage Compartments
Storage Compartments . . . . . . . 122
Instrument Panel Storage . . . . 122
Glove Box . . . . . . . . . . . . . . . . . . . . 122
Cupholders . . . . . . . . . . . . . . . . . . . 123
Sunglasses Storage . . . . . . . . . . 123
Center Console Storage . . . . . . 123
Floor Console Storage . . . . . . . . 124
Additional Storage Features
Cargo Tie-Downs . . . . . . . . . . . . . 124
Storage
Compartments
{Warning
Do not store heavy or sharp
objects in storage compartments.
In a crash, these objects may
cause the cover to open and
could result in injury.
Instrument Panel Storage
If equipped, there is storage under
the climate control system.
To access, pull down on the handle.
Card Holder
If equipped, there is a card holder
on the front instrument panel to the
left of the steering wheel.
Glove Box
To access the upper glove box,
unlock with the key and pull up on
the handle.
To access the lower glove box, pull
down on the handle.

Chevrolet Silverado LD 1500 and Silverado 2500/3500 Owner Manual (GMNA-
Localizing-U.S./Canada-12162993) - 2019 - crc - 4/4/18
224 Climate Controls
1. Open the lower glove box doorcompletely.
2. Remove the four screws from around the lower glove box.
The door does not need to be
removed to access the screws.
3. Close the lower glove box doorand pull it from its frame to
remove the entire unit.
4. Release the two tabs holding
the service door. Open the
service door and remove the
old filter.
5. Install the new air filter.
6. Close the service door and secure the tabs.
7. Reverse the steps to reinstall the glove box.
See your dealer if additional
assistance is needed.
Service
All vehicles have a label underhood
that identifies the refrigerant used in
the vehicle. The refrigerant system
should only be serviced by trained
and certified technicians. The air
conditioning evaporator should
never be repaired or replaced by
one from a salvage vehicle.
It should only be replaced by a new
evaporator to ensure proper and
safe operation.
During service, all refrigerants
should be reclaimed with proper
equipment. Venting refrigerants
directly to the atmosphere is harmful
to the environment and may also
create unsafe conditions based on
inhalation, combustion, frostbite,
or other health-based concerns.
The air conditioning system requires
periodic maintenance. See
Maintenance Schedule 0430.

Chevrolet Silverado LD 1500 and Silverado 2500/3500 Owner Manual (GMNA-
Localizing-U.S./Canada-12162993) - 2019 - crc - 4/4/18
244 Driving and Operating
equipment. See www.gmupfitter.com
for additional pickup box load
bearing structural information.
Truck-Camper Loading
Information
A vehicle-specific Truck-Camper
Loading Information label is
attached to the inside of the
vehicle's glove box. This label
indicates if a slide-in camper
can be carried, how much of a
load the vehicle can carry, and
how to correctly spread out the
load. It will help to match the
right slide-in camper to the
vehicle.
Your dealer can help make a
good vehicle-camper match and
help determine the Cargo
Weight Rating (CWR).
When installing and loading a
slide-in camper, check the
manufacturer's instructions.When carrying a slide-in
camper, the total cargo load of
the vehicle is the weight of the
camper plus:
.Everything added to the
camper after it left the
factory.
.Everything in the camper.
.All the people inside.
The CWR is the maximum
weight of the load the vehicle
can carry. It does not include the
weight of the people inside. But,
use about 68 kg (150 lb) for
each seat.
The total cargo load must not be
more than the vehicle's CWR.
Refer to the Truck-Camper
Loading Information label in the
glove box for dimensions A and
B as shown in the following
illustration.Use the rear edge of the load
floor for measurement purposes.
The recommended location for
the cargo center of gravity is at
point C for the CWR. It is the
point where the mass of a body
is concentrated and,
if suspended at that point, would
balance the front and rear.

