Instrument and control functions
5-9
1
2
3
4
5
6
7
8
9
10
11
12
13
14 To increase the seat heater tempera-
ture, push the “ ” side of the select
switch. To decrease the seat heater
temperature, push the “ ” side of the
select switch.
NOTICE
ECA23980
Be sure to wear protective cloth-
ing that covers your hip and
legs when using the seat heater.
If the ambient temperature is 20

C (68 F) or higher, do not set
the seat heater to the high set-
ting.
If the seat becomes worn or
damaged, stop using the seat
heater and replace the seat.
Changing the information display
The information display items are
grouped into 3 display pages.
Push the “ ” or “ ” side of the select
switch to rotate among the 3 display
pages.
TIP
The items for each display page can be
customized. (See page 5-15.) Odometer:
The odometer shows the total distance
traveled by the vehicle.
Tripmeters:
“TRIP1” and “TRIP2” show the distance
traveled since they were last set to ze-
ro.
To reset a tripmeter, use the select
switch to select the information display
page that contains the tripmeter you
want to reset. Push the “ ” side of the
select switch for one second so that the
tripmeter flashes, and then push the
“ ” side of the select switch again for
one second while the tripmeter is flash-
ing.
TIP
The odometer will lock at 999999.
The tripmeters will reset and con-
tinue counting after 9999.9 is
reached.
When approximately 3.0 L (0.79
US gal, 0.66 Imp.gal) of fuel remains in
the fuel tank, the last segment of the
fuel meter starts flashing. In addition,
UBV1E1_1.book 9 ページ ２０１８年４月２７日　金曜日　午後４時４１分

Instrument and control functions
5-11
1
2
3
4
5
6
7
8
9
10
11
12
13
14 The instantaneous fuel consumption
mode “CRNT.F” can be set to “km/L” or
“L/100km”. For UK-spec vehicles:
“MPG”. (See page 5-14.)
TIP
Instantaneous fuel consumption
cannot be reset.
If traveling at speeds under 10
km/h (6 mi/h), “– –.–” will be dis-
played.
NOTICE
ECA15474
If there is a malfunction, “– –.–” will
be continuously displayed. Have a
Yamaha dealer check the vehicle.
Menu mode
Stop the vehicle and then push the
“MENU” switch for 2 seconds to enter
the menu mode. To exit the menu
mode and return to the standard dis-
play mode, push the “MENU” switch
again for 2 seconds or select
“”.
TIP
Starting off or turning the vehicle power
off saves all settings changes and exits
the setting mode.
Menu items
Grip warmer settings
1. Use the select switch to highlight
“Grip Warmer”.
1. Setting mode display
1
Category Description
This function allows you to
set the low, middle, and
high settings to 10
temperature levels.
This function allows you to
set the low, middle, and
high settings to 10
temperature levels.
This function allows you to
turn the traction control
system on or off.
This function allows you to
check and reset the oil
change interval (indicator),
V-Belt change interval
(indicator), and the “FREE”
maintenance interval.
This function allows you to
switch the fuel
consumption units
between “L/100km” and
“km/L”.
For UK-spec vehicles: this
function is not available.
This function allows you to
change the items shown in
3 information displays.
This function allows you to
adjust the brightness of the
instrument panel.
This function allows you to
set the clock.
This function allows you to
reset all items to their
factory preset or default
settings; excepting the
odometer, clock, and
maintenance counter items
“Oil” and “V-Belt”.
Grip Warmer
Seat Heater
Tr action Control
Maintenance
Unit
Display
Brightness
Clock
All Reset
UBV1E1_1.book 11 ページ ２０１８年４月２７日　金曜日　午後４時４１分

Instrument and control functions
5-17
1
2
3
4
5
6
7
8
9
10
11
12
13
14 “YES”, and then push the “MENU”
switch. All items are reset to facto-
ry preset or default settings.
TIP
The odometer, clock, maintenance
counter item “Oil” and maintenance
counter item “V-Belt” will not be reset.
To exit the setting mode
1. Use the select switch to highlight
“Return”.
2. Push the “MENU” switch to exit the setting mode and return to the
standard display mode.
EAU44912
Front brake lever
The front brake lever is located on the
right side of the handlebar. To apply the
front brake, pull this lever toward the
throttle grip.
The front brake lever is equipped with a
position adjusting dial. To adjust the
distance between the front brake lever
and the throttle grip, turn the adjusting
dial while holding the front brake lever
pushed away from the throttle grip.
Make sure that the appropriate setting
on the adjusting dial is aligned with the
“ ” mark on the front brake lever.
1. Front brake lever
2. Brake lever position adjusting dial
3. “ ” mark
4. Distance between brake lever and handlebar grip
1
2
3 4
UBV1E1_1.book 17 ページ ２０１８年４月２７日　金曜日　午後４時４１分

Periodic maintenance and adjustment
8-3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
EAU71031
TIP
The annual checks must be performed every year, except if a distance-
based maintenance is performed instead.
From 50000 km (30000 mi), repeat the maintenance intervals starting from
10000 km (6000 mi).
Items marked with an asterisk should be performed by a Yamaha dealer as
they require special tools, data and technical skills.
EAU71071
Periodic maintenance chart for the emission control system
NO. ITEM
1 * Fuel line Check fuel hoses for cracks or
damage.
Replace if necessary. 
2 * Spark plugs Check condition.
Adjust gap and clean.

