2019 CHEVROLET CORVETTE technical data

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
ContentsIntroduction . . . . . . . . . . . . . . . . . . . . . . 2
In Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Keys, Doors, and Windows . . . . . 25
Seats and Restraints . . . . . . . . . . . 58
Storage . . . . . . . . . . . . . . . . . . . . . . . . . 94
Instruments and Controls . . . . . . . 98
Lighting . . . . . . . . . . . . . . . . . . . . . . . 139
Infotainment System . . . . . . . . . . 145
Climate Controls . . . . . . . . . . . . . . 151
Driving and Operating . . . . . . . . . 157
Vehicle Care . . . . . . . . . . . . . . . . . . 218
Service and Maintenance . . . . . 310
Technical Data . . . . . . . . . . . . . . . . 325
Customer Information . . . . . . . . . 330
Reporting Safety Defects . . . . . . 340
OnStar . . . . . . . . . . . . . . . . . . . . . . . . 344
Connected Services . . . . . . . . . . . 352
Index . . . . . . . . . . . . . . . . . . . . 356

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
Technical Data 325
Technical Data
Vehicle Identification
Vehicle IdentificationNumber (VIN) . . . . . . . . . . . . . . . 325
Service Parts Identification Label . . . . . . . . . . . . . . . . . . . . . . . . 325
Vehicle Data
Capacities andSpecifications . . . . . . . . . . . . . . . 326
Engine Drive Belt Routing . . . . 329
Vehicle Identification
Vehicle Identification
Number (VIN)
This legal identifier is in the front
corner of the instrument panel, on
the driver side of the vehicle. It can
be seen through the windshield from
outside. The Vehicle Identification
Number (VIN) also appears on the
Vehicle Certification and Service
Parts labels and certificates of title
and registration.
Engine Identification
The eighth character in the VIN is
the engine code. This code
identifies the vehicle's engine,
specifications, and replacement parts. See
“Engine Specifications”
under Capacities and Specifications
0 326 for the vehicle's engine code.
Service Parts
Identification Label
There may be a label under the
carpet in the hatch/trunk area on the
passenger side, that contains the
following information:
.
Vehicle Identification
Number (VIN)
. Model designation
. Paint information
. Production options and special
equipment
If there is no label, there is a
barcode on the certification label on
the center (B) pillar to scan for this
same information.

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
326 Technical Data
Vehicle Data
Capacities and Specifications
The following approximate capacities are given in metric and English conversions.
SeeRecommended Fluids and Lubricants 0321.
Application Capacities
Metric English
Air Conditioning Refrigerant For the air conditioning system refrigerant charge type and amount, see the refrigerant label underthe hood. See your dealer for more information.
Engine Cooling System LT1 and LT4 Engines with V08 Heavy Duty Cooling
System 12.0 L 12.7 qt
LT1 and LT4 Engines without V08 Heavy Duty Cooling
System 11.2 L 11.8 qt
LT5 Engine 13.1 L 13.8 qt
Intercooler System LT4 Engine 4.3 L 4.5 qt
LT5 Engine 5.0 L 5.3 qt
Engine Oil with Filter 6.2L LT1 V8 Engine with Z51 or Grand Sport 9.3 L 9.8 qt

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
Technical Data 327
ApplicationCapacities
Metric English
6.2L LT1 V8 Engine without Z51 or Grand Sport 6.6 L 7.0 qt
6.2L LT4 V8 Supercharged Engine 9.3 L 9.8 qt
6.2L LT5 V8 Supercharged Engine 9.3 L 9.8 qt
Fuel Tank 70.4 L 18.6 gal
Wheel Nut Torque 140 Y100 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this
manual. Recheck fluid level after filling
Engine Specifications
Engine VIN Code Transmission Spark Plug Gap Firing Order
6.2L LT1 V8 Engine 7Automatic
Manual 0.95–1.10 mm
(0.037–0.043 in) 1–8–7–2–6–5–4–3
6.2L LT4 V8 Supercharged
Engine 6
Automatic
Manual 0.725–0.875 mm
(0.029–0.034 in) 1–8–7–2–6–5–4–3
6.2L LT5 V8 Supercharged
Engine 9
Automatic
Manual 0.725–0.875 mm
(0.029–0.034 in) 1–8–7–2–6–5–4–3

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
328 Technical Data
Engine Data
EngineHorsepower TorqueDisplacement Compression Ratio
6.2L LT1 V8 Engine 455 460 lb ft6.2L11.5:1
6.2L LT1 V8 Engine
with Performance
Exhaust 460
465 lb ft 6.2L11.5:1
6.2L LT4 V8
Supercharged
Engine 650
650 lb ft 6.2L10.0:1
6.2L LT5 V8
Supercharged
Engine 755
715 lb ft 6.2L10.0:1

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
Technical Data 329
Engine Drive Belt Routing
6.2L LT1 Engine
6.2L LT4 and LT5 SuperchargedEngines
