268 Vehicle Care
Wheels and Tires
Tires
Every new GM vehicle has
high-quality tires made by a
leading tire manufacturer. See
the warranty manual for
information regarding the tire
warranty and where to get
service. For additional
information refer to the tire
manufacturer.
{Warning
.Poorly maintained and
improperly used tires are
dangerous.
.Overloading the tires can
cause overheating as a
result of too much
flexing. There could be a
blowout and a serious
crash. SeeVehicle Load
Limits 0172.
(Continued)
Warning (Continued)
.Underinflated tires pose
the same danger as
overloaded tires. The
resulting crash could
cause serious injury.
Check all tires frequently
to maintain the
recommended pressure.
Tire pressure should be
checked when the tires
are cold.
.Overinflated tires are
more likely to be cut,
punctured, or broken by
a sudden impact —such
as when hitting a pothole.
Keep tires at the
recommended pressure.
.Worn or old tires can
cause a crash. If the
tread is badly worn,
replace them.
(Continued)
Warning (Continued)
.Replace any tires that
have been damaged by
impacts with potholes,
curbs, etc.
.Improperly repaired tires
can cause a crash. Only
the dealer or an
authorized tire service
center should repair,
replace, dismount, and
mount the tires.
.Do not spin the tires in
excess of 56 km/h
(35 mph) on slippery
surfaces such as snow,
mud, ice, etc. Excessive
spinning may cause the
tires to explode.
All-Season Tires
This vehicle may come with
all-season tires. These tires are
designed to provide good overall

Buick LaCrosse Owner Manual (GMNA-Localizing-U.S./Canada-12032549) -
2019 - crc - 8/20/18
Vehicle Care 275
Tire Pressure
Tires need the correct amount of
air pressure to operate
effectively.
{Warning
Neither tire underinflation nor
overinflation is good.
Underinflated tires, or tires
that do not have enough air,
can result in:
.Tire overloading and
overheating which could
lead to a blowout.
.Premature or
irregular wear.
.Poor handling.
.Reduced fuel economy.
Overinflated tires, or tires that
have too much air, can
result in:
.Unusual wear.
(Continued)
Warning (Continued)
.Poor handling.
.Rough ride.
.Needless damage from
road hazards.
The Tire and Loading
Information label on the vehicle
indicates the original equipment
tires and the correct cold tire
inflation pressures. The
recommended pressure is the
minimum air pressure needed to
support the vehicle's maximum
load carrying capacity. See
Vehicle Load Limits 0172.
How the vehicle is loaded
affects vehicle handling and ride
comfort. Never load the vehicle
with more weight than it was
designed to carry. When to Check
Check the tires once a month or
more. Do not forget the compact
spare, if the vehicle has one.
The cold compact spare tire
pressure should be at 420 kPa
(60 psi). See
Compact Spare
Tire 0300.
How to Check
Use a good quality pocket-type
gauge to check tire pressure.
Proper tire inflation cannot be
determined by looking at the tire.
Check the tire inflation pressure
when the tires are cold, meaning
the vehicle has not been driven
for at least three hours or no
more than 1.6 km (1 mi).
Remove the valve cap from the
tire valve stem. Press the tire
gauge firmly onto the valve to
get a pressure measurement.
