Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12460268) - 2019 - crc - 9/14/18
CLIMATE CONTROLS 179
0:Clears the windshield of fog or
frost more quickly. Air is directed to
the windshield. Press
0to turn on or
off. Changing the air delivery mode
also turns the defrost off.
A/C Mode : Touch AC Mode on the
climate control display to turn the
automatic air conditioning on or off.
If the fan is turned off or the outside
temperature falls below freezing, the
air conditioner will not run.
Press AUTO to return to automatic
operation and the air conditioner runs
as needed.
Automatic Air Recirculation : When
the AUTO indicator light is on, the air
is automatically recirculated as
needed to help quickly cool the inside
of the vehicle.
@: Press to alternate between
recirculating air inside the vehicle or
pulling in outside air. The indicator
light on the button is lit when
recirculation mode is active. This
helps to quickly cool the air inside the
vehicle and reduce the entry of
outside air and odors. Pressing this button cancels automatic
recirculation. Press AUTO to return to
automatic operation; recirculation
runs automatically as needed.
Manual recirculation mode is not
available when in Defrost or Defog
modes.
Auto Defog :
The climate control
system uses a sensor to automatically
detect high humidity inside the
vehicle. When high humidity is
detected, the climate control system
may adjust to outside air supply, turn
on the air conditioner, and direct
more air to the windshield. If the
climate control system does not
detect possible window fogging, it
returns to normal operation. To turn
Auto Defog off or on, see “Climate and
Air Quality” underVehicle
Personalization 0155.
Rear Window Defogger
K:Press to turn the rear window
defogger on or off. An indicator light
on the button comes on to show that
the rear window defogger is on. The rear window defogger only works
when the ignition is on. The defogger
turns off if the ignition is turned off
or to ACC/ACCESSORY.
The rear window defogger can be set
to automatic operation. When Auto
Rear Defog is selected, the rear
window defogger turns on
automatically when the vehicle is first
started in cold weather and turns off
when the vehicle is warmed. To turn
Auto Rear Defog on or off, see
“Climate and Air Quality”
under
Vehicle Personalization 0155.
The heated outside mirrors turn on
when the rear window defogger
button is on and help to clear fog or
frost from the surface of the mirrors.
Caution
Do not try to clear frost or other
material from the inside of the
front windshield and rear window
with a razor blade or anything else
that is sharp. This may damage the
rear window defogger grid and (Continued)
Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12460268) - 2019 - crc - 9/19/18
406 INDEX
E
Electric Parking Brake . . . . . . . . . . . . . . 219
Electric Parking Brake Light . . . . . . . 142
Electrical Equipment, Add-On . . . . . 275
Electrical SystemEngine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 301
Fuses and Circuit Breakers . . . . . . . 301
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 305, 307
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . 300
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 310
Emergency
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 392
Engine Air Cleaner/Filter . . . . . . . . . . . . . . . . . 285
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . . . . . 140
Compartment Overview . . . . . . . . . . 280
Coolant Temperature Gauge . . . . . 137
Coolant Temperature Warning Light . . . . . . . . . . . . . . . . . . . 145
Cooling System . . . . . . . . . . . . . . . . . . . 286
Drive Belt Routing . . . . . . . . . . . . . . . . 376
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204 Engine (cont'd)
Oil Life System . . . . . . . . . . . . . . . . . . . . 283
Oil Pressure Light . . . . . . . . . . . . . . . . . 146
Overheating . . . . . . . . . . . . . . . . . . . . . . . 289
Power Messages . . . . . . . . . . . . . . . . . . 154
Running While Parked . . . . . . . . . . . 209
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Entry Lighting . . . . . . . . . . . . . . . . . . . . . . 173
Equipment, Towing . . . . . . . . . . . . . . . . . 265
Event Data Recorders . . . . . . . . . . . . . . 389
Exit Lighting . . . . . . . . . . . . . . . . . . . . . . . . 173
Extended Parking . . . . . . . . . . . . . . . . . . . 208
Extender, Seat Belt . . . . . . . . . . . . . . . . . . 85
Exterior Lamp Controls . . . . . . . . . . . . 167
Exterior Lamps Off Reminder . . . . . . 169
Exterior Lighting Battery Saver . . . . 174
F
Fan Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
Features Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter, Engine Air Cleaner . . . . . . . . . . . . . . . . 285
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . 169
Flashers, Hazard Warning . . . . . . . . . . 171
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331 Changing . . . . . . . . . . . . . . . . . . . . . . . . . . 332 Floor Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . 357
Fluid
Automatic Transmission . . . . . . . . . 284
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Four-Wheel DriveTransfer Case . . . . . . . . . . . . . . . . . . . . 214
Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
Folding Mirrors . . . . . . . . . . . . . . . . . . . . . . 52
Forward Automatic Braking . . . . . . . . 246
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
Four-Wheel Drive . . . . . . . . . . . . . .214, 294
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 387
Front Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . 294
Front Seats Heated and Cooled . . . . . . . . . . . . . . . . . 69
Fuel Additives . . . . . . . . . . . . . . . . . . . . . . . . . . 253
Economy Driving . . . . . . . . . . . . . . . . . . . 25
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . . . . . . 255
Filling the Tank . . . . . . . . . . . . . . . . . . . 253
Foreign Countries . . . . . . . . . . . . . . . . . 253
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Low Fuel Warning Light . . . . . . . . . 146
Management, Active . . . . . . . . . . . . . . 208
Prohibited Fuels . . . . . . . . . . . . . . . . . . 252
