7799-2. Customization
9
Vehicle specifications
■Vehicle customization
●When the Speed linked door locking function and the Shift position linked
door locking function are both on, the door lock operates as follows.
• When shifting the shift position to any position other than P, all the doors
will be locked.
• If the vehicle is started with all the doors locked, the Speed linked door locking function would not operate.
• If the vehicle is started with any door unlocked, the Speed linked door locking function will operate.
● When the smart key system is off, Smart door unlocking cannot be custom-
ized.
● When the doors remain closed after unlocking the doors and the automatic
door lock function is activated, the signals will be generated in accordance
with the operation signal (buzzer) and the operation signal (emergency
flashers) settings.
■ In the following situations, customiz e mode will automatically be turned
off.
● A warning message appears after the customize mode screen is displayed.
● The power switch is turned off.
● The vehicle begins to move while the customize mode screen is displayed.
■
Maintenance system
WARNING
■ Cautions during customization
As the hybrid system needs to be oper ating during customization, ensure
that the vehicle is parked in a place with adequate ventilation. In a closed
area such as a garage, exhaust gases including harmful carbon monoxide
(CO) may collect and enter the vehicle. This may lead to death or a serious
health hazard.
NOTICE
■ During customization
To prevent 12-volt battery discharge, ensure that the hybrid system is oper-
ating while customizing features.
Oil Maintenance
(U.S.A. only)Resetting the message indicating maintenance
is required: →P. 592
Tire pressure warning
systemInitializing the tire pr essure warning system:
→ P. 6 2 0

798What to do if... (Troubleshooting)
PRIUS_OM_OM47B89U_(U)
What to do if... (Troubleshooting)
●If you lose your mechanical keys, new genuine mechanical keys can be
made by your Toyota dealer. ( →P. 167)
●If you lose your electronic keys, the risk of vehicle theft increases signifi-
cantly. Contact your Toyota dealer immediately. ( →P. 170)
●Is the electronic key battery weak or depleted? (→P. 646)
●Is the power switch in ON mode?
When locking the doors, turn the power switch off. ( →P. 233)
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. (→P. 184)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (→P. 174)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

799What to do if... (Troubleshooting)
PRIUS_OM_OM47B89U_(U)
●Did you press the power switch while firmly depressing the brake pedal?
(→P. 231)
●Is the shift position in P? ( →P. 241)
●Is the electronic key anywhere detectable inside the vehicle? ( →P. 182)
●Is the electronic key battery weak or depleted?
In this case, the hybrid system can be started in a temporary way.
(→P. 727)
●Is the 12-volt battery discharged? ( →P. 729)
●Is the window lock switch pressed?
The power windows except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( →P. 204)
●The auto power off function will be operated if the vehicle is left in
ACCESSORY or ON mode (the hybrid system is not operating) for a
period of time. ( →P. 233)
If you think something is wrong
The hybrid system does not start
The windows do not open or close by operating the power
window switches
The power switch is turned off automatically

800What to do if... (Troubleshooting)
PRIUS_OM_OM47B89U_(U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (→P. 678)
●The parking brake indicator is on
Is the parking brake released? (→P. 247)
Depending on the situation, other types of warning buzzer may also sound.
( →P. 673, 684)
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display. ( →P. 684)
●When a warning light turns on or a warning message is displayed, refer to \
P. 673, 684.
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed

802Alphabetical index
PRIUS_OM_OM47B89U_(U)
Alphabetical index
A/C .................................... 516, 526Air conditioning filter ............. 634
Automatic air
conditioning system .... 516, 526
Climate control ...................... 519
Eco score (A/C score)........... 136
Humidity sensor ............ 523, 533
S-FLOW mode .............. 518, 528
ABS (Anti-lock Brake System)...... 408 Function ................................ 408
Warning light ......................... 674
Air conditioning filter .............. 634
Air conditioning system ............................ 516, 526 Air conditioning filter ............. 634
Automatic airconditioning system .... 516, 526
Climate control ...................... 519
Eco score (A/C score)........... 136
Humidity sensor ............ 523, 533
S-FLOW mode .............. 518, 528
Air intake vent ............................ 83
Cleaning................................ 637 Airbags ....................................... 36
Airbag operating conditions .... 44
Airbag precautions for
your child .............................. 39
Airbag warning light .............. 674
Correct driving posture ........... 28
Curtain shield airbag operating conditions ............. 45
Curtain shield airbag precautions........................... 42
Front passenger occupant
classification syst em ............ 50
General airbag precautions .... 39
Locations of airbags ............... 36
Modification and disposal of airbags ............................. 43
Side airbag operating
conditions ............................. 45
Side airbag precautions .......... 41
Side and curtain shield airbags operating
conditions ............................. 45
Side and curtain shield
airbags precautions .............. 42
SRS airbag instructions for Canadian owners ............... 785
SRS airbags ........................... 36
Anchor brackets ........................ 74
Antenna Radio .................................... 443
Smart key system ................. 182
A

