2018 YAMAHA EX engine

Care and storage
80
EX Deluxe: Shift rod (reverse gate end) and
ball joint
TIP:
Disconnect the shift rod from the ball joint be-
fore lubricating.
EJU44790Rustproofing
Rustproofing the hull, deck, and engine
Spray metallic parts of the hull, deck, and en-
gine with a rust inhibitor.
Rustproofing the internal engine compo-
nents
Rustproof the internal engine components
with a rust inhibitor.
To rustproof the internal engine components:
(1) Remove the seat and fire extinguisher
holder. (See page 38 for seat removal
and installation procedures and page 43
for information on the fire extinguisher
holder.)
(2) Remove the plastic tie that is fastening
the fuel hose to the holder on the star-
board side of the air filter case.(3) Release the hooks on the port side of the
air filter case, and remove the air filter
case cover.
(4) Spray a rust inhibitor into the intake
opening for 3 seconds. WARNING! Do
not spray flammable rust inhibitor
products on engine surfaces while the
1Hook
2Air filter case cover
3Fuel hose
4Holder
5Plastic tie
1
23
4
5
UF3Y71E0.book Page 80 Thursday, May 25, 2017 11:17 AM

Care and storage
81
engine is hot. The sprayed substance
or propellants could catch fire.
[EWJ00262]
(5) Place the air filter case cover in its origi-
nal position, and then fit the hooks onto
the cover.
TIP:
Make sure that the air filter case cover is se-
curely installed.
(6) Fasten the fuel hose to the holder using
the plastic tie.
(7) Make sure that the area around the wa-
tercraft is clear, and then start the engine
in a well-ventilated area and let it run at
idle for 15 seconds. (See page 25 for in-
formation on starting the engine.)
(8) Stop the engine.
(9) Securely install the fire extinguisher hold-
er and seat in their original positions.
1Intake opening
1
UF3Y71E0.book Page 81 Thursday, May 25, 2017 11:17 AM

Maintenance
82
EJU33769
Maintenance
Periodic checks and lubrication will keep
your watercraft in the safest and most effi-
cient condition possible. Therefore, make
sure to carry out the periodic maintenance.
Safety is an obligation of the watercraft own-
er. Proper maintenance must be carried out
to keep the exhaust emission and sound lev-
els within the regulated limits. The most im-
portant points of watercraft inspection and
lubrication are explained on the following pa-
ges.
See a Yamaha dealer for genuine Yamaha re-
placement parts and optional accessories
designed for your watercraft.
Remember, failures that are the result of the
installation of parts or accessories which are
not qualitatively equivalent to genuine
Yamaha parts are not covered by the limited
warranty.
Maintenance, replacement, or repair of
the emission control devices and system
may be performed by any marine SI engine
repair establishment or individual. War-
ranty repair, however, must be performed
at an authorized Yamaha marine dealer-
ship.
WARNING
EWJ00312
Be sure to turn off the engine when you
perform maintenance unless otherwise
specified. If you are not familiar with ma-
chine servicing, this work should be done
by a Yamaha dealer or other qualified me-
chanic.
EJU33803Tool kit
A tool kit is included with this watercraft. Pla-
ce the tool kit in a waterproof bag and alwayscarry it with you whenever you use the water-
craft.
1Tool bag
2Screwdriver
3Garden hose adapter
410/12 mm box wrench
5Pliers
610/12 mm open-end wrench
UF3Y71E0.book Page 82 Thursday, May 25, 2017 11:17 AM

Maintenance
83
EJU43101Periodic maintenance chart
The periodic maintenance chart gives general guidelines for periodic maintenance. Have a
Yamaha dealer perform the checks in the following chart. However, maintenance may need
to be performed more frequently depending on your operating conditions. If you have any
questions, consult a Yamaha dealer.
This “√” mark indicates items to be checked and serviced by a Yamaha dealer.
Item OperationInitial Thereafter every
Page
10 hours50 hours
or 12
months
*1100
hours or
12
months
*1200
hours or
24
months
*1
Fuel lineCheck fuel hoses and
clamps√—
Fuel filler cap/Wa-
ter separatorCheck O-rings for cracks
and deformation√—
Fuel tankCheck installation and
straps√—
Water inlet strainerCheck for clogs and dam-
age√—
Cooling water hos-
esCheck for damage and
leakage, and check
clamps√—
Engine oilReplace√√85
Oil filterReplace√85
Spark plugsCheck√√—
BatteryCheck state of charge,
terminals, bands, and
breather hose√—
Battery leadsCheck terminals√—
Steering masterCheck operation and for
looseness√√—
Steering cableCheck exterior and con-
nections, and lubricate√—
Shift lever (EX
Sport)Check exterior and con-
nections, and lubricate√—
Shift cable and re-
verse gate (EX
Sport)Check exterior and con-
nections, and lubricate√—
Shift rod and re-
verse gate
(EX Deluxe)Check exterior and con-
nections, and lubricate√—
Air filter elementCheck for damage and
dirt√—
UF3Y71E0.book Page 83 Thursday, May 25, 2017 11:17 AM