If the cold tire inflation pressure
matches the recommended
pressure on the Tire and
Loading Information label, no

Buick LaCrosse Owner Manual (GMNA-Localizing-U.S./Canada-12032549) -
2019 - crc - 8/20/18
364 Index
DrivingAssistance Systems . . . . . . . . . . 214
Characteristics and
Towing Tips . . . . . . . . . . . . . . . . . 227
Defensive . . . . . . . . . . . . . . . . . . . . . 166
Drunk . . . . . . . . . . . . . . . . . . . . . . . . . 166
For Better Fuel Economy . . . . . . . 26
Hill and Mountain Roads . . . . . . 169
If the Vehicle is Stuck . . . . . . . . . 171
Loss of Control . . . . . . . . . . . . . . . 168
Off-Road Recovery . . . . . . . . . . . 168
Vehicle Load Limits . . . . . . . . . . . 172
Wet Roads . . . . . . . . . . . . . . . . . . . 169
Winter . . . . . . . . . . . . . . . . . . . . . . . . 170
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . 157
E
Electric Parking Brake . . . . . . . . . . 193
Electric Parking Brake Light . . . . 125
Electrical Equipment,
Add-On . . . . . . . . . . . . . . . . . . . . . . . 233
Electrical System Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 261
Fuses and Circuit Breakers . . . 261
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 265 Electrical System (cont'd)
Overload . . . . . . . . . . . . . . . . . . . . . 260
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . 350
Energy Information . . . . . . . . . . . . . 131
Engine Air Cleaner/Filter . . . . . . . . . . . . . 245
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 122
Compartment Overview . . . . . . . 238
Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . .119
Coolant Temperature Warning Light . . . . . . . . . . . . . . . 127
Cooling System . . . . . . . . . . . . . . . 246
Drive Belt Routing . . . . . . . . . . . . 334
Exhaust . . . . . . . . . . . . . . . . . . . . . . 186
Heater . . . . . . . . . . . . . . . . . . . . . . . . 180
Oil Life System . . . . . . . . . . . . . . . 244
Oil Pressure Light . . . . . . . . . . . . 128
Overheated Protection Operating Mode . . . . . . . . . . . . . 252
Overheating . . . . . . . . . . . . . . . . . . 250
Power Messages . . . . . . . . . . . . . 138
Running While Parked . . . . . . . . 186
Starting . . . . . . . . . . . . . . . . . . . . . . . 177
Engine Oil Temperature Gauge . . . . . . . . . . .118 Entry Lighting . . . . . . . . . . . . . . . . . . . 154
Equipment, Towing . . . . . . . . . . . . . 232
Event Data Recorders . . . . . . . . . . 347
Exit Lighting . . . . . . . . . . . . . . . . . . . . 154
Extended Parking . . . . . . . . . . . . . . . 185
Extender, Seat Belt . . . . . . . . . . . . . . 69
Exterior Lamp Controls . . . . . . . . . 149
Exterior Lamps Off Reminder . . . 150
Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . . . 155
F
FeaturesMemory . . . . . . . . . . . . . . . . . . . . . . . . . 11
Filter, Engine Air Cleaner . . . . . . . . . . . 245
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 150
Flashers, Hazard Warning . . . . . . 151
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 287
Changing . . . . . . . . . . . . . . . . . . . . . 296
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 317
Fluid
Automatic Transmission . . . . . . 245
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 254
Washer . . . . . . . . . . . . . . . . . . . . . . . 252
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 152
Folding Mirrors . . . . . . . . . . . . . . . . . . 46
Forward Automatic Braking . . . . . 216

Buick LaCrosse Owner Manual (GMNA-Localizing-U.S./Canada-12032549) -
2019 - crc - 8/20/18
Index 365
Forward Collision Alert(FCA) System . . . . . . . . . . . . . . . . . 214
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 345
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Front Pedestrian Braking
(FPB) System . . . . . . . . . . . . . . . . . 218
Front Seats Heated and Ventilated . . . . . . . . . . 59
Fuel
Additives . . . . . . . . . . . . . . . . . . . . . 225
Economy Driving . . . . . . . . . . . . . . . 26
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 227
Filling the Tank . . . . . . . . . . . . . . . 225
Foreign Countries . . . . . . . . . . . . 225
Gauge . . . . . . . . . . . . . . . . . . . . . . . . .117
Low Fuel Warning Light . . . . . . . 129
Management, Active . . . . . . . . . . 185
Prohibited Fuels . . . . . . . . . . . . . . 224
Recommended . . . . . . . . . . . . . . . 224
Top Tier . . . . . . . . . . . . . . . . . . . . . . 224
Fuses Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 261
Fuses and Circuit Breakers . . . 261 Fuses (cont'd)
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 265
G
Garage Door Opener . . . . . . . . . . . 145Programming . . . . . . . . . . . . . . . . . 145
