2018 YAMAHA VXR display

Instrument operation
39
display segment will be shown. (See page 33
for trim angle selection procedures.)
EJU31515Fuel level meter
The fuel level meter shows the amount of fuel
remaining in the fuel tank. The amount of re-
maining fuel is shown using eight display
segments, which disappear two at a time as
the fuel level decreases.
TIP:
The accuracy of the fuel level meter varies
depending on the operating conditions. Use
this function as a reference only.
EJU44020Fuel level warning
If the fuel remaining in the fuel tank drops to
about 18 L (4.8 US gal, 4.0 Imp.gal), the low-
est two fuel level segments, the fuel level
warning indicator, and the “WARNING” indi-cator light blink, and the buzzer sounds inter-
mittently for 30 seconds.
If the fuel level warning is activated, refill the
fuel tank as soon as possible. (See page 49
for information on filling the fuel tank.)
After the fuel tank is refilled, the warning sig-
nals will be cleared when the engine is re-
started.
EJU43720Oil pressure warning
If the oil pressure drops significantly, the oil
pressure warning indicator, the check engine
warning indicator, and the “WARNING” indi-
cator light blink, and the buzzer sounds inter-
mittently for 30 seconds. At the same time,
the maximum engine speed is limited.
If the oil pressure warning is activated, imme-
diately reduce the engine speed, return to
shore, and then check the engine oil level.
(See page 52 for information on checking the
engine oil level.) If the oil level is sufficient,
have a Yamaha dealer check the watercraft.
1Trim indicator
1Fuel level meter
1
1
UF2W74E0.book Page 39 Thursday, July 6, 2017 3:49 PM

Instrument operation
41
TIP:
The elapsed time will be kept even if the bat-
tery terminals have been disconnected.
EJU43751Voltmeter
The voltmeter shows the battery voltage.
When the battery voltage is normal, the volt-
meter displays approximately 12 volts.
If the battery voltage has dropped significant-
ly, “Lo” is displayed on the voltmeter, and the
information display, hour meter, and indicator
lights turn off. If the battery voltage has risen
significantly, “HI” is displayed. If “Lo” or “HI”
is displayed, immediately return to shore and
have a Yamaha dealer service the watercraft.
1Hour meter
1Vo l t m et e r
1
1
UF2W74E0.book Page 41 Thursday, July 6, 2017 3:49 PM

Pre-operation checks
65
Securely install the stern drain plugs by tight-
ening them until they stop.
EJU43810Hood check
Push down the hood latch and make sure
that it is securely closed.
EJU40146Post-launch checks
Perform the post-launch checks in the pre-
operation checklist while the watercraft is in
the water and the engine is running.
To perform the post-launch checks:
(1) Launch the watercraft. (See page 68 for
information on launching the watercraft.)
(2) Perform the checks and make sure that
there are no malfunctioning items or oth-
er problems.
EJU40553Cooling water pilot outlet check
Make sure that water is discharged from the
cooling water pilot outlet while the engine isrunning. (See page 29 for information on the
cooling water pilot outlet.)
EJU32715Multifunction information center check
Make sure that the multifunction information
center operates properly. (See page 37 for in-
formation on proper operation of the multi-
function information center.)
EJU43392Shift system check
Operate the throttle lever and RiDE lever, and
check that the watercraft moves or does not
move according to the displayed shift indica-
tor. (See page 31 for shift system operation
procedures.) WARNING! To avoid colli-
sions, operate at safe speeds and keep a
1Stern drain plug
1
UF2W74E0.book Page 65 Thursday, July 6, 2017 3:49 PM

Operation
69
is attached correctly. If the engine
shut-off cord (lanyard) is not attached
correctly, it may not pull free when the
operator falls off, allowing the water-
craft to continue to run and cause an
accident.
[EWJ00582]
(4) With the throttle lever released, push the
start switch (green button) to start the
engine. (See page 27 for information on
operating the start switch.)
EJU32863Stopping the engine
Release the throttle lever, and then push the
engine stop switch (red button) to stop the
engine. WARNING! You need throttle to
steer. Shutting the engine off can cause
you to hit an obstacle you are attemptingto avoid. A collision could result in severe
injury or death.
[EWJ00602]
EJU32873
Leaving the watercraft
If leaving the watercraft, remove the clip from
the engine shut-off switch to prevent acci-
dental starting or unauthorized operation by
children or others.
EJU43411Operating the watercraft
When the throttle lever is squeezed, the “F”
(forward) shift indicator will be displayed and
the watercraft will move forward. While the
“F” (forward) shift indicator is displayed, the
watercraft will move forward at trolling speed
even if the throttle lever is in the fully closed
1Clip
2Engine shut-off switch
3Engine shut-off cord (lanyard)
2
3
1
UF2W74E0.book Page 69 Thursday, July 6, 2017 3:49 PM