Maintenance
84
*1: Whichever comes first.
*2: Check every 200 hours.
Perform the pre-operation checks and post-operation checks before performing periodic
maintenance.
Air intake hosesCheck for damage, and
check clamps√—
Throttle bodyLubricate throttle valve√—
Exhaust systemCheck for exhaust leak-
age, and check hoses and
clamps√—
Breather hoseCheck breather hose and
clamps√—
ImpellerCheck for bends, dam-
age, and foreign material√—
Jet thrust nozzleCheck movement, and lu-
bricate√—
Jet vacuum bilgeCheck hoses for clogs
and damage, check
clamps, and clean bilge
strainer√—
Stern drain plugsCheck O-rings√—
AnodeCheck for corrosion, and
clean√ *2 —
Valve clearanceCheck and adjust√ *2 —
Rubber couplingCheck for cracks, inden-
tations, looseness, and
noise√—
Engine mountCheck for damage and
peeling√— Item OperationInitial Thereafter every
Page
10 hours50 hours
or 12
months
*1100
hours or
12
months
*1200
hours or
24
months
*1
UF3Y71E0.book Page 84 Thursday, May 25, 2017 11:17 AM

Maintenance
85
EJU36943Engine oil and oil filter
WARNING
EWJ00341
Engine oil is extremely hot immediately af-
ter the engine is turned off. Coming in con-
tact with or getting any engine oil on your
clothes could result in burns.
NOTICE
ECJ00992
Do not run the engine with too much or not
enough oil in the engine, otherwise the en-
gine could be damaged.
It is recommended to have a Yamaha dealer
change the engine oil and the engine oil filter.
However, if you choose to change the oil and
filter on your own, consult a Yamaha dealer.
UF3Y71E0.book Page 85 Thursday, May 25, 2017 11:17 AM

Specifications
86
EJU34543
Specifications
Watercraft capacity:
Maximum people on board:
3 person
Maximum load capacity:
220 kg (486 lb)
Dimensions and weight:
Length:
3130 mm (123.2 in) (EX)
3140 mm (123.6 in) (EX Sport / EX Deluxe)
Width:
1130 mm (44.5 in)
Height:
1150 mm (45.3 in)
Dry weight:
262 kg (578 lb) (EX)
265 kg (584 lb) (EX Sport)
272 kg (600 lb) (EX Deluxe)
Performance:
Maximum output (according to ISO 8665/SAE
J1228):
74.6 kW at 7300 r/min
Maximum fuel consumption:
28.5 L/h (7.5 US gal/h, 6.3 Imp.gal/h)
Cruising range at full throttle:
1.75 hour
Trolling speed:
1500 ±100 r/min
Engine:
Engine type:
Liquid cooled 4-stroke, DOHC
Number of cylinders:
3
Engine displacement:
1049 cm³
Bore × stroke:
82.0 × 66.2 mm (3.23 × 2.61 in)
Compression ratio:
11.0 : 1
Valve clearance-intake (cold):
0.15–0.22 mm (0.0059–0.0087 in)
Valve clearance-exhaust (cold):
0.26–0.32 mm (0.0102–0.0126 in)
Lubrication system:
Dry sump
Cooling system:
WaterStarting system:
Electric
Ignition system:
T.C.I.
Spark plug (NGK):
CR9EB
Spark plug gap:
0.7–0.8 mm (0.028–0.031 in)
Battery capacity:
12 V, 19 Ah
Charging system:
Flywheel magneto
Drive unit:
Propulsion system:
Jet pump
Jet pump type:
Axial flow, single stage
Impeller rotation:
Counterclockwise
Jet thrust nozzle angle:
24+24 °
Fuel and oil:
Recommended fuel:
Regular unleaded gasoline
Minimum octane rating (PON):
86
Minimum octane rating (RON):
90
Recommended engine oil:
YAMALUBE 4W or 4-stroke motor oil
Recommended engine oil type SAE:
SAE 10W-30, 10W-40, 20W-40, 20W-50
Recommended engine oil grade API:
API SG, SH, SJ, SL
Fuel tank total capacity:
50 L (13.2 US gal, 11.0 Imp.gal)
Engine oil quantity with oil filter replacement:
3.4 L (3.59 US qt, 2.99 Imp.qt)
Engine oil quantity without oil filter replacement:
3.2 L (3.38 US qt, 2.82 Imp.qt)
Engine oil total quantity:
3.7 L (3.91 US qt, 3.26 Imp.qt)
UF3Y71E0.book Page 86 Thursday, May 25, 2017 11:17 AM

Trouble recovery
87
EJU34562
Troubleshooting
If you have any trouble with your watercraft, use the troubleshooting chart to check for the
possible cause.
If you cannot find the cause, consult a Yamaha dealer.
EJU44430Troubleshooting chart
Confirm the possible cause and remedy, and then refer to the applicable page.
TROUBLE POSSIBLE CAUSE REMEDY PAGE
Engine does not
start (Starter motor
does not turn over)Engine shut-
off switchClip not in place Install clip
25
Fuse Burned out Have serviced by
Yamaha dealer—
Battery Run down Recharge 76
Poor terminal con-
nectionsTighten as required
76
Terminal corroded Clean or replace 76
Starter motor Faulty Have serviced by
Yamaha dealer—
Engine does not
start (Starter motor
turns over)Throttle lever Squeezed Release 25
Faulty Have serviced by
Yamaha dealer—
RiDE lever
(EX Deluxe)Squeezed Release 25
Faulty Have serviced by
Yamaha dealer—
Fuel Fuel tank empty Refill as soon as pos-
sible44
Stale or contaminat-
edHave serviced by
Yamaha dealer—
Fuel tank Water or dirt present Have serviced by
Yamaha dealer—
Spark plug Fouled or defective Have serviced by
Yamaha dealer—
Fuel injec-
tion systemFuel pump faulty Have serviced by
Yamaha dealer—
