2018 TOYOTA COROLLA iM navigation

2.MAPSCREENOPERATIONANDMAPICONS2.MAPSCREENOPERATIONANDMAPICONS
IconName
ATM/Banking
Automotive
Coffee Shops
Community
Entertainment
Gas Stations
Highway Exit
Hospital
Hotels/Motels
Other
Parking
Recreation
Restaurants
Shopping
IconName
Tra vel
Truck
LIST OFPOI ICONS
MAIN
CATEGORIES
Some Main POI Categories have sub-
categories.
 Some POIs will be displayed with
branded icon. Availability of branded POI
icons might change after future
Nav igation database update.
 The list of available POI categories might
change after future Navigation database
update.
121

3.DESTINATIONSEARCH3.DESTINATIONSEARCH
SEARCHING ONTHEMAP
1Display theMAP: press the “ME DIA ”
button.
Each time the“MEDIA ”button
is pressed the system will switch the
screen between MAP a nd the last
audio mode us ed.
2Select the desired p oint on t he m ap.
3Select “Go”.
Whe n“Save ”is sel ect ed, the po intis
re gis tere d in the “ Favori tedesti nation ”
list. ( →P.143)
 The rou tewill be c alcula ted.
SEAR CHING BY
COORDI NATES
Geocoordinates can be enteredin
DMS f ormat (Degrees
°,Minutes’,
Sec onds”). Only coordinate values
tha t can potentially exist areable tobe
entered. Impossible coordinate values
and their relevant screen buttonswill
be grayed out.
1Disp lay the “Navigation ” me nu screen
and select “Enteraddress”.
(→P.112)
2Select “Geo-coordinate s”.
3Select “N”or “S”.
4Enter the latitude.
5Select “W”or “E”.
6Enter t he long itude.
7Select “OK”.
130

4.ROUTEGUIDANCE
1.STARTINGROUTEGUIDANCE
4.ROUTEGUIDANCE
No.Information
Distanceand arriv alor remaining
time to the destinationEach time information b ox is
selected, thescreen wi llchangebetwe en arrival ti meand remaining time to the destination.
Guidance route
Select to switchbetween full screen
map view and splitmap screen view.Sidebar isonly shown on fullscreenmap view.
Thename of the current street or the
next street (when approaching a maneuver point)
Current position
Distance to the next turn withthearrow indicating the turn direction.
Select to repeat the last navigation announcement.
ROUTE GUIDANCE SCREENSIGNPOS TS
When approaching the turn, asig npost
Wh ile guiding the route, the route
guidance screen willbedisp layed. will
automatically be di splayed.
INTERST ATE JUNCTION SCREEN
When approaching an interstate
junction, junction view images will
automat icallybe displ ayed.
TUNNEL JUN CTION SCREEN
When approaching a tunnel junction,
tunnel junction view images will
automatically be displayed.
2. ROUTE GUIDANCE
134

4. ROUTE GUIDANCE

WARNING
Be sure to obey the
traffic regulations
and keep the road conditio n in mi nd
especial ly wh en you are driving on IP D
roads (roads that are not completely
d ig iti zed in the navigation dat abase).
Th e rou te guid ance may not have the
upd ated in formation such as the
d irec tion of a one-wa y st reet.
136

4. ROUTE GUIDANCE 5. FAVORITE DESTINATIONS
5. FAVORITE DESTINATIONS




REGISTERING A NEW ENTRY

Up to 200 entries can be registered
with this system.

REGISTERI NG FROM THE
“Favor ite destination” LIST
1 Display the “Navigation” me nu screen
and select
. (→ P.1 12)
2 Select “Create n ew e ntry” .

3 Enter the en try ad dress and then sel ect
“Save new entry” .

4 Enter the entry name and then select
“OK” .
5 Check that the en try is reg istered in the
“Favorite destination” list.

 Se lect to d ispla y and e dit the
entry inf ormation. (→P.1 47)






1. REGISTERING AN ENTRY

143

5.MYDESTINATIONS5.FAVORITEDESTINATIONS
REGISTERING FROMENTRY
OPT IONS SCR EEN
1D ispl ay entry options scre en.
(→P.1 47)
2Select “Add to favorites ”.
 Screen i fentry selected from the
Navigation menu options:
Screen if entry selected from the
Phone book :
3Follow the st eps “REGISTERING
FROM THE“Favorite destination”
LIST” from“STEP 4”. ( →P.143)
INFORMA TION
If thecontact includes an ad dressand a
phone number , they will be stored inthe
“ Favorites ” list under the “Phone ” menu
( → P.69 )and in the “Favorite
destination ” list under the “ Navigation”
menu. ( →P.147)
REGISTERING FROMTHE
RO UTE INFORMA TION
SCREEN
1Disp laythe route information screen.
(→P.1 40)
2Select nexttothe desired
waypoint or main desti nation.
3Select “Add to favorites ”.
4Fol low the st eps “REGIS TERING
FROM THE“Favorite destination”
LIST” from“STEP 4”. ( →P.143)
146

.5.FAVORITE DESTINATION S
SETTING UP
AUTO- NAVIGATION
AUTO-NAVIGATION OPTIONS
1Disp lay t he “Nav igation ” menu screen
and select
“Favorite
destination” list.(→P.143)
2Selectne xt to the de sired entry.
 If list entry is not defined, auto-
navigation icon will be grayed-out.
3Enter the newname and then
select “OK”
3Select to return to the
“Favorite destination” list.
Auto-navigation evaluation is performed once per ignition
cycle. If current time is
outside of any of the defined
and enabled Auto-navigation
timeframes when the ignition
is turned to the “ACC” or
“ON” position, then the Auto-
navigation feature will not be
activated.
No.Function
Select to turn on/off Auto-Navigation feature for the selected entry.
Select to change the timeframe for the selected day of the week
Select to turn on/off Auto-Navigation for the selected day of the week
Select to copy the timeframe information to all other days of the week
Select to return to the “ Favorite destination” list.
3. AUTO-NAVIGATION TO ENTRY
Auto-navigation option will offer
option to automatically set as
destination any entries from the
“Favorite destination” list to match
regular route driving schedules.
149

5. MY DESTINATIONS 5. FAVORITE DESTINATIONS


SENDING STORED
CONTACTS TO A USB
ME MO RY

The entries stor ed in th e “Favorites”
list under the “ Phone” menu ( →P.69)
and in the “ Favorite destination ” list
under the “ Navigation” menu.
( →P.147) can be transferred to a
USB memory.

1 Op en th e cove r of the USB port.






2 Conne ct a USB memo ry.
3 Press the button.
4 Select “General” .
5 Select “Backup favorit es to USB ”.

6 Ch eck t hat a confirmation scre en is
di splay ed w hen th e operation is
compl ete.
INFORMA TION
Down loading may not c omplet e
cor rectl y in the following cases:
• Veh icles with out a smart entry & st art
system : If the ignition is turn ed to the
“L OCK ” pos ition duri ng downloa ding.
• V ehicles wit h a smart entry & st art
system : If the ignition is t urned off
duri ng dow nloading.
• If the USB memor y is re moved before
downloading is comple te
4. SENDING AND RESTORING STORED CONTACTS


150