Operation
72
proximately 110 m (360 ft) after the throttle le-
ver is released or the engine is stopped,
although this distance will vary depending on
many factors, including gross weight, water
surface conditions, and wind direction.
If the RiDE lever is squeezed to slow down,
the stopping distance is approximately 30%
shorter than when the RiDE lever is not used.
However, this distance will vary depending
on many factors, including gross weight, wa-
ter surface conditions, and wind direction.
WARNING
EWJ01791
Allow adequate stopping distance.
Take early action to avoid collisions. Re-
member, watercraft and other boats do
not have brakes.
Operate defensively at safe speeds and
keep a safe distance away from people,
objects, and other watercraft to give you
time to stop.
Do not shut the engine off when slowing
down in case you need engine power to
steer away from a boat or other obstacle
that comes into your path.
To avoid rear-end collisions while oper-
ating the watercraft, check behind you
before using the RiDE lever to slow
down or stop the watercraft.
EJU43443Operating the watercraft in reverse or
neutral
Operating in reverse
When the RiDE lever is squeezed, the “R” (re-
verse) shift indicator will be displayed and the
watercraft will move in reverse. (See page 31
for shift system operation procedures.)
Make sure that there are no obstacles or peo-
ple behind you before shifting into reverse.
TIP:
This model is equipped with a function which
limits the engine speed in reverse.
Operating in neutral
When the RiDE lever is squeezed lightly and
released, the “N” (neutral) shift indicator will
be displayed and the watercraft will stop in its
110 m (360 ft)
1“R” (Reverse position)
1
UF2W74E0.book Page 72 Thursday, July 6, 2017 3:49 PM

99
Index
A
After removing the watercraft from the
water ..................................................... 78
B
Battery care.............................................. 80
Battery checks ......................................... 60
Battery, jumping ....................................... 94
Beaching and docking the watercraft ...... 77
Bilge water check..................................... 60
Bilge water, draining ................................ 53
Bilge water, draining on land ................... 53
Bilge water, draining on water ................. 54
Boarding alone ......................................... 73
Boarding and starting off from a dock ..... 76
Boarding the watercraft ........................... 73
Boarding with passenger(s) ..................... 74
Bow eye ................................................... 44
Bow storage compartment ...................... 45
Builder’s plate ............................................ 2
C
Capsized watercraft ................................. 76
Check engine warning ............................. 40
Cleaning ................................................... 83
Cleaning the watercraft ............................ 80
Cleat ......................................................... 44
Cooling water pilot outlet ......................... 29
Cooling water pilot outlet check .............. 65
Craft Identification Number (CIN)............... 1
Cruising limitations................................... 11
E
Electric trim system.................................. 33
Emergency procedures ............................ 93
Engine break-in ........................................ 56
Engine compartment check ..................... 59
Engine cover, removing and installing ..... 84
Engine idling speed check ....................... 66
Engine oil ................................................. 52
Engine oil and oil filter .............................. 88
Engine oil level check............................... 60
Engine oil requirements ........................... 52
Engine overheat warning ......................... 40
Engine serial number ................................. 1
Engine shut-off cord (lanyard) check ....... 62
Engine shut-off switch ............................. 27
Engine stop switch................................... 27Engine unit check ..................................... 60
Enjoy your watercraft responsibly ............ 19
Equipment ................................................ 42
F
Fire extinguisher check ............................ 64
Fire extinguisher holder and cover........... 47
Fire extinguisher holder, cover, and
band checks ......................................... 63
Flushing the cooling water passages....... 79
Fuel .......................................................... 49
Fuel level check........................................ 59
Fuel level meter ........................................ 39
Fuel level warning..................................... 39
Fuel requirements .................................... 49
Fuel system checks ................................. 59
Fuses, replacing ....................................... 95
G
Getting to know your watercraft .............. 67
Glossary, watercraft ................................. 20
Glove compartment ................................. 46
H
Handgrip .................................................. 43
Hazard information................................... 15
Hood check .............................................. 65
Hour meter ............................................... 40
Hull and deck check ................................ 64
I
Identification numbers ............................... 1
Information display................................... 37
J
Jet intake and impeller, cleaning.............. 93
Jet intake checks ..................................... 64
Jet thrust nozzle and reverse gate
check .................................................... 64
Jumper cables, connecting ...................... 94
L
Labels, important ....................................... 4
Labels, other .............................................. 8
Labels, warning .......................................... 5
Launching the watercraft ......................... 68
Learning to operate your watercraft......... 67
Leaving the watercraft.............................. 69
Limitations on who may operate the
watercraft .............................................. 10
Long-term storage ................................... 83
UF2W74E0.book Page 99 Thursday, July 6, 2017 3:49 PM
