298 Vehicle Care
10. Connect the other end of thenegative (−) cable to the
negative (−) terminal (2) on the
dead battery.
11. Now start the vehicle with the good battery and run the
engine for a while.
12. Try to start the vehicle that had the dead battery. If it will not
start after a few tries, it
probably needs service.Caution
If the jumper cables are
connected or removed in the
wrong order, electrical shorting
may occur and damage the
vehicle. The repairs would not be
covered by the vehicle warranty.
Always connect and remove the
jumper cables in the correct order,
making sure that the cables do
not touch each other or other
metal.
Jumper Cable Removal
Reverse the sequence exactly when
removing the jumper cables.
After starting the disabled vehicle
and removing the jumper cables,
allow it to idle for several minutes.
The power windows may need to be
initialized. See “Window Indexing”
under Power Windows 046.
Towing the Vehicle
Caution
Incorrectly towing a disabled
vehicle may cause damage. The
damage would not be covered by
the vehicle warranty. Do not lash
or hook to suspension
components. Use the proper
straps around the tires to secure
the vehicle. Do not drag a locked
wheel/tire while loading the
vehicle. Do not use a sling type
lift to tow the vehicle. This could
damage the vehicle.
GM recommends a flatbed tow truck
to transport a disabled vehicle. Use
ramps to help reduce approach
angles, if necessary. A towed
vehicle should have its drive wheels
off the ground. Contact Roadside
Assistance or a professional towing
service if the disabled vehicle must
be towed.

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
306 Vehicle Care
Interior Care
To prevent dirt particle abrasions,
regularly clean the vehicle's interior.
Immediately remove any soils.
Newspapers or dark garments can
transfer color to the vehicle’s
interior.
Use a soft bristle brush to remove
dust from knobs and crevices on the
instrument cluster. Using a mild
soap solution, immediately remove
hand lotions, sunscreen, and insect
repellent from all interior surfaces or
permanent damage may result.
Use cleaners specifically designed
for the surfaces being cleaned to
prevent permanent damage. Apply
all cleaners directly to the cleaning
cloth. Do not spray cleaners on any
switches or controls. Remove
cleaners quickly.
Before using cleaners, read and
follow all safety instructions on the
label. While cleaning the interior,
open the doors and windows to get
proper ventilation.To prevent damage, do not clean
the interior using the following
cleaners or techniques:
.
Never use a razor or any other
sharp object to remove soil from
any interior surface.
. Never use a brush with stiff
bristles.
. Never rub any surface
aggressively or with too much
pressure.
. Do not use laundry detergents or
dishwashing soaps with
degreasers. For liquid cleaners,
use approximately 20 drops per
3.8 L (1 gal) of water.
A concentrated soap solution will
create streaks and attract dirt.
Do not use solutions that contain
strong or caustic soap.
. Do not heavily saturate the
upholstery when cleaning.
. Do not use solvents or cleaners
containing solvents.
Interior Glass
To clean, use a terry cloth fabric
dampened with water. Wipe droplets
left behind with a clean dry cloth.
If necessary, use a commercial
glass cleaner after cleaning with
plain water.
Caution
To prevent scratching, never use
abrasive cleaners on automotive
glass. Abrasive cleaners or
aggressive cleaning may damage
the rear window defogger.
Cleaning the windshield with water
during the first three to six months
of ownership will reduce tendency
to fog.
Speaker Covers
Vacuum around a speaker cover
gently, so that the speaker will not
be damaged. Clean spots with water
and mild soap.

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
Vehicle Care 307
Coated Moldings
Coated moldings should be cleaned.
.When lightly soiled, wipe with a
sponge or soft, lint-free cloth
dampened with water.
. When heavily soiled, use warm
soapy water.
Fabric/Carpet/Suede
Start by vacuuming the surface
using a soft brush attachment. If a
rotating vacuum brush attachment is
being used, only use it on the floor
carpet. Before cleaning, gently
remove as much of the soil as
possible:
.Gently blot liquids with a paper
towel. Continue blotting until no
more soil can be removed.
. For solid soils, remove as much
as possible prior to vacuuming.
To clean:
1. Saturate a clean, lint-free colorfast cloth with water.
Microfiber cloth is
recommended to prevent lint
transfer to the fabric or carpet. 2. Remove excess moisture by
gently wringing until water does
not drip from the cleaning cloth.
3. Start on the outside edge of the soil and gently rub toward the
center. Fold the cleaning cloth
to a clean area frequently to
prevent forcing the soil in to the
fabric.
4. Continue gently rubbing the soiled area until there is no
longer any color transfer from
the soil to the cleaning cloth.
5. If the soil is not completely removed, use a mild soap
solution followed only by plain
water.
If the soil is not completely
removed, it may be necessary to
use a commercial upholstery
cleaner or spot lifter. Test a small
hidden area for colorfastness before
using a commercial upholstery
cleaner or spot lifter. If ring
formation occurs, clean the entire
fabric or carpet.
After cleaning, use a paper towel to
blot excess moisture.
Cleaning High Gloss Surfaces
and Vehicle Information and
Radio Displays
Use a microfiber cloth on high gloss
surfaces or vehicle displays. First,
use a soft bristle brush to remove
dirt that can scratch the surface.
Then gently clean by rubbing with a
microfiber cloth. Never use window
cleaners or solvents. Periodically
hand wash the microfiber cloth
separately, using mild soap. Do not
use bleach or fabric softener. Rinse
thoroughly and air dry before
next use.
Caution
Do not attach a device with a
suction cup to the display. This
may cause damage and would
not be covered by the vehicle
warranty.

