2019 CADILLAC CTS washer fluid

Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12460273) - 2019 - CRC - 5/8/18
352 SERVICE AND MAINTENANCE
Brakes
Brakes stop the vehicle and are crucial
to safe driving.
.Signs of brake wear may include
chirping, grinding, or squealing
noises, or difficulty stopping.
. Trained dealer technicians have
access to tools and equipment to
inspect the brakes and recommend
quality parts engineered for the
vehicle.
Fluids
Proper fluid levels and approved fluids
protect the vehicle’s systems and
components. See Recommended Fluids
and Lubricants 0354 for GM approved
fluids.
. Engine oil and windshield washer
fluid levels should be checked at
every fuel fill.
. Instrument cluster lights may
come on to indicate that fluids
may be low and need to be filled. Hoses
Hoses transport fluids and should be
regularly inspected to ensure that
there are no cracks or leaks. With a
multi-point inspection, your dealer
can inspect the hoses and advise if
replacement is needed.
Lamps
Properly working headlamps,
taillamps, and brake lamps are
important to see and be seen on
the road.
.
Signs that the headlamps need
attention include dimming, failure
to light, cracking, or damage. The
brake lamps need to be checked
periodically to ensure that they
light when braking.
. With a multi-point inspection,
your dealer can check the lamps
and note any concerns. Shocks and Struts
Shocks and struts help aid in control
for a smoother ride.
.
Signs of wear may include steering
wheel vibration, bounce/sway
while braking, longer stopping
distance, or uneven tire wear.
. As part of the multi-point
inspection, trained dealer
technicians can visually inspect
the shocks and struts for signs of
leaking, blown seals, or damage,
and can advise when service is
needed.
Tires
Tires need to be properly inflated,
rotated, and balanced. Maintaining
the tires can save money and fuel, and
can reduce the risk of tire failure.
. Signs that the tires need to be
replaced include three or more
visible treadwear indicators; cord
or fabric showing through the
rubber; cracks or cuts in the tread
or sidewall; or a bulge or split in
the tire.

Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12460273) - 2019 - CRC - 5/8/18
SERVICE AND MAINTENANCE 355
UsageFluid/Lubricant
Rear Axle (Limited-Slip Differential) SAE 75W-90 Synthetic Axle Lubricant (GM Part No. 88862624, in Canada 88862625) meeting GM Specification 9986290.
Rear Axle (Non-Limited Slip Differential) SAE 75W-90 Synthetic Axle Lubricant (GM Part No. 88863089, in
Canada 88863090) meeting GM Specification 9986285.
Transfer Case (All-Wheel Drive) Transfer Case Fluid (GM Part No. 88861950, in Canada 88861951).
Weatherstrip Conditioning Weatherstrip Lubricant (GM Part No. 3634770, in Canada 10953518) or equivalent.
Windshield Washer Automotive windshield washer fluid that meets regional freeze protection
requirements.
Maintenance Replacement Parts
Replacement parts identified below by name, part number, or specification can be obtained from your dealer.
Part GM Part Number ACDelco Part Number
Engine Air Cleaner/Filter 2.0L L4 Engine 20857930 A3178C
3.6L V6 Engine (LGX) 20857930 A3178C
3.6L V6 Engine (LF3) 22844634 A3185C
6.2L V8 Engine (V-Series) 22935844 A3203C

Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12460273) - 2019 - CRC - 5/8/18
392 INDEX
Driving (cont'd)Hill and Mountain Roads . . . . . . . . 186
If the Vehicle is Stuck . . . . . . . . . . . . 188
Loss of Control . . . . . . . . . . . . . . . . . . . . 181
Off-Road Recovery . . . . . . . . . . . . . . . . 180
Track Events and Competitive . . . 181
Vehicle Load Limits . . . . . . . . . . . . . . 189
Wet Roads . . . . . . . . . . . . . . . . . . . . . . . . . 186
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . . . . . 168
E
Electric Parking Brake . . . . . . . . . . . . . . 205
Electric Parking Brake Light . . . . . . . 131
Electrical Equipment, Add-On . . . . . 255
Electrical SystemEngine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Fuses and Circuit Breakers . . . . . . . 291
Instrument Panel Fuse Block . . . . 295
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 378
Engine Air Cleaner/Filter . . . . . . . . . . . . . . . . . 272 Engine (cont'd)
Check Light (Malfunction
Indicator) . . . . . . . . . . . . . . . . . . . . . . . . 129
Compartment Overview . . . . . . . . . . 261
Coolant Temperature Gauge . . . . . 125
Coolant Temperature
Warning Light . . . . . . . . . . . . . . . . . . . 134
Cooling System . . . . . . . . . . . . . . . . . . . 274
Drive Belt Routing . . . . . . . . . . . . . . . . 362
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Oil Life System . . . . . . . . . . . . . . . . . . . . 271
Oil Pressure Light . . . . . . . . . . . . . . . . . 135
Overheating . . . . . . . . . . . . . . . . . . . . . . . 279
Power Messages . . . . . . . . . . . . . . . . . . 144
Running While Parked . . . . . . . . . . . 201
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Engine Oil
Temperature Gauge . . . . . . . . . . . . . . . 125
Entry Lighting . . . . . . . . . . . . . . . . . . . . . . 160
Equipment, Towing . . . . . . . . . . . .254, 255
Event Data Recorders . . . . . . . . . . . . . . 375
Exit Lighting . . . . . . . . . . . . . . . . . . . . . . . . 160
Extended Parking . . . . . . . . . . . . . . . . . . . 200
Extender, Seat Belt . . . . . . . . . . . . . . . . . . 75
Exterior Lamp Controls . . . . . . . . . . . . 154
Exterior Lamps Off Reminder . . . . . . 156
Exterior Lighting Battery Saver . . . . 161
F
Features Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter, Engine Air Cleaner . . . . . . . . . . . . . . . . 272
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . 156
Flashers, Hazard Warning . . . . . . . . . . 158
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 320
Floor Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . 342
Fluid Automatic Transmission . . . . . . . . . 272
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 282
Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Folding Mirrors . . . . . . . . . . . . . . . . . . . . . . 46
Forward Automatic Braking . . . . . . . . 237
Forward Collision Alert (FCA)
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 373
Front Seats Heated and Ventilated . . . . . . . . . . . . . 63
Fuel Additives . . . . . . . . . . . . . . . . . . . . . . . . . . 246
Economy Driving . . . . . . . . . . . . . . . . . . . 27
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . . . . . . 248
Filling the Tank . . . . . . . . . . . . . . . . . . . 246
Foreign Countries . . . . . . . . . . . . . . . . . 246

Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12460273) - 2019 - CRC - 5/8/18
INDEX 399
U
Uniform Tire Quality Grading . . . . . . 317
Universal Remote System . . . . . . . . . . 150Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Programming . . . . . . . . . . . . . . . . . . . . . . 150
Using This Manual . . . . . . . . . . . . . . . . . . . . 2
V
Vehicle Alarm System . . . . . . . . . . . . . . . . . . . . . . . 43
Canadian Owners . . . . . . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Identification Number (VIN) . . . . . 358
Load Limits . . . . . . . . . . . . . . . . . . . . . . . 189
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Personalization . . . . . . . . . . . . . . . . . . . 145
Remote Start . . . . . . . . . . . . . . . . . . . . . . . . 35
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Speed Messages . . . . . . . . . . . . . . . . . . . 145
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
Vehicle Ahead Indicator . . . . . . . . . . . . 132
Vehicle Care Storing the Tire Sealant andCompressor Kit . . . . . . . . . . . . . . . . . . 328
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 307
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 374
Vehicle-to-Vehicle . . . . . . . . . . . . . . . . . . 242 Ventilation, Air . . . . . . . . . . . . . . . . . . . . . 175
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
W
Warning
Brake System Light . . . . . . . . . . . . . . . 131
Caution and Danger . . . . . . . . . . . . . . . . . 2
Lane Departure (LDW) . . . . . . . . . . . 240
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Warnings Hazard Flashers . . . . . . . . . . . . . . . . . . . 158
Washer Fluid . . . . . . . . . . . . . . . . . . . . . . . . 280
Wheels Alignment and Tire Balance . . . . . 318
Different Size . . . . . . . . . . . . . . . . . . . . . . 317
Replacement . . . . . . . . . . . . . . . . . . . . . . 319
When It Is Time for New Tires . . . . 314
Where to Put the Restraint . . . . . . . . . 94
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Windshield Replacement . . . . . . . . . . . . . . . . . . . . . . 287
Wiper/Washer . . . . . . . . . . . . . . . . . . . . . 111 Winter
Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Winter Tires . . . . . . . . . . . . . . . . . . . . . . . . . 301
Wiper Blade Replacement . . . . . . . . . . 286
Wireless Charging . . . . . . . . . . . . . . . . . . 115
