2018 VOLVO XC90 TWIN ENGINE keyless

KEY, LOCKS AND ALARM
}}
* Option/accessory. 253
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
Any changes or modification not expressly
approved by the party responsible for compliance
could void the user's authority to operate this
equipment.
Canada
Volvo Standard Key IC: 4008C-HUF8423
Volvo Tag ID IC: 4008C-HUF8432
This device complies with Industry Canada
license-exempt RSS standards. Operation is sub-
ject to the following two conditions:
(1) This device may not cause harmful interfer-
ence, and (2) this device must accept any inter-
ference received, including interference that may
cause undesired operation.
Immobilizer and Passive entry/Passive
start* systems
USA-FCC ID: LTQVO3134
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation. Any changes or modification not expressly
approved by the party responsible for compliance
could void the user's authority to operate this
equipment.
Canada-IC:3659A-VO3134
This device complies with Industry Canada
license-exempt RSS standards. Operation is sub-
ject to the following two conditions:
(1) This device may not cause harmful interfer-
ence, and (2) this device must accept any inter-
ference received, including interference that may
cause undesired operation.
Related information
•
Remote key (p. 239) Keyless and touch-sensitive
surfaces*
If the vehicle is equipped with keyless locking
and unlocking, it is only necessary to have the
remote key within range, e.g. in a pocket or bag,
which makes it easier to open the vehicle if your
hands are full.

||KEY, LOCKS AND ALARM
* Option/accessory.
254
Pressure-sensitive surfaces
Door handle
There are indentations on the outside of the
outer door handles for locking, and pressure-sen-
sitive surfaces on the inside of the handles for
unlocking. Pressure-sensitive indentation for locking
Pressure-sensitive surface for unlocking
NOTE
It is important that only one pressure-sensi-
tive surface is activated at a time. If the han-
dle is grasped at the same time as the lock
area is pressed, there is a risk that double
commands may be sent. This may cause the
requested action (locking/unlocking) to be
delayed or not performed at all.
Tailgate
The tailgate handle has a rubberized pressure
plate that can only be used for unlocking.
NOTE Please be aware that the system could be
activated in a car wash if the remote key is
within range.
Related information
•
Keyless locking and unlocking* (p. 254)
• Keyless tailgate unlock* (p. 256) Keyless locking and unlocking*
The vehicle can be locked or unlocked from out-
side using the door or tailgate handles if the
vehicle is equipped with keyless locking/unlock-
ing (Passive Entry)*. Pressure-sensitive indentation for locking
Pressure-sensitive surface for unlocking

KEY, LOCKS AND ALARM
* Option/accessory.255Rubberized pressure plate on the tailgate used only for
unlocking.
NOTE
One of the vehicle's remote keys must be
within range for locking and unlocking to be
possible.
NOTE
Please be aware that the system could be
activated in a car wash if the remote key is
within range.
Keyless lockingAll of the doors have to be closed before the
vehicle can be locked. However, the tailgate can
be open when a door handle is used for locking.
–
To lock, touch the marked area on the out-
side of one of the door handles after the
door is closed or press the button on the
lower edge of the tailgate 11
before it is
closed.
>

The lock indicator light in the windshield
will flash to confirm that the vehicle is
locked.
To close all door windows at the same time -
place your finger on the pressure-sensitive
indentation on the outside of the door handle and
hold it there until the side windows have closed.
Locking when the tailgate is open
NOTE If the vehicle is locked and the tailgate is still
open, make sure that the remote key is not
left in the cargo compartment when the tail-
gate is closed and the entire vehicle is
locked
12
.
Keyless unlocking
– To unlock, grasp a door handle or press the
rubberized pressure plate on the underside
of the tailgate handle.
>
The lock indicator light in the windshield
will go out to confirm that the vehicle is
unlocked. Open the doors or tailgate as
usual.
Automatic relockingIf none of the doors or tailgate are opened within
two minutes after being unlocked, they will auto-
matically relock. This function reduces the risk of
inadvertently leaving the vehicle unlocked.
Related information
• Keyless unlock settings* (p. 256)
• Keyless tailgate unlock* (p. 256)
• Keyless and touch-sensitive surfaces*
(p. 253) 11
Applies to vehicles with power tailgate*.
12 If the key is detected in the vehicle, the tailgate will not lock when i\
t is closed.

KEY, LOCKS AND ALARM
* Option/accessory.
256 Keyless unlock settings*
Several different sequences are available for
keyless unlocking.
1. Tap Settings in the center display's Top
view.
2.

Tap My Car Locking Keyless Unlock
3. Select alternative:
•All Doors
- unlocks all doors at the same time.
• Single Door
- unlocks the selected door.
Related information
• Keyless locking and unlocking* (p. 254)
• Keyless and touch-sensitive surfaces*
(p. 253) Keyless tailgate unlock*
The tailgate can be opened using the remote
key. The key only needs to be within range, e.g.
in a pocket or bag.
The tailgate is held closed by an electronic lock-
ing mechanism. To open the tailgate:
1.