Chevrolet Silverado LD 1500 and Silverado 2500/3500 Owner Manual (GMNA-
Localizing-U.S./Canada-12162993) - 2019 - crc - 4/4/18
Technical Data 445
Technical Data
Vehicle Identification
Vehicle IdentificationNumber (VIN) . . . . . . . . . . . . . . . 445
Service Parts Identification Label . . . . . . . . . . . . . . . . . . . . . . . . 445
Vehicle Data
Capacities andSpecifications . . . . . . . . . . . . . . . 446
Engine Drive Belt Routing . . . . 448
Vehicle Identification
Vehicle Identification
Number (VIN)
This legal identifier is in the front
corner of the instrument panel, on
the driver side of the vehicle. It can
be seen through the windshield from
outside. The Vehicle Identification
Number (VIN) also appears on the
Vehicle Certification and Service
Parts labels and certificates of title
and registration.
Engine Identification
The eighth character in the VIN is
the engine code. This code
identifies the vehicle's engine,
specifications, and replacement parts. See
“Engine Specifications”
under Capacities and Specifications
0 446 for the vehicle's engine code.
Service Parts
Identification Label
There may be a label on the inside
of the glove box that contains the
following information:
.
Vehicle Identification
Number (VIN)
. Model designation
. Paint information
. Production options and special
equipment
If there is no label, there is a
barcode on the certification label on
the center (B) pillar to scan for this
same information.

Chevrolet Silverado LD 1500 and Silverado 2500/3500 Owner Manual (GMNA-
Localizing-U.S./Canada-12162993) - 2019 - crc - 4/4/18
480 Index
Gauges (cont'd)Voltmeter . . . . . . . . . . . . . . . . . . . . . 142
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . 135
General Information Service and Maintenance . . . . . 428
Towing . . . . . . . . . . . . . . . . . . . . . . . . 294
Vehicle Care . . . . . . . . . . . . . . . . . . 324
Glove Box . . . . . . . . . . . . . . . . . . . . . . 122
GM Mobility Reimbursement
Program . . . . . . . . . . . . . . . . . . . . . . . 453
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 357
Hazard Warning Flashers . . . . . . . 175
Head Restraints . . . . . . . . . . . . . . . . . 56
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 357
Automatic . . . . . . . . . . . . . . . . . . . . . 174
Bulb Replacement . . . . . . . . . . . . 357
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 174
Flash-to-Pass . . . . . . . . . . . . . . . . . 174
Headlamps, Front Turn Signal, Sidemarker, and
Parking Lamps . . . . . . . . . . . . . . 358
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 358 Headlamps (cont'd)
High-Beam On Light . . . . . . . . . . 153
High/Low Beam Changer . . . . . 173
Lamps On Reminder . . . . . . . . . 154
Heated Steering Wheel . . . . . . . . . . . . . . . 128
Heated and Ventilated Front Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Heated Mirrors . . . . . . . . . . . . . . . . . . . 48
Heater
Engine Coolant . . . . . . . . . . . . . . . 251
Heating . . . . . . . . . . . . . . .216, 218, 220
High-Beam On Light . . . . . . . . . . . . 153
High-Speed Operation . . . . . . . . . . 380
Hill and Mountain Roads . . . . . . . . 235
Hill Descent Control (HDC) . . . . . 275
Hill Descent Control Light . . . . . . . 150
Hill Start Assist (HSA) . . . . . . . . . . 272
Home Page . . . . . . . . . . . . . . . . . . . . . 184
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 326
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
How to Wear Seat Belts Properly . . . . . . . . . . . . . . . . . . . . . . . . 68
HVAC . . . . . . . . . . . . . . . . .216, 218, 220
I
Idle System Fast . . . . . . . . . . . . . . . . . . . . . . . . . . 250
Ignition Positions . . . . . . . . . . . . . . . 247
Ignition Transmission Lock Check . . . . . . . . . . . . . . . . . . . . . . . . . 354
Immobilizer . . . . . . . . . . . . . . . . . . . . . . 44
Indicator Vehicle Ahead . . . . . . . . . . . . . . . . 151
Infants and Young Children,
Restraints . . . . . . . . . . . . . . . . . . . . . . 92
Information Publication Ordering . . . . . . . . . . 458
Infotainment . . . . . . . . . . . . . . . . . . . . 181
Infotainment System . . . . . . . . . . . . 462
Instrument Cluster . . . . . . . . . . . . . . 136
Instrument Panel
Storage Area . . . . . . . . . . . . . . . . . 122
Interior Rearview Mirrors . . . . . . . . . 49
Introduction . . . . . . . . . . . . . . . . . . . . . . . 2
J
Jack Auxiliary . . . . . . . . . . . . . . . . . . . . . . 195
Jump Starting - North America . . . . . . . . . . . . . . . . . . . . . . . 408