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 257
Gauges Driver Efficiency . . . . . . . . . . . . . . .118
Engine Coolant
Temperature . . . . . . . . . . . . . . . . .119
Engine Oil Temperature . . . . . . . .118
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . .117
Odometer . . . . . . . . . . . . . . . . . . . . . .116
Speedometer . . . . . . . . . . . . . . . . . .116
Tachometer . . . . . . . . . . . . . . . . . . . .116
Voltmeter . . . . . . . . . . . . . . . . . . . . . .119
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . .113
General Information Service and Maintenance . . . . . 318
Towing . . . . . . . . . . . . . . . . . . . . . . . . 227
Vehicle Care . . . . . . . . . . . . . . . . . . 235
Glove Box . . . . . . . . . . . . . . . . . . . . . . 102
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 339
H
Hazard Warning Flashers . . . . . . . 151
Head Restraints . . . . . . . . . . . . . . . . . 53
Head-up Display . . . . . . . . . . . . . . . . 134
HeadlampsAdaptive ForwardLighting (AFL) . . . . . . . . . . . . . . . 151
Aiming . . . . . . . . . . . . . . . . . . . . . . . . 258
Automatic . . . . . . . . . . . . . . . . . . . . . 150
Bulb Replacement . . . . . . . . . . . . 258
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . 150
Flash-to-Pass . . . . . . . . . . . . . . . . . 150
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 258
High-Beam On Light . . . . . . . . . . 129
High/Low Beam Changer . . . . . 150
Lamps On Reminder . . . . . . . . . 130
Heated
Steering Wheel . . . . . . . . . . . . . . . 106
Heated and Ventilated Front Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Heated Mirrors . . . . . . . . . . . . . . . . . . . 46
Heater Engine . . . . . . . . . . . . . . . . . . . . . . . . 180
Heating . . . . . . . . . . . . . . . . . . . . . . . . . 157
High-Beam On Light . . . . . . . . . . . . 129
High-Speed Operation . . . . . . . . . . 276

Buick LaCrosse Owner Manual (GMNA-Localizing-U.S./Canada-12032549) -
2019 - crc - 8/20/18
368 Index
Operating ModeOverheated Engine
Protection . . . . . . . . . . . . . . . . . . . 252
Operation Fog Lamps . . . . . . . . . . . . . . . . . . . 152
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 108
Overheated Engine Protection Operating Mode . . . . 252
Overheating, Engine . . . . . . . . . . . . 250
P
Park Shifting Into . . . . . . . . . . . . . . . . . . . 182
Shifting Out of . . . . . . . . . . . . . . . . 182
Park Assist . . . . . . . . . . . . . . . . . . . . . 210
Parking Extended . . . . . . . . . . . . . . . . . . . . . 185
Over Things That Burn . . . . . . . 185
Parking or Backing Assistance Systems . . . . . . . . . . 210
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 121
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Passenger Sensing System . . . . . 77
Perchlorate Materials
Requirements, California . . . . . . 236 Personalization
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 138
Power Door Locks . . . . . . . . . . . . . . . . . . . . . 39
Flows . . . . . . . . . . . . . . . . . . . . . . . . . 131
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Outlets . . . . . . . . . . . . . . . . . . . . . . . 108
Protection, Battery . . . . . . . . . . . . 155
Retained Accessory (RAP) . . . 181
Seat Adjustment . . . . . . . . . . . . . . . . 54
Windows . . . . . . . . . . . . . . . . . . . . . . . 47
Pregnancy, Using Seat Belts . . . . 69
Privacy Vehicle Data Recording . . . . . . . 347
Program Courtesy Transportation . . . . . . 341
Prohibited Fuels . . . . . . . . . . . . . . . . 224
Proposition 65 Warning,
California . . . . . . . . . 235, 255, 301, 302,
Back Cover
Publication Ordering Information . . . . . . . . . . . . . . . . . . . . 344
R
Radio Frequency Statement . . . . 345
Reading Lamps . . . . . . . . . . . . . . . . . 153
Rear Seat Armrest . . . . . . . . . . . . . . . 63
Rear Seats . . . . . . . . . . . . . . . . . . . . . . 61
Rear Vision Camera (RVC) . . . . . 210
Rear Window Sunshade . . . . . . . . . 50
Rearview MirrorsAutomatic Dimming . . . . . . . . . . . . . 47
Reclining Seatbacks . . . . . . . . . . . . . 55
Recommended
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 224
Recommended Fluids and Lubricants . . . . . . . . . . . . . . . . . . . . . 329
Records Maintenance . . . . . . . . . . . . . . . . . . 331
Recreational Vehicle Towing . . . . 306
Regenerative Braking . . . . . . . . . . . 196
Reimbursement Program, GM Mobility . . . . . . . . . . . . . . . . . . . 339
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . . 29
Remote Vehicle Start . . . . . . . . . . . . 35
Replacement Parts Airbags . . . . . . . . . . . . . . . . . . . . . . . . . 83
Maintenance . . . . . . . . . . . . . . . . . . 330
Replacing Airbag System . . . . . . . . 83