Lightly press the rubberized pressure plate
on the underside of the tailgate handle.
> The lock will disengage.
NOTE One of the vehicle's remote keys must be
within range behind the vehicle for unlocking
to be possible. 2. Lift the outer handle to fully open the tail-
gate.
CAUTION •
Only light pressure on the rubberized pres-
sure plate is necessary to release the tail-
gate's locking mechanism.
• Use the handle to lift the tailgate and do
not apply force to the rubberized pressure
plate. Too much force can damage the
pressure plate's electrical connections. Hands-free unlocking of the tailgate is also pos-
sible using a foot movement under the rear
bumper; see the separate section.
WARNING
Do not drive with the tailgate open. Toxic
exhaust fumes can be sucked into the vehicle
through the cargo compartment.
Related information
•
Keyless locking and unlocking* (p. 254)
• Keyless and touch-sensitive surfaces*
(p. 253)
• Remote key range (p. 243)
• Foot movement tailgate operation* (p. 265)

KEY, LOCKS AND ALARM
}}
* Option/accessory. 257
Antenna locations for the start and
lock system
The vehicle is equipped with a keyless start and
lock system 13
that uses a number of integrated
antennas positioned throughout the vehicle. Location of the antennas.
Under the cup holder in the front section of
the tunnel console
In the upper front section of the left-side rear
door
14 In the upper front section of the right-side
rear door
14 In the center of the rear seat backrest
14
WARNING Individuals with an implanted pacemaker
should not allow the pacemaker to come
closer than 22 cm (9 in.) to the Keyless sys-
tem antennas. The aim of this is to prevent
disturbances between the pacemaker and the
Keyless system.
Related information
•
Keyless and touch-sensitive surfaces*
(p. 253)
• Remote key range (p. 243) Locking and unlocking from inside
the vehicle
The doors and tailgate can be locked and
unlocked from inside the vehicle using the cen-
tral lock buttons in the front doors. The lock but-
tons in the rear doors* can be used to lock/
unlock that particular door.
Central locking Button with indicator light for locking and unlocking in
front door.
Unlocking using the front door buttons
–
Press the button to unlock all side doors
and the tailgate.
Press and hold the button to open all
side windows at the same time 15
. 13
The keyless lock system only applies to vehicles equipped with keyless l\
ocking and unlocking (Passive Entry*).
14 Only in vehicles equipped with keyless locking and unlocking (Passive E\
ntry*).
15 The total airing function can be used to e.g. quickly air out the vehicl\
e in hot weather.

||KEY, LOCKS AND ALARM
* Option/accessory.
262 –
Move your foot in a kicking motion* under the
rear bumper.
Closing the power tailgate
To close the tailgate 17
, do one of the following: –
Press the button on the lower edge of
the tailgate to close. > The tailgate will close automatically - the
tailgate will remain unlocked.
NOTE The button remains active 24 hours after the
tailgate was opened. After this time, the tail-
gate must be closed manually.
–
Press and hold the button on the
remote key.
>

The tailgate closes automatically and an
audible signal will sound - the tailgate will
remain unlocked. –
Press and hold the button on the dash-
board.
>

The tailgate closes automatically and an
audible signal will sound - the tailgate will
remain unlocked.
– Move your foot in a kicking motion* under
the rear bumper.
>

The tailgate closes automatically and an
audible signal will sound - the tailgate will
remain unlocked. 17
Vehicles equipped with keyless locking and unlocking (Passive Entry*) have a button for closing and a button for closing and locking.

KEY, LOCKS AND ALARM
}}
* Option/accessory. 263
Closing and locking 17
the power
tailgate
– Press the button on the lower edge of
the tailgate to close and simultaneously lock
the tailgate and doors (all doors must be
closed in order to lock).
>
The tailgate closes automatically - the tail-
gate and doors lock, and the alarm* is
activated.
NOTE •
One of the vehicle's remote keys must be
within range for locking and unlocking to
be possible.
• When the keyless locking or closing* func-
tions are used, three audible signals will
sound if the key is not detected close
enough to the tailgate.
CAUTION When operating the tailgate manually, open
and close it slowly. If you encounter resis-
tance, do not use force. This could lead to
damage and loss of function.
Interrupting opening or closingInterrupt opening or closing by doing one of the
following:
• Press the button on the dashboard.
• Press the button on the remote key.
• Press the close button on the underside of
the tailgate.
• Press the rubberized pressure plate on the
underside of the tailgate's outer handle.
• Using a foot movement*.
Tailgate movement is interrupted and stops. The
trunk lid can then be opened or closed manually.
Pinch protectionIf anything obstructs the tailgate with enough
force to prevent it from opening or closing, pinch
protection will be activated.
• When opening - the tailgate will stop moving
and an audible signal will sound.
• When closing - the tailgate will stop, a long
audible signal will sound and the tailgate will
return to the programmed maximum opening
position.
WARNING Be aware of the risk of serious injury when
operating the tailgate. Before opening/clos-
ing, make sure that no one is in the path of
the tailgate who could be injured by its move-
ment.
Always operate the tailgate with caution.
Preloaded springs
Preloaded springs for the power tailgate.
WARNING
Do not attempt to open or access the preloa-
ded springs in the power tailgate struts. They
are preloaded with high pressure and can
cause injury if opened.
17
Vehicles equipped with keyless locking and unlocking (Passive Entry*) have a button for closing and a button for closing and locking.

||KEY, LOCKS AND ALARM
* Option/accessory.
266 To activate opening and closing using a foot
movement on a vehicle with skid plate, make a
kicking motion from the side of the vehicle. One
of the vehicle's remote keys must be within range
(approx. 1 meter (3 feet)) for opening and closing
to be possible.
Kicking motion within the sensor's activation area.
Related information
•
Keyless and touch-sensitive surfaces*
(p. 253)
• Opening and closing the power tailgate*
(p. 261)
• Remote key range (p. 243) Private Locking
The glove compartment and the tailgate can be
locked using the private locking function to pre-
vent them from being opened, e.g. when the
vehicle is left at a workshop or with a valet.
The function button for private
locking is located in the center
display's Function view.
Depending on the current sta-
tus of the lock, Private
Locking Unlocked or Private Locking Locked will be dis-
played.
Related information
• Activating and deactivating private locking
(p. 267)