Chevrolet Silverado LD 1500 and Silverado 2500/3500 Owner Manual (GMNA-
Localizing-U.S./Canada-12162993) - 2019 - crc - 4/4/18
Index 485
Software Updates . . . . . . . . . . . . . . 184
Special Application Services . . . . 436
Specifications andCapacities . . . . . . . . . . . . . . . . . . . . . 446
Speedometer . . . . . . . . . . . . . . . . . . . 139
StabiliTrak OFF Light . . . . . . . . . . . . . . . . . . . . . 151
Start Assist, Hill . . . . . . . . . . . . . . . . . 272
Start Vehicle, Remote . . . . . . . . . . . 38
Starter Switch Check . . . . . . . . . . . 354
Starting the Engine . . . . . . . . . . . . . 249
Steering . . . . . . . . . . . . . . . . . . . . . . . . 228 Fluid, Power . . . . . . . . . . . . . . . . . . 345
Heated Wheel . . . . . . . . . . . . . . . . 128
Wheel Adjustment . . . . . . . . . . . . 127
Wheel Controls . . . . . . . . . . . . . . . 127
Steps Power Assist . . . . . . . . . . . . . . . . . . . 42
Stoplamps and Back-up Lamps Bulb Replacement . . . . . . . . . . . . 359
Storage Areas
Center Console . . . . . . . . . . . . . . . 123
Floor Console . . . . . . . . . . . . . . . . 124
Glove Box . . . . . . . . . . . . . . . . . . . . 122
Instrument Panel . . . . . . . . . . . . . 122
Sunglasses . . . . . . . . . . . . . . . . . . . 123
Storage Compartments . . . . . . . . . 122 Struts
Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . 356
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 237
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 53
Sunglass Storage . . . . . . . . . . . . . . . 123
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Switches Airbag On-Off . . . . . . . . . . . . . . . . . . . 82
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Forward Collision
Alert (FCA) . . . . . . . . . . . . . . . . . . 282
Infotainment . . . . . . . . . . . . . 181, 462
Noise Control . . . . . . . . . . . . . . . . . 352
Systems Driver Assistance . . . . . . . . . . . . . 279
T
Tachometer . . . . . . . . . . . . . . . . . . . . . 139
Tailgate . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Taillamps . . . . . . . . . . . . . . . . . . . . . . . 359
Bulb Replacement . . . . . . . . . . . . 359
Text Telephone (TTY) Users . . . . 452
Theft-Deterrent Systems . . . . . . . . . 45 Immobilizer . . . . . . . . . . . . . . . . . . . . . 44
Throttle, Adjustable . . . . . . . . . . . . . 246
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370
All-Season . . . . . . . . . . . . . . . . . . . . 370
All-Terrain . . . . . . . . . . . . . . . . . . . . 372
Buying New Tires . . . . . . . . . . . . . 389
Chains . . . . . . . . . . . . . . . . . . . . . . . . 394
Changing . . . . . . . . . . . . . . . . . . . . . 396
Designations . . . . . . . . . . . . . . . . . 374
Different Size . . . . . . . . . . . . . . . . . 390
Full-Size Spare . . . . . . . . . . . . . . . 407
If a Tire Goes Flat . . . . . . . . . . . . 394
Inspection . . . . . . . . . . . . . . . . . . . . 385
Low Profile . . . . . . . . . . . . . . . . . . . 371
Pressure . . . . . . . . . . . . . . . . . 378, 380
Pressure Light . . . . . . . . . . . . . . . . 152
Pressure Monitor Operation . . 381
Pressure Monitor System . . . . . 380
Rotation . . . . . . . . . . . . . . . . . . . . . . 386
Sidewall Labeling . . . . . . . . . . . . . 372
Terminology and Definitions . . 376
Uniform Tire QualityGrading . . . . . . . . . . . . . . . . . . . . . 391
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . . . 392
Wheel Replacement . . . . . . . . . . 393
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 388
Winter . . . . . . . . . . . . . . . . . . . . . . . . 371
Top Tier Fuel . . . . . . . . . . . . . . . . . . . 289