804Alphabetical index
PRIUS_OM_OM47B89U_(U)
Bluetooth® audio ..................... 472
Bluetooth® phone .................... 474
Deleting the call history......... 494
Making a call ......................... 477
Managing the contacts.......... 490
Message function.................. 484
Phone settings ...................... 489
Receiving a call..................... 480
Speaking on the phone ......... 481
Bottle holders .......................... 543
Brake Fluid ...................................... 751
Parking brake........................ 247
Regenerative braking.............. 80
Warning light ......................... 673
Brake assist ............................. 408
Brake Override System ........... 215
Break-in tips ............................. 216
Brightness control Instrument cluster
light control ........................... 94
BSM (Blind Spot Monitor) ....... 326
Care Aluminum wheels.................. 583
Camera sensor ..................... 277
Exterior ................................. 582
Interior................................... 588
Radar sensor ........................ 276
Seat belts .............................. 589
Water-repellent coating......... 583
Cargo capacity ......................... 228
Catch protection function ....... 205 Cargo hooks ............................ 547
CD player.................................. 444
Chains ...................................... 419
Child restraint system............... 58
Fixed with a LATCH
system .......... ..................... ... 71
Fixed with a seat belt .............. 65
Front passenger occupant classification syst em ............ 50
Points to remember ................ 59
Riding with children ................ 57
Types of child restraint system installation
method ................................. 61
Using an anchor bracket ................................. 74
Child safety ................................ 57
12-volt battery precautions ... 612
Airbag precautions.................. 39
Back door precautions .......... 179
Child restraint system ............. 58
How your child should wear the seat belt ................. 31
Installing child restraints ......... 61
Moon roof precautions .......... 211
Power window lock switch .... 204
Power window precautions ... 206
Rear door child-protectors .... 174
Removed key battery precautions......................... 648
Riding with children ................ 57
Seat belt extender precautions........................... 35
Seat belt precautions .............. 70
Seat heater precautions ....... 536
Child-protectors ...................... 174
C

806Alphabetical index
PRIUS_OM_OM47B89U_(U)
DoorsAutomatic door locking
and unlocking system ......... 174
Back door.............................. 177
Door glasses ......................... 204
Door lock............................... 171
Open door warning buzzer................................. 675
Open door warning light........ 675
Outside rear view mirrors...... 202
Rear door child-protectors .... 174
Side doors............................. 171
Drive information ..................... 116
Drive-Start Control .................. 216
Driver’s seat belt reminder light......................................... 675
Driving
Break-in tips .......................... 216
Correct posture ....................... 28
Driving in the rain .................. 215
Driving mode select switch ................................. 324
Hybrid vehicle driving tips ..... 415
Procedures ........................... 214
Winter drive tips .................... 418
Dynamic radar cruise control with full-speed range ............ 304
ECB (Electronically Controlled Brake System) .... 408
Eco drive mode ........................ 324
EDR (Event data recorder) .............. 11
Electric motor Location .................................. 78
Specification ......................... 747 Electric Power Steering (EPS)
Function ................................ 408
Warning light......................... 674
Electronic key If the electronic key does
not operate properly ........... 726
Replacing the battery............ 646
Electronically Controlled
Brake System (ECB) ............. 408
Emergency flashers ................ 664
Emergency, in case of If a warning buzzer sounds................................ 673
If a warning light turns on ..... 673
If a warning message is
displayed ............................ 684
If the 12-volt battery is
discharged.......................... 729
If the electronic key does not operate properly ........... 726
If the hybrid system will not start .............................. 724
If you have a flat tire ............. 691
If you lose your keys ..... 167, 170
If you think something
is wrong .............................. 672
If your vehicle becomes
stuck ................................... 740
If your vehicle has to be stopped in an
emergency ......................... 665
If your vehicle needs to be towed.................................. 666
If your vehicle overheats....... 735
Energy monitor ........ 117, 153, 158
E

809Alphabetical index
PRIUS_OM_OM47B89U_(U)
I/M test ...................................... 597
IdentificationEngine................................... 746
Vehicle .................................. 745
Ignition switch
(Power switch) ....................... 231 Auto power off function ......... 233
Changing the power switch modes...................... 233
If your vehicle has to be stopped in an
emergency.......................... 665
Starting the hybrid system .... 231
Illuminated entry system ........ 540
Immobilizer system ................... 89
Indicators ................................. 100
Initialization
Intelligent Clearance Sonar .................................. 360
Items to initialize ................... 780
Maintenance data ................. 592
Moon roof.............................. 210
Power windows ..................... 205
S-APGS (Simple Advanced
Parking Guidance
System) .............................. 388
Tire pressure warning
system ......... ....................... 621
Inside rear view mirror ............ 200
Instrument cluster light control ...................................... 94
Intelligent Clearance Sonar .... 350
Interior lights............................ 538 Switch ........................... 539, 540
Wattage ................................ 754
Intuitive parking assist............ 339 Jack
Positioning a floor jack.......... 603
Vehicle-equipped
jack ............................. 692, 707
Jack handle ...................... 692, 707
Jam protection function
Moon roof ............................. 209
Power windows..................... 205
Keyless entry Smart key system ................. 182
Wireless remote control ........ 166
Keys .......................................... 166
Electronic key ....................... 166
Engine switch ....................... 231
If the electronic key does not operate properly ........... 726
If you lose your keys ..... 167, 170
Key number plate ................. 166
Keyless entry ........................ 166
Keys...................................... 166
Mechanical key ..................... 166
Power switch ........................ 231
Replacing the battery............ 646
Warning buzzer .................... 183
Wireless remote control key...................................... 166
Knee airbags .............................. 36
IJ
K