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
Service and Maintenance 315
Footnotes—Maintenance
Schedule Additional Required
Services - Normal
(1) Or every two years, whichever
comes first. More frequent
passenger compartment air filter
replacement may be needed if
driving in areas with heavy traffic,
poor air quality, high dust levels,
or environmental allergens.
Passenger compartment air filter
replacement may also be needed if
there is reduced airflow, window
fogging, or odors. Your GM dealer
can help determine when to replace
the filter.
(2) Visually check all fuel and vapor
lines and hoses for proper
attachment, connection, routing, and
condition.
(3) Or every four years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed. (4)
Or every five years, whichever
comes first.
See Cooling System (Engine) 0242
or Cooling System (Aero Panel)
0 246 orCooling System
(Intercooler on LT4 and LT5
Engines) 0247.
(5) Or every 10 years, whichever
comes first. Inspect for fraying,
excessive cracking, or damage;
replace, if needed.
(6) Replace brake fluid every three
years. See Brake Fluid 0250.
(7) Replace clutch fluid every three
years. See Hydraulic Clutch 0239.
(8) Or every 12 months, whichever
comes first. See Wiper Blade
Replacement 0254.

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
Service and Maintenance 317
Footnotes—Maintenance
Schedule Additional Required
Services - Severe
(1) Or every two years, whichever
comes first. More frequent
passenger compartment air filter
replacement may be needed if
driving in areas with heavy traffic,
poor air quality, high dust levels,
or environmental allergens.
Passenger compartment air filter
replacement may also be needed if
there is reduced airflow, window
fogging, or odors. Your GM dealer
can help determine when to replace
the filter.
(2) Visually check all fuel and vapor
lines and hoses for proper
attachment, connection, routing, and
condition.
(3) Or every four years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed. (4)
Or every five years, whichever
comes first.
See Cooling System (Engine) 0242
or Cooling System (Aero Panel)
0 246 orCooling System
(Intercooler on LT4 and LT5
Engines) 0247.
(5) Or every 10 years, whichever
comes first. Inspect for fraying,
excessive cracking, or damage;
replace, if needed.
(6) Replace brake fluid every three
years. See Brake Fluid 0250.
(7) Replace clutch fluid every three
years. See Hydraulic Clutch 0239.
(8) Or every 12 months, whichever
comes first. See Wiper Blade
Replacement 0254.Special Application
Services
.
Severe Commercial Use
Vehicles Only: Lubricate chassis
components every oil change.
. Have underbody flushing service
performed. See "Underbody
Maintenance" in Exterior Care
0 300.

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
362 Index
Messages (cont'd)Vehicle Speed . . . . . . . . . . . . . . . . 128
Mirrors Automatic Dimming . . . . . . . . . . . . . 45
Automatic Dimming
Rearview . . . . . . . . . . . . . . . . . . . . . . 46
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 44
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 45
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 45
Manual Rearview . . . . . . . . . . . . . . . 45
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Tilt in Reverse . . . . . . . . . . . . . . . . . . 45
Mirrors, Interior Rearview . . . . . . . . 45
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 Driver Control . . . . . . . . . . . . . . . . . 200
Monitor System, Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 275
N
NavigationConnected Services . . . . . . . . . . 352
Net, Convenience . . . . . . . . . . . . . . . 97
New Vehicle Break-In . . . . . . . . . . . 179
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . 108 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . 160 Oil
Engine . . . . . . . . . . . . . . . . . . . . . . . . 232
Engine Oil Life System . . . . . . . 237
Pressure Light . . . . . . . . . . . . . . . . .119
Older Children, Restraints . . . . . . . 85
Online Owner Center . . . . . . . . . . . 333
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 343
OnStar Additional Information . . . . . . . . . . . . . . . . . . . . 346
OnStar Emergency . . . . . . . . . . . . . 346
OnStar Overview . . . . . . . . . . . . . . . 344
OnStar Security . . . . . . . . . . . . . . . . 346
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 101
Overheating, Engine . . . . . . . . . . . . 247
P
Panel, Roof . . . . . . . . . . . . . . . . . . . . . . 48
Park Shifting Into . . . . . . . . . . . . . . . . . . . 184
Shifting Out of . . . . . . . . . . . . . . . . 185
Park Assist . . . . . . . . . . . . . . . . . . . . . 210
Parking . . . . . . . . . . . . . . . . . . . . . . . . . 185 Brake and P (Park)Mechanism Check . . . . . . . . . . 254
Extended . . . . . . . . . . . . . . . . . . . . . 186
Over Things That Burn . . . . . . . 185 Parking or Backing
Assistance Systems . . . . . . . . . . 210
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 112
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Passenger Sensing System . . . . . 79
Perchlorate Materials
Requirements, California . . . . . . 220
Performance Data Recorder (PDR) . . . . . . . . . . . . . . . 145
Personalization Vehicle . . . . . . . . . . . . . . . . . . . . . . . 128
Power Door Locks . . . . . . . . . . . . . . . . . . . . . 36
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Outlets . . . . . . . . . . . . . . . . . . . . . . . 101
Protection, Battery . . . . . . . . . . . . 144
Retained Accessory (RAP) . . . 183
Seat Adjustment . . . . . . . . . . . . . . . . 59
Windows . . . . . . . . . . . . . . . . . . . . . . . 46
Pregnancy, Using Seat Belts . . . . 72
Privacy Vehicle Data Recording . . . . . . . 342
Program
Courtesy Transportation . . . . . . 336
Prohibited Fuels . . . . . . . . . . . . . . . . 213

