2019.75 VAUXHALL CROSSLAND X engine coolant

176Vehicle careCaution
Overfilled engine oil must be
drained or suctioned out. If the oil exceeds the maximum level, do
not start the vehicle and contact a
workshop.
Capacities 3 226.
Fit the cap on straight and tighten it.
Engine coolant The factory filled coolant provides
freeze protection down to approx.
-37 °C.
Caution
Only use approved antifreeze.
Coolant and antifreeze 3 217.
Coolant level
Caution
Too low a coolant level can cause engine damage.
If the cooling system is cold, the
coolant level should be above the
MIN mark. Top up if the level is low.
9Warning
Allow the engine to cool before
opening the cap. Carefully open
the cap, relieving the pressure
slowly.
To top up, use a 1:1 mixture of
released coolant concentrate mixed
with clean tap water. If no coolant
concentrate is available, use clean
tap water. Install the cap tightly. Have
the coolant concentration checked
and have the cause of the coolant
loss remedied by a workshop.
Washer fluid
Fill with clean water mixed with a
suitable quantity of approved
windscreen washer fluid which
contains antifreeze.

Service and maintenance217Recommended fluids,
lubricants and parts
Recommended fluids and lubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The engine oil quality ensures e.g. engine
cleanliness, wear protection and
engine oil aging control, whereas
viscosity grade gives information on
the oil's thickness over a temperature range.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 221.
Topping up engine oilCaution
In case of any spilled oil, wipe it up and dispose it properly.
Engine oils of different manufacturersand brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 221.
Additional engine oil additives
The use of additional engine oil
additives could cause damage and
invalidate the warranty.
Engine oil viscosity grades
The SAE viscosity grade gives
information of the thickness of the oil.
Multigrade oil is indicated by two
figures, e.g. SAE 5W-30. The first figure, followed by a W, indicates the
low temperature viscosity and the
second figure the high temperature
viscosity.
Select the appropriate viscosity grade depending on the minimum ambient
temperature 3 221.
All of the recommended viscosity
grades are suitable for high ambient
temperatures.
Coolant and antifreeze
Use only organic acid type-long life
coolant (LLC) antifreeze approved for
the vehicle. Consult a workshop.
The system is factory filled with
coolant designed for excellent
corrosion protection and frost
protection down to approx. -37 °C.
This concentration should be
maintained all year round. The use of additional coolant additives that
intend to give additional corrosion
protection or seal against minor leaks
can cause function problems. Liability

241Control indicators.......................... 81
Control of the vehicle .................121
Controls ........................................ 70
Convex shape .............................. 33
Coolant and antifreeze ...............217
Cornering lights .......................... 102
Cruise control ...................... 87, 139
Cupholders .................................. 61
Curtain airbag system .................. 53
D Danger, Warnings and Cautions ...4
Daytime running lights ...............102
Declaration of conformity ............229
DEF ............................................ 129
Deflation detection system ...........85
Diesel exhaust fluid ....................129
Diesel fuel system bleeding .......179
Door open .................................... 87
Doors ............................................ 29
Driver alert .................................. 163
Driver assistance systems ..........139
Driver Information Centre .............87
Driving characteristics and towing tips .............................. 168
Driving hints ................................ 121
E Electric adjustment ......................33
Electrical system......................... 188
Electronic climate control system 112Electronic driving programmes ..133
Electronic key system ...................22
Electronic Stability Control and Traction Control system ....84, 137
Electronic Stability Control and Traction Control system off .......84
Emergency call ............................. 97
End-of-life vehicle recovery .......173
Engine compartment fuse box ...189
Engine coolant ........................... 176
Engine coolant temperature ........84
Engine coolant temperature gauge ....................................... 79
Engine data ............................... 223
Engine exhaust .......................... 128
Engine identification ...................220
Engine oil ...........175, 217, 221, 227
Engine oil level monitor ................79
Engine oil pressure ......................85
Entry lighting .............................. 106
Event data recorders ..................235
Exhaust filter ......................... 85, 128
Exit lighting ................................ 106
Exterior care .............................. 208
Exterior light ................................. 86
Exterior lighting ......................12, 99
Exterior mirrors ............................. 33F
Fault ........................................... 134 First aid ......................................... 66
First aid kit ................................... 66
Fixed air vents ........................... 118
Floor mats................................... 211
Folding mirrors ............................. 34
Forward collision alert................. 144
Front airbag system .....................52
Front fog lights .............86, 103, 183
Front pedestrian protection ........148
Front seats.................................... 41
Fuel............................................. 164
Fuel for diesel engines ..............164
Fuel for petrol engines ...............164
Fuel gauge ................................... 79
Fuel tank ..................................... 227
Fuses ......................................... 188
G Gauges ......................................... 77
Gear selection ........................... 132
Gear shifting ................................. 84
General information ...................167
Glass panel .................................. 38
Glovebox ..................................... 61
H Halogen headlights ....................180
Hand brake ................................. 136
Hazard warning flashers ............102
