2018 VOLKSWAGEN CC warning

Warning and indicator lights

Flashes Possible cause Proper response
D
Steering system stiff. Turn the steering wheel back
and forth.
Steering column not
locked/unlocked.
Switch the ignition off and
then switch it on again. Heed
any messages shown in the
instrument cluster display, if
applicable.
On vehicles with Keyless Ac-
cess ,press the starter button
briefly twice in a row without
depressing the brake or
clutch pedal.
Do not drive any farther if
the steering column remains
locked after you switch on the
ignition. Contact your author-
ized Volkswagen dealer or an
authorized Volkswagen Ser-
vice Facility for assistance.

When the ignition is switched on, several warning and indicator lights
come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.

WARNING
The counter-steering assistance in ESC can do no more than
help the driver steer in difficult situations. The driver must still
control the vehicle. The vehicle does not steer by itself with this
feature!
NOTICE
If the ignition is off, the steering column lock will engage and the
vehicle cannot be steered. For this reason, you must leave the
ignition on when going through an automatic car wash, for ex-
ample, so that the wheels will still steer.

WARNING
Parking improperly can cause serious personal injury.
Never remove the key from the ignition switch while the vehi-
cle is moving or rolling to a stop. The steering wheel will lock
and you will not be able to steer or control the vehicle.
Never park the vehicle where the hot exhaust system or cata-
lytic converter could ignite flammable materials, such as brush,
leaves, dry grass, spilled fuel, etc.
Always apply the electronic parking brake when parking your
vehicle.
Improper use of the electronic parking brake can seriously
injure you and your passengers.
Never use the parking brake to slow down the vehicle when it
is moving, except in an emergency. The stopping distance is
much longer because only the rear wheels are braked. Always
use the foot brake to stop the vehicle.
Never activate the throttle manually from the engine com-
partment when the engine is running and the automatic trans-
mission is in gear. The vehicle will start to move as soon as the
engine speed increases even if the parking brake is on.
Never leave children or anyone who cannot help themselves
behind in the vehicle. They could switch off the parking brake
and move the gear selector lever or gear shift, which could
cause the vehicle to start moving. This can lead to a crash and
serious personal injuries.
Always take the key with you when you leave the vehicle. The
engine can be started and vehicle systems such as the power
windows can be operated, leading to serious personal injury.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
with the remote control vehicle key, trapping passengers in the
vehicle in an emergency. For example, depending on the time
of year, people trapped in the vehicle can be exposed to very
high or very low temperatures.

Heat buildup in the passenger and luggage compartment of a
parked vehicle can result in temperatures in the vehicle that are
much higher than the outside temperatures, particularly in
summer. Temperatures can quickly reach levels that can cause
unconsciousness and death, particularly to small children.
NOTICE
Always be careful when you park in areas with parking barri-
ers or high curbs. These vary in height and could damage your
bumper and related parts if the front of your vehicle hits a barrier
or curb that is too high while you are getting into or out of a
parking spot. To help prevent damage, stop before the tires of
your vehicle touch a parking barrier or curb.
Always be careful when you enter a driveway or drive up or
down steep ramps or over curbs or other obstacles. Parts of the
vehicle close to the ground may be damaged (such as bumper
covers, spoilers, and parts of the engine, suspension, and ex-
haust systems).
Warning and indicator lights

WARNING
Driving with bad brakes can cause a collision and serious per-
sonal injury.
If the brake warning light "2!+% or H does not go out, or
comes on when driving, either the brake fluid level in the reser-
voir is too low or there is a fault in the brake system. Stop the
vehicle as soon as you can do so safely and get expert assis-
tance ⇒  Brake fluid.
If the brake warning light "2!+% or H comes on at the same
time as the ABS warning light !"3 or J, the ABS may not be
working properly. This could cause the rear wheels to lock up
relatively quickly during braking. Rear wheel brake lock-up can
cause loss of vehicle control.
If you believe the vehicle is safe to drive, drive slowly and
very carefully to the nearest authorized Volkswagen dealer, au-
thorized Volkswagen Service Facility, or other qualified work-
shop and have the brake system inspected. Avoid sudden hard
braking and steering.
If the ABS indicator light !"3 or J does not go out, or if it
comes on while driving, the ABS system is not working proper-
ly. The vehicle can then be stopped only with the standard
brakes (without ABS). You will not have the protection ABS
provides. Contact your authorized Volkswagen dealer or an au-
thorized Volkswagen Service Facility as soon as possible.
If the symbol "2!+% 7%!2 or I lights up in the instrument clus-
ter display, whether alone or together with a text message, im-
mediately contact an authorized Volkswagen dealer or author-
ized Volkswagen Service Facility to have the brake pads
checked and, if necessary, replaced.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.

clutch pedal all the way down before you start driving so the system
recognizes that the parking brake should be released.
Emergency braking function
Only use the emergency braking function in an emergency, when you
cannot stop the vehicle using the brake pedal ⇒ !
Pull and hold the button ⇒ fig. 144 to brake the vehicle hard. An
audio warning signal will sound at the same time.
To stop the braking maneuver, release the button or press the ac-
celerator pedal.
WARNING
Improper use of the electronic parking brake can cause acci-
dents and severe injuries.
Never use the parking brake to slow down the vehicle when it
is moving, except in an emergency. Braking distance is much
longer, since only the rear wheels are braked. Always use the
foot brake.
Never press the accelerator pedal when a selector lever posi-
tion or gear is engaged and the engine is running. The vehicle
could begin moving, even if the electronic parking brake is set.
Never activate the throttle manually from the engine com-
partment when the engine is running and the automatic trans-
mission is in gear. The vehicle will start to move even if the
parking brake is engaged.
NOTICE
Even though the transmission is in Park (P), the vehicle may
move a couple of inches (a few centimeters) forwards or back-
wards if you take your foot off the brake pedal after stopping the
vehicle without first firmly setting the parking brake.
Vehicles with manual transmission: the electronic parking brake
releases automatically when you release the clutch pedal and press
the accelerator pedal at the same time.

Facing downhill, turn the front wheels so that they point toward the
curb.
Facing uphill, turn the front wheels so that they point away from the
curb.
WARNING
The vehicle exhaust system and the catalytic converter get very
hot. They can cause fires and serious personal injury.
Never park where the hot exhaust system could ignite flam-
mable materials, such as brush, leaves, dry grass, spilled fuel,
etc.
NOTICE
Always be careful when you park in areas with parking barri-
ers or high curbs. These vary in height and could damage your
bumper and related parts if the front of your vehicle hits a barrier
or curb that is too high while you are getting into or out of a
parking spot. To help prevent damage, stop before the tires of
your vehicle touch a parking barrier or curb.
Always be careful when you enter a driveway or drive up or
down steep ramps or over curbs or other obstacles. Parts of the
vehicle close to the ground may be damaged (such as bumper
covers, spoilers, and parts of the engine, suspension, and ex-
haust systems).
About the brakes