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032182) - 2019 - crc - 5/8/18
Index 365
Tires (cont'd)Uniform Tire Quality
Grading . . . . . . . . . . . . . . . . . . . . . 282
Wheel Alignment and Tire
Balance . . . . . . . . . . . . . . . . . . . . . 284
Wheel Replacement . . . . . . . . . . 284
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 280
Winter . . . . . . . . . . . . . . . . . . . . . . . . 266
Top Tier Fuel . . . . . . . . . . . . . . . . . . . 212
Towing General Information . . . . . . . . . . 216
Recreational Vehicle . . . . . . . . . . 300
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 298
Track Events and Competitive Driving . . . . . . . . . . . 161
Traction Limited-Slip Differential . . . . . . . 207
Off Light . . . . . . . . . . . . . . . . . . . . . . .117
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . . 198
Transmission Automatic . . . . . . . . . . . . . . . . . . . . . 187
Fluid, Automatic . . . . . . . . . . . . . . 238
Fluid, Manual . . . . . . . . . . . . . . . . . 239
Transportation Program, Courtesy . . . . . . . . . . . . . . . . . . . . . . 336
Trip Odometer . . . . . . . . . . . . . . . . . . 108 Turn and Lane-Change
Signals . . . . . . . . . . . . . . . . . . . . . . . . 142
U
Uniform Tire Quality Grading . . . 282
Universal Remote System . . . . . . 135Operation . . . . . . . . . . . . . . . . . . . . . 138
Programming . . . . . . . . . . . . . . . . . 135
Using This Manual . . . . . . . . . . . . . . . . 2
V
Vehicle Alarm System . . . . . . . . . . . . . . . . . . 41
Canadian Owners . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . 159
Identification Number (VIN) . . . 325
Load Limits . . . . . . . . . . . . . . . . . . . 175
Messages . . . . . . . . . . . . . . . . . . . . 127
Personalization . . . . . . . . . . . . . . . 128
Remote Start . . . . . . . . . . . . . . . . . . . 33
Security . . . . . . . . . . . . . . . . . . . . . . . . 41
Speed Messages . . . . . . . . . . . . . 128
Towing . . . . . . . . . . . . . . . . . . . . . . . . 298
Vehicle Care Storing the Tire Sealantand Compressor Kit . . . . . . . . . 294
Tire Pressure . . . . . . . . . . . . . . . . . 274
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . 342 Ventilation, Air . . . . . . . . . . . . . . . . . . 155
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
W
Warning
Brake System Light . . . . . . . . . . . .115
Caution and Danger . . . . . . . . . . . . . 2
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . 102
Warnings Hazard Flashers . . . . . . . . . . . . . . 142
Washer Fluid . . . . . . . . . . . . . . . . . . . 248
Wheels
Alignment and Tire Balance . . 284
Different Size . . . . . . . . . . . . . . . . . 282
Replacement . . . . . . . . . . . . . . . . . 284
When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Windows . . . . . . . . . . . . . . . . . . . . . . . . 46 Power . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Windshield
Replacement . . . . . . . . . . . . . . . . . 255
Wiper/Washer . . . . . . . . . . . . . . . . . . 99
Winter Driving . . . . . . . . . . . . . . . . . . . . . . . . 173
Winter Tires . . . . . . . . . . . . . . . . . . . . 266
Wiper Blade Replacement . . . . . . 254