Replace. 
3 * Valve clearance Check and adjust. Every 40000 km (24000 mi)
4 * Fuel injection Check engine idle speed.

Check and adjust synchronization. 
5 * Exhaust system Check for leakage.
Tighten if necessary.
Replace gaskets if necessary. 
6* Evaporative
emission control
system Check control system for
damage.
Replace if necessary. X 1000 km
CHECK OR
MAINTENANCE JOB
X 1000 mi
ODOMETER READINGS
ANNUAL CHECK
110203040
0.66121824
UBV1E1_1.book 3 ページ ２０１８年４月２７日　金曜日　午後４時４１分

Periodic maintenance and adjustment
8-4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
EAU71372
General maintenance and lubrication chart
NO. ITEM
1* Diagnostic system
check Perform dynamic inspection
using Yamaha diagnostic tool.
Check the error codes. 
2 * Air filter element Replace. 
3* V-belt case air filter
elements Clean.

Replace. 
4 * Front brake Check operation, fluid level, and
for fluid leakage.
Replace brake pads if necessary. 
5 * Rear brake Check operation, fluid level, and
for fluid leakage.
Replace brake pads if necessary. 
6 * Brake hoses Check for cracks or damage.

Replace. Every 4 years
7 * Brake fluid Change. Every 2 years
8 Rear brake lock
cable Check cable length.
Adjust if necessary. At the initial interval and 4000
km (2400 mi) after the initial
1000 km (600 mi) and every
5000 km (3000 mi) thereafter.
9 * Rear brake lock Check operation.
Adjust. 
10 * Wheels Check runout and for damage.
Replace if necessary. 
11 * Tires Check tread depth and for
damage.
Replace if necessary.
Check air pressure.
Correct if necessary. 
12 * Wheel bearings Check bearing for looseness or
damage. X 1000 km
CHECK OR
MAINTENANCE JOB
X 1000 mi
ODOMETER READINGS
ANNUAL CHECK
110203040
0.66121824
UBV1E1_1.book 4 ページ ２０１８年４月２７日　金曜日　午後４時４１分

Periodic maintenance and adjustment
8-5
1
2
3
4
5
6
7
8
9
10
11
12
13
14
13 * Drive belt Check belt condition.
Replace if damaged.
Check belt tension.
Adjust if necessary. At the initial interval and every
10000 km (6000 mi) until 40000 km (24000 mi), and every 5000 km (3000 mi) thereafter.
14 * Drive pulley and
drive axle Lubricate.

15 * Steering bearings Check bearing assemblies for
looseness.  
Moderately repack with lithium- soap-based grease. 
16 * Chassis fasteners Make sure that all nuts, bolts
and screws are properly
tightened. 
17 Front and rear
brake lever pivot
shaft Lubricate with silicone grease.

18 Sidestand,
centerstand Check operation.
Lubricate with lithium-soap-
based grease. 
19 * Sidestand switch Check operation and replace if
necessary. 
20 * Front fork Check operation and for oil
leakage.
Replace if necessary. 
21 * Shock absorber
assembly Check operation and for oil
leakage.
Replace if necessary. 
22 * Rear suspension
relay arm and
connecting arm
pivoting points Check operation.

23 Engine oil Change (warm engine before
draining).
Check oil level and vehicle for oil leakage. At the initial interval and
when the oil change
indicator flashes or comes on [every 5000km (3000 mi)]. 
24 Engine oil filter
cartridge Replace.

NO. ITEM
X 1000 km
CHECK OR
MAINTENANCE JOB
X 1000 mi
ODOMETER READINGS
ANNUAL CHECK
110203040
0.66121824
UBV1E1_1.book 5 ページ ２０１８年４月２７日　金曜日　午後４時４１分

Periodic maintenance and adjustment
8-6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
EAU72781
TIP
Air filters
The engine air filter uses a disposable oil-coated paper element. This element
cannot be cleaned with compressed air, doing so will only damage it.
If you often ride in the rain or in dusty areas, have the engine air filter and
V-belt air filter elements serviced more frequently.
Hydraulic brake service
Regularly check the brake fluid levels in the reservoirs, and refill as necessary.
Replace the internal components of the brake master cylinders and calipers,
and change the brake fluid every 2 years.
Replace the brake hoses every 4 years, or sooner if cracked or damaged.
25 * Cooling system Check coolant level and vehicle
for coolant leakage. 
Change. Every 3 years
26 * V-belt Replace. When the V-belt replacement
indicator flashes [every 20000 km (12000 mi)]
27 * Front and rear
brake switches Check operation.

28 * Moving parts and
cables Lubricate.

29 * Throttle grip
housing and cable Check operation and free play.
Adjust the throttle cable free
play if necessary.
Lubricate the throttle grip housing, cable and grip warmer
wire. 
30 * Lights, signals and
switches Check operation.
Adjust headlight beam.

NO. ITEM
X 1000 km
CHECK OR
MAINTENANCE JOB
X 1000 mi
ODOMETER READINGS
ANNUAL CHECK
110203040
0.66121824
